HEATER CONNECTIONS - 16 WATER OUT Remove plug from intake manifold and install proper barbed fitting. The plug is located toward the front of the intake (belt end) on the even cylinder side.
WATER RETURN Remove plug from circulation pump and install proper barbed fitting. The plug is located on the side of the circulation pump.
Figure 16-1 5.7L Applications
