Sincetheinventionofthree-dimensional(3D)printing inthe1980s,ithasbecomeawidelyemployed manufacturingtechnologyusedinmanyindustriessuch asaerospace,automotive,consumergoods,industrial goods,andhealthcare.Ascomparedtotraditional manufacturingtechnologies,3Dprintingisamoreefficientprocessthateasilyallowsforthecreationof customizedproductswithgreaterdesign flexibilityina muchreducedtimeframe.Today,therearethousandsof 3Dprintersoperatingaroundtheworld,andthese includebothlow-costdesktopmachinesandhigh-end industrialmachines.

Atthistime,3Dprintedanatomicmodelsderived frompatient-specificvolumetricmedicalimagingdata arebeingcreatedandusedincreasinglyinmedicine. These3Dprintedmodelsexpanduponthecurrent capabilitiesoftraditional3Dmedicalimagevisualizationonatwo-dimensional(2D)screenbyproviding visuo-hapticfeedbacktoenhancetheunderstandingof complexanatomies.3Dprintedanatomicmodelscan beusedformanyapplicationsinhealthcareincluding surgicalplanning,intra-operativeguidance,patient communication,andtraineeeducation,ultimatelyleadingtoimprovedpatientcare.

Thecreationof3Dprintedmodelsfromradiological imagingdataisacomplexprocesswhichinvolves manipulatingtheoriginalimagingdataintoavolume

thatrepresentspatient-specificanatomy.Theseselect dataarethenoptimizedfor3Dprinting.Asanextension of3Dprintedanatomicmodels,anatomicguidesmaybe createdfromthesedatatobeuseddirectlyintheoperatingroom.Thesesamemethodsmayalsobeusedto createpersonalizedimplants;however,thesewillnotbe discussedindetailinthisbookduetoregulatoryconcernsforprintinghigh-riskdevicesinthehospitalatthe presenttime.

Thisbookistargetedforthepracticingradiologist interestedinlearningaboutcurrentandfutureapplicationsof3Dprintinginradiologyandmedicine.Through thisbook,methodstocreate3Dprintedanatomical modelsfrommedicalimagesaredescribedandclinical applicationskeytoradiologyarehighlighted.Itis importanttonotethatthechaptersinthisbookare focusedonthe3Dprintingworkflowtocreatemedical modelsfromimagingdata.Inaddition,clinicalareas suchasinterventionalradiology,nuclearmedicine,and radiationtherapywhichareimportanttoradiologistsare highlighted.Theinsightsandexplanationsprovided herearedesignedtobevaluabletothereaderforunderstandingthecomprehensiveworkflowrequiredto createmedicalmodels,identifyinghow3Dprintingis usedinradiology,anduncoveringhowthesemethods couldshapethefutureof3Dprintinginradiologyand medicine.

Acknowledgments

Thankstoeveryauthorandcontributorforhelpingmetomakethisbookareality.Also,specialthankstoSamuel YoungandNiranjanBhaskaran,myEditorialandProductionProjectManagers,fortheirpatienceandassistance.

AnAbbreviatedHistoryofMedical3D Printing

ANDYCHRISTENSEN,BS,FSME

INTRODUCTION

Three-dimensional(3D)printingtechnologiesarenow enteringtheirfourthdecadeofuseandmanymedical applicationsnowareverywellestablishedandoptimized.Despitethis,manyinthemedical fieldare surprisedtohearthat3Dprintingisnotrelatively new.Thischapterisnotanexhaustivelookatevery developmentalongthetimelineformedical3Dprintingbutinsteadmeanttopointoutsomemajormilestoneswhichhaveledustothestate-of-the-arttoday. Thebasisofmuchoftheworkdonewith3Dprinting inmedicineissurroundingpersonalizationofsurgery. Thisgoesallthewaybacktothebeginningand continuestoday.Personalizationtypicallyrelieson useofvolumetricmedicalimagingdata,allowingthe therapytotrulybepersonalizedtotheindividual patient.Flexibility,complexityofdesign,andlotsizes ofonemake3Dprintingagood fitforsupportofthe tools,guides,models,andimplantswhichmakeup theworldofpersonalizedsurgery.Ifweconsiderthe medical3Dprintingtechnologiesandapplicationsas thetoolbox,manypioneeringengineers,surgeons, andotherscontributedtothecreationofthetoolsin thetoolbox.Overtimethetoolboxhascontinuously expandedbywayofsoftwaretools,hardwaretools, materialtools,andworkflowswhichcombinethese toolsinspecificwaystosolvespecificclinicalproblems. 3Dprintinghassignificantlyalteredseveralkeyareasof medicineincludingcraniomaxillofacialsurgery,orthopedicsurgery,andbeyond.

1980s 3DPRINTINGPIONEERINGWORK ANDEARLIEST3DPRINTINGINMEDICINE

Themajorityoftheworkforpersonalizedsurgerystarts withavolumetricmedicalimagingstudysuchas computedtomography(CT)ormagneticresonance imaging(MRI).WiththeadventoftheCTscannerin

1967,volumesofdatacouldbeacquired,givingfor the firsttimeasenseofscaleandpositionofdifferent elementsbydensity.1 TraditionalX-raysdidnotcapture scaleandcompressedwhatwas3Ddata(thepatient) intooneverytwo-dimensional(2D)planarimage. MRIwascommercializedinthe1980sandledtothe abilitytoimagesofttissueswithmuchmorediscretion thanwasallowedbyCT.(PleaserefertoChapter2for moreinformationonmedicalimaging.)

Intheearly1980s,inventorsHideoKodama(Japan) andChuckHull(US)startedindependentworkonthe first3Dprintingprocesswhichwaslatercoinedstereolithography.Hull’ s firstUSPatentwasissuedin19872 andthe first3Dprintingcompany(3DSystems,Rock Hill,SC)wasfoundedwhichfocusedonselling3D printers,thenreferredtoasthe fieldofrapidprototyping.Onemightthinkthat1987couldbethestartfor 3Dprintinginmedicine,butseveralveryimportant buildingblocks,keytothis fieldcomingtofruition, actuallystretchbackto1981.

In1981,Dr.JeffreyMarsh,acraniofacialsurgeon,and Dr.MichaelVannier,aradiologist,bothphysiciansatthe WashingtonUniversitySchoolofMedicine(St.Louis, MO),workedwithanengineernamedJamesWarren (McDonnellDouglas,St.Louis,MO)ontheconceptof anatomicmodeling.Thegoalwastotakeslicedata fromaCTscananduseittoreplicateindividualslices ofmaterialsthatwouldforma3Dobjectwhenassembled.McDonnellDouglaswasintheaerospace field andworkingwithmanyhigh-performancematerials includingtitanium.Animagepostprocessingtechnique calledthresholding(DescribedinChapter3)wasused todelineatetheHounsfieldunits(measureofgrayscale intensity)forboneintheCTscan,creatingindividualslicesofdatajustforthebonestructure.Thiswas firstused tomodelayoungboywithalargefrontonasalencephalocele.Thedigital filesfromthesegmentedCTsliceswere transferredtoamillingmachinewhichtracedthese

slices,whichwereofthesamethicknessastheCTscan slices,intotitanium.Whenassembledandstackedup theseslicesformed,toscale,amodeloftheboy’sbone structurewhichclearlyillustratedthelargebonyperforationabovehisleftorbit.Thisworkcontinuedinto1982 withlessexoticmaterials,movingtoacrylicsheets insteadoftitanium.3,4 Duetolackoffunding,thework ceasedin1982,butseveralofthemodelsremainintact. MarshandVannierpublishedapaperandabookon theirpioneeringeffortsin3Dimagingintheearly 1980s,buttherewasonlyapassingcommentmadein thepaperregardingtheirphysicalmodelingefforts (Fig.1.1and1.2).5,6

Alsoin1981,aphysicistnamedF.BrixinKiel,Germany,startedworkthatusedtheexternalshapeofthe body,derivedfromaCTscan,milledfromdifferentmaterials,asradiationtherapycompensators.Thisworkledto othersinKiel,includingUlrichKliegis,tostartmilling3D shapesfromsolidblocksoffoam,beginningwith anatomicmodels.7 Kliegisstartedacompanycalled MEK/Endoplan(Kiel,Germany)tooffertheserviceof anatomicmodelingandlatercommercializedan anatomicmodelingsystemthatwasevenbroughtto theannualmeetingoftheRadiologicalSocietyofNorth

FIG.1.1 Dr.JeffreyMarshisshownwiththeearliestknown anatomicmodelcreatedfrommedicalimagingdata.The modeldepictsayoungpatientwithalargefrontal encephaloceleabovetheleftorbit.

FIG.1.2 Acloserviewofthemodelfrom1981whichwas constructedbymillingindividuallayersoftitaniumtomatch theCTslicesandstackingtheindividuallayerstoformthe3D model.

America(RSNA)inthemid-1980s.Thisconceptwasway aheadofitstimeandcommercializationwasslow,but workprogressedinthe1980sandbeyondforKliegis andthegroupatKiel.Manyinfluentialmaxillofacialsurgeonswhointhe1980strainedatKiellatertooktheconceptsforanatomicmodelingwiththemtoSwitzerland (ProfessorDr.J.ThomasLambrecht)andAustria(ProfessorDr.RolfEwers)wheretheapplicationsandtechnologycontinuedtoevolveandmature.8,9 Lambrecht’ s book,publishedin1996,containsclinicalcasesfrom thelate1980stotheearly1990sandisconsideredby manytobetheauthoritativeworkonearlyoraland maxillofacialsurgeryapplications(Fig.1.3).8

FIG.1.3 ProfessorDr.J.ThomasLambrechtusedthis modelwhichincludedintegrateddentalcastsofthe patient’steethforplanningorthognathicsurgery.Themodel wasmilledfromalightweightfoammaterialbyUlrichKliegis inKiel,Germany. 2 3DPrintingfortheRadiologist

IntheDepartmentofRadiologyattheUniversityof California,LosAngeles(UCLA),in1984,aphysicist namedDr.NicholasMankovichwashardatworksolvingsomeofthesameissuesforanatomicmodeling.He andhisteamusedasimilarapproachtotheSt.Louis groupformillingofindividualslicesofaCTscan fromacrylicandstackingthemtocreatelife-sized3D modelsofanatomy.The firstclinicalneedswerefor modelingthebonestructureofpatientswithdefects intheirskullrequiringcranialreconstruction.10 The teamcreatedmodelsthatwouldallowfordesignand constructionofpatient-matchedimplantsfortheskull, calledcranioplasties,workingwithlegendarymaxillofacialprosthodontistDr.JohnBeumer.Thisworkat UCLAcontinueduntil1988whenMankovichcollaboratedwithChuckHullandScottTurnerat3DSystems tocreatewhatwasthevery first3Dprintedanatomic model,createdwithstereolithography.11 Oncethe conceptofstereolithographyhadbeenproventowork andshowedtheneededaccuracy,theUCLAteamabandonedtheearlierstackedlayermethodsinfavorofthe morerobustandaccuratestereolithographyprocess.

AUSpatentwasissuedtoDavidWhitein1982fora techniquesurroundinganatomicmodelingprimarily forcustomimplantcreationusingsubtractive,milling techniques.12 CEMAX(Fremont,CA)licensedthis patentin1985andusedittocreateaservicebusiness foranatomicmodeling,servicingsurgeonsandmedicaldevicecompaniesinneedofthesemodelstoplan surgeryordesignpatient-matchedimplants.13 One suchuseroftheseanatomicmodelswasDr.William BinderandthecompanyImplantechAssociates (Ventura,CA).14 Implantechhaspioneeredpatientmatchedsiliconefacialandbodyprosthesesmade usingCTimaging.

AnothercompetingmethodtotheWhitemethod wasbeingusedatanotherCalifornia-basedorthopedic implantcompanycalledTechmedica(Camarillo,CA) inthe1980sandintotheearly1990s.15 Themodel qualityseemscrudebytoday’sstandards,buttheaccuracyoftheanatomicmodelsmettheclinicalneedsat thattime.Themodelswerecreatedbytracing1:1CT scanimagesbyatracerintoacrylicsheetswhichwere thenstackedtogether,smoothedalongtheoutside contourswithclay,andthenusedtocastsequential copiesoftheanatomy.Theprimaryclinicalfocusfor Techmedicawasonlargeorthopedictumorreconstructioncases,limbsalvagecases,andcomplexjointrevisioncases.TechmedicawaslatersoldtoIntermedics Orthopedics(Austin,TX),butatleastoneproductstill existsfromtheTechmedicadays,apatient-matchedtotaljointreplacementforthetemporomandibularjoint, nowsoldbyTMJConcepts(Ventura,CA).16

1990s 3DPRINTEDANATOMICMODELS ANDPERSONALIZEDIMPLANTS

FriedVancraenandhis firmMaterialise(Leuven, Belgium)playanimportantroleinthisindustrystarting in1990,thesameyearthatMaterialisewasfounded. Vancraenwasinterestedinthe3Dprintingofanatomic modelswithanewlyacquiredSLA-250,withserial number32(3DSystems,RockHill,SC),andhis first anatomicmodelmadebystereolithographywasproducedinNovember1990.17 Vancraenquicklylearned thatthesoftwareworkflowforconvertingwhatwere thenproprietary fileformatsforeachCTscannerwas verydifficulttoutilize.In1991,tohelpthisworkflow, theMaterialiseInteractiveMedicalImageControl System(Mimics)softwarewascreated;anditwas commercializedin1992.18 Thissoftwarepavedthe wayincreatingaservicebusinessforMaterialiseand forotherstofollowintheirfootsteps.Vancraenwas instrumentalinlaunchingandleadingthePhidiasprojectinEuropetospecificallystudytheclinicalbenefitsof 3Dprintedanatomicmodelsincomparisontostatic3D virtualimages.ThePhidiasProject,runbyEuropean radiologists,lastedfrom1992to1995withtrailing datareportsfollowing.19 Thisprojectwaswayahead ofitstimeingatheringdatatosupportreimbursement for3Dprintedanatomicmodels.Oneofthelastingand importantcontributionsofthePhidiasprojectwasthe creationofa first-of-its-kindmaterialforstereolithographywhichallowedselectivecolorationbyovercuring selectregionsofinterestandbiocompatibility.The materialwasdevelopedbyMaterialiseandZeneca Specialties(London,UnitedKingdom)andalloweda second,redcolorationtobeusedtohighlightselect anatomicstructureswithintheotherwiseclearanatomic model.20 ThismaterialwascommercializedbyZeneca andlatersoldtoHuntsman(TheWoodlands,TX). Huntsmanwasacquiredby3DSystemsin2011and foldedintotheirstereolithographymaterialsportfolio. Thismaterialisstillinactive,worldwideusetoday.

3CDesign(FoundedbyRWChristensen,DCChase, andDCrook)wasstartedinDallas,TX,in1992,to focusonaerospace,industrial,andmedicalusesfor stereolithography.In1995,thecompanyfoldedand whatwouldbecomeMedicalModeling(Golden,CO) gotitsstartwiththesametechnologyinGolden,Colorado.At first,theapplicationsfocusedsolelyonpreoperativeanatomicmodelstoassistwithtotaljoint replacementofthetemporomandibularjoint,butthey quicklyexpandedtoservemanysurgicalspecialties andclinicalneeds.In2000,AndyChristensen, employedwithMedicalModelingsince1996, purchasedthecompanyandkeptaddingtoitsarmamentariumofservicesandworkflowdevelopmentto

supportthemedicalapplicationsof3Dprinting.21 This includedanatomicmodeling,designofpersonalized implants,virtualsurgicalplanning,andeventuallyadditivemetalsforimplantproduction.

In1994,ontheothersideoftheglobe,buildingon theworkofMankovich,Beumer,andothers,the companyAnatomics(Melbourne,Australia),ledby neurosurgeonDr.PaulD’Urso,wascreatedwithafocus onanatomicmodelingandpatient-matchedcranioplastyimplants.D’Ursoandgrouplaterpublisheda seminalpaperonaprospectiveclinicaltrialfor3D printedanatomicmodelsin1999whichshowedbenefitstosurgeon,patient,andhospital.22

Companieswhosold3Dprintersstartedtotake noticeofthisemergingmarket;and,in1996,there wasmajormovementfromStratasys(EdenPrairie, MN),anothermajorplayerinthe3Dprinterandmaterialspace.ScottCrumpinventedthetechnology calledFusedDepositionModeling(FDM)and cofoundedStratasyswithhiswifeLisain1989. 23 Lisa becamequiteinterestedintheanatomicmodeling areaandin1996ledtheeffortforStratasystoobtain the fi rst(andpossiblystilltheonly)FoodandDrug Administration(FDA)clearanceofa3Dprinter,the FDMMedModeller.24 Stratasyscommercializedthe productandevenexhibitedattheRSNAannual meetinginChicagointhelate1990stotryandmarket 3Dprinterstohospitals.TheMaterialiseMimicssoftwarewasalsoFDAclearedatthesametimetoprovide moreofanend-to-endsolutionfromCTscanto model. 25 Acompanywaseventuallyspun-outofStratasystocommercializethisidea,buteventuallyitwas discontinuedduetolackoftraction.Thisconceptwas 20yearsaheadofitstimeandtheindustryowesLisa Crumpadebtofgratitudeforpushingpointofcare 3Dprinting fi rst.

Theverybeginningsofvirtualsurgeryalsodateback tothemid-1990s,withDr.JamesXia’sworkinHong Kong.Xia’sworkdealtwithmanipulating,cutting, andmovingobjectsinspacerelatedtooralandmaxillofacialsurgicalprocedures.26 HerelocatedtoHouston around2000andsobeganalongcareerwithoraland maxillofacialsurgeonDr.JaimeGateno firstatUniversityofTexas(Houston,TX)andlateratMethodistHospital(Houston,TX).Thegroup’sfocuswason orthognathicsurgeryinvolvingosteotomiesofthe mandibleandmaxilla.Inthe2000s,thisdynamic teamhadasingularfocusontacklingeachstepofthe virtualsurgeryandclinicaltransferprocessstepby step.Publishingeachsubsequentstepalongtheway theyestablishedworkflowsandaccuracystandardsfor thisworkincollaborationwithclinicalandindustry

collaborators.27 29 Throughworkfundedbyseveral NIHgrants,theteam flushedoutmanyofthekeysteps oftheprocessalongwithcollaboratorMedical Modeling,whocommercializedsomeoftheworkflow stepsinitsservicesfororthognathicsurgicalplanning andguidance.Atthecoreofthesetechnologieswas theabilitytoosteotomizebonysegmentsinavirtual environmentandthenmovethesesegmentstodesired, new,positions.Oncethedesiredoutcomewas expresseddigitally,aseriesof3Dprintedtemplatesor splintswouldbeoutputtotransfertheclinicalplan fromthecomputertotheoperatingroom.Thisgroup wentontopublishsomeofthemostinfluentialmanuscriptsinthisspace.30,31

2000s DIGITALDESIGN,ADDITIVE METALS,ANDFOUNDATIONSFORFUTURE VIRTUALWORK

The firstmeaningfuluseoftemplatescamewiththe launchofSurgiCasebyMaterialisein2000.Building onprevioussoftwaredevelopmentandworkflows,the SurgiCasesoftwarewasinitiallytargetedfordental implantsimulation,translatingtheimplant’sposition fromthesimulationtothepatient,anditalsoincluded thecreationofpatient-speci fic,3Dprinteddentaldrill guides.32 In2001,MaterialisepurchasedColumbia Scientific(Columbia,MD),anindustryleaderfor dentalimplantplanningsoftware(SimPlant),thereby combiningtheirSurgiCasesoftwareproductlinewith SimPlant.Anothertechnologicaladvancethathelped pushthisapplicationforwardwasthecommercializationofCone-BeamCT(CBCT),whichallowsforvolumetricimagingstudiestobeperformedintheoral surgeon ’sofficeandledtomuchwideruseofCTin thecraniomaxillofacialarea.

Around2000,computer-aideddesign(CAD)softwareprogramsstartedtobecomemoreadvancedand productssuchasFreeformModelingSystems3Dtouch enabledhapticdevicesystemsformedicalanddental modeling,productdesign,anddigitalcontentcreation becameavailable(SensableTechnologies,Woburn, MA).Dr.RichardBibbinCardiff,Wales,didpioneering workwiththesehapticdevicesanddesignsoftware. Usingthemoreartisticinterfaceallowedforcreation ofpatient-matchedcraniomaxillofacialimplants;and forthe firsttimetheseimplantscouldbedesignednet shape,somethingverydifficultpreviouslywithtraditionalCADsoftware.Thisworkhadanimmenseimpact onthespecificclinicalapplicationforpatient-matched cranioplastyandchangedhowthisworkwouldbe doneinthefuturearoundtheworld.33

MeanwhileinDallas,TX,in2001,acraniofacialsurgeonnamedDr.KennethSalyerembarkedonwhat wouldbeamultiyearprojecttoseparatetwotwin boysbornjoinedatthehead(craniopagustwins). UsingthelatestanatomicmodelingprovidedbyMedicalModeling(Golden,CO),heandhisteamcreated3D printedmodelsofbone,skin,brains,venousandarterialsystems,ventricles,andmorethatwereintegralto thesuccessfulseparationwhichtookplacein2003.34 Whilenotthe firstcasewhereanatomicmodelswere usedbysurgeonsseparatingtwins,thiscasegarnered nationalattentionandleadtoaseminalpaperon3D printingforcraniopaguscasesanda20043DSystems UserGroupSLAExcellenceAwardGrandPrize.35 Earlier anatomicmodelsforconjoinedtwinsseparation surgeriesgobackasfaras1995withtheRaineytwins whowereseparatedatWilfordHallMedicalCenter, LacklandAirForceBaseinSanAntonio,TX.36 Medical Modeling’sworkforconjoinedtwinsincluded modelingfor15setsoftwinsby2006.37 Salyeris nowretiredfromclinicalpracticebuthadused anatomicmodelstoplanformorethan500craniofacial surgeriesduringthe2000s(Fig.1.4).

TheworkofSwedishmetaladditivemanufacturing machinemakerArcam(Molndal,Sweden)cameto theUnitedStates(US)in2003withthe firstmachine

beingplacedinanengineeringlabatNorthCarolina StateUniversity(Raleigh,NC)withDr.OlaHarryson (IndustrialEngineering)andDr.DenisCormier(MaterialsScience).Theyquicklywenttoworkqualifyingtitaniumalloy(Ti6Al4V)usingtheelectronbeammelting (EBM)process,somethingthathadnotyetbeenaccomplished.38 Thiswouldbethestart,inearnest,forthe industrysegmentfocusedonusingadditivemetalsfor implantproduction.ThemedicalservicebureauMedicalModelingbuiltonthisworkandinstalledtheir first EBMmachinein2005tofocusontitaniumimplant production.39 HarrysonandCormierwentontoqualify manydifferentmaterialsforEBMalongwithspreading generalknowledgeabouttheapplicationofadditive metalstothemanufacturingsegment.

Intheearly2000s,WalterReedArmyMedicalCenter(WRAMC,Washington,DC),undertheleadership ofDr.StevenRouse,wasinstrumentalinestablishing oneofthe fi rst “pointofcaremanufacturing ” centers withinWRAMC.40 Rouseandcolleaguesincluding Dr.PeterLiacouras,thecurrent3Dprintinglabdirector,used3Dprinting,originallyinpolymers,tohelp surgeonsreconstructallmanneroftraumaticinjuries sufferedbyoursoldiersinthegulfwar.Hundredsof activedutymilitarybene fi ttedfrompersonalized implants,anatomicmodels,andmoremadebythis

FIG.1.4 Atwo-colorstereolithographymodeloftheEgyptianconjoinedtwinboysAhmedandMohammed Ibrahim,showingbothboneandunderlyingvascularstructures.Dr.KennethSalyerandteamusedthismodel andotherstoaidinpreparationforthesuccessful38hseparationsurgery.

lab.In2011,WRAMCwascombinedwiththeNaval facilityinBethesda,MD,andsawtheopeningofa combinedWalterReedNationalMilitaryMedicalCenter(WRNMMC)inBethesda.Dr.JerryGrantwashead ofthiseffortatWRNMMCinBethesdaformany years. 41

EarlierdiscussionaboutvirtualsurgeryandtemplatingbyGateno,Xia,andtheMaterialiseSurgiCaseproductwasfurtherexpandeduponbyorthopedicsurgeon Dr.SteveHowell(Sacramento,CA)around2005for applicationtototaljointarthroplasty.42 Howellbuilt acompanycalledOtisMed(Hayward,CA)which focusedonvirtualplanningfortotalkneearthroplasty (TKA)usinghismethodofanatomicalignment.Using aCTscantovisualizethepatient’sbonestructure,the specificsizeofatotalkneereplacementimplantcould beaccuratelypredicted.Patient-matchedcuttingblocks weredesignedtotransferthepositionoftheimplants fromtheperfectlyplannedvirtualsessiontothepatient insurgery.Howell’smethodwasagnostictothemanufactureroftheimplantsystem,aconceptthatwas definitelyaheadofitstime.Whilenotoriginally3D printed,theconceptforTKAplanningandguidance sawfurthergrowthwithStryker’sacquisitionof OtisMedin2009andcompaniessuchasMaterialise, Biomet(nowZimmerBiomet,Warsaw,IN),Zimmer (nowZimmerBiomet,Warsaw,IN),DePuyOrthopaedics/Johnson&Johnson(Warsaw,IN),andSmith& Nephew(Nashville,TN)jumpedinandcontinueto commercializeproductsandpushthistechnology forward.43 Itisestimatedthatmorethan100,000TKA casesareperformedannuallyusing3Dprintedsurgical guidestoday.

Orthognathicsurgeryrelatestothesurgicalprocedureswhichcorrectdentofacialdeformitiesoftheface, mostofteninvolvingthemandibleandmaxilla. LeveragingtheresearchofGatenoandXia,Medical Modelinglaunchedproductsandtrainedsurgeonsin workflowsaimedtoturnwhatwasacompletelymanual methodforsurgicalplanningoforthognathicsurgeries intoamostlydigitalmethod.Theoldmethod,which wasstandardofcarefor30years,involvedstandardXrays,tracingonacetatepaper,takingimpressionsof teeth,mountingtheseimpressionsandthencutting andmovingthemaroundbefore finallyproducingby handanacrylicbitewafercalledasplintwhichwould transferthisplantosurgery.MedicalModeling commercializedproductsfororthognathicsurgical planningandtemplatingin2007withamostlydigital workflowinvolvinguseofaCTorCBCT,digitaldental models(thenscannedfromcasts,todaycompletelydigital),andevendigitalmeasurementsforhowthepatient

holdstheirhead,theso-calledNaturalHeadPosition, whichvariesforeachpatient.Thesedigitalworkflows offeredaneasierpreparationforsurgery(1hrvs. 8hrs)andamorepredictablesurgicalexperience becausethesurgeonwasdirectlyplanningonthe patient’sanatomy.44

WhatHowellstartedfortheorthopedicsectorwas takentotheheadandneckregionfortumorreconstructionbysurgeonsincludingDr.DanielBuchbinder(New York,NY),Dr.EvanGarfein(Bronx,NY),andDr.David Hirsch(NewYork,NY)collaboratingwithcompanies suchasMedicalModelingandMaterialise.45,46 Reconstructionofthemandibleusinga fibulafree flapwas routinelyperformedwithlimitedabilitytopreoperativelyplanpriorto2007.Followingapplicationof virtualsurgeryandtemplating,manyoftheseproceduresarenowroutinelycarriedoutwith3Dprinted anatomicmodels,guides,andtemplates.Theresection isplannedandguided,thegraftosteotomiesareguided, andeventhe fixationispreplannedandeitherguidedor personalizedcompletely.47

Buildingonthenovelabilityto3Dprintinbiocompatiblemetals3Dprintingwasutilizedtocreatethe actualimplantedpart;and,in2006,ProfessorDr.Jules Poukens(Leuven,Belgium)implantedatitanium cranioplastyproducedbyEBM,perhapsthe firstknown implanted3Dprintedtitaniumpartforcraniomaxillofacialsurgery.48 Thepartwasphysicallyproducedby CarlFruthandFITAG(Lupburg,Germany).Poukens laterwentonin2011toimplantwhatwascitedas theworld’ s first3Dprintedtotaljawreplacement,producedinconjunctionwithXilloc(Sittard-Geleen,The Netherlands)andLayerWise(Leuven,Belgium,now partof3DSystems).49 In2007,thecompanyEnztec (Christchurch,NewZealand)workedwithMedical ModelingandlocalorthopedicsurgeonDr.James Burntoproducepatient-matchedimplantsforcomplex totaljointrevisionsurgeriesinvolvingthehipandknee (Fig.1.5).50

2010s VIRTUALSURGERYAND TEMPLATES,HOSPITAL-BASED3D PRINTING,THEFDA,REIMBURSEMENT

Additivemanufacturinginbiocompatiblemetalssuch astitaniumalloyandcobalt chromealloyhadbeen aroundfor fiveplusyearsalreadywhenin2010the first USFDAclearanceforaproductwasissuedinthisspace. Exactech(Gainesville,FL)gainedclearancefortheir InteGripacetabularimplantlinein2010,partnered forproductionwithMedicalModeling.51 Thiswasthe firstFDAclearanceofanykindfora3Dprintedmetal

implant.In2011,the firstspineimplant,afusioncage, wasclearedthroughtheFDAby4WebMedical(Frisco, TX),againsupportedbyMedicalModeling.52 Interestingly,bothoftheseFDAclearanceswerefor off-the-shelf,non-personalizedorthopedicimplant components.The firstFDAclearanceforapolymeric 3Dprintedimplanthappenedin2013withOxfordPerformanceMaterials(SouthWindsor,CT)clearingtheir OsteoFabPatient-SpecificCranialDevice.53

TheFDAoverseesallmedicaldevicemarketinginthe USandhasbeenquiteinterestedin3Dprintingandits useformedicaldevicesforalongtime.In2014,the FDAdecidedtoconveneanopenforummeetingwith industry,academia,andphysiciansinvitedtodiscuss thetopicofadditivemanufacturingformedicaldevices.54 Overtwodaysabout500attendeeshelpedprovideinputtotheFDA.Thisinputwascriticaltothe FDA’sdevelopmentofatechnicalguidancedocument foradditivemanufacturingofmedicaldevices.55 The FDArunsitsowninternalworkinggrouponadditive manufacturingandcontinuestofosterdiscussion regardingthesafeandeffectiveuseofthesetechnologies inthemedicaldevicespace.

Aroundthattime,alongwiththeexpirationofsome oftheoriginal3DprintingpatentsheldbyChuckHull andScottCrump,desktop3Dprinterscameinto fruitionandhospitalsstartedtoincorporate3Dprinting.Oneofthe firstandlargestinitiativeswasthatby theMayoClinic(Rochester,MN),aworld-leading

medicalcenterwhichhasembraced3Dprintingina clinicalenvironmentsincethemid-2000s.Centeredin radiology,theireffortshavebeenledbyDr.JaneMatsumoto(pediatricradiologist)andDr.JayMorris(interventionalneuroradiologist). 56 In2015,MayoClinic offeredwhatwasthe firstcontinuingmedical educationmeetingtosharetheirknowledgewiththe worldrelatedto3Dprinting.Surgeonsfromadozen surgicalspecialties,radiologists,andothersinresearch sharedtheirinsightsoverthreedaysinScottsdale,Arizona. 57 Thismeetingwasheldannuallyforseveralyears untilbeingdiscontinuedin2019.

Anothermajorstepforwardforhospital-based3D printinghappenedin2016withtheestablishmentof theRSNA3DPrintingSpecialInterestGroup(SIG).58 Dr.FrankRybicki(UniversityofCincinnati)pioneered theestablishmentoftheSIGandservedasits firstChair. The firstrotationofwhatwouldbeelectedpositionsin theleadershipoftheSIGwereDr.JayMorris(Mayo Clinic),Dr.JaneMatsumoto(MayoClinic),Dr.William Weadock(UniversityofMichigan),andDr.PeterLiacouras(WalterReedNationalMilitaryMedicalCenter). Thisgroupfocusesoneducation,creationofguidelines forappropriateclinicaluseof3Dprinting,andthe importanttopicofreimbursementforthesetools whenproducedinahospitalenvironment.59 Todate theSIGhasmembershipofover500individualsand RSNAhasopeneda3DprintingSIGmembershipcategorytoallwhoareinterested.58

FIG.1.5 ProfessorDr.JulesPoukensimplantedwhatmayhavebeentheworld’s first3Dprintedtitanium implant,acranioplasty,in2006.Theelectronbeammeltingprocesswasusedtoproducethisimplantin titaniumalloy.

Thesafetyandaccuracyof3Dprintedmedicalmodels isofgreatconcerntobothhospitalsandregulatory bodiessuchastheFDA.In2017,theFDAandRSNA SIGheldajointmeetinginspecificallyonanatomic modelsandtheregulatoryimplicationsforproduction inhospitals.60 Historically,productionofanatomic modelswasaccomplishedbyindustrygroupssuchas MaterialiseandMedicalModeling,butwiththemovementoftheseservicesinsideofthehospitaltheregulatoryenvironmenthasbeenchanging.Severalkeypoints wereclarifiedatthismeetingincluding(1)clarification ofwhatrepresents “diagnosticuse,” (2)thefactthatimageprocessingsoftwarehasthemostimportancetothe FDA,and(3)howindustrycouldcleartheseproducts throughFDApathways,aslightlychallengingprocess sincetheimageprocessingsoftware,3Dprintinghardware,andevenmaterialsneededtobeincluded. Followingthismeeting,in2018,the firstproducttoproceedthroughthe “ new ” pathwaytoincludeindications fordiagnosticuse,3Dprintedanatomicmodelswas theMimicsInPrintproduct(Materialise).61 FurtherconsiderationsonthistopiccanbefoundinChapter9. Onemoretopicofconversationfortheentirehistory ofthis fieldhasbeenreimbursementfor3Dprinted anatomicmodels.Amajorstepforwardforthis occurredin2018whentheAmericanMedicalAssociationapprovedestablishing first-everCategoryIII CurrentProceduralTerminology(CPT)Codesfor anatomicmodelsandanatomicguides.62 Theeffortto establishthesecodeswasledbytheAmericanCollege ofRadiology(ACR)alongwithRSNASIGleadership. FourCategoryIIICPTCodeswent “live” foruseasreimbursementnomenclatureinJulyof2019.While paymentfortheseCategoryIIIcodesisvoluntary,they openthedoorforfuturecodeswhichhavevalueassociatedwiththemandmaybemorewidelyreimbursed.In 2019,aregistryfor3Dprintedanatomicmodelsand guideswasestablishedbytheRSNAandACR.63 The purposeoftheregistry,whichissupportedby3DprintingindustrypartnersHP(PaloAlto,CA),Formlabs (Cambridge,MA),Materialise(Leuven,Belgium),and Stratasys(EdenPrairie,MN),istogatherdataon hospital-based3Dprintinginsupportoffuturereimbursementefforts.Thesedataincludethetypeofclinicalindication,theeffortputintotheproductionof themodel,thetechnologyused,andtheclinicalfeedbackrelatingtotheuseofthemodel.Theregistry went “live” toacceptnewcasesubmissionsin2020 andwillcontinueforseveralyears,furtheringtheevidenceof3Dprintedanatomicmodelsandguides. MoreinformationonreimbursementandtheRSNAACR3DprintingregistrycanbefoundinChapter8.

Theprevioussectionsprovidesomekeymilestones inthecollectivehistoryof3Dprintinginmedicine. Fromtheintroductionanddevelopmentof3Dprinting technologiestotheirincorporationwithmedicalimagingmodalities,3Dprintinghasbeenutilizedoverthe yearstoenhancepatientcare.Withmoreandmorehospitalsutilizingthetechnologiesalongwithrapid improvementsinthetechnologiesandpossiblereimbursementformodels,itisexpectedthattheuseof 3Dprintingwillbecomeevenmoremainstreamin thefuture.Furthermore,thecombinationofregenerativemedicinetechnologieswithmedicalimagingisexpectedtorevolutionizepersonalizedmedicine.Thenext severalyearswillbeinstrumentalformedical3Dprintinganditwillbeinterestingtoseewhichclinicalapplicationsareimpactedthemost.
