CONNECTOR PINOUTS JUNCTION BLOCK C1 CAV
CIRCUIT
FUNCTION
1
-
-
2
-
3
A21 12RD/DB
IGNITION SWITCH OUTPUT (RUN-START)
4
E2 20OR
PANEL LAMPS DRIVER
5
E2 20OR
6
-
PANEL LAMPS DRIVER -
-
7
X3 20BK/RD
HORN RELAY CONTROL
8
L78 20DG/YL (EXCEPT EXPORT)
FUSED PARK LAMP RELAY OUTPUT
8
L78 18DG/YL (EXPORT)
FUSED PARK LAMP RELAY OUTPUT
9
F1 20DB (PREMIUM)
FUSED IGNITION SWITCH OUTPUT (RUN-START)
10
E2 20OR
PANEL LAMPS DRIVER
11
E2 20OR
PANEL LAMPS DRIVER
12
M1 20PK
FUSED B(+)
13
F33 20PK/RD
14
FUSED B(+) -
-
15
M1 20PK
FUSED B(+)
16
L50 18WT/TN
BRAKE LAMP SWITCH OUTPUT
17
Z300 16BK
GROUND
18
-
-
19
-
-
20
Z131 10BK/GY
GROUND
21
L309 20LG/WT
HIGH BEAM RELAY CONTROL
22
F14 18LG/YL
FUSED IGNITION SWITCH OUTPUT (RUN-START)
23
M2 20YL
COURTESY LAMP DRIVER
24
M2 20YL
COURTESY LAMP DRIVER
25
F33 20PK/RD (PREMIUM)
FUSED B(+)
26
F88 20BR/RD
FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
27
M1 20PK
FUSED B(+)
28
V23 20BR/PK
FUSED IGNITION SWITCH OUTPUT (RUN)
29
V23 20BR/PK
FUSED IGNITION SWITCH OUTPUT (RUN)
30 31
F87 20TN/BK
FUSED IGNITION SWITCH OUTPUT (RUN-START)
32
-
33
F38 16RD/WT
34
C16 20LB/YL
FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
35
F30 16RD
FUSED IGNITION SWITCH OUTPUT (RUN-ACC)
36
FUSED B(+)
-
-
37
F32 18PK/DB
FUSED B(+)
38
F15 18DB/WT
FUSED IGNITION SWITCH OUTPUT (RUN)
39
F23 18DB/YL
FUSED IGNITION SWITCH OUTPUT (RUN)
40
A31 12BK/WT
IGNITION SWITCH OUTPUT (RUN-ACC)
41
A15 18PK/OR
FUSED B(+)
42
A22 12BK/OR
IGNITION SWITCH OUTPUT (RUN)
421
