CONNECTOR PINOUTS JUNCTION BLOCK C3 CAV
CIRCUIT
FUNCTION
1
A12 10RD/TN
FUSED B(+)
2
A13 10PK/WT
FUSED B(+)
3
A4 12BK/PK
FUSED B(+)
4
L44 18VT/RD
FUSED RIGHT LOW BEAM OUTPUT
5
L43 18VT
FUSED LEFT LOW BEAM OUTPUT
6
-
7
V55 16TN/RD
FRONT WIPER PARK SWITCH SENSE
-
8
F1 20DB (RHD)
FUSED IGNITION SWITCH OUTPUT (RUN-START)
8
F1 18DB (LHD)
FUSED IGNITION SWITCH OUTPUT (RUN-START)
9
V6 16DB/YL (LHD)
FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
9
V6 14DB/YL (RHD)
FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
10
-
11
A12 10RD/TN
-
12
-
-
13
-
-
14
-
15
V14 18RD/VT
FRONT WIPER ON/OFF RELAY CONTROL
16
L34 18RD/OR
FUSED RIGHT HIGH BEAM OUTPUT
17
-
FUSED B(+)
-
-
18
V16 18VT/YL
FRONT WIPER HIGH/LOW RELAY CONTROL
19
F20 18WT
FUSED IGNITION SWITCH OUTPUT (RUN)
20
-
-
21
-
-
22
-
-
23
-
24
L50 18WT/TN
25
-
-
26
-
-
27
-
BRAKE LAMP SWITCH OUTPUT
-
28
L77 18BK/YL
FUSED LEFT INBOARD TAIL LAMP
29
M1 18PK
FUSED B(+)
30
L78 18DG/YL
FUSED PARK LAMP RELAY OUTPUT
31
-
32
F15 18DB/WT
FUSED IGNITION SWITCH OUTPUT (RUN)
33
L39 18LB
FRONT FOG LAMP RELAY OUTPUT
34
A18 10PK
-
FUSED B(+)
35
-
36
-
-
37
L33 18LG/BR
38
F22 18DB/PK (ABS)
FUSED IGNITION SWITCH OUTPUT (RUN)
39
X2 18DG/RD
HORN RELAY OUTPUT
40
A18 10PK
41 42
FUSED LEFT HIGH BEAM OUTPUT
FUSED B(+) -
A7 10RD/BK
423
C O N N E C T O R
FUSED B(+)
P I N O U T S
