INTRODUCTIONTODESIGN 1
CHAPTERCONTENTS
1.1Introduction
1.2NatureofDesign
1.3TheAnatomyofaChemicalManufacturingProcess
1.4TheOrganizationofaChemicalEngineeringProject
1.5ProjectDocumentation
1.6CodesandStandards
1.7DesignFactors(DesignMargins)
1.8SystemsofUnits
1.9Optimization
1.10References
1.11Nomenclature
1.12Problems
KEYLEARNINGOBJECTIVES
• Howdesignprojectsarecarriedoutanddocumentedinindustry
• Whyengineersinindustryusecodesandstandardsandbuildmarginsintotheirdesigns
• Howtoimproveadesignusingoptimizationmethods
• Whyexperienceddesignengineersveryrarelyuserigorousoptimizationmethodsinindustrialpractice
1.1 INTRODUCTION
Thischapterisanintroductiontothenatureandmethodologyofthedesignprocess,anditsapplication tothedesignofchemicalmanufacturingprocesses.
1.2 NATUREOFDESIGN
Thissectionisageneraldiscussionofthedesignprocess.Thesubjectofthisbookischemical engineeringdesign,butthemethodologydescribedinthissectionappliesequallytootherbranches ofengineering.
ChemicalEngineeringDesign. https://doi.org/10.1016/B978-0-08-102599-4.00001-1 # 2020ElsevierLtd.Allrightsreserved.
Chemicalengineeringhasconsistentlybeenoneofthehighest-paidengineeringprofessions.There isademandforchemicalengineersinmanysectorsofindustry,includingthetraditionalprocessing industries:chemicals,polymers,fuels,foods,pharmaceuticalsandpaper,aswellasothersectorssuch aselectronicmaterialsanddevices,consumerproducts,miningandmetalsextraction,biomedical implantsandpowergeneration.
Thereasonthatcompaniesinsuchadiverserangeofindustriesvaluechemicalengineerssohighly isthefollowing:
Startingfromavaguelydefinedproblemstatementsuchasacustomerneedorasetofexperimental results,chemicalengineerscandevelopanunderstandingoftheimportantunderlyingphysical sciencerelevanttotheproblemandusethisunderstandingtocreateaplanofactionandsetofdetailed specifications,whichifimplemented,willleadtoapredictedfinancialoutcome
Thecreationofplansandspecificationsandthepredictionofthefinancialoutcomeiftheplanswere implementedistheactivityofchemicalengineeringdesign.
Designisacreativeactivity,andassuchcanbeoneofthemostrewardingandsatisfyingactivities undertakenbyanengineer.Thedesigndoesnotexistatthestartoftheproject.Thedesignerbeginswith aspecificobjectiveorcustomerneedinmind,andbydevelopingandevaluatingpossibledesigns, arrivesatthebestwayofachievingthatobjective;beitabetterchair,anewbridge,orforthechemical engineer,anewchemicalproductorproductionprocess.
Whenconsideringpossiblewaysofachievingtheobjective,thedesignerwillbeconstrainedby manyfactors,whichwillnarro wdownthenumberofpossiblede signs.Therewillrarelybejust onepossiblesolutiontotheproblem,justonede sign.Severalalterna tivewaysofmeetingthe objectivewillnormallybepossible,evensevera lbestdesigns,dependingonthenatureofthe constraints.
Theseconstraintsonthepossiblesolutionstoadesignproblemariseinmanyways.Some constraintswillbefixedandinvariable,suchasthosethatarisefromphysicallaws,government regulations,andstandards.Otherswillbelessrigid,andcanberelaxedbythedesigneraspartof thegeneralstrategyforseekingthebestdesign.Theconstraintsthatareoutsidethedesigner’sinfluence canbetermedtheexternalconstraints.Thesesettheouterboundaryofpossibledesigns,asshownin Figure1.1.Withinthisboundarytherewillbeanumberofplausibledesignsboundedbytheother constraints,theinternalconstraints,overwhichthedesignerhassomecontrol;suchas,choiceof process,choiceofprocessconditions,materials,andequipment.
Economicconsiderationsareobviouslyamajorconstraintonanyengineeringdesign:plantsmust makeaprofit.Processcostingandeconomicsarediscussedin Chapter6 Timewillalsobeaconstraint.Thetimeavailableforcompletionofadesignwillusuallylimitthe numberofalternativedesignsthatcanbeconsidered.
Thestagesinthedevelopmentofadesign,fromtheinitialidentificationoftheobjectivetothe finaldesign,areshowndiagrammaticallyin Figure1.2.Eachstageisdiscussedinthefollowing sections.
Figure1.2 showsdesignasaniterativeprocedure;asthedesigndevelopsthedesignerwillbeaware ofmorepossibilitiesandmoreconstraints,andwillbeconstantlyseekingnewdataandideas,and evaluatingpossibledesignsolutions.
FIGURE1.1
Designconstraints
Determine customer needs
Region of all designs
Customer approval
FIGURE1.2
Thedesignprocess
Plausible designs
Possible designs
Set design specifications
Generate design concepts
‘External’ constraints ‘Internal’ constraints
Predict fitness for service Build performance models
Evaluate economics, optimize and select design
Detailed design and equipment selection
Procurement and construction
R&D if needed
Begin operation
1.2.1 THEDESIGNOBJECTIVE(THENEED)
Alldesignstartswithaperceivedneed.Inthedesignofachemicalprocess,theneedisthepublicneedfor theproduct,creatingacommercialopportunity,asforeseenbythesalesandmarketingorganization. Withinthisoverallobjectivethedesignerwillrecognizesub-objectives;therequirementsofthevarious unitsthatmakeuptheoverallprocess.
Beforestartingwork,thedesignershouldobtainascomplete,andasunambiguous,astatementof therequirementsaspossible.Iftherequirement(need)arisesfromoutsidethedesigngroup,froma customerorfromanotherdepartment,thenthedesignerwillhavetoelucidatetherealrequirements throughdiscussion.Itisimportanttodistinguishbetweentheneedsthatare“musthaves”andthose thatare“shouldhaves”.The“shouldhaves”arethosepartsoftheinitialspecificationthatmaybe thoughtdesirable,butthatcanberelaxedifrequiredasthedesigndevelops.Forexample,a particularproductspecificationmaybeconsidereddesirablebythesalesdepartment,butmaybe difficultandcostlytoobtain,andsomerelaxationofthespecificationmaybepossible,producing asaleablebutcheaperproduct.Wheneverpossible,thedesignershouldalwaysquestionthedesign requirements(theprojectandequipmentspecifications)andkeepthemunderreviewasthedesign progresses.Itisimportantforthedesignengineertoworkcloselywiththesalesormarketing departmentorwiththecustomerdirectly,tohaveasclearaspossibleanunderstandingofthe customer’sneeds.
Whenwritingspecificationsforothers,suchasforthemechanicaldesignorpurchaseofapieceof equipment,thedesignengineershouldbeawareoftherestrictions(constraints)thatarebeingplacedon otherdesigners.Awell-thought-out,comprehensive,specificationoftherequirementsforapieceof equipmentdefinestheexternalconstraintswithinwhichtheotherdesignersmustwork.
1.2.2 SETTINGTHEDESIGNBASIS
Themostimportantstepinstartingaprocessdesignistranslatingthecustomerneedintoadesignbasis. Thedesignbasisisamoreprecisestatementoftheproblemthatistobesolved.Itwillnormallyinclude theproductionrateandpurityspecificationsofthemainproduct,togetherwithinformationon constraintsthatwillinfluencethedesignsuchas:
1. Thesystemofunitstobeused.
2. Thenational,localorcompanydesigncodesthatmustbefollowed.
3. Detailsofrawmaterialsthatareavailable
4. Informationonpotentialsiteswheretheplantmightbelocated,includingclimatedata,seismic conditionsandinfrastructureavailability.Sitedesignisdiscussedindetailin Chapter14
5. Informationontheconditions,availabilityandpriceofutilityservicessuchasfuelgas,steam, coolingwater,processair,processwaterandelectricity,thatwillbeneededtoruntheprocess.
Thedesignbasismustbeclearlydefinedbeforedesigncanbebegun.Ifthedesigniscarriedoutfora clientthenthedesignbasisshouldbereviewedwiththeclientatthestartoftheproject.Most companiesusestandardformsorquestionnairestocapturedesignbasisinformation.Anexample templateisgivenin AppendixG andcanbedownloadedinMSExcelformatfromtheon-linematerial at http://books.Elsevier/com/companions.
1.2.3 GENERATIONOFPOSSIBLEDESIGNCONCEPTS
Thecreativepartofthedesignprocessisthegenerationofpossiblesolutionstotheproblemfor analysis,evaluationandselection.Inthisactivity,mostdesignerslargelyrelyonpreviousexperience, theirownandthatofothers.Itisdoubtfulifanydesignisentirelynovel.Theantecedenceofmost designscanusuallybeeasilytraced.Thefirstmotorcarswereclearlyhorse-drawncarriageswithout thehorse;andthedevelopmentofthedesignofthemoderncarcanbetracedstepbystepfromthese earlyprototypes.Inthechemicalindustry,moderndistillationprocesseshavedevelopedfromthe ancientstillsusedforrectificationofspirits;andthepackedcolumnsusedforgasabsorptionhave developedfromprimitive,brushwood-packedtowers.So,itisnotoftenthataprocessdesignerisfaced withthetaskofproducingadesignforacompletelynovelprocessorpieceofequipment.
Experiencedengineersusuallypreferthetriedandtestedmethods,ratherthanpossiblymore excitingbutuntriednoveldesigns.Theworkthatisrequiredtodevelopnewprocesses,andthecost, areusuallyunderestimated.Commercializationofnewtechnologyisdifficultandexpensiveand fewcompaniesarewillingtomakemulti-milliondollarinvestmentsintechnologythatisnotwell proven(knownas“methird”syndrome).Progressismademoresurelyinsmallsteps;however, wheninnovationiswanted,previousexperience,throughprejudice,caninhibitthegenerationand acceptanceofnewideas(knownas“notinventedhere”syndrome).
Theamountofwork,andthewayitistackled,willdependonthedegreeofnoveltyinadesign project.Developmentofnewprocessesinevitablyrequiresmuchmoreinteractionwithresearchers andcollectionofdatafromlaboratoriesandpilotplants.
Chemicalengineeringprojectscanbedividedintothreetypes,dependingonthenoveltyinvolved:
1. Modifications,andadditions,toexistingplant;usuallycarriedoutbytheplantdesigngroup.
2. Newproductioncapacitytomeetgrowingsalesdemand,andthesaleofestablishedprocessesby contractors.Repetitionofexistingdesigns,withonlyminordesignchanges,includingdesignsof vendor’sorcompetitor’sprocessescarriedouttounderstandwhethertheyhaveacompellingly bettercostofproduction.
3. Newprocesses,developedfromlaboratoryresearch,throughpilotplant,toacommercialprocess. Evenhere,mostoftheunitoperationsandprocessequipmentwilluseestablisheddesigns.
Themajorityofprocessdesignsarebasedondesignsthatpreviouslyexisted.Thedesignengineervery seldomsitsdownwithablanksheetofpapertocreateanewdesignfromscratch,anactivitysometimes referredtoas“processsynthesis”.Eveninindustriessuchaspharmaceuticals,whereresearchandnew productdevelopmentarecriticallyimportant,thetypesofprocessusedareoftenbasedonprevious designsforsimilarproducts,soastomakeuseofwell-understoodequipmentandsmooththeprocess ofobtainingregulatoryapprovalforthenewplant.
Thefirststepindevisinganewprocessdesignwillbetosketchoutaroughblockdiagramshowing themainstagesintheprocess;andtolisttheprimaryfunction(objective)andthemajorconstraintsfor eachstage.Experienceshouldthenindicatewhattypesofunitoperationsandequipmentshouldbe considered.Thestepsinvolvedindeterminingthesequenceofunitoperationsthatconstitutesaprocess flowsheetaredescribedin Chapter4.
Thegenerationofideasforpossiblesolutionstoadesignproblemcannotbeseparatedfromthe selectionstageofthedesignprocess;someideaswillberejectedasimpracticalassoonastheyare conceived.
