Furniture Design Drawings

Page 1

OSB PARTITION

frameless, heavy duty, joint to pallet

JOINTS osb - pallet roll bolts or large wood screws

JOINTS table to table roll bolts

PALLET TABLE TOP

heaviest europallet 1200 x 800 mm modified smooth tabletop finish clear matte vannich

STEEL BASE FRAME

matte black finish soft edjes

heaviest available hollow steel (rounded edges)

construction plans FURNITURE

JOINTS table to table roll bolts

GSPublisherVersion 0.4.100.100 0,650 0,025 0,475 1,150 0,020 0,560 0,020 0,563 0,040 0,600 0,650 0,150 0,350 1,150 1,200 0,071 1,059 0,071 0,500 0,050 1,100 0,050 0,600 0,650 0,025 0,475 0,675 1,205 1,150 0,650 0,500
