T1530
84244199 6/09
Replaces84187223
TOTHEOWNER
ThismanualcontainsinformationconcerningtheadjustmentandmaintenanceofyourNewHollandT1530 tractor.Youhavepurchasedadependablemachine,butonlybypropercareandoperationcanyouexpectto receivetheperformanceandlongservicebuiltintothistractor.Pleasehavealloperatorsreadthismanual carefullyandkeepitavailableforreadyreference.
Thismachinewasdesignedtopowerandpropelitself.Itisintendedtopullorcarrytractorattachmentsorload andmovematerialswhenequippedwithafrontendloaderwithavarietyofbuckets.OnlyattachmentsrecommendedorapprovedbyNewHollandshouldbeusedwithyourtractor.
YourNewHollanddealerwillinstructyouinthegeneraloperationofyourtractor.(RefertotheìDeliveryReportî atthebackofthismanual.)Yourdealerísstaffoffactory-trainedservicetechnicianswillbegladtoanswerany questionsthatmayariseregardingtheoperationofyourtractor.
YourNewHollanddealercarriesacompletelineofgenuineNewHollandserviceparts.Thesepartsaremanufacturedandcarefullyinspectedtoinsurehighqualityandaccuratefittingofanynecessaryreplacementparts.Be preparedtogiveyourdealerthemodelandPINnumberoftheengineandtractor,whenorderingparts.Locate thesenumbersnowandrecordthembelow.RefertotheìGeneralInformationîsectionofthismanualforthelocationofthemodelandPINnumbersofyourtractor.
86091821
WARNING
Thissafetyalertsymbolindicatesimportantsafetymessagesinthismanual.Whenyouseethissymbol, carefullyreadthemessagethatfollowsandbealerttothepossibilityofpersonalinjuryordeath.
M171C
WARNING
Picturesinthismanualmayshowprotectiveshieldingopenorremoved tobetterillustrateaparticular featureoradjustment.
Becertain,however,tocloseorreplaceallshieldingbeforeoperatingthemachine.
IMPROVEMENTS
M1317
CNHAmericaLLCiscontinuallystrivingtoimproveitsproducts.Wereservetherighttomakeimprovementsor changeswhenitbecomespracticalandpossibletodoso,withoutincurringanyobligationtomakechangesor additionstotheequipmentsoldpreviously.
0-1
Model PINNumber
CONTENTS
SAFETY0-5 ........................................................
GENERALINFORMATION1-1 ......................................
OPERATION2-1 ....................................................
LUBRICATIONANDMAINTENANCE3-1 ..............................
SPECIFICATIONS4-1 ...............................................
INDEX4-9 .........................................................
DELIVERYREPORT4-11 .............................................
0-2
DieselengineexhaustandsomeofitsconstituentsareknowntotheStateof Californiatocausecancer,birthdefects,andotherreproductiveharm.
Batteryposts,terminalsandrelatedaccessoriescontainleadandlead compounds. Washhandsafterhandling.
0-3 (NorthAmericaOnly) (CaliforniaOnly) CALIFORNIA
Proposition65Warning
PRECAUTIONARY STATEMENTS
PERSONALSAFETY
Thisisthesafetyalertsymbol.Itisusedtoalertyoutopotential personalinjuryhazards.Obeyallsafetymessagesthatfollowthis symboltoavoidpossibleinjuryordeath.
Throughoutthismanualandonmachinedecals,youwillfindsignalwords DANGER, WARNING,and CAUTION followedbyspecificinstructions.Theseprecautionsareintendedforthepersonalsafetyofyouandthoseworking withyou.Pleasetakethetimetoreadthem.
DANGER
DANGERindicatesahazardoussituationwhich,ifnotavoided,willresult indeathorseriousinjury.The colorassociatedwithDangerisRED.
M1169A
WARNING
WARNINGindicatesahazardoussituationwhich,ifnot avoided,couldresultindeathorseriousinjury. ThecolorassociatedwithWarningisORANGE.
M1170A
CAUTION
CAUTION,usedwiththesafetyalert symbol,indicatesahazardoussituationwhich,ifnotavoided,could resultinminorormoderateinjury.ThecolorassociatedwithCautionisYELLOW.
M1171A
FAILURETOFOLLOWDANGER,WARNING,ANDCAUTIONINSTRUCTIONSCOULDRESULTINDEATH ORSERIOUSINJURY.
MACHINESAFETYANDINFORMATION
NOTICE isusedtoaddresspracticesnotrelatedtopersonalinjury.
NOTICE: Thesignalword NOTICE isusedthroughoutthismanualfollowedbyspecificinstructions.These messagesareintendedformachinesafety,ortoidentifyandpresentsupplementaryinformation.
ASAES441.3FEB04
ISO11684
VERSION--FEBí08
0-4
SAFETY
PRECAUTIONARYSTATEMENTS
Acarefuloperatoristhebestoperator.Mostaccidentscanbeavoidedbyobservingcertainprecautions.Tohelp preventaccidents,readandtakethefollowingprecautionsbeforeoperatingthisequipment.Equipmentshould beoperatedonlybythosewhoareresponsibleandinstructedtodoso.
Carefullyreviewtheproceduresgiveninthismanualwithalloperators.Itisimportantthatalloperatorsbefamiliar withandFollowsafetyprecautions.
THETRACTOR
1.ReadtheOperatorísManualcarefullybefore usingthetractor.Lackofoperatingknowledge canleadtoaccidents.
2.Useanapprovedrollbarandseatbeltforsafe operation.Overturningatractorwithoutarollbar canresultindeathorinjury.Ifyourtractorisnot equippedwitharollbarandseatbelt,seeyour NewHollandDealer.
3.Alwaysusetheseatbelt.Theonlyinstancewhen theseatbeltshouldnotbeusedisiftherollbar hasbeenremovedfromthetractor.
4.Ifafrontendloaderistobeinstalled,alwaysuse aFOPS(FallingObjectProtectiveStructure) canopytoavoidinjuryfromfallingobjects.
5.Usethehandholdsandstepplateswhengetting onandoffthetractortopreventfalls.Keepsteps andplatformclearedofmudanddebris.
6.Donotpermitanyonebuttheoperatortorideon thetractor.Thereisnosafeplaceforextrariders.
7.Keepallsafetydecalscleanofdirtandgrime, andreplaceallmissing,illegible,ordamaged safetydecals.SeethelistofdecalsintheDecal sectionofthismanual.
SERVICINGTHETRACTOR
1.Thecooling system operatesunderpressure whichiscontrolledbytheradiatorcap.Itis dangeroustoremovethecapwhilethesystemis hot.Alwaysturnthecapslowlytothefirststop andallowpressuretoescapebeforeremoving thecapentirely.
2.Keepanytypeofopenflameawayfromthe tractoranddonotsmokewhilerefueling.Waitfor theenginetocoolbeforerefueling.
3.Keepthetractorandequipment,particularly brakesandsteering,maintainedinareliableand satisfactoryconditiontoensureyoursafetyand complywithlegalrequirements.
4.Keepopenflameorcoldweatherstartingaids awayfromthebatterytopreventfiresor explosions.Usejumpercablesaccordingto instructionstopreventsparkswhichcouldcause explosion.
5.Stoptheenginebeforeperforminganyservice onthetractor.
6.Escapinghydraulic/dieselfluidunderpressure canpenetratetheskincausingseriousinjury.If fluidisinjectedintotheskin,obtainmedical attentionimmediatelyorgangrenemayresult.
• DONOTuseyourhandtocheckforleaks. Useapieceofcardboardorpapertosearch forleaks.
• Stoptheengineandrelievepressurebefore connectingordisconnectinglines.
• Tightenallconnectionsbeforestartingthe engineorpressurizinglines.
7.Donotmodifyorpermitanyoneelsetomodifyor alterthistractororanyofitscomponentsor functionswithoutfirstconsultingaNewHolland Dealer.
8.Thefueloilintheinjectionsystem isunderhigh pressureandcanpenetratetheskin.Unqualified personsshouldnotremoveorattempttoadjust apump,injector,nozzle,oranyotherpartofthe fuelinjectionsystem.Failuretofollowthese instructionscanresultinseriousinjury.
9.Continuouslong-termcontactwithusedengine oilmaycauseskincancer.Avoidprolonged contactwithusedengineoil.Washskinpromptly withsoapandwater.
0-5
10.Somecomponentsofyourtractor,suchas gasketsandfrictionsurfaces(brakelinings, clutchlinings,etc.)maycontainasbestos. Breathingasbestosdustisdangeroustoyour health.Youareadvisedtohaveanymaintenanceorrepaironsuchcomponentscarriedout byanauthorizedNewHollandDealer.However, ifserviceoperationsaretobeundertakenon partsthatcontainasbestos,theessential precautionslistedbelowmustbeobserved:
• Workoutofdoorsorinawellventilatedarea.
• Dustfoundonthetractororproducedduring workonthetractorshouldberemovedby extraction,notbyblowing.
• Dustwasteshouldbedampened,placedin asealedcontainer,andmarkedtoensure safedisposal.
• Ifanycutting,drilling,etc.isattemptedon materialscontainingasbestos,theitem shouldbedampenedandonlyhandtoolsor lowspeedpowertoolsused.
OPERATINGTHETRACTOR
1.Beforestartingthetractor,applytheparking brake,placethePTOleverintheìOFFîposition, theliftcontrolleverinthedownposition,the remotecontrolvalveleversintheneutral position,andthetransmissioninneutral.
2.Alwayssitinthetractorseatwhenstartingthe engineoroperatingcontrols.Donotstartthe engineoroperatecontrolswhilestandingbeside thetractor.
3.Donotbypasstheneutralstartswitches.Consult yourNewHollandDealerifyourneutralstart controlsmalfunction.Usejumpercablesonlyin therecommendedmanner.Improperusecan resultintractorrunaway.
4.Avoidaccidentalcontactwiththegearshiftlever whiletheengineisrunning,asthiscancause unexpectedtractormovement.
5.Beforegettingoffthetractor,disengagethePTO, turntheengineoff,andapplytheparkingbrake. Nevergetoffthetractorwhileitisinmotion.
6.Donotparkthetractoronasteepincline.
7.Donotoperatethetractorengineinanenclosed buildingwithoutadequateventilation.Exhaust fumescancausedeathorillness.
8.Ifthepowersteeringorengineceasesoperating, stopthetractorimmediately.
9.Pullonlyfromthedrawbarorthelowerlink drawbarinthedownposition.Useonlyadrawbar pinthatlocksinplace.Pullingfromthetractor rearaxleoranypointabovetheaxlemaycause thetractortoupset.
10.Ifthefrontendofthetractortendstorisewhen heavyimplementsareattachedtothethreepointhitch,installfrontendorfrontwheel weights.Donotoperatethetractorwithalight frontend.
11.Alwayssetthehydraulicselectorleverinposition controlwhenattachingortransportingequipment.Ensurehydrauliccouplersareproperly mountedandwilldisconnectsafelyincaseof accidentaldetachmentofimplement.
12.Donotleaveequipmentintheraisedposition.
13.Usetheflasher/turnsignallightsandSMVsigns whentravelingonpublicroadsbothdayand night(unlessprohibitedbylaw).
14.Whenoperatingatnight,adjustlightstoprevent blindingoncomingdrivers.
DRIVINGTHETRACTOR
1.Watchwhereyouaregoing,especiallyatrow ends,onroads,aroundtreesandlowhanging obstacles.
2.Toavoidupsets,drivethetractorwithcareandat asafespeed.Useextracautionwhenoperating overroughground,whencrossingditchesor slopes,andwhenturningcorners.
3.Toprovidetwo-wheelbraking,locktractorbrake pedalstogetherwhentransportingonroads.
4.Donotcoastorfreewheeldownhills.Usethe samegearwhengoingdownhillasisusedwhen goinguphill.
5.Anytowedvehiclewithatotalweightexceeding thatofthetowingtractorshouldbeequippedwith brakesforsafeoperation.
6.Ifthetractorbecomesstuckorthetiresbecome frozentotheground,backupthetractorto preventupset.
7.Alwayscheckoverheadclearance,especially whentransportingthetractor.
8.Whenoperatingatnight,adjustlightstoprevent blindingoncomingdrivers.
0-6
OPERATINGTHEPTO
1.WhenoperatingPTOdrivenequipment,shutoff theengineandwaituntilthePTOstopsbefore gettingoffthetractoranddisconnectingthe equipment.
2.Donotwearlooseclothingwhenoperatingthe powertake-offorwhennearrotatingequipment.
3.WhenoperatingstationaryPTOdrivenequipment,alwaysplacebothgearshiftleversin neutral,applythetractorparkingbrake,and blocktherearwheelsfrontandback.
4.Toavoidinjury,donotclean,adjust,unclog,or servicePTOdrivenequipmentwhenthetractor engineisrunning.
5.EnsurethePTOmastershieldisinstalledatall times.AlwaysreplacethePTOshieldcapwhen thePTOisnotinuse.
DIESELFUEL
1.UNDERNOCIRCUMSTANCESshouldgasoline,alcohol,orblendedfuelsbeaddedtodiesel fuel.Thesecombinationscancreatean increasedfireorexplosivehazard.Suchblends aremoreexplosivethanpuregasolineina closedcontainersuchasafueltank.DONOT USETHESEBLENDS.
2.Neverremovethefuelcaporrefuelwiththe enginerunningorhot.
3.Donotsmokewhilerefuelingorwhenstanding nearfuel.
4.Maintaincontrolofthefuelfillerpipenozzlewhen fillingthetank.
5.Donotfillthefueltanktocapacity.Allowroomfor expansion.
6.Wipeupspilledfuelimmediately.
7.Alwaystightenthefueltankcapsecurely.
8.Iftheoriginalfueltankcapislost,replaceitwith aNewHollandapprovedcap.Anon-approved, proprietarycapmaynotbesafe.
9.Keepequipmentcleanandproperlymaintained.
10.Donotdriveequipmentnearopenfires.
11.Neverusefuelforcleaningpurposes.
12.Arrangefuelpurchasessothatwintergradefuels arenotheldoverandusedinthespring.
13.Uselowsulfurfuel.
SAFETYFRAME(ROPS)
YourNewHollandtractorisequippedwithasafety frame.Itmustbemaintainedinaserviceable condition.Becarefulwhendrivingthroughdoorways orworkinginconfinedspaceswithlowheadroom.
UNDERNOCIRCUMSTANCESshouldyou:
• modify,drill,oralterthesafetyframeinanyway. Doingsomayrenderyouliabletolegalprosecution.
• attempttostraightenorweldanypartofthemain frameorretainingbracketswhichhavesuffered damage.Doingsomayweakenthestructureand endangeryoursafety.
• secureanypartsonthemainframeorattach yoursafetyframewithanythingotherthanthe specialhightensileboltsandnutsspecified.
• attachchainsorropestothemainframeforpullingpurposes.
• takeunnecessaryriskseventhoughyoursafety frameaffordsyouthemaximumprotectionpossible.
WHENYOUSEETHISSYMBOL ITMEANS: ATTENTION!
BECOMEALERT!
YOURSAFETYISINVOLVED!
0-7
OPERATORPROTECTIVESTRUCTURE WARNING
YourmachineisequippedwithanoperatorProtective Structure,suchas:aRolloverProtectiveStructure (ROPS)orFallingObjectProtectiveStructure(FOPS) orCabwithROPS.AROPSmaybeacabframeor atwo-postedorfour-postedstructureusedforthe protectionoftheoperatortominimizethepossibilityof seriousinjury.Themountingstructureandfasteners formingthemountingconnectionwiththemachine arepartoftheROPS.
TheProtectiveStructureisaspecialsafety componentofyourmachine.
DONOTattachanydevicetotheProtective Structureforpullingpurposes.DONOTdrillholesto theProtectiveStructure.
TheProtectiveStructureandinterconnecting componentsareacertifiedsystem.Anydamage, fire,corrosionormodificationwillweakenthe structureandreduceyourprotection.Ifthisoccurs, the ProtectiveStructureMUSTbereplaced sothat itwillprovidethesameprotectionasanewProtective Structure.ContactyourdealerforProtective Structureinspectionandreplacement.
Afteranaccident,fire,tiporrollover,thefollowing MUST beperformedbyaqualifiedtechnicianbefore returningthemachinetofieldorjobsiteoperation:
• TheProtectiveStructure MUSTbereplaced.
• ThemountingorsuspensionfortheProtective Structure,operatorseatandsuspension,seat beltsandmountingcomponentsandwiring withintheoperatorísprotectivesystemMUSTbe carefullyinspectedfordamage.
• Alldamagedparts MUSTbereplaced
DONOTWELD,DRILLHOLES,ATTEMPTTO STRAIGHTENORREPAIRTHEPROTECTIVE STRUCTURE.MODIFICATIONINANYWAYCAN REDUCETHESTRUCTURALINTEGRITYOFTHE STRUCTUREWHICHCOULDCAUSEDEATHOR SERIOUSINJURYINTHEEVENTOFFIRE,TIP, ROLLOVER,COLLISIONORACCIDENT.
IftheROPSisloweredorremovedfromthepower unitforanyreason,itmustbeerectedand/orrefitted immediately.Originalboltsorequivalentreplacementsmustbeusedandtightenedtothecorrect torque.
NewHollanddoesnotrecommendtheuseofthe mowerwiththeROPSremoved.
IfyouhaveafoldableROPS,itcanbefoldeddown formowerstorage.It must bepinnedintheupright positionpriortomachineoperation.
0-8
SERVICEAREA,FIREEXTINGUISHER,FIRSTAIDKIT
NOTICE: Keeptheareausedforservicingthe machinecleananddry.Wetoroilyfloorsareslippery. Wetspotscanbedangerouswhenworkingwith electricalequipment.Besureallelectricaloutlets andtoolsareproperlygrounded.
DoNotOperateTag
Beforeyoustartservicingthemachine,attachaìDo NotOperateîwarningtagtothemachineinanarea thatwillbevisible.
0-9
RH01N064
RH99E028
RH99E029
SAFETYDECALS
Thefollowingsafetydecalshavebeenplacedon yourmachineintheareasindicated.Theyare intendedforyourpersonalsafetyandforthose workingwithyou.Pleasetakethismanualandwalk
aroundyourmachinetonotethecontentandlocation ofthesewarningsigns.Reviewthesewarningsigns andtheoperatinginstructionsdetailedinthismanual withyourmachineoperators.
DANGER: Explosive/Acid-Poison
PARTNO:SBA390197660
LOCATION:UpperPartofhoodsupport WARNING
WARNING:PullOnlyFromDrawbar
PARTNO:SBA390198920
LOCATION:TopofPTOShield
WARNING:ToJumpStart
PARTNO:SBA490990571
LOCATION:OnRadiator
WARNING
WARNING:BeforeStarting andOperating
PARTNO:SBA390198380
LOCATION:Centerof LeftFender
DANGER:StartEngineOnly FromOperatorísSeat
PARTNO:SBA190196684
LOCATION:OnStarterMotor
WARNING:RotatingFanandBelts
PARTNO:SBA390198470
LOCATION:BothSidesofRadiator
0-10
WARNING
WARNING: OperateControlsOnly FromTractorSeat
PARTNO:SBA390198710
LOCATION:InnerRH&LHFender BehindROPS
WARNING:DoNotOperate withShieldRemoved
PARTNO:SBA390198480
LOCATION:RH&LHFrontofDashboard andRHEngineSideShield
RedReflectiveTape
PARTNO:SBA385150260
LOCATION:RearSurfaceof RH&LHROPSUprights
WARNING:CoolingSystemOperates UnderPressure
PARTNO:SBA390198721
LOCATION:UpperRearofRadiatorScreen
DANGER:SeatBelt/ROPS
PARTNO:SBA390197531
LOCATION:TopUnderSideofROPS
0-11
INSTRUCTIONDECALS
RangeSelector Lever (12x12)
PARTNO:
SBA390174470
LOCATION:
LeftSideQuadrant
Front-Wheel DriveControl Lever
PARTNO:
SBA390173871
LOCATION: BelowSeatPan
BackofLever
PTOEngagement
PARTNO:
SBA390174161
LOCATION:
LeftControl
Quadrant
Forward/Reverse ShuttleLever (12x12)
PARTNO:
SBA390174131
LOCATION:Left
SideofDash
RangeSelectorLever
-Hydrostatic
PARTNO:
SBA390174460
LOCATION:
OntheLeverGuide
DraftControlLever(Optional)
PARTNO:
SBA390372531
LOCATION:
RightLeverGuide
PositionControl Lever
PARTNO:
SBA390372490
LOCATION: RightSideFender
OperatingRemote ControlValve-Single Spool(Optional)
PARTNO:
SBA390372560Green#1Valve
PARTNO:
SBA390372810Blue#2Valve
LOCATION: RightSideQuadrant
0-12
Hyd.ManifoldOperation (SeeOperatorísManual)
PARTNO:SBA390198320
LOCATION: Right-HandSideofHyd. Manifold/AirFilterCap
StarterSwitch
PARTNO:SBA390197280
LOCATION: StarterSwitch,RightSide ofInstrumentPanel
LowSulfurFuel
PARTNO:SBA390199390
LOCATION:UndersideofFuelFill Lid
Coupler-Extending (Withdoublespoolcontrolvalve)
PARTNO:86532920
Coupler-Retracting (Withdoublespoolcontrolvalve)
PARTNO:86532919
DieselFuel
PARTNO:SBA390198340
LOCATION:Undersideof
FuelFillLid
Coupler-Extending (Withdoublespoolcontrolvalve)
PARTNO:86532921
Coupler-Retracting (Withdoublespoolcontrolvalve)
PARTNO:86532922
Lubricationand MaintenanceIntervals
PARTNO: SBA390199311
LOCATION: UndersideofHood
0-13
DifferentialLock
PARTNO:SBA390198301
LOCATION:AbovePedal FlowControlValve
PARTNO:SBA390372471
LOCATION:TopofFlow ControlKnob
DieselEngineOilInformation
PARTNO:SBA390198370
LOCATION:UnderSideofHood
IMPORTANT-ForNormalOperation
PARTNO:SBA390198310
LOCATION:CenterPanelof SteeringColumnConsole
ParkingBrake
PARTNO:SBA390198361
LOCATION:Centerofdash
HandThrottle
PARTNO:SBA390430290
LOCATION:UpperRH Dashboard
SpeedSetControlInstructions(optional)
PARTNO:SBA390199410
LOCATION:TopofL.H.Fender
USAGE-TractorsThataretobeStored(12x12)
PARTNO:SBA390194690
LOCATION:OnClutchPedalSpacerBlock
InstallingPedalSpacer(12x12)
PARTNO:SBA390194700
LOCATION:OnClutch
PedalSpacerBlock
0-14
ECOLOGYANDTHEENVIRONMENT
Soil,air,andwaterarevitalfactorsofagricultureand lifeingeneral.Whenlegislationdoesnotyetrulethe treatmentofsomeofthesubstanceswhichare requiredbyadvancedtechnology,commonsense shouldgoverntheuseanddisposalofproductsofa chemicalandpetrochemicalnature.
Thefollowingarerecommendationswhichmaybeof assistance:
• Becomeacquaintedwithandensurethatyouunderstandtherelativelegislationapplicableto yourcountry.
• Wherenolegislationexists,obtaininformation fromsuppliersofoils,filters,batteries,fuels,antifreeze,cleaningagents,etc.,withregardtotheir effectonmanandnatureandhowtosafelystore, useanddisposeofthesesubstances.Agriculturalconsultantswill,inmanycases,beabletohelp youaswell.
HELPFULHINTS
1.Avoidfillingtanksusingcansorinappropriate pressurizedfueldeliverysystemswhichmay causeconsiderablespillage.
2.Ingeneral,avoidskincontactwithallfuels,oils, acids,solvents,etc.Mostofthemcontain substanceswhichmaybeharmfultoyourhealth.
3.Modernoilscontainadditives.Donotburn contaminatedfuelsandorwasteoilsinordinary heatingsystems.
4.Avoidspillagewhendrainingoffusedengine coolantmixtures,engine,gearboxandhydraulic oils,brakefluids,etc.Donotmixdrainedbrake fluidsorfuelswithlubricants.Storethemsafely untiltheycanbedisposedofinaproperwayto complywithlocallegislationandavailable resources.
5.Moderncoolantmixtures,i.e.antifreezeand otheradditives,shouldbereplacedeverytwo years.Theyshouldnotbeallowedtogetintothe soilbutshouldbecollectedanddisposedof safely.
6.Donotopentheair-conditioningsystemyourself. Itcontainsgaseswhichshouldnotbereleased intotheatmosphere.Yourdealerorair conditioningspecialisthasaspecialextractorfor thispurposeandwillhavetorechargethesystem properly.
7.Repairandleaksordefectsintheenginecooling orhydraulicsystemimmediately.
8.Donotincreasethepressureinapressurized circuitasthismayleadtoacomponentfailure.
9.Protecthosesduringweldingaspenetrating weldsplattermayburnaholeorweakenthem, allowingthelossofoils,coolant,etc.
0-15
UNIVERSALSYMBOLS
Asaguidetotheoperationofyourtractor,variousuniversalsymbolshavebeenutilizedontheinstruments,controls,switches,andfusebox.Thesymbolsareshownbelowwithanindicationoftheirmeaning.
Thermostart startingaid
Alternator charge
Fuellevel
Automatic Fuelshut-off
Enginespeed (rev/minx100)
Hoursrecorded
Engineoil pressure
Enginecoolant temperature
Coolant level
Tractorlights
Headlamp mainbeam
Radio
P.T.O.
Position Control
KAM N
Keepalive memory
Turnsignals
Turnsignals -onetrailer
Turnsignals -twotrailers
Frontwindscreen wash/wipe
Rearwindscreen wash/wipe
Transmission inneutral
Creeper gears
Slowor lowsetting
Fastorhigh setting
Ground speed
Differential lock
Draft Control
Accessory socket
Implement socket
%age slip
Hitchraise (rear)
Hitchlower (rear)
Hitchheight limit(rear)
Rearaxle oiltemperature
Hitchheight limit(front)
Heaterfan
Heatertemperaturecontrol Airconditioner
Airfilter blocked
Parking brake
Transmission oilpressure
FWD engaged
FWD disengaged
Hitchdisabled
Hydraulicand transmission filters
Remote valveextend
Worklamps
Headlamp dippedbeam Stop lamps
Horn
Brakefluid level
Trailer brake
Roof beacon
Warning! Corrosive substance
Warning!
Hazard warninglights
Variable control
Pressurised! Opencarefully
Remote valveretract
Remote valvefloat
Malfunction! SeeOperatorís Manual
Malfunction! (alternativesymbol)
0-16
GENERALINFORMATION
PLEASEREADCAREFULLY: Foracompletelistofthepre-deliveryservicechecks performedbyyourdealer,refertothePRE-DELIVERYSERVICEchecklistfoundatthebackofthis manual.Keeponecopyasyourrecordoftheservice performed.Theothercopyshouldberemovedfrom themanualandkeptbyyourdealer.MAKESURE THATBOTHCOPIESARECOMPLETEDANDTHAT YOUANDTHEDEALERSIGNBOTHCOPIES.
APRODUCTIDENTIFICATIONPLATE,1,islocated onthe left-handsideofthetransmissionhousing. Thenumbersontheplateareimportantintheevent yourtractorshouldrequirefutureservice.Foryour convenience,haveyourdealerrecordthese numbersintheappropriatespacesbelow.
CNHAmericaLLCiscontinuallystrivingtoimprove itsproducts.Wereservetherighttochangeprices, specification,orequipmentatanytimewithout notice.
Alldatagiveninthisbookissubjecttoproduction variations.Dimensionsandweightsareapproximate only,andtheillustrationsdonotnecessarilydepict tractorsinstandardcondition.Forexactinformation aboutanyparticulartractor,pleaseconsultyourNew Hollanddealer.
1-1 SECTION1
20046476 1 76075628 1
Suggest:
If the above button click is invalid.
Please download this document first, and then click the above link to download the complete manual.
Thank you so much for reading
BIODIESELFUEL
FattyAcidMethylEsterBiodiesel(BiodieselFuel) consistsofafamilyoffuelsderivedfromvegetable oilstreatedwithmethylesters.
NOTICE: BiodieselFuelblendsareapprovedfor yourengineonlyiftheycomplywithSpecification standardsEN14214orASTMD6751.
NOTICE: Itisimperativethatyoucheckwhichblend isapprovedforyourenginewithyourlocaldealer. BewarethattheuseofBiodieselFuelthatdoesnot complywiththeStandardsmentionedabovecould leadtoseveredamageto theengineand fuel system ofyourmachine.Theuseoffuelsthatarenot approvedmayvoidWarrantycoverage.
BiodieselFuelUsageConditions
NOTICE: TheBiodieselFuelmustmeetthefuel Specificationmentionedabove.
BiodieselFuelmustbepurchasedfromatrusted supplierthatunderstandstheproductandmaintains goodfuelquality.BiodieselFuelmustbepre-blended bythesupplier.MixingBiodieselFuelson-sitecan resultincorrectmixturethatcanleadtoproblems withbothengine andfuel system.
Engineperformanceisaffectedbytheuseof BiodieselFuel.Theremaybeupto12percent reductioninpowerortorquedependingontheblend used.
NOTICE: DONOTmodifytheengineand/orinjection pumpsettingstorecoverthereducedperformance.
Thereducedpowermustbeacceptedifusingany BiodieselFuelblend.
Somemodificationmayberequiredtoallowyour enginetorunBiodieselFuel.Consultyoudealerfor completeinformationonthesemodifications.
BiodieselFuelhasahighercloudpointthanDiesel Fuel.
NOTICE: TheusesofhighBiodieselFuelblendsare notrecommendedincoldweatherconditions.
WithBiodieselFuels,itmaybenecessarytochange theengineoil,engineoilfilterandfuelfilterelements
morefrequentlythanwithDieselFuels.Biodiesel Fuelcanremoverustandparticlesfromtheinsideof on-sitefuelstoragetanksthatwouldnormallyadhere tothesidesofthetank.Likeparticlesdepositsthat commonlyoccurwithDieselFuel,theseparticlescan becometrappedbythemachinefuelfilters,causing blockageandshorteningfilterlife.Incoldweather, thisismorelikelytohappen.Consultyoudealerfor informationoncoldweatheroperationandproper maintenanceintervalswhenusinganyBiodiesel Fuelblend.
WhenhandlingBiodieselFuel,caremustbetaken nottoallowwaterintothefuelsupply.BiodieselFuel willactuallyattractmoisturefromtheatmosphere. Fueltanksmustbekeptasfullaspossibletolimitthe amountofairandwatervaporsinthem.Itmaybe necessarytodrainthefuelfilterwatertapmore frequently.
Potentialoxidationandstabilitycouldbeaproblem withthefuelstoredinthemachine.
NOTICE: Machinesmustnotbestoredformorethan 3monthswithBiodieselFuelblendsinthefuel system.
Iflongstorageperiodsarenecessary,theengine mustrunonDieselFuelfor20hourstoflushthe BiodieselFueloutofthe enginefuel systempriorto storage.
NOTICE: BiodieselFuelmustnotbestoredinon-site storagetanksformorethan3months.
AnyspillageofBiodieselFuelmustbecleanedup immediatelybeforeitcancausedamagetothe environmentandthepaintfinishofthemachine.
BeforeusingBiodieselFuelblendsyoushould consultwithyourdealertoreceivefullinformation abouttheapprovedblendforyourmachineandany detailedconditionsofitsusage.
NOTICE: BeawarethatnotfulfillingtherequirementsandconditionsofBiodieselFuelusagemay voidyourmachineísWarrantycoverage.
SECTION1-GENERALINFORMATION 1-2
