Fuel/Lubrication/Cooling
3. Remove the connector from the IAT sensor (A); then loosen the inlet boot clamp (B) and remove the mounting screw (C).
! WARNING Whenever the gasline hoses are removed (other than for pressure testing), the battery must be disconnected to prevent inadvertent activation of the electronic fuel pump.
! WARNING Whenever any maintenance or inspection is performed on the fuel system during which there may be fuel leakage, there should be no welding, smoking, open flames, etc., in the area.
TROUBLESHOOTING
1. Verify that the electric fuel pump is operating by listening for a “whirring” sound for several seconds after the ignition switch is turned to the ON position. If no sound can be heard, see EFI Sensors/Components in Electrical System.
PR486A
4. Disconnect the crankcase breather hose from the air filter housing; then remove the air filter assembly from the vehicle.
2. Check for a flashing EFI icon on the LCD. If EFI is flashing, see EFI Diagnostic System in the Electrical System section. 3. Make sure there is sufficient, clean gas in the gas tank. SPECIAL TOOLS
A number of special tools must be available to the technician when performing service procedures in this section. Refer to the current Special Tools Catalog for the appropriate tool description. NOTE: When indicated for use, each special tool
will be identified by its specific name, as shown in the chart below, and capitalized. Description
p/n
Oil Pressure Test Kit
0644-495
Tachometer
0644-275
NOTE: Special tools are available from the Arctic Cat Service Department.
PR487A
5. Slowly disconnect the gasline hose connector from the fuel rail.
! WARNING Gasoline may be under pressure. Depressurize the fuel system by disconnecting the fuel pump electrical connector and running the engine until it stalls. Place an absorbent towel around the connector to absorb any gasoline when disconnecting.
Throttle Body (700) REMOVING
1. Turn the ignition switch to the OFF position; then remove the ignition switch key.
! WARNING Do not turn the ignition switch to the ON position with the hoses removed. Gasoline will be pumped by the electric fuel pump causing a safety hazard.
2. Remove the left and right seats; then remove the center console and disconnect the battery.
136
FI092A
6. Remove the screw securing the throttle actuator cover to the throttle body; then remove the cover. 7. Remove the throttle cable from the actuator arm.
