CONNECTOR PINOUTS FUSES (FUSE/RELAY BLOCK) FUSE NO.
AMPS
FUSED CIRCUIT
FUNCTION
1
20A
F33 20PK/RD
FUSED B(+)
1
20A
F33 18PK/RD
FUSED B(+)
2
20A
F32 18PK/DB
FUSED B(+)
3
20A
X60 16DG/RD
FUSED B(+)
4
10A
Z1 20BK
DOOR AJAR SWITCH OUTPUT
5
10A
F23 18DB/YL
FUSED IGNITION SWITCH OUTPUT (RUN)
6
20A
V23 18BR/PK
FUSED IGNITION SWITCH OUTPUT (RUN)
7
10A
F20 20VT/WT
FUSED IGNITION SWITCH OUTPUT (RUN)
8
10A
F24 20RD/DG
FUSED IGNITION SWITCH OUTPUT (RUN)
9
10A
F14 18LG/YL (RHD)
FUSED IGNITION SWITCH OUTPUT (RUN-START)
9
10A
F14 18LG/YL
FUSED IGNITION SWITCH OUTPUT (RUN-START)
10
10A
G5 20DB/WT
FUSED IGNITION SWITCH OUTPUT (RUN-START)
10
10A
G5 20DB/WT
FUSED IGNITION SWITCH OUTPUT (RUN-START)
C O N N E C T O R
11
10A
F12 20RD/LG
FUSED IGNITION SWITCH OUTPUT (RUN-START)
12
10A
F15 20DB
FUSED IGNITION SWITCH OUTPUT (RUN-START)
12
10A
F15 20DB
FUSED IGNITION SWITCH OUTPUT (RUN-START)
13
10A
L5 20BK/GY
FUSED IGNITION SWITCH OUTPUT (RUN-START)
14
25A
V6 16PK/BK
FUSED IGNITION SWITCH OUTPUT (RUN-START)
14
25A
V6 16PK/BK
FUSED IGNITION SWITCH OUTPUT (RUN-START)
P I N O U T S
15
10A
X12 16PK
FUSED IGNITION SWITCH OUTPUT (RUN-START)
16
10A
L22 10LG/DG
DIMMER SWITCH LOW BEAM OUTPUT
17
10A
F81 20DB/RD
FUSED REAR WINDOW DEFOGGER RELAY OUTPUT
18
20A
SPARE
19
20A
F38 16LB
FUSED IGNITION SWITCH OUTPUT (RUN)
19
20A
F38 16LB
FUSED IGNITION SWITCH OUTPUT (RUN)
20
20A
T141 14YL/RD (A/T)
FUSED IGNITION SWITCH OUTPUT (START)
290
-
