Periodic Maintenance This section has been organized into sub-sections which show common maintenance procedures for the Arctic Cat ATV. NOTE: Arctic Cat recommends the use of new gaskets, lock nuts, and seals and lubricating all internal components when servicing the engine/transmission.
SPECIAL TOOLS A number of special tools must be available to the technician when performing service procedures in this section. Description
XR029A
3. Carefully remove the pre-filter from the air filter. If the air filter is dirty, it must be replaced.
p/n
Compression Tester Kit
0444-213
Oil Filter Wrench
0644-389
Spanner Wrench
0444-240
Valve Clearance Adjuster
0444-255
NOTE: Special tools are available from the Arctic Cat Service Department.
Lubrication Points It is advisable to lubricate certain components periodically to ensure free movement. Apply light oil to the components using the following list as reference. A. Throttle Lever Pivot B. Brake Lever Pivot
XR049
4. Using an air hose, clean the pre-filter. 5. Slide the pre-filter over the closed end of the new filter and install into the housing. Tighten the clamp securely. 6. Install the air filter housing cover and secure with the clips.
C. Auxiliary Brake Pedal Pivot
7. Install the seat.
Air Filter
CHECKING AND CLEANING DRAINS
1. Remove the seat; then remove the clips securing the air filter housing cover.
1. Inspect the drains beneath the main housing for water/oil and for proper sealing.
XR055A XR002A
2. Loosen the clamp securing the air filter to the inside of the housing; then remove the filter. 6
