CONNECTOR PINOUTS POWERTRAIN CONTROL MODULE C3 (GAS) CAV 1
CIRCUIT C13 18DG
2
FUNCTION A/C CLUTCH RELAY CONTROL
-
-
3
K51 18DB/YL
AUTO SHUT DOWN RELAY CONTROL
4
V36 18TN/RD
SPEED CONTROL VACUUM SOLENOID CONTROL
5
V35 18LG/RD
SPEED CONTROL VENT SOLENOID CONTROL
6
K90 18TN (M/T)
CLUTCH SWITCH OVERRIDE RELAY CONTROL
7
K42 18DB/LB (3.7L)
KNOCK SENSOR NO. 1 SIGNAL
7
K42 18DB/LB (2.4L)
NOT USED
8
K99 18BR/OR
OXYGEN SENSOR 1/1 HEATER CONTROL
9
K512 18RD/YL
OXYGEN SENSOR DOWNSTREAM RELAY CONTROL
10
K106 18WT/DG
LEAK DETECTION PUMP SOLENOID CONTROL
11
V32 18YL/RD
SPEED CONTROL SUPPLY
12
F142 18OR/DG
FUSED AUTO SHUT DOWN RELAY SENSE INPUT
13
T10 18YL/DG
TORQUE MANAGEMENT REQUEST SENSE
14
K107 18OR
LEAK DETECTION PUMP SWITCH SENSE
15
K118 18PK/YL
BATTERY TEMPERATURE SENSOR SIGNAL
16
K299 18BR/WT (2.4L)
OXYGEN SENSOR 1/2 HEATER CONTROL
16
K299 18BR/WT (3.7L)
OXYGEN SENSOR 2/1 HEATER CONTROL
17
B22 18DG/YL
VEHICLE SPEED OUTPUT
18
K142 18GY/BK (3.7L)
KNOCK SENSOR NO. 2 SIGNAL
18
K142 18GY/BK (2.4L)
NOT USED
19
K31 18BR
FUEL PUMP RELAY CONTROL
20
K52 18PK/BK
EVAP/PURGE SOLENOID CONTROL
21
-
22
C21 18DB/OR
A/C SWITCH SENSE
23
-
24
K29 18WT/PK
BRAKE SWITCH SENSE
25
K125 18WT/DB
GENERATOR SOURCE
26
K226 18DB/WT
FUEL LEVEL SENSOR SIGNAL
27
D21 18PK
SCI TRANSMIT
28
-
-
29
D32 18LG
30
D25 18YL/VT
SCI RECEIVE (PCM) PCI BUS
31
-
-
32
V37 18RD/LG
SPEED CONTROL SWITCH SIGNAL
437
