C E R T I F I C A T I O N
ALL UNITS NOT TAGGED AS MOBILITY SHALL BE ADAPTABLE
COMMON STAIR: MAX. RISER HEIGHT OF 7" AND MIN. TREAD DEPTH OF 11" (PER CBC 1011.5.2) MIN.
HEADROOM 80" (PER CBC 1011.3)
GUARDRAIL MIN. 42" A.F.F. WITH 4" MAX. OPENINGS. (PER CBC 1015.3 & 1015.4)
HANDRAILS TO BE BETWEEN 34" AND 38" A.F.F. (PER CBC 1014)
ALL DIMENSIONS TO STUD FACE OF WALL U.O.N. GRIDLINES ARE TO FACE OF STUD OR CENTER OF CONC.COLUMN, U.O.N.
ALL COMMON WC'S ARE FULLY ACCESSIBLE PER CBC CHAPTER 11B
ALL EXTERIOR WALLS TO BE W06BPER A5.01 AT GROUND FLOOR UON
ALL EXTERIOR WALLS TO BE W11BPER A5.01 AT LEVELS 2-5 UON
ALL UNIT DEMISING WALLS TO BE P16CPER A5.02 UON
ALL CORRIDOR TO UNIT WALLS TO BE P15BPER A5.02 UON
ALL CORRIDOR TO UNIT WALLS AT RECESSED UNIT ENTRY TO BE P20 PER A5.02 UON
ADA CLEARANCES & GRAB BARS NOT SHOWN IN OVERALL FLOOR PLANS; SEE ENLARGED PLANS.
3
GENERAL NOTES
ALL UNITS NOT TAGGED AS MOBILITY SHALL BE ADAPTABLE
COMMON STAIR: MAX. RISER HEIGHT OF 7" AND MIN. TREAD DEPTH OF 11" (PER CBC 1011.5.2) MIN. HEADROOM 80" (PER CBC 1011.3)
GUARDRAIL MIN. 42" A.F.F. WITH 4" MAX. OPENINGS. (PER CBC 1015.3 & 1015.4)
HANDRAILS TO BE BETWEEN 34" AND 38" A.F.F. (PER CBC 1014)
ALL DIMENSIONS TO STUD FACE OF WALL U.O.N. GRIDLINES ARE TO FACE OF STUD
OR CENTER OF CONC.COLUMN, U.O.N.
ALL COMMON WC'S ARE FULLY ACCESSIBLE PER CBC CHAPTER 11B
ALL EXTERIOR WALLS TO BE W06BPER A5.01 AT GROUND FLOOR UON
ALL EXTERIOR WALLS TO BE W11BPER A5.01 AT LEVELS 2-5 UON
ALL UNIT DEMISING WALLS TO BE P16CPER A5.02 UON
ALL CORRIDOR TO UNIT WALLS TO BE P15BPER A5.02 UON
ALL CORRIDOR TO UNIT WALLS AT RECESSED UNIT ENTRY TO BE P20 PER A5.02 UON
ADA CLEARANCES & GRAB BARS NOT SHOWN IN OVERALL FLOOR PLANS; SEE ENLARGED PLANS.
1. ALL DIMENSIONS NOTED AS "CLR." OR "MIN." ARE TO FINISHED SURFACE, TYP.
2. ALL CLOSETS TO HAVE WIRE SHELVING SYSTEM PER SPECIFICATIONS. AT ACCESSIBLE UNITS, TOP OF SHELVING AND/OR CLOTHING ROD TO BE 48" A.F.F.
3. ALL PARTITION TYPES P04A (GROUND FLOOR) OR P12A (LEVELS 2-5) U.O.N.
4. KITCHEN/BATHROOM CASEWORK ALONG PARTY WALLS TO HAVE SLOW CLOSING HINGES. RESILIENT MATERIAL SUCH AS FELT OR RUBBER TO BE PLACED AT CONTACT POINTS.
5. GYPSUM BOARD SHALL BE CONTINUOUS ABOVE ALL SOFFITS AND DROPPED CEILINGS TO MAINTAIN RATING OF FLOOR/CEILING ASSEMBLY WHERE REQ'D.
6. FINISHED CEILING TO BE UNDERSIDE OF RATED FLOOR-CEILING ASSEMBLY EXCEPT WHERE SOFFITS AND DROPPED CEILINGS OCCUR, AS INDICATED ON LEGEND. TYPICAL DROPPED CEILING TO BE 7'-9" A.F.F. U.O.N.
7. FOR LOCATION OF MOBILITY AND COMMUNICATION UNITS SEE OVERALL PLANS
GENERAL NOTES
1. ALL DIMENSIONS NOTED AS "CLR." OR "MIN." ARE TO FINISHED SURFACE, TYP.
2. ALL CLOSETS TO HAVE WIRE SHELVING SYSTEM PER SPECIFICATIONS. AT ACCESSIBLE UNITS, TOP OF SHELVING AND/OR CLOTHING ROD TO BE 48" A.F.F.
3. ALL PARTITION TYPES P04A (GROUND FLOOR) OR P12A (LEVELS 2-5) U.O.N.
4. KITCHEN/BATHROOM CASEWORK ALONG PARTY WALLS TO HAVE SLOW CLOSING HINGES. RESILIENT MATERIAL SUCH AS FELT OR RUBBER TO BE PLACED AT CONTACT POINTS.
5. GYPSUM BOARD SHALL BE CONTINUOUS ABOVE ALL SOFFITS AND DROPPED CEILINGS TO MAINTAIN RATING OF FLOOR/CEILING ASSEMBLY WHERE REQ'D.
6. FINISHED CEILING TO BE UNDERSIDE OF RATED FLOOR-CEILING ASSEMBLY EXCEPT WHERE SOFFITS AND DROPPED CEILINGS OCCUR, AS INDICATED ON LEGEND. TYPICAL DROPPED CEILING TO BE 7'-9" A.F.F. U.O.N.
7. FOR LOCATION OF MOBILITY AND COMMUNICATION UNITS SEE OVERALL PLANS
CEILING LEGEND
GYP. WALL BOARD ON DROPPED CEILING
GYP. WALL BOARD ON STRUCTURE
RCP FIXTURE / DEVICE \SYMBOL LEGEND
CEILING FAN
FIRE SPRINKLER PENDANT
SMOKE DETECTOR LINEAR PENDANT
BUILDING ASSEMBLIES SCHEDULE NOTES
1. FIRE RATED ASSEMBLIES ARE BASED ON CBC, UL, OR US GYPSUM ASSOCIATION (GA) TEST DATA AND ARE TO BE CONSTRUCTED IN ACCORDANCE WITH THE REQUIREMENTS OF THE TESTING AGENCIES. REFER TO SPECIFIC TEST REPORTS INDICATED FOR REQUIRED COMPONENTS AND ASSEMBLY. CONTRACTOR SHALL PROVIDE (2) COPIES OF EACH REFERENCED MANUAL TO THE JOBSITE TO COORDINATE FIRE RESISTIVE ATTACHMENT WITH SHEAR CONNECTORS AND SOUND RATED ASSEMBLIES. GA 600 MANUAL IS ACCEPTED BY 2016 CBC TABLE 721.1(2) NOTE O FOR NON-PROPRIETARY ASSEMBLIES.
2. EXTENTS OF ASSEMBLIES ARE SHOWN ON THE PLANS AND SECTIONS. FIRE RATED WALL ASSEMBLIES FORM A SEPARATION THAT SHALL BE CONTINUOUS FROM FLOOR TO STRUCTURE ABOVE WITH NO BREAKS AT COLUMNS, WALL TRANSITIONS, OR OTHER OBSTRUCTIONS.
3. ALL PENETRATIONS IN FIRE RATED ASSEMBLIES REQUIRED TO HAVE PROTECTED OPENINGS SHALL BE FIRESTOPPED OR PROVIDED WITH APPROVED SMOKE AND/OR FIRE DAMPERS PER CODE REQUIREMENTS.
4. PROVIDE THRU-PENETRATION FIRESTOP SYSTEMS FOR RATED ROOFS, WALLS, AND FLOORS THAT ARE PRODUCED AND INSTALLED TO RESIST THE SPREAD OF FIRE ACCORDING TO REQUIREMENTS INDICATED, RESIST PASSAGE OF SMOKE AND OTHER GASES, AND MAINTAIN ORIGINAL FIRERESISTANCE RATING OF THE ASSEMBLY PENETRATED.
5. FIRE RATED WALLS MAY HAVE OPENINGS FOR STEEL ELECTRICAL BOXES NOT TO EXCEED 16 SQUARE INCHES PROVIDED THE AGGREGATE AREA OF ALL BOXES DOES NOT EXCEED 100 SQUARE INCHES FOR ANY 100 SQUARE FEET OF PARTITION
P07
6. ALL GYPSUM BOARD SHALL BE TYPE "X" UNLESS NOTED OTHERWISE.
7. SUBSTITUTE TYPE "X" MOLD AND WATER RESISTANT GYPSUM BOARD AT TOILET, SHOWER, JANITOR, AND KITCHEN ROOMS, KITCHENETTE, AND SIMILAR "WET" USES.
8. PROVIDE TILE BACKER BOARD AT TILE FINISHES. DO NOT REDUCE REQUIRED FIRERESISTANCE RATING OF WALL ASSEMBLY.
9. PROVIDE BLOCKING AT THE FOLLOWING LOCATIONS: CASEWORK, SHELVING, AND PANELING; ACCESSORIES AND EQUIPMENT; DOOR HARDWARE; TOILET PARTITIONS AND ACCESSORIES; ACOUSTICAL PANELS; AND OTHER LOCATIONS WHERE REQUIRED PER MANUFACTURER'S RECOMMENDATIONS OR INDUSTRY STANDARDS.
10. FIREBLOCK IN ACCORDANCE WITH 2016 CBC SECTION 717 AT THE FOLLOWING CONCEALED DRAFT LOCATIONS:
• IN CONCEALED WALL SPACES AT 10' O.C. EACH WAY AND AT CEILING / FLOOR LEVELS.
• AT INTERCONNECTIONS OF CONCEALED SOFFITS, DROPPED CEILINGS AND COVES
• IN OPENINGS AROUND VENTS, PIPES, DUCTS AT CEILING / FLOOR LEVELS.
BUILDING ASSEMBLIES SCHEDULE NOTES
1. THE BLDG ASSEMBLY SYMBOL CONSISTS OF 2 ELEMENTS: THE TOP ALPHA CHARACTER INDICATES THE TYPE OF ASSEMBLY SYSTEM; THE LOWER NUMBER INDICATES THE ASSEMBLY NUMBER KEYED TO THE ADJACENT SCHEDULE. W21A ASSEMBLY TYPE (WITH ALPHA MODIFIER IF INDICATED) ASSEMBLY SYSTEM (R = ROOF, W = EXT. WALL, P = PARTITION, F = FLOOR
12. FOR PROPERTIES OF COOLER OR WALLBOARD NAILS, SEE ASTM C 514, ASTM C 547 OR ASTM F 1667.
13. THESE DETAILS REPRESENT MINIMUM ARCHITECTURAL REQUIREMENTS. SEE STRUCTURAL DRAWINGS FOR REQUIREMENTS AND DIMENSIONS THAT MAY EXCEED THOSE SHOWN HERE.
14. DRAFTSTOPPING IS NOT REQUIRED IN FLOOR/CEILING SPACES PER CBC SECTION 717.3.2, EXCEPTION 1. THE BUILDING WILL BE EQUIPPED THROUGHOUT WITH AN AUTOMATIC SPRINKLER SYSTEM IN ACCORDANCE WITH SECTION 903.3.1.1 (NFPA 13).
15. ADDITIONAL LAYER(S) OF GYP. BD. WILL BE REQUIRED AT ADJACENT, DIFFERING WALL TYPES TO ALIGN FINISHES. SURFACES TO BE FLUSH & CONTINUE UNBROKEN IN ROOMS, U.O.N.
1. ACOUSTIC NOTES:
A. PROVIDE ACOUSTIC SEALANT AT TOP AND BOTTOM OF ALL WALLS WITH ACOUSTIC INSULATION. SEE DETAILS FOR MORE INFORMATION.
B. GYP BD. JOINTS ON OPPOSITE SIDES OF STUDS SHALL BE STAGGERED TO AVOID SOUND LEAK.
C. WHERE DOUBLE LAYERS OF GYP. BD. OCCUR, JOINTS SHALL BE STAGGERED TO AVOID SOUND LEAK.
SHEAR PLY, WHERE EXISTS SSD WOOD STUDS.SEE LETTER SUFFIX FOR FRAMING BATT INSULATION AT BEDROOMS & ALL PLUMBING WALLS (NOISE SENSITIVE AREAS
BOARD
58GA-NGC-305660
1. FIRE RATED ASSEMBLIES ARE BASED ON CBC, UL, OR US GYPSUM ASSOCIATION (GA) TEST DATA AND ARE TO BE CONSTRUCTED IN ACCORDANCE WITH THE REQUIREMENTS OF THE TESTING AGENCIES. REFER TO SPECIFIC TEST REPORTS INDICATED FOR REQUIRED COMPONENTS AND ASSEMBLY. CONTRACTOR SHALL PROVIDE (2) COPIES OF EACH REFERENCED MANUAL TO THE JOBSITE TO COORDINATE FIRE RESISTIVE ATTACHMENT WITH SHEAR CONNECTORS AND SOUND RATED ASSEMBLIES. GA 600 MANUAL IS ACCEPTED BY 2016 CBC TABLE 721.1(2) NOTE O FOR NON-PROPRIETARY ASSEMBLIES.
2. EXTENTS OF ASSEMBLIES ARE SHOWN ON THE PLANS AND SECTIONS. FIRE RATED WALL ASSEMBLIES FORM A SEPARATION THAT SHALL BE CONTINUOUS FROM FLOOR TO STRUCTURE ABOVE WITH NO BREAKS AT COLUMNS, WALL TRANSITIONS, OR OTHER OBSTRUCTIONS.
3. ALL PENETRATIONS IN FIRE RATED ASSEMBLIES REQUIRED TO HAVE PROTECTED OPENINGS SHALL BE FIRESTOPPED OR PROVIDED WITH APPROVED SMOKE AND/OR FIRE DAMPERS PER CODE REQUIREMENTS.
4. PROVIDE THRU-PENETRATION FIRESTOP SYSTEMS FOR RATED ROOFS, WALLS, AND FLOORS THAT ARE PRODUCED AND INSTALLED TO RESIST THE SPREAD OF FIRE ACCORDING TO REQUIREMENTS INDICATED, RESIST PASSAGE OF SMOKE AND OTHER GASES, AND MAINTAIN ORIGINAL FIRERESISTANCE RATING OF THE ASSEMBLY PENETRATED.
5. FIRE RATED WALLS MAY HAVE OPENINGS FOR STEEL ELECTRICAL BOXES NOT TO EXCEED 16 SQUARE INCHES PROVIDED THE AGGREGATE AREA OF ALL BOXES DOES NOT EXCEED 100 SQUARE INCHES FOR ANY 100 SQUARE FEET OF PARTITION
6. ALL GYPSUM BOARD SHALL BE TYPE "X" UNLESS NOTED OTHERWISE.
7. SUBSTITUTE TYPE "X" MOLD AND WATER RESISTANT GYPSUM BOARD AT TOILET, SHOWER, JANITOR, AND KITCHEN ROOMS, KITCHENETTE, AND SIMILAR "WET" USES.
8. PROVIDE TILE BACKER BOARD AT TILE FINISHES. DO NOT REDUCE REQUIRED FIRERESISTANCE RATING OF WALL ASSEMBLY.
9. PROVIDE BLOCKING AT THE FOLLOWING LOCATIONS: CASEWORK, SHELVING, AND PANELING; ACCESSORIES AND EQUIPMENT; DOOR HARDWARE; TOILET PARTITIONS AND ACCESSORIES; ACOUSTICAL PANELS; AND OTHER LOCATIONS WHERE REQUIRED PER MANUFACTURER'S RECOMMENDATIONS OR INDUSTRY STANDARDS.
10. FIREBLOCK IN ACCORDANCE WITH 2016 CBC SECTION 717 AT THE FOLLOWING CONCEALED DRAFT LOCATIONS:
• IN CONCEALED WALL SPACES AT 10' O.C. EACH WAY AND AT CEILING / FLOOR LEVELS.
• AT INTERCONNECTIONS OF CONCEALED SOFFITS, DROPPED CEILINGS AND COVES
• IN OPENINGS AROUND VENTS, PIPES, DUCTS AT CEILING / FLOOR LEVELS.
BUILDING ASSEMBLIES SCHEDULE NOTES
1. THE BLDG ASSEMBLY SYMBOL CONSISTS OF 2 ELEMENTS: THE TOP ALPHA CHARACTER INDICATES THE TYPE OF ASSEMBLY SYSTEM; THE LOWER NUMBER INDICATES THE ASSEMBLY NUMBER KEYED TO THE ADJACENT SCHEDULE.
W21A ASSEMBLY TYPE (WITH ALPHA MODIFIER IF INDICATED) ASSEMBLY SYSTEM (R = ROOF, W = EXT. WALL, P = PARTITION, F = FLOOR
12. FOR PROPERTIES OF COOLER OR WALLBOARD NAILS, SEE ASTM C 514, ASTM C 547 OR ASTM F 1667.
13. THESE DETAILS REPRESENT MINIMUM ARCHITECTURAL REQUIREMENTS. SEE STRUCTURAL DRAWINGS FOR REQUIREMENTS AND DIMENSIONS THAT MAY EXCEED THOSE SHOWN HERE.
14. DRAFTSTOPPING IS NOT REQUIRED IN FLOOR/CEILING SPACES PER CBC SECTION 717.3.2, EXCEPTION 1. THE BUILDING WILL BE EQUIPPED THROUGHOUT WITH AN AUTOMATIC SPRINKLER SYSTEM IN ACCORDANCE WITH SECTION 903.3.1.1 (NFPA 13).
/IIC RATINGTESTRATINGTEST
15. ADDITIONAL LAYER(S) OF GYP. BD. WILL BE REQUIRED AT ADJACENT, DIFFERING WALL TYPES TO ALIGN FINISHES. SURFACES TO BE FLUSH & CONTINUE UNBROKEN IN ROOMS, U.O.N.
1. ACOUSTIC NOTES:
A. PROVIDE ACOUSTIC SEALANT AT TOP AND BOTTOM OF ALL WALLS WITH ACOUSTIC INSULATION. SEE DETAILS FOR MORE INFORMATION.
B. GYP BD. JOINTS ON OPPOSITE SIDES OF STUDS SHALL BE STAGGERED TO AVOID SOUND LEAK.
C. WHERE DOUBLE LAYERS OF GYP. BD. OCCUR, JOINTS SHALL BE STAGGERED TO AVOID SOUND LEAK.
DOOR
101BAW.CNR3' - 0"8' - 0"52
102BAG1STOREFRONT DOORNR3' - 0"9' - 0"1
105.2AG1STOREFRONT DOORNR3' - 0"8' - 0"1
105.3AOFFICE STORAGENR3' - 0"8' - 0"1
105.4AOFFICE STORAGENR3' - 0"8' - 0"1
105.5AG1STOREFRONT DOORNR3' - 0"8' - 0"1
105.7AW.CNR3' - 0"8' - 0"1
105.9AOFFICE STORAGENR3' - 0"8' - 0"1
106.1AG1STOREFRONT DOORNR3' - 0"8' - 0"1
106.1CACOMMON USENR3' - 0"8' - 0"1
106.2AG1STOREFRONT DOORNR3' - 0"8' - 0"1
106.3BAG1STOREFRONT DOORNR3' - 0"8' - 0"1
106.4ALW.CNR3' - 0"8' - 0"1
106.5AG1STOREFRONT DOORNR3' - 0"8' - 0"1
106.6AG1STOREFRONT DOORNR3' - 0"8' - 0"2
106.7AG1STOREFRONT DOORNR3' - 0"8' - 0"1
106.8AG1STOREFRONT DOORNR3' - 0"8' - 0"1
106.9SCOMMON USENR6' - 0"8' - 0"1
108AAACOMMON USENR6' - 0"7' - 0"1
108BM_Door-Overhead-RollingGARAGE DOORNR12' - 0"10' - 0"2
110AACOMMON USENR3' - 0"7' - 0"1
111AACOMMON USENR6' - 0"7' - 0"1
112AELEVATOR CONTROL ROOM45 MIN3' - 0"7' - 0"1
115AACOMMON USE90 MIN3' - 0"7' - 0"2
116AA2PUMP ROOMNR5' - 0"7' - 0"1
118ACOMMON USENR3' - 0"7' - 0"1
119ARVOverhead DoorNR11' - 0"11' - 0"1
219AIDFNR3' - 0"7' - 0"1
ST1.1AASTAIR DOOR90 MIN3' - 0"8' - 0"6
ST1.1BASTAIR DOORNR3' - 0"7' - 0"1
ST1.1CAG1STAIR DOORNR3' - 0"7' - 6"1
ST2.1AASTAIR DOORNR3' - 0"7' - 0"2
UO1AUO1AUNIT ENTRY3' - 0"7' - 0"1
UO1AAUNIT ENTRY20 MINS3' - 0"7' - 0"16
UO7AUNIT CLOSETNR3' - 0"6' - 8"23
UO9M_Door-Double-SlidingUNIT CLOSETNR4' - 0"6' - 8"16
UO9 AM_Door-Double-SlidingUNIT CLOSETNR4' - 0"6' - 8"8
GENERAL DOOR NOTES
1. SEE SPECIFICATION FOR HARDWARE GROUPS AND GLASS TYPE OF DOORS & WINDOWS.
2. PAINTED DOORS & FRAMES TO MATCH ADJACENT WALL COLOR, U.O.N.
3. SEE PARTITION SCHEDULE AND DOOR DETAILS FOR DEPTH OF ALL DOOR FRAMES IN GYP. BOARD WALLS.
4. ALL DOORS ARE TO BE UNDERCUT PER FLOOR FINISHES & SPECIFICATIONS.
5. WIDTH & HEIGHT DIMENSIONS ARE DOOR LEAF OPENING SIZE, TYP U.O.N.
6. SEE DOOR DETAILS FOR FLOOR TRANSITION DETAILS.
7. ALL RATED DOORS INSTALLED ON THIS PROJECT SHALL COMPLY WITH 2016 CBC SECTION 716. "LABEL" SHALL MEAN "FIRE ASSEMBLY" AS DEFINED IN THE 2016 INCLUDING SECTIONS CBC SECTION 716.5 AND 716.5.7. ALL 20 MINUTE RATED ASSEMBLIES SHALL BE PROVIDED AND INSTALLED WITH APPROVED GASKETING MATERIAL TO PROVIDE A SEAL WHERE THE DOOR MEETS THE STOP ON BOTH SIDES AND ACROSS THE TOP. THE DOOR AND FRAME SHALL BEAR AN APPROVED LABEL OR OTHER IDENTIFICATION SHOWING THE RATING THEREOF, FOLLOWED BY THE LETTER "S". FIRE RATED DOOR FRAMES SHALL BE INSTALLED STRICTLY PER MANUFACTURER’S PRINTED INSTRUCTIONS. MANUFACTURER'S PRINTED INSTRUCTIONS SHALL BE MADE AVAILABLE TO THE INSPECTING AUTHORITIES.
8. PREPARE DOORS AND FRAMES FOR SPECIFIED SECURITY DOOR HARDWARE AS NOTED.
9. ANY FIRE-RATED OR SOUND-RATED DOORS TO BE FULLY GASKETED WITH DOOR BOTTOM. GASKETING TO BE MECHANICALLY FASTENED TYPE.
10. ALL INTERIOR DOORS WITH WOOD FRAMES TO HAVE 3/4" x 2-1/4" DOOR CASINGS AT JAMBS AND HEAD.
11. FIRE-RATED DOORS AND FRAMES TO HAVE A MAXIMUM TRANSMITTED TEMPERATURE RISE OF NOT MORE THAN 450 DEG. F ABOVE AMBIENT AT THE END OF 30 MINUTES OF STANDARD FIRE TEST EXPOSURE.
12. DOOR OPENING FORCE: THE FORCE FOR PUSHING OR PULLING OPEN INTERIOR AND EXTERIOR SWINGING EGRESS DOORS, OTHER THAN FIRE DOORS, SHALL NOT EXCEED 5 POUNDS (22 N). FOR OTHER SWINGING DOORS, AS WELL AS SLIDING AND FOLDING DOORS, THE DOOR LATCH SHALL RELEASE WHEN SUBJECTED TO A 15-POUND (67 N) FORCE. THE DOOR SHALL BE SET IN MOTION WHEN SUBJECTED TO A 30-POUND (133 N) FORCE. THE DOOR SHALL SWING TO A FULLOPEN POSITION WHEN SUBJECTED TO A 15-POUND (67 N) FORCE. FORCES SHALL BE APPLIED TO THE LATCH SIDE OF THE DOOR.
13. WHERE DOOR THRESHOLD DETAILS ARE CALLED OUT AS "N/A" NO THRESHOLD PRODUCT IS TO BE INSTALLED.
14. DOORS WITH POWER DOOR OPERATORS SHALL BE CONTROLLED ON INTERIOR & EXTERIOR SIDES OF THE DOOR WITH WIRED OR WIRELESS 4"X4" PUSH PLATES. THE CENTERLINE OF ONE ONE PUSH PLATE SHALL BE MOUNTED BETWEEN 7" MINIMUM & 8" MAXIMUM A.F.F. AND THE CENTERLINE OF THE 2ND PUSH PLATE SHALL BE 30" MINIMUM & 44" MAXIMUM A.F.F. (4 PUSH PLATES PER DOOR). EACH PUSH PLATE SHALL BE A MINIMUM OF 4" DIAMETER OR A MINIMUM OF 4" BY 4" & SHALL DISPLAY THE INTERNATIONAL SYMBOL OF ACCESSIBILITY COMPLYING WITH 2016 CBC SECTION 11B-703.7.
15. DOOR CLOSERS AND GATE CLOSERS SHALL BE ADJUSTED SO THAT FROM AN OPEN POSITION OF 90 DEGREES, THE TIME REQUIRED TO MOVE THE DOOR TO A POSITION OF 12 DEGREES FROM THE LATCH IS 5 SECONDS MINIMUM.
DOOR TYPE LEGEND
GENERAL NOTES
1. ELEVATIONS PROVIDED ON EDGE OF DECK AND EDGE OF SLAB PLAN INDICATE RELATIVE ELEVATION .
2. T.O.F= TOP OF FOOTING
3. DEPTH OF THICKENED GRADE BEAM IS 1'-0" UNO
4. GB# DENOTES GRADE BEAM NUMBER.
5. F# DENOTES FOOTING NUMBER.
GENERAL NOTES
2. T.O.F= TOP OF FOOTING
1. ELEVATIONS PROVIDED ON EDGE OF DECK AND EDGE OF SLAB PLAN INDICATE RELATIVE ELEVATION .
3. DEPTH OF THICKENED GRADE BEAM IS 1'-0" UNO
4. GB# DENOTES GRADE BEAM NUMBER.
5. F# DENOTES FOOTING NUMBER.
GENERAL NOTES
1. ELEVATIONS PROVIDED ON EDGE OF DECK AND EDGE OF SLAB PLAN INDICATE RELATIVE ELEVATION
2. T.O.F= TOP OF FOOTING
3. DEPTH OF THICKENED GRADE BEAM IS 1'-0" UNO
4. GB# DENOTES GRADE BEAM NUMBER.
5. F# DENOTES FOOTING NUMBER.
1. ELEVATIONS PROVIDED ON EDGE OF DECK AND EDGE OF SLAB PLAN INDICATE RELATIVE ELEVATION
2. T.O.F= TOP OF FOOTING
3. DEPTH OF THICKENED GRADE BEAM IS 1'-0" UNO
4. GB# DENOTES GRADE BEAM NUMBER.
5. F# DENOTES FOOTING NUMBER.
MarkDescriptionCount
C44DF#1 4X442
C46DF#1 4X634
C66DF#1 6X623
C68DF#1 6X83
C410DF#1 4X106
C412DF#1 4X128
C610DF#1 6X101
HSS33HSS3 X 3X3X5/164
HSS35HSS3 X 3X5X1/44
