CAUTION
Suspension The following suspension system components should be inspected periodically to ensure proper operation. A. Shock absorber rods not bent, pitted, or damaged.
Additional support stands are necessary to support the rear axle when the shock absorbers are removed or damage may occur.
3. Remove the two cap screws and nut securing each rear shock absorber to the frame and lower A-arm. Account for bushings and sleeves from each.
B. Rubber damper not cracked, broken, or missing. C. Shock absorber body not damaged, punctured, or leaking. D. Shock absorber eyelets not broken, bent, or cracked. E. Shock absorber eyelet bushings not worn, deteriorated, cracked, or missing. F. Shock absorber spring not broken or sagging. SPECIAL TOOL A special tool must be available to the technician when performing service procedures in this section. Description Spring Tool
p/n
AF626D
4. Using Spring Tool, compress the shock absorber spring, remove the retainer, and remove the spring.
0444-224
NOTE: Special tools are available from the Arctic Cat Service Department.
Shock Absorbers REMOVING 1. Secure the ATV on a support stand to elevate the wheels and to release load on the suspension.
! WARNING
CF341
CLEANING AND INSPECTING
Make sure the ATV is solidly supported on the support stand to avoid injury.
2. Remove the two cap screws and nuts securing each front shock absorber to the frame and the upper A-arm. Account for bushings and sleeves from each.
1. Clean all shock absorber components using a pressure washer. 2. Inspect each shock rod for nicks, pits, rust, bends, and oily residue. 3. Inspect all springs, spring retainers, shock rods, sleeves, bushings, shock bodies, and eyelets for cracks, leaks, and bends. INSTALLING 1. Place the shock absorber spring over the shock absorber, compress the spring, and install the retainer.
AF605D
238
