Arona 2018 ➤ , Ateca 2017 ➤ , Ibiza 2016 ➤ , Ibiza 2018 ➤ , Ibiza ST ... 3-cylinder petrol engine (1.0 l direct injection, 4 V, turbocharger, EA211) - Edition 07.2018 Checking cylinder head for distortion – Use straight edge 500 mm - VAS 6075- and feeler gauge to measure cylinder head for distortion at several points. •
Max. permissible distortion: 0.05 mm
1.2
Assembly overview - camshaft housing
1 - Seal ❑ Renew after removal 2 - Seal ❑ For inlet camshaft (pul‐ ley end) ❑ Renewing ⇒ “3.3.1 Removing and installing camshaft oil seal, inlet camshaft”, page 206 3 - Seal ❑ For exhaust camshaft (pulley end) ❑ Renewing ⇒ “3.3.2 Removing and installing camshaft oil seal, exhaust camshaft, pulley end”, page 208 4 - Camshaft case ❑ Removing and installing ⇒ “1.4 Removing and in‐ stalling camshaft hous‐ ing”, page 166
Protected by copyright. Copying for private or commercial purposes, in part or in whole, is not
unless authorised by SEAT S.A. SEAT S.A does not guarantee or accept any liability with 5permitted - Bolt respect to the correctness of information in this document. Copyright by SEAT S.A. ❑ Specified torque and tightening sequence ⇒ page 162 ❑ Renew after removal
6 - O-ring ❑ Check O-ring for dam‐ age. ❑ O-ring not available as a separate part; renew to‐ gether with camshaft control valve 1 - N205- if damaged. 7 - Camshaft adjustment valve ❑ Inlet side: camshaft control valve 1 - N205❑ Removing and installing ⇒ “3.5 Removing and installing inlet camshaft control valve 1 N205 ”, page 220 ❑ Exhaust side camshaft control valve 1 - N318-
160
Rep. gr.15 - Cylinder head, valve gear
