CONNECTOR PINOUTS JUNCTION BLOCK C2 CAV 1
C O N N E C T O R P I N O U T S
CIRCUIT F37 14RD/LB (MIDLINE/ HIGHLINE)
FUNCTION FUSED B(+)
2
-
3
C15 12BK/WT
4
F89 18OR/RD
FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
5
P37 20LG (EXCEPT BASE)
DOOR LOCK SWITCH GROUND
6
P33 18OR/BK (EXCEPT BASE)
LOCK RELAY OUTPUT
7
F22 18DB/PK
FUSED IGNITION SWITCH OUTPUT (RUN)
8
P34 18PK/BK (EXCEPT BASE)
DRIVER DOOR UNLOCK RELAY OUTPUT
9
P35 18OR/VT (EXCEPT BASE)
UNLOCK RELAY OUTPUT
10
P36 20PK/VT (EXCEPT BASE)
DOOR LOCK SWITCH MUX
11
P37 20LG (EXCEPT BASE)
DOOR LOCK SWITCH GROUND
12
M20 20BR
COURTESY LAMP LOAD SHED
13
L50 18WT/TN
BRAKE LAMP SWITCH OUTPUT
14
P36 20PK/VT (EXCEPT BASE)
DOOR LOCK SWITCH MUX
15
P30 16OR/WT
TAILGATE LOCK DRIVER
16
F70 18PK/BK
FUSED B(+)
17
L77 18BK/YL
FUSED LEFT INBOARD TAIL LAMP
18
M1 20PK
FUSED B(+)
19
M1 20PK
FUSED B(+)
20
E2 20OR
PANEL LAMPS DRIVER
21
E2 20OR
22
REAR WINDOW DEFOGGER RELAY OUTPUT
PANEL LAMPS DRIVER -
-
23
V23 20BR/PK (HIGHLINE)
FUSED IGNITION SWITCH OUTPUT (RUN)
24
V23 20BR/PK (EXCEPT BASE)
FUSED IGNITION SWITCH OUTPUT (RUN)
25
V23 20BR/PK (MIDLINE/ HIGHLINE)
FUSED IGNITION SWITCH OUTPUT (RUN)
26
L78 18DG/YL
FUSED PARK LAMP RELAY OUTPUT
27 28
A6 16RD/BK (MIDLINE/ HIGHLINE)
29
FUSED B(+)
-
-
30
M2 18YL
COURTESY LAMP DRIVER
31
C16 18LB/YL (EXCEPT BASE)
FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
32
F14 18LG/YL (SIDE AIRBAG)
FUSED IGNITION SWITCH OUTPUT (RUN-START)
33
F14 18LG/YL (SIDE AIRBAG)
FUSED IGNITION SWITCH OUTPUT (RUN-START)
34
L38 18BR/WT (HIGHLINE)
REAR FOG LAMP RELAY OUTPUT
35
P31 16PK/WT
TAILGATE UNLOCK DRIVER
36
-
-
37
F60 16DG/RD (MIDLINE/ HIGHLINE)
FUSED B(+)
38
F87 20WT/BK
FUSED IGNITION SWITCH OUTPUT (RUN-START)
39
C16 18LB/YL (EXCEPT BASE)
FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
40
F85 16VT/WT (MIDLINE/ HIGHLINE)
FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
41
F41 16PK/VT
FUSED B(+)
42
A3 16RD/WT (HIGHLINE)
FUSED B(+)
