Adlår Castra - Why we make a difference!

Aurora II: Make A Difference Voted Fastest Payback Heat Pump

Of all the heat pumps on Heat Pump Comparator,

Adlår Castra has the most favorable ratio between a (low) purchase price and (high) energy savings.

In terms of energy savings, the Aurora II is one of

the best heat pumps in its class. On the other hand, the competitive price of the Aurora II is even more striking.

Source: warmtepompvergelijker.nl

H e a t Pu mp Ex p e r t s

Congratulations on your decision to invest in a sustainable future!

Thank you for your trust in Adlår. We look forward to providing your home with an efficient, environ-

mentally friendly and comfortable heating system. Together we are working towards a sustainable future! In this document we lay out how we optimise your heat pump journey and deliver a better product for you.

1 Adlår’s System - Simpler, more efficient system with better equipment and at a lower cost 2 Technical Understanding - Understanding the advantages of our setup 3 Understanding Heat Pump Warmth - The heating equivelent of the tortoise and hare 4 Adlår Castra - How we Aspire to Make A Difference 5 ASHP Cylinder - The future of hot water now!

6 £7,500 Grant and Site Checks - Check you eligibility and property suitability 7 Save by providing site survey information 8 Getting your site ready - Total potential savings £1,753 9 Your Installation Options Brochure

Chat

QUOTE

Heat Pump Experts

BOOK SURVEY

1

Adlår’s System - Simpler, more efficient system with better equipment and at a lower cost

Our game-changing split system: A lot of heat pump companies are slowly transitioning from the boiler industry. Not us. We came fresh into the heat pump industry and are fully specialised in them. This means we understand the product to the core and don’t install it as you would a gas boiler which many companies still do, because they don’t understand the core principes of heat pumps.

ADLÅR’S SYSTEM

CONVENTIONAL SYSTEM

Overview of our system v Less parts - especially high-failure parts

v Quicker install - less pipework and electrical connections v More efficient - low power hot water heating v More efficient - direct into emitters v Priority hot water AND heating

v Backup heating - 2 ASHPs, and 2 electric immersions v Better looking, smaller footprint

Heat Pump Experts

H e a t Pump Ex-

2 Technical Understanding - Understanding the advantages of our setup v Less high-failure parts From the images on page 3, you can get an idea of the extra connections required between a conventional system and our split-inline system. As a summary of those components and the disadvantages of them: Extra Parts in Conventional System Part

Disadvantage

Why Needed

Water Pump(s)

High failure point

As there additional valves and the water goes

Additional operation cost

through a low loss header a pump is required to

increase water pressure and water flow.

2-port Valve(s)

This is needed to control the flow into the heating

High failure point

water system from the low loss header.

3-port Valve(s)

High failure point

This is needed to control the flow between hot water

and heating.

Electrical connections

Additional cost and install time

To control the above devices requires a lot of

additional wiring.

Water connections

Additional cost and install time

A lot more piping is required to route all the water

systems between the valves and their flows.

Extra Parts in Adlår’s System Part

Advantage

Why Needed

Backup heater

Smart boost of water temperature

In most low loss header cylinders they only have

immersion heaters in the hot water section. In our

system we have both. The heat pump smartly controls this to boost power if the outdoor

temperature is very cold and the heat pump thinks

it is more efficient to heat through a boost.

v More Efficient - Straight to Emiiters In conventional systems a low-loss-header is used. You can see in the diagram how the flow and return water goes through this low-loss header. This is fine when you have a boiler and your water temperature is 80 degrees but because heat pumps work at lower temperatures, the heat loss in the low-loss-header makes a big difference to your felt comfort at your radiators or underfloor heating.

In Adlår’s system we arrange the heatpump in what is called an “inline” setup. This means the water goes straight from the heat pump into your emitters without high heat loss.

50°C

50°C

45°C

30°C

35°C

30°C

Heat Pump Experts

v More Efficient - No losses in your piping network In conventional systems a 3-port valve directs the water between your hot water and your heating. This is usually situated where the low loss header is, which could be multiple meters away from your heat pump, for example in a loft.

Heat pumps work best by adjusting your heating water temperature smartly to save you more on your heating bills. To maximise the savings the water in your heating system doesn’t want to always be +50 degrees.

It should instead change temperatures, and be as cool as you need to get the right comfort in your home. In contrast, your hot water does want to be at a consistent temperature, usually around 50-55 degrees.

Having multiple meters of pipework between your heat pump and the 3-port valve means anytime a hot water demand happens there will be significant losses. As an example, your heating is running at 30 degrees (a medium temperature for underfloor heating systems, equivalent to 45 degrees for a medium radiator temperature), and a hot water demand comes on. The heat pump will then start heating the water to 50 degrees.

Before it gets up to temperature however, the 3-port valve will open and the 30 degree water will start entering your hot water tank.

It will take several minutes, if not longer, to get the water temperature up from 30 degrees to 50 degrees if the heat pump is running in an efficient mode. During that time the hot water tank will be filling with this colder water. The heat pump will then have to continue to work much longer and harder in order to refill your hot water tank with 50 degree water, first displacing the cold water that entered it, and then heating the whole water tank up to 50 degrees. This is a massively inefficient process.

v More Efficient - 1.3kW Heating of Hot Water Your heat pump is specified based on the heat loss of your home. In other words, it is specified based on your heating demand, not your hot water demand. Hot water demand requires a lot less energy capacity than your heating does.

It therefore doesn’t make sense to use a 6, 10 or 14kW heat pump when a 1.3kW heat pump is more than sufficient. By being able to use a 1.3kW cylinder heat pump for your hot water, the running cost savings are significant compared to if you did it with a large unit. This is especially prevelant in the summer months when you won’t need your heating on.

With our split system you can have your outdoor unit off during warm weather and have your small indoor unit keeping your hot water warm.

Heat Pump Experts

v Priority Hot Water AND Heating In a conventional system you can either heat your hot water OR your heating, the 3-port valve switching the water between the two. In the Adlår system, these are separate and therefore you can have both at the same time.

As an example, you can imagine a cold day where having your heating on and constant is desired in order to have maximum comfort, however if you also decided to have a bath or run your hot water, it is likely the hot water demand would be triggered. As these system work in priority hot water it means.

v Backup Heating - 2x Immersion Heaters In most low loss headers there is only an immersion heater in the hot water section, and not in the heating buffer vessel. This can be okay, but it is better to design the system for the worst case scenario, and not just the design temperature.

To understand this better, using the government MCS protocol for heat pump design, the heat pump is designed to match a design temperature. In Surrey for example, this design temperature is -2.2 degrees. The recent lowest recorded temperature in 2010 in Surrey was -10 degrees.

By designing in backup heaters which the heat pump controls using smart sensors to monitor the outside temperature and the heat pump workload, not only can the heat pump work more efficiently, but you also ensure under the worst possible weather you aren’t running cold.

v Better Looking - Smaller Footprint On a design front, we’ll let you be the judge of whether you think our outdoor unit looks better than others. The other big advantage however is that our indoor space requirements are much less using our design. As a general rule, a buffer tank with 25 litres of water per kW output are required. In a typical 3-bed home with a heat pump of 10kW, you would require a buffer tank of ~150 litres. This takes up a lot of space. It is also inefficient to boost heat when the weather is very cold, with most low-loss heater units not even having immersion heaters connected. This means on the coldest days you could struggle to get the heat you want.

Due to our system setup, which includes the smart backup heater and a state-of-art Grundfos pump we turn your home into a buffer tank and thermal store, meaning we only need a very small buffer tank (35 litres) in most circumstances. Heating this small buffer tank is more efficient.

Heat Pump Experts

3 Understanding Heat Pump Warmth - the heating equivelent of the tortoise and hare v Tortoise (Heat Pump) and the Hare (Boiler) Changing from a boiler to a heat pump requires a rethink in the way you heat your home. As one of our customers recently said “somehow the heat is much nicer than gas”.

A boiler burns fossil fuels to super-heat cold water to ~80°C rapidly, to do this a boiler burns at roughly 1,200°C. This isn’t an exact process, and not a very efficient process either, and results in a yo-yo effect between the boiler and your thermostat turning ON/OFF the boiler to try to maintain the temperature you desire.

A heat pump, in contrast, maintains a constant flow and changes the water temperature in a much more controlled way, one degree at a time. This maintains a constant temperature in your home resulting in a much more comfortable heat.

As with the traditional tortoise and hare race, we also like to claim the heat pump wins the race when the race is comfort and the prize is lower energy bills.

v Smart Heat Curves Smart heating curves lie at the heart of your home’s resting temperature.

As our heat pump sits outside it is easy to measure the outside ambient temperature and adjust your heating temperature without you needing to worry about it. As it gets colder the heat pump increases the water temperature accordingly based on your personal preferences and your learnt heating patterns.

We have 16 different heating curves for you to choose from, allowing you to find the most efficient and comfortable mode to suit you, or to adjust the modes when you feel cold.

v Radiators and Emitters A key component of heat pumps working optimally is to conduct a detailed heat loss survey of your property, measuring each room in your home’s heat loss and checking the BTU (output) of your radiators is sufficient to cover the heat loss of that room.

During our site survey we will do these detailed measurements and after the results are processed and finalised we will communicate with you which ones might need upgrading in order to get the optimum results from your heat pump.

Heat Pump Experts

H e a t Pump Ex-

4 Adlår Castra - Aspire to Make A Difference v Largest Installer in Holland Whilst Adlår is fresh in the UK we are the largest installer in Holland. The UK market is not quite the same as it is on the continent, but with changing perception and education we know this is the right market to be in. Adlår UK and Adlår Holland coordinate and combine all our research and development on both manufacturing and installation practices to bring you the best service.

v Two Day Install - A few hours without heat

Due to our system setup and optimised installation methods, we can complete installs much quicker than conventional systems. In a lot of cases where the boiler doesn’t need to be decommissioned until the end of the install you heating can even remain on during the install and only be turned off near the end.

v Direct from the manufacturer Direct from the manufacturer: Adlår focuses on offering customers excellent service. By delivering and installing a product the business has manufactured itself, rather than relying on various sub-contractors, we ensure everything is put in place to a high standard and quickly.

Performance: Designed and engineered to deliver exceptional performance in various climates and conditions, Adlår heat pumps undergo rigorous testing and quality control measures to ensure optimal operation and reliable heating and cooling performance.

Committed to make a difference: Lower CO² emissions and delivering warmth in Ukraine are just some of Adlår’s ambitions. Even when we aren’t installing eco-friendly technology in homes, we look to provide warmth to those who are less fortunate. In the winter of 2022, Adlår supplied sleeping bags to the Dombas region as part of our “CO² to aid” program.

Cutting edge technology: We focus on innovative and cutting-edge technology, with tier-1 components used in the manufacturing of its products. We also constantly invests in research and development to deliver fantastic products that offer amazing performance and efficiency.

Heat Pump Experts

Declaration of conformity to legal standards

Surrey, UK. 07-04-2023 Noise Pressure Standards We declare that the Adlår Castra Aurora II 6, 10 and 14 kW heat pumps comply with the (EU) No 813/2013 standard regarding outdoor sound power, measured directly next to the heat pump. The legal standards apply as follows: Noise pressure: During the day (07:00 to 19:00) maximum 45 db(A).

During the night (19:00 to 07:00) maximum 40 db(A). ​ The maximum sound pressure of the AURORA II (open field test) is: 1 meter away 2 meters away 6 kW 42 dB(A) 36 dB(A) 10 kW 43 dB(A) 37 dB(A) 14 kW 47 dB(A) 41 dB(A)

Nightmode (at source) Between 27 dB(A) and 38 dB(A) Between 28 dB(A) and 38 dB(A) Between 30 dB(A) and 38 dB(A)

For further details on conformity, please refer to the Noise Standard itself (EU) No 813/2013.

Other legal standards Adlår Castra also declares that it complis with the following legal standards: EN 14825:2018 EN 12102-1:2017 EN14511-4:2018 (EU) No 813/2013

EU 2016/2282:2016-11-30 EN60335-1:2012/A15:2021 EN60335-2-40:2003/A13:2012 EN62233:2008

With warmest regards, Team Adlår

Heat Pump Experts

Download

Maintenance Packages

1 YEAR BRONZE

5 YEARS SILVER

GOLD

MOST POPULAR

PLATINUM

ADLÅR

WARMTE GARANTIE

PREMIUM

Yearly maintenance Support lines always available No mobile app subscribtopn fees 5 Year Warranty Breakdown priority Efficiency Optimisation Annual inspection not including labour resulting from inspection (1x per year)

Annual water and filter clean Full Electric assurance control Warranty extension after 5 years No material costs for maintenance No call-out costs for additional maintenance Assistance within 24hrs of issue

Per Year

99,-

129,-

149,-

229,-

What is not covered: • Pipework; Connections; Electrics; • Any other equipment not directly related to your heat pump (third party equipment not produced by Adlår.

Core Details: Annual Home Visit for full system service 5 year heat pump warranty 5 year warranty on your heat pump cylinder

Any damages or associated costs caused by: • Lack of care or neglect; • Accidental damage, malicious damage, misuse, or any alteration; • Maintenance servicing by any third party; • Failure to use for installation purpose; • Lack of power or water, water contamination or scale formation or air pollution.

10 year warranty on emitters (radiators or underfloor) Access to our helpline (see website for open times) No call-out fees (if repair covered under warranty) Heat Pump Warranty Period You may ask why our heat pump warranty period changes based on your service package selection. This is because, like anything, proper maintenance ensures the product works and functions as desired.

We like to insist we do your maintenance to ensure it is done correctly and well. By doing this we can easily extend our warranty and equally give you peace of mind.

Full Terms and Conditions During your site visit our surveyor will recommend our service packages to you and discuss your options. Following your decision we will supply you with our package full terms and conditions.

If you would like to read these in advance please ask your sales contact or enquire here.

Heat Pump Experts

5 ASHP Cylinder - Split system, the future of hot water now! v The Future of Hot Water Heating As detailed in the technical section our ASHP Cylinders are a core component in our split system design. They are really the future of hot water heating and will become a standarad feature in future homes. Adlår has worked hard to develop our own cylinder with core advantages above the rest. See above for the cost saving and system advantages.

v R290 Refriderant R290 has a zero ODP value, which means that it has no negative impact on the ozone layer. In addition, the GWP value is close to 0, which means there is a minimal impact on the global-warming. What’s more? R290 is not only an environmentally friendly refrigerant, but also achieves a higher COP and higher water temperature.

v Micro-Channel Heat Coil High-density micro-channel heat coils with multi-flow allow the refrigerant and the surface of the stainless steel water tank to have a larger heat exchange area, which highly improves the heat transfer efficiency.

v Stainless Steel Our ASHP Cylinder is made with stainless steel providing higher water quality over a longer time than other materials.

v Filters - Magnesium or Titanium Electrical You can choose between a magnesium or a titanium electrical anode filter. These filters balance the mineral content of your water by filtering out calcium, extraneous particles, chlorine and heavy metals. This results in an almost neutral pH. The titanium electrical anode has the advantage that it doesn’t need to be replaced, and will extend the life of your cylinder dramatically.

Magnesium anodes in contrast are sacrificial meaning you need to stay on top of them to replace them when they are ~70% dissolved.

Filters are very important for long-term water quality, with recent studies showing not only the critical importance of filtered drinking water, but also bath and shower water, and the impacts of heavy metals absorbed through the sink during bathing.

Heat Pump Experts

H e a t Pump Ex-

6 £7,500 Grant and Site Checks - Check you eligibility and property suitability We arrange

Click to read more:

Learn about all the details of the BUS Scheme grant.

I own my property or have permission from the owner.

your BUS grant

£7,500

I am replacing a fossil fuel based heating system

Links:

My EPC is up-to-date

1. EPC Certificate Check

My EPC doesn’t have any loft or cavity wall recommendations.

2. Ofgem Checklist

My property is not classed as social housing or is benefit to other government funding or support for renewables (exc. solar).

3. MCS Checklist

If my property is listed I have planning permission or I have told my Adlår sales support that I have a listed building.

What we do and your responsibilities.

You must provide us with all relevant information regarding your property to properly check your eligibility.

Adlår will apply for your grant >10 days in advance of your install to confirm eligibility from the government. On receipt of the confirmation email from Ofgem you must confirm your details.

If your application isn’t successful due to your EPC or other circumstances we must pre-pay the grant amount and have it retrospectively applied once the grant goes through. Usually this is due to your EPC requiring material upgrades.

7 SAVE BY PROVIDING PRE-SITE SURVEY INFORMATION Advanced Pre-Survey Checks

Basic Pre-Survey Checks -£100

If you answer our basic pre-survey checks we give you £100 off your heat pump price.

-£150

If you answer our advanced pre-survey checks we give you £150 off your heat pump price.

The questions only involve basic usage of a tape measure and laying out your home’s floor plan., This prepares you and us much better for your site visit.

The questions only involve basic usage of a tape measure, but prepare you and us much better for your site visit.

Heat Pump Experts

8 GETTING YOUR SITE READY - TOTAL POTENTIAL SAVING £1,753 Heat Pump Ground Preparation

Boiler Decommissioning & Removal

If your heat pump will be sited on the ground you can prepare the site in advance of your installation.

We are heat pump experts. It can therefore be cheaper to get a local contractor to decommission your existing system.

Depending on your site you can save between £120 to £380.

Fuse Board / Power to Heat Pump

System Flush

In most cases a new fuse board shouldn’t be required. If your fuse board does not have capacity or needs upgrading to the BS 7671 + P standard we will need to upgrade your electrics.

It is not neccissary to flush your system, but it can improve the performance of your heat pump and improve its longevity.

It can often be more cost effective to get this done by a local contractor.

If you are able to provide and run a 3-core cable to the heat pump location from your fuse cupboard to your heat pump you will save a further £250.

9 Your Installation Options

Heat Pump Experts

Neighbours We can pass a significant saving onto you by

bundling installation and travel costs together when you get a heat pump at the same time as your neighbour.

For neighbours within

5 miles, save

10-20%

If you’re both looking for wall or roof mounted heat

How does it work?

install closer to 10%.

neighbour’s details. We can give you an indication

Adlår Castra appreciates your efforts and rewards

during your MCS Site Survey we will confirm the total

pumps the savings will be closer to 20%, a standard

it with discounts depending on the installation

methods and the number of neighbors participating.

All you need to do is contact us with you and your

of your savings over the phone and email, and then amount.

This promotion is valid until 31-12-2023.

In this way we make sustainable solutions affordable and accessible to everyone in your area.

TIP!

Friends & Family If you don’t have a neighbour that is interested,

you’ve already installed your heat pump and you’re now the envy of the village, or your friend living a

distance from you is interested in one, you can still get rewarded for recommending us.

When your family or friend gets a heat pump you will recieve £100.00, and they will get £100.00 off their heat pump also.

For every new customer

receive

2x £100.00

How does it work

1. Register on our website form - www.adlar.co.uk promotions.

2. You will recieve a unique code from us that the new Adlår customer can pass on at the time of purchase

3. You will receive £100 directly upon completion

of the install, and your friend will receive an £100 discount off their heat pump.

Ga nu naar adlar.nl/friends

This promotion is valid until 31-12-2023.
