Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 – Screw in lock ring - VAS 611 007/2- -B- max. 2 turns by hand. – Make sure that the shaft is free to move. •
Adapter for angle sensor - VAS 611 007/9- and adapter for angle sensor - VAS 611 007/10- should turn easily.
2.4.2
Installing test tool - VAS 611 007-
Special tools and workshop equipment required ♦ Test tool - VAS 611 007-
Procedure – Preassemble test tool - VAS 611 007⇒ “2.4.1 Preassembling test tool VAS 611 007 ”, page 180 . – Teach-in test tool - VAS 611 007- electronically and perform basic setting ⇒ page 185 – Turn adapter for angle sensor - VAS 611 007/9- and adapter for angle sensor - VAS 611 007/10- until display is set to ap‐ prox. 0°. – Perform the preliminary work for checking the valve timing ⇒ “2.5 Checking valve timing”, 187Copying . Protectedpage by copyright. for private or commercial purposes, in part or in whole, is not permitted unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with
– Make sure that the piston in respect cylinder 1 is at TDC position to theno. correctness of information in this document. Copyright by SEAT S.A. ⇒ “4.7 Setting piston to TDC position”, page 155 . – Make sure that brakes on angle sensor - VAS 611 007/1- are released on both sides ⇒ page 182 . Note
Before positioning the test tool - VAS 611 007- against the cam‐ shaft housing, the grooves of the camshafts must be checked for damage.
2. Toothed belt drive
183
