11A-1-6b
4G9 ENGINE (E - W) - Specifications
Items
Nm
Beam camshaft cap (M6)
11
Rocker cover and camshafts (MIVEC) Rocker cover
4
Oil pump
11
Arm spring holder
11
Camshaft bearing cap (M6)
11
Camshaft bearing cap (M8)
23
Oil control valve
9
Rocker arms and rocker shaft caps (MIVEC) Rocker shaft cap
11
Cylinder head and valves CylInder head bolt
74 Nm and then completely loosen, finally tighten 20 Nm + 90_ + 90_
Oil pressure switch
10
Front case and oil pump Oil pump cover
10
Oil pump case
14
Relief plug
44
Oil screen
19
Oil pan
7
Upper oil pan <Only M6 ´ 121>
7
Upper oil pan <Except M6 ´ 121>
11
Upper oil pan <M8>
24
Lower oil pan
7
Cover
7
Baffle plate <For CARISMA, SPACE STAR only>
7
Drain plug
39
Oil pressure switch
10
Baffle plate mounting bolt
7
Piston and connecting rod Connecting rod cap nut
20 + 90_ to 100_
Crankshaft, cylinder block, flywheel and drive plate Bearing cap bolt
25 + 90_ to 100_
Oil seal case
11
Bell housing cover
9
Rear plate
11
Drive plate bolt
98
Flywheel bolt
98
Baffle plate
9
Knock sensor
22
E Mitsubishi Motors Corporation
Dec. 1998
PWEE9502-E
Revised
