CONNECTOR PINOUTS

PASSENGER DOOR LOCK MOTOR/AJAR SWITCH (EXCEPT BASE) CAV

CIRCUIT

FUNCTION

1

G74 20TN/WT (LHD)

RIGHT FRONT DOOR AJAR SWITCH SENSE

1

G75 20TN/WT (RHD)

LEFT FRONT DOOR AJAR SWITCH SENSE

2

Z350 20BK/LG (RHD)

GROUND

2

Z351 20BK/LG (LHD)

GROUND

3

P35 18OR/VT

UNLOCK RELAY OUTPUT

4

P33 18OR/BK

LOCK RELAY OUTPUT

C O N N E C T O R P I N O U T S

429
