Service Cards (Mode 07 & 08

Service Cards | Freelocker R/W with Master Cards and Emergency opening Cards

Freelocker R/W principle (free choice of cabinet - read/write): The transponder/card that locks must unlock the lock again. Otherwise the lock remains blocked for other transponders. The master cards serve as programming cards should the current Mode of the lock be changed. An emergency opening card is used to open a locker should a transponder be forgotten or lost. The emergency cards have the ability to unlock the lock and lock it again, if desired. The forgotten or lost transponder would then still be working. The transponder can be deleted by unlocking the locker, using a XLOCK segment cleaner or the smartphone APP. An info terminal can be installed in order for the users to find the right locker again. The locker number is written on the transponder on Sector 10 when locking.

07

With a master card and the service card 07 the Freelocker Mode 07 R/W - Sector 10 (free locker selection) can be activated. In addition, "Cabinet occupied" is written to the transponder. The lock will not unlock automatically. The lock will stay locked.

! Only works with Mifare 4 Byte Type Classic 1K / Mifare and Classic 4 K transponders !

08

With a master card and the service card 08 the Freelocker mode 08 R/W - Sector 10 (free locker selection) can be activated. In addition, "Cabinet occupied" is written to the transponder. The lock will unlock automatically XX hours after the last booking.

! Only works with Mifare 4 Byte Type Classic 1K / Mifare and Classic 4 K transponders !
