TM
9-803 64 l/,-TON
4 x 4 TRUCK (WILLYS-OVERLAND and FORD MODEL GPW)
MODEL MB
RA PD 305195
Figure 32 -Distributor spring, then lift off breaker point, and lift out point.
arm. Remove
Wires screw in stationary
breaker
(3) INSTALLATION. Place stationary breaker point in distributor, and install locking screw loosely. Lightly lubricate breaker arm pivot pin, and install breaker arm. Place spring in position with condenser lead, insert screw, and tighten securely in place. Aline points if necessary. To adjust points refer to step (1) above. e.
Distributor
Condenser.
(1) DESCRIPTION. The condenser is attached by one screw to the support plate in the distributor, and connected by a short flexible wire across the distributor points. The condenser functions to absorb momentarily any current which has a tendency to arc across the points when they open. The condenser must be firmly attached to the 122
