Neuroradiology: Spectrum and Evolution of Disease

Neuroradiology: Spectrum and Evolution of Disease

JUAN E. SMALL, MD, MSc

Section Chief, Neuroradiology Lahey Hospital and Medical Center Burlington, Massachusetts

DANIEL L. NOUJAIM, MD

Neuroradiologist

Department of Radiology Beaumont Hospital Dearborn, Michigan

DANIEL T. GINAT, MD, MS

Department of Radiology Pritzker School of Medicine

The University of Chicago Chicago, Illinois

HILLARY R. KELLY, MD

Radiologist

Massachusetts Eye and Ear Infirmary Neuroradiologist

Massachusetts General Hospital

Assistant Professor of Radiology

Harvard Medical School Boston, Massachusetts

PAMELA W. SCHAEFER, MD

Associate Director of Neuroradiology

Clinical Director of MRI

Massachusetts General Hospital

Associate Professor of Radiology

Harvard University Boston, Massachusetts

Contributors

Sama Alshora, MD

Assistant Professor of Radiology

Lahey Hospital and Medical Center Burlington, Massachusetts

Assistant Professor of Radiology

King Saud University Medical City Riyadh, Saudi Arabia

Arwa O. Badeeb, MBBS

Chief Resident, Diagnostic Radiology

Lahey Clinic Burlington, Massachusetts

Lawrence Bahoura, MD

Oakland University William Beaumont School of Medicine

Royal Oak, Michigan

Girish Bathla, MBBS, FRCR, DMRD, MMeD

Resident

Department of Radiology University of Iowa Hospitals and Clinics

Iowa City, Iowa

Adam P. Bryant, MD

Resident Department of Radiology

University of Iowa Hospitals and Clinics

Iowa City, Iowa

Paul M. Bunch, MD

Assistant Professor of Radiology

Wake Forest School of Medicine

Wake Forest Baptist Health Winston-Salem, North Carolina

Walter L. Champion, MD

Lahey Hospital and Medical Center Burlington, Massachusetts

Pauley Chea, MD

Chief Resident Department of Radiology

Lahey Hospital and Medical Center Burlington, Massachusetts

Lindsay A.N. Duy, MD

Assistant Professor of Radiology

Wake Forest Baptist Medical Center

Winston-Salem, North Carolina

Suzanne K. Freitag, MD

Director, Ophthalmic Plastic Surgery

Department of Ophthalmology

Massachusetts Eye and Ear Infirmary

Associate Professor of Ophthalmology

Harvard Medical School

Boston, Massachusetts

Merav Galper, MD

Radiologist

Kaiser Permanente Mid-Atlantic Permanente Medical Group (MAPMG) Rockville, Maryland

Daniel T. Ginat, MD, MS

Department of Radiology

Pritzker School of Medicine

The University of Chicago Chicago, Illinois

Louis Golden, MD

Neuroradiology Section

Stanford University Stanford, California

Jason Handwerker, MD

Associate Clinical Professor of Radiology

University of California, San Diego San Diego, California

Jeffrey A. Hashim, MD

Assistant Professor of Radiology

Diagnostic Radiology

Lahey Hospital and Medical Center Burlington, Massachusetts

Doreen T. Ho, MD

Staff Neurologist

Lahey Hospital and Medical Center Burlington, Massachusetts

Dean T. Jeffery, MD

Radiology and Diagnostic Imaging

University of Alberta Edmonton, Alberta, Canada

Hillary R. Kelly, MD

Radiologist

Massachusetts Eye and Ear Infirmary Neuroradiologist

Massachusetts General Hospital

Assistant Professor of Radiology

Harvard Medical School Boston, Massachusetts

DaeHee Kim, MD

Chief Resident Department of Radiology

Lahey Hospital and Medical Center Burlington, Massachusetts

Philip D. Kousoubris, MD

Neuroradiology

Lahey Clinic

Burlington, Massachusetts

Mara Kunst, MD

Assistant Professor of Radiology

Tufts University School of Medicine

Section Head of Neuroradiology

Department of Radiology

Lahey Hospital and Medical Center

Burlington, Massachusetts

Daniel Lam, MD

Pritzker School of Medicine

University of Chicago Chicago, Illinois

Dann Martin, MD

Radiology

Lahey Hospital and Medical Center

Burlington, Massachusetts

William A. Mehan Jr., MD

Attending Neuroradiologist

Massachusetts General Hospital Boston, Massachusetts

Toshio Moritani, MD, PhD

Clinical Professor of Radiology

University of Michigan Medicine

Ann Arbor, Michigan

Daniel L. Noujaim, MD

Neuroradiologist

Department of Radiology

Beaumont Hospital

Dearborn, Michigan

Samir Noujaim, MD

Professor of Radiology

Division of Neuroradiology

Oakland University William Beaumont School of Medicine

Royal Oak, Michigan

Omar Parvez, MD

Neuroradiology Clinical and Research Fellow

Massachusetts General Hospital Boston, Massachusetts

Aaron B. Paul, MD

Staff Neuroradiologist

Lahey Hospital and Medical Center

Burlington, Massachusetts

Victor Hugo Perez Perez, MD

Neurosurgeon

UMAE Centro Médico Nacional

Mexico City, Mexico

Bruno Policeni, MD

Clinical Professor of Radiology

University of Iowa Hospital and Clinics

Iowa City, Iowa

Otto Rapalino, MD

Instructor in Radiology

Harvard Medical School

Assistant Radiologist

Massachusetts General Hospital Boston, Massachusetts

Katherine L. Reinshagen, MD

Instructor in Radiology

Harvard Medical School

Massachusetts Eye and Ear Boston, Massachusetts

Seyed Rezapour, MD

Hospital Medicine/Internal Medicine

Lahey Hospital and Medical Center Burlington, Massachusetts

Emily Rutan, BS

Department of Radiology

Lahey Hospital and Medical Center Burlington, Massachusetts

Juan E. Small, MD, MSc

Section Chief, Neuroradiology

Lahey Hospital and Medical Center

Burlington, Massachusetts

Nathaniel Temin, MD

Radiologist

South Shore Radiology Associates

South Weymouth, Massachusetts

Jaclyn A. Therrien, DO

Department of Diagnostic Radiology

Lahey Hospital and Medical Center Burlington, Massachusetts

Marie Tominna, DO

Oakland University William Beaumont School of Medicine

Royal Oak, Michigan

Pankaj Watal, MD

Department of Radiology

University of Iowa Hospitals and Clinics

Iowa City, Iowa

Gene M. Weinstein, MD

Clinical Fellow

Department of Radiology

Massachusetts General Hospital Boston, Massachusetts

Yun Sean Xie, MD Neuroradiologist

Department of Radiology

Baptist M&S Imaging

San Antonio, Texas

Fang Frank Yu, MD Neuroradiology Fellow

Massachusetts General Hospital Boston, Massachusetts

1 Brain Parenchymal Hematoma Evolution

INTRODUCTION

Magnetic resonance imaging (MRI) can differentiate between acute, subacute, and chronic hemorrhage because of its sensitivity and specificity to hemoglobin degradation products. Therefore the imaging interpreter is, with proper knowledge, able to estimate the age of a brain parenchymal hematoma. The blood products in a hematoma evolve through a predictable variation in hemoglobin oxygenation states and hemoglobin byproducts. This predictable pattern of hematoma evolution over time leads to a specific pattern of changing signal intensities on conventional MRI. There are limitations to the accuracy of hematoma age interpretation. Several direct and indirect factors, including the operating field strength of the magnet, the mode of image acquisition, and a wide range of biologic factors particular to the patient, may affect the imaging evolution of a parenchymal hematoma. Despite substantial variability, it is generally accepted that five stages of parenchymal hemorrhage can be distinguished by MRI. A basic understanding of the biochemical evolution of brain parenchymal hemorrhage and magnetic properties that affect MRI signal are essential for interpretation.

TEMPORAL EVOLUTION: OVERVIEW

A well-described pathophysiologic process of evolution and resorption for parenchymal hemorrhage involves five distinct phases (Fig. 1.1).

With this knowledge, the imaging interpreter can often identify the relative age of a brain parenchymal hematoma based on the T1 and T2 characteristics of the collection. However, it is important to realize that hematoma evolution is a fluid process (without static or punctuated steps). Therefore, stages of hemorrhage commonly coexist within the same hematoma because hemoglobin degradation proceeds at variable rates in the center versus the periphery of a single hematoma cavity. By convention, the most mature form of hemoglobin present defines the stage of hematoma evolution (Fig. 1.2).

TEMPORAL EVOLUTION: IN GREATER DEPTH

Extravascular blood in a hemorrhagic collection remains as oxyhemoglobin for 2 to 3 hours. The immediate activation of the clotting cascade begins the process of clot formation. Deoxyhemoglobin begins to form at the periphery of the hematoma. Eventually, the failure of metabolic pathways preventing oxidation of heme iron results in conversion of hemoglobin to methemoglobin. In the hyperacute stage, parenchymal hemorrhage is a liquid almost completely composed of intracellular oxygenated hemoglobin.

Over the course of a few hours, a heterogeneous blood clot forms within the hematoma cavity, composed of red blood cells, platelets, and serum. In the acute phase, intracellular hemoglobin becomes deoxygenated. Vasogenic edema develops in the surrounding brain parenchyma. In the early subacute phase, deoxyhemoglobin is gradually converted to intracellular methemoglobin. Then, in the late subacute phase, lysis of red blood cells leads to the release of methemoglobin into the extracellular space. During this time, the surrounding vasogenic edema slowly begins to decrease and the clot slowly retracts. In the chronic stage, macrophages and glial cells phagocytose the hematoma, leading to intracellular ferritin and hemosiderin. Eventually, the hematoma resolves and leaves a posthemorrhagic cavity with hemosiderin-stained walls.

It is critical to realize that Fig. 1.1 represents a simplified version of events designed to aid in memory. As noted previously, hematoma evolution is a fluid process (without static or punctuated steps). Stages of hemorrhage commonly coexist within the same hematoma because hemoglobin degradation proceeds at variable rates in the center versus the periphery of a single hematoma cavity (Figs. 1.3 and 1.4).

Of note, chronic posthemorrhagic parenchymal cavities may collapse nearly completely and appear as thin, relatively linear cavities with associated chronic blood products (Fig. 1.5).

Other sources of confusion include the presence of superimposed blood products of differing ages (acute or subacute hemorrhage in an area of subacute to chronic blood) or the presence of a hemorrhagic fluid level (Fig. 1.6). The presence of a blood-fluid level is moderately sensitive and highly specific for hemorrhage resulting from an underlying coagulopathy.

A NOTE ON GRADIENT ECHO SEQUENCES

Gradient echo (GRE) sequences are extremely sensitive to the paramagnetic and superparamagnetic effects of some hemoglobin breakdown products (deoxyhemoglobin, intracellular methemoglobin, ferritin, and hemosiderin). Hyperacute hemorrhage on GRE demonstrates a hypointense rim (deoxyhemoglobin) surrounding the isointense core (oxyhemoglobin). Acute and early subacute hemorrhage demonstrates diffuse hypointensity (due to deoxyhemoglobin and intracellular methemoglobin respectively). Late subacute hemorrhage demonstrates a hypointense rim (ferritin and/or hemosiderin) surrounding the hyperintense core (extracellular methemoglobin). Large areas of chronic hemorrhage demonstrate a heterogeneous/irregular hypointense rim (due to ferritin and/or hemosiderin) surrounding a posthemorrhagic encephalomalacic cavity. GRE images are not very helpful in estimating the age of small hemorrhagic foci because these appear hypointense throughout.

Figure 1.1. Five stages of parenchymal hematoma evolution on magnetic resonance imaging. One can easily remember the T1 and T2 characteristics of an evolving hematoma by memorizing this figure. Start from the center of the figure and move according to the direction of the arrows to remember the signal characteristics of the five distinct phases of hematoma evolution.

Figure 1.6. Sources of confusion—superimposed blood products of differing ages and hemorrhagic fluid levels. A patient on anticoagulation with a prior left frontal parenchymal hematoma and known subacute left frontal hemorrhagic cavity presents after an acute exacerbation. Coronal (A) and axial (B and C) computed tomography images at the time of the acute exacerbation demonstrate a hypodense left frontal hemorrhagic cavity with peripheral areas of hyperdense acute hemorrhage (arrows). There are also foci of acute subarachnoid hemorrhage (arrowheads). Axial T2 (D), axial T1 (E), and axial gradient echo (F) magnetic resonance imaging (MRI) images of the brain performed on the same day demonstrate a hemorrhagic fluid level within the subacute hemorrhagic cavity. Without the presence of an appropriate history, and considering the presence of multiple confounding factors, it would be difficult to predict the age of this hemorrhage based on the MRI signal characteristics alone.

SUGGESTED READING

Allkemper T, Tombach B, Schwindt W, et al. Acute and subacute intracerebral hemorrhages: comparison of MR imaging at 1.5 and 3.0 T–initial experience. Radiology. 2004;232(3):874–881.

Aygun N, Masaryk TJ. Diagnostic imaging for intracerebral hemorrhage. Neurosurg Clin N Am. 2002;13(3):313–334, vi.

Gomori JM, Grossman RI. Mechanisms responsible for the MR appearance and evolution of intracranial hemorrhage. Radiographics 1988;8(3):427–440.

Kidwell CS, Wintermark M. Imaging of intracranial haemorrhage. Lancet Neurol. 2008;7(3):256–267.

Parizel PM, Makkat S, Van Miert E, et al. Intracranial hemorrhage: principles of CT and MRI interpretation. Eur Radiol. 2001;11(9):1770–1783.

Pfleger MJ, Hardee EP, Contant CF Jr, et al. Sensitivity and specificity of fluid-blood levels for coagulopathy in acute intracerebral hematomas. AJNR Am J Neuroradiol. 1994;15(2):217–223.

Figure 2.4. Acute subdural hygroma. Axial computed tomography image conducted shortly after a motor vehicle accident (A) demonstrates hyperdense subarachnoid hemorrhage within the right sylvian fissure (white arrow). One day later (B), a hypodense collection consistent with an acute subdural hygroma is seen overlying the right frontal lobe (gray arrow). Complete resolution of the collection is evident 1 month later (C)

Figure 2.5. Intraoperative photograph of craniotomy for evacuation of an acute subdural hematoma. Notice the large semisolid heterogeneous dark-red subdural blood clot (white arrow) between the overlying folded dura and the underlying brain. The semisolid gelatinous consistency of the acute subdural clot differs from that of the viscous fluid of the unclotted acute blood (black arrow) and from that of the less viscous bloody cerebrospinal fluid evident at the edge of the picture (gray arrow) (Courtesy Dr. Kavian Shahi.)

Figure 2.6. Axial noncontrast computed tomography image of acute subdural collections. Notice the space-occupying, masslike subdural blood clot (white arrow). The morphology and density of the clot differs from that of the more fluid-like morphology of acute only partially clotted hyperdense blood (black arrows) and even that of the bloody cerebrospinal fluid (CSF) (gray arrow). Notice the bloody CSF is intermediate in density between the hyperdense blood products and the fluid density CSF evident anteriorly between the hemispheres.

Figure 2.7. Variable concentrations of blood and cerebrospinal fluid (CSF) in a subdural collection lead to differentiating imaging features of subdural hematoma and subdural CSF. Axial noncontrast computed tomography (CT) image of the brain (A) demonstrates right hemispheric and parafalcine subdural collections (orange arrows). Comparing coronal noncontrast CT (B) to coronal post contrast T1 (C) and coronal T2 magnetic resonance (D) images of the brain demonstrates to better advantage the differences between various portions of the right hemispheric subdural collection. In particular, on the coronal T2 image, the differences between the normal left-sided subarachnoid space (blue arrow), right-sided subdural hematoma (red arrow), right-sided subdural clot (orange arrow), and subdural CSF (yellow arrow) are readily evident.

Figure 2.8. Classic descriptions of acute, subacute, and chronic subdural hematoma density. A left tentorial hyperdense subdural hematoma is evident on an axial computed tomography image a few hours after head trauma (A, white arrow). At 2.5 weeks, heterogeneously isodense blood products are evident (B, white arrow). By 4 weeks, the hematoma is entirely hypodense as compared with the brain parenchyma (C, white arrow).

Figure 2.9. Different patterns of subdural density may be seen. An acute homogeneously hyperdense subdural hematoma (A, arrow) easily lends itself to a word description of its density. Other patterns of hemorrhage, including heterogeneous (B, arrow) and layering (C, arrow) collections, do not as easily conform to simply hyperdense, isodense, or hypodense categories. Estimating age based on density is therefore more challenging for complex collections.

Figure 2.10. Neomembranes encapsulate a chronic subdural hematoma. Operative photographs during craniotomy for chronic subdural hematoma evacuation demonstrate an outer membrane (OM) immediately under the reflected dura (A). After partial removal of the OM, the chronic subdural hematoma (CSDH) can be seen as heterogeneous old blood products (B) After removal of the chronic blood products, the inner membrane (IM) is evident (C) Only after incision of the IM can the brain be seen (D) (Courtesy Dr. Khalid Al-Kharazi.)

Outermembrane

Chronicsubduralhematoma

Innermembrane

Figure 2.11. Chronic subdural hematoma neomembrane neovascularization. Chronic subdural blood products are encapsulated within thick outer and thin inner neomembranes (blue area). Neovascularization (serpigionus red channels) predominantly involving the outer membrane accompanies neomembrane formation.

Neovascularization accompanies the formation of neomembranes and predominantly involves the outer membrane. Recurrent bleeding from these fragile vessels leads to acute on chronic hematoma expansion (Fig. 2.11).

As the neomembrane matures in the context of multiple rebleeding episodes, various layers and septations may form (Fig. 2.12). Initially, the neomembranes are thin, although they occasionally may become quite thick over time or even calcify (Fig. 2.13). The risk of rebleeding diminishes markedly with a longstanding chronic subdural collection with this advanced degree of organization.

In summary, multiple patterns of SDH may be encountered by the imaging interpreter. The patterns range from acute (acute SDH and acute subdural hygroma), to subacute (subacute SDH with resolving clot, as well as subacute subdural hygroma with xanthochromic CSF), to chronic (chronic SDH with or without septations) collections (Fig. 2.14).

SUBDURAL HEMATOMA EVOLUTION: IN GREATER DEPTH

After one is equipped with the previously mentioned knowledge, the variations in the natural history of subdural collections are easier

to interpret. As noted previously, the variable concentrations of blood and/or CSF within a specific area of the acute hematoma lead to different fluid properties and therefore different fluid behavior over time (Fig. 2.15).

In addition, the knowledge of the friable nature of the neovascularity along the outer neomembrane of a chronic SDH enables the imaging interpreter to more accurately identify the presence of an acute on chronic or subacute on chronic SDH (Fig. 2.16).

DIFFERENTIAL DIAGNOSIS

Subdural hemorrhagic and CSF collections are common and therefore by far the most reasonable diagnostic consideration of an enlarged extraaxial space. However, other more rare diagnostic considerations mimicking an SDH should at times be entertained. These include prominent dural thickening which may appear alone as a hypodense extraaxial structure on CT (Fig. 2.17) or in combination with subdural hemorrhage (Fig. 2.18) and usually due to intracranial hypotension, subdural empyema (Fig. 2.19), and impaired CSF resorption related to metastatic disease (Fig. 2.20).

Text continued on p 19

Figure 2.12. Multiple patterns of septations may be seen within chronic subdural hematomas. (A–C) Schematics and (D–F) cases. A relatively simple chronic subdural hematoma has only inner and outer membranes (A) However, radial septation (B) and/or concentric septation (C) patterns can be encountered. Case D demonstrates a simple, homogeneous, chronic hypodense right-sided subdural collection with a single membrane delineating its inner border. Case E demonstrates a complex right hemispheric subdural collection with concurrent presence of concentric (green arrows) and radial septations (blue arrow). Case F demonstrates an acute on chronic right hemispheric subdural hemorrhage collection with clear delineation of a concentric septation (green arrows) ([A–C], Modified from Abecassis IJ, Kim LJ. Craniotomy for treatment of chronic subdural hematoma. Neurosurg Clin N Am. 2017;28[2]:229-237.)

2.13. Craniotomy for resection of a chronic subdural hematoma (CSDH) with thick membranes. Directly underlying the dura, an operative photograph (A) demonstrates chronic blood clot (CSDH) enveloped by thick outer (OM) and inner membranes (IM). A photograph of the specimen resected en bloc (B) further demonstrates the marked thickness of the membranes. (Courtesy Dr. Victor Hugo Perez-Perez.)

Figure

Figure 2.17. Dural thickening in a patient presenting with postural headaches. Axial computed tomography (CT) (A) and coronal CT (B) images demonstrate bilateral hemispheric extraaxial hypodensities (yellow arrows) mimicking subdural collections in a patient with a ventricular catheter in place (blue arrow). On axial T1 (C) and coronal T2 (D) images the bilateral extraaxial CT finding correlates with T1 hypointensity and T2 hyperintensity, again mimicking subdural collections (yellow arrows). However, this finding correlates with marked dural thickening and enhancement on postcontrast axial T1 (E) and coronal T1 (F) images, due to chronic intracranial hypotension. When a ventricular catheter is in place, dural thickening related to chronic overshunting should be considered.
