EXHAUST INSTALLATION GUIDELINES The top of the exhaust riser must be a minimum of 12 inches above the water line with the boat at rest and a full load aboard. It is recommended by the ABYC, and a Pleasurecraft Engine Group requirement, that there be a drop in the exhaust run between the engine and exhaust outlet of a minimum of 1 inch per foot of run, with a minimum of four (4) inches drop overall. The drop must be constant so that no low spots exist at any point in the exhaust hose. The above are minimum guidelines for installation, however, meeting the minimum guidelines will not necessarily insure no water intrusion under all operating conditions. It is the responsibility of the boat builder to confirm, for each model, that under any and all running angles and other conditions of operation, no water ingestion will occur.
B
EXHAUST OUTLET MUST HAVE INTERNAL SHUTTER AND/OR EXHAUST FLAPPER INSTALLED
A
EXHAUST SYSTEM DROP MUST BE 1" PER FOOT OR MINIMUM 4" TOTAL
A - B = 12" MINIMUM
