3025
Frese elicoidali Z3 in HM integrale con rompitruciolo ELICA NEGATIVA. Twist router drills in HM integral with chipbreaker Z3 with NEGATIVE PROPELLER. Mèches hélicoidales Z3 en HM intégral HÉLICE NEGATIVE avec brisecopeau. Spiralbohrer Oberfräser Spannfutter zu HM integralZ3 mit NEGATIV PROPELLER. Fresas helicoidales Z3 en HM macizo con rompeviruta HÉLICE NEGATIVA.
D
LU
LT
Att.
Z
rpm
ID nr. DX
8 8 10 10 12 12 12 14 14 16 16 16 18 18 20 20 20
22 32 32 42 32 42 52 42 52 42 52 72 52 72 52 72 102
80 80 80 100 80 100 100 100 100 100 100 120 100 120 100 120 150
Ø8 Ø8 Ø10 Ø10 Ø12 Ø12 Ø12 Ø14 Ø14 Ø16 Ø16 Ø16 Ø18 Ø18 Ø20 Ø20 Ø20
3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3 3
24000 24000 24000 24000 24000 24000 24000 24000 24000 24000 24000 24000 24000 24000 24000 24000 24000
3025001 3025002 3025003 3025004 3025005 3025006 3025007 3025008 3025009 3025010 3025011 3025012 3025013 3025014 3025015 3025016 3025017
MEC
Caratteristiche Esecuzione in HM integrale. Particolarmente idonea per eseguire lavorazione di foratura e contornatura con buona finitura superficiale ed elevata velocità di avanzamento su tutti i tipi di legno naturale. Elica negativa: espulsione del truciolo verso il basso, ottima finitura lato superiore del pannello.
Att. D
DX LU
Characteristics Execution in Integral HM. Recommended for drilling and edges operations with good surface quality and high advancing speed on all naturall woods. Negative propeller: expulsion of the shaving towards the low with perfect finish of upper side of panel.
LT
181
