General catalogue 2016

Antology: Not-invasive medicine “From the skin to the musculoskeletal system�

Multimedia Antology Scan QR codes with your smartphone or tablet: Training, videos with protocols and more online material

YouTube Channel

www.winformweb.it

Energy applied to registered therapeutic processes In order to produce a therapeutic process using energy, it is necessary to respect the optimal dose indipendently of the mode.

Biostimulation does not occur due to a technical process (continuous, pulsed, Duty Cycle), but due to a quantity of optimal energy able to modify the treated tissues.

The freqeuncy interaction is a fundamental factor to have optimal therapeutic responses.

It is necessary to choose the frequencies and, thus, the suitable medical device according to the pathology and the result the operator wants to achieve.

In order to register the therapeutic effect, is important to quantify the energy absorbed by the organism.

Imagine the human body as a water container and the energy system - the chosen medical device -, as the sink that regulates the energy supplied.

The energy absorbed by the organism produces: •

chemical enzyme action;

•

a mechanical action induced by the increase of temperature;

•

a specific mechanical action.

These actions are quantified in Joule.

4

Frequency interaction with the tissue From 10 Hz to 1000 Hz Electrostimulation Transdermal Delivery

From 16 Hz to 20 MHz Shock Wave

0,5 MHz Diathermy

1 - 3 MHz Ultrasound

454 MHz Hyperaemia

THz Lasertherapy

5

What is Tecarforesi Transdermal Delivery mode Tecarforesi is transdermal delivery associated with Tecar (Capacitive and Resistive Energy Transfer). A painless method without side effects. This method allows to transdermal deliver active ingredients with high molecular weight in the cellular intestitial spaces without intermediation of blood circulation in the first phase (i.e. drugs, homeopatic products, phytocompounds).

The device uses, as carrier, low frequency electrical pulses (electroporation). The stimulation electric wave is produced by a generator of constant current able to evaluate the variations of skin resistance with stable and reproducible conditions.

With an appropriate variation of electric parameters, this method makes possible the vehiculation of substance through the skin whitout altering the tissues and reaching optimal depths.

Transdermal Delivery mode changes radically and effectively the way to administer active ingredients both with low and high molecular weight, such as hyaluronic acid or fibrinolytics.

Penetration The main function of the skin is to be a “barrier“ of the body and this feature is almost enterely represented by the stratum corneum. The low permeability of this layer is linked with the lipid extracellular matrix constituted by ceramides, cholesterol, long chain of fatty acids in defined molar, critical and functional relationship with the integrity of the barrier.

The penetration of a substance applied on the skin may occur:

Through glands appendages (i.e. pilosebaceous apparatus and eccrine glands)

By transcutaneous way (i.e. intercellular or extracellular path)

6

Transdermal delivery of gel active principles and H20 Transdermal delivery is a not-invasive method to administer drugs or medicinal substances by transdermal pathways directly into the site of interest without using the needle. Transdermal delivery uses current micro-pulses to accelerate the absorption, which occurs in a few minutes. The beneficial effect will be quick and will not cause any problem to the skin texture, as happens instead with other methods, such as the laser, that damages the skin to renew it (the patient cannot immediately return to his social activity). Transdermal delivery, built on adequate energy parameters, has the ability to deliver, at first, active ingredients through extracellular pathway and then the active ingredients with lower molecular weight can penetrate into the cells stimulated by the energy charge, obtaining greater performance on the tissue to be treated.

Processes that cause blemishes, occur both inside and outside the cells and this mehod allows to act at 360° without renouncing the total comfort for the patient.

P.R.P. Plasma Rich of Platelets The new frontier of the transdermal delivery Scientific studies are currently underway for the delivery of P.R.P (plasma rich of platelets). P.R.P is a biorevitalization in which are used patient’s substances (autologus) suitably treated and reinserted in the areas to be renjuvanated: face, neck, décolleté, back of hands and scalp (in cases of androgenetic alopecia) with very important results.

The usual technique to infiltrate P.R.P is based on small injections made nearby each other (about 1 cm).

With transdermal delivery, is avoided the use of the needle and is reached the epidermis basal layer, in particular the stem cells stimulated by P.R.P in order to spontaneously renew the skin tissues.

7

What is the Pressure Shock Wave method Shock waves are acoustic waves (sound pulses) that carry high energy characterized by a particular wave shape (rapid peak of positive pressure followed by a rapid phase of negative pressure), able to produce a direct mechanical stimulation. They are generated in a watery means and then are carried to a defined spot, said “focus” (or target); they transmit a measurable quantity of energy able to produce therapeutic effects.

How Shock Waves act

When living tissues are crossed by a shock wave (through energy levels suitable for the pathology and for desired therapeutic effect), they are subjected to a sort of beneficial “micro hydro-massage“ able to promote a series of biochemical and cellular reactions responsible of the therapeutic effect.

Calcifications, which often occur when tendons and ligaments are inflamed, disappear after a treatment with shock waves that does not “break“ them but it melts them due to local biochemical processes.

8

SIN Shock Wave The handpiece is composed of piezoelectric crystals, which show sudden contraction and expansion of thei volume causing tiny pressure waves that are added and carried into the focus F when a strong difference of high voltage is applied.

Piezoceramic crystals are crossed by a high voltage electric pulse and expand their own volume along their longitudinal axis. Thanks to this feature, they are able to generate a shock wave (focused) in a wellprecise spot without the aid of reflectors or focal lens.

Hence, the piezoelectric shock wave generates a “Direct Focusing“. Therefore, it is achieved a flat surface from the therapeutic head (source-patient match) with a well-defined focal area.

Main conditions of application The shock wave therapy is used for inflammatory and degenerative affections of tendons at different levels; in particular:: •

Shoulder rotator cuff (with of without calcifications);

•

Knee patellar tendon;

•

Achilles tendon and inflammation in the insertion of the plantar fascia (the so-called “painful calcaneal spine”);

•

At the elbow: epicondylitis and apitrochleitis (“Tennis elbow” or “Golfer’s elbow”);

•

Pseudarthrosis / no fractures stabilization;

•

Stress fractures;

•

Myositis ossificans;

•

Heterotopic calcifications;

•

Early-stage of osteonecrosis;

•

Early-stage of ostechondritis dissecans after skeletal maturation;

•

Bone dystophy with sympathetic reflexes.

9

What is Tecar method It is the application of an energetic transmission system in radiofrequency, applied to the human body as a curative method, which controls and quantifies the quality and quantity of energy accumulated by the body.

Therefore, Tecar is a medical device that uses the energy applied to therapeutic registered processes.

Premise: in order to obtain these conditions with a phisical principle of endogenous radiofreqeuncy, the human body has the role of main actor, so that the principle is suitable in real-time and meets the clinical and biological processes of the organism.

How Tecar works It is a generator that uses the physical principle of the condenser at high frequency, by creating an electromagnetic field between active and negative electrodes involving the human body in a hyperactivity of movement through the shifting of electrolytic charges within the body. All these elements operate when the circuits are closed, creating an electric differential that generates energy and creates a movement of charges equal to the number of pulses emitted by the generator.

The electrical differential is measured as a voltage generator. The human body is an armor of second type and has the function of conductor with resistances that can be superficial and deep.

It explains why are affected all those tissues that are interposed between the active and the counter electrode, forcing us to consider not only the skin impedance, but the impedances that are formed inside the body in the different tissues crossed by the energy. Therefore, the unit of measurement cannot be only the voltage, but necessarily the electrical conduction with all parameters of resistance, both superficial and deep.

10

If the physical principle (the generator) is finally able to control the voltage, the current and the resistance, we are able to control the thermal effect, that does not carry out a healing action, but if the operator loses the control, it may be a contraindication.

This will finally determine the possibility to quantify the energy absorbed in Joule per cm2, so that the operator is able to quantify the suitable energetic dosage to apply to the treatment required with the typical selectivity of the emission frequency, allowing to register the therapy no more subjectively but objectively.

This allows three fundamental factors: •

More effectiveness, given by the optimal energy dose;

•

Less contraindications and result certainty, eliminating the energetic overdosage;

•

This technology creates an epochal change by fixing different parameters on the use and application of radiofrequency physical principles applied to the body for therapeutic process.

11

What is SIN method SIN is a harmonic resonance system that develops a synchronous action of more freqeuncies on the cell. The freqeuncies of emission obtain a stimulation of intercellular and extracellular processes, causing an increasing of blood flow in the microcirculation, due to the arteriolar wall dilatation, a relaxation of venules and yielding of precapillary sphincters increasing the blood flow on capillaries physiologically closed.

The tipology and quantity of energy supplied are such that it can be absorbed and used by the body in order to achieve high performance on soft, fibrotic and calcified tissues.

How SIN works SIN method generates an electromagnetic field with different frequencies: 10 Hz - this frequency stimulates the action potential of the neuro-motor nerves; 450.000 Hz - this frequency increases the movement of electrolyte charges; 3.000.000 Hz - this frequency generates pressure to produce micro implosions of liquids.

The selective performance of each emitted frequency ensures, thus, the synergy of 3 actions.

Chemical Action: produced by the increase of blood flow through the most electric conductivity induced by tissues rich in ions, with a transcutaneous contribution of liquids through a water-soluble gel.

Mechanical Action: phenomenon induced by the rhythmic succession of complession waves and expansion of acoustic waves that generate vacuum micro-bubbles. These, imploding under the load of the external pressure, determine a shock wave responsible of adipocytes mobilization and soft fibrotic tissues. Thus, it promotes the disposal of excess fat without being invasive.

Energetic Action: the movement of electrolyte charges, which occurs in synergy with the actions described above, allows the tissues to be biostimu12

SIN is an innovative and certified method that applies a synergic and simulatneous action allowing to attack effectively PEFS and localized adiposity. SIN method stimulates energetically the connective tissues involving the cells responsible of the pathology, such as adipocytes, fibroblasts, myofibroblasts, mast cells, macrophages and extracellular matrix.

Through the action of the cell membrane, it carries out a primary action in the interaction between extracellular space and cytoplasm, and between lipid “tails” and phosphate “heads“.

The vibrations emitted by the device have a positive effect on the cell: such synergic vibrations, meeting each other, amplify the result performing a multiple and complete interaction.

The operator may verify the effectiveness of this method through different diagnosis devices, while the patient will personally check the change of adipose and skin tissue thanks to a progressive and painless action.

The harmonic resonance produced with SIN, is a simple concept: it is like dropping two stones of the same dimensions at the same time in a pond. The coordinated action of the two waves will be added to form a wave of double width.

The synergic and energetic hyperactivity emitted by SIN, allow to obtain effective results in a physiological and painless way.

13

It is the first device in the world able to control, manage and quantify the radiofrequency, transdermal delivery and shock wave, by applying their synergic action to the body healing process.

TECAR SIN combines more devices in a single one by giving the operator the possibility to optimize the energetic, nutritional and mechanical effects.

TECAR SIN is the technology able to obtain the best performance with the lower cost. TECAR SIN is a diagnostic and therapeutic device, able to effective counteract the macromolecules degradation by optimizing anabolic and catabolic cell metabolism.

TECAR SIN allows the operator to distinguish or associate endogenous radiofreqeuncy, transdermal delivery and harmonic electromagnetic resonance.

SIN ergonomic handpiece

Tecar

Transdermal Delivery

Shock Wave 14

15

The first medical device, result of scientific research, able to unify a cellular stimulation synergy and to modify and optimize the tissues involved in a not-invasive and painless way.

The combined action of electrolytic movement and shock wave, allows a more physiologic and painless stimulation. Even combining the deliver of active ingredients, such as fibrolytic and anti-edemigenous, is achieved a better performance by accellerating the healing processes.

SIN Shock Wave allows to control the thermal effect and to quantify the energy absorbed.

The technical patents in use allow the operator to immediately work on the area to be treated, even with edema.

The therapy is more performing if it is controlled by an ultrasound scanning.

SIN Shock Wave uses piezoelectric matrix to generate suitable pressure to the synergy with diathermy.

Available with two handpieces: one for big surfaces with planar shock wave and one for small areas with focused mode.

The operator may evaluate and set the absorbed and delivered energetic data both in Watt/cm2 and Joule/cm2, and both for SHOCKWAVE action and for TECAR diathermic action.

Ergonomic handpiece with double ultrasound transductor “High Power SIN“

Ergonomic handpiece with single ultrasound trasductor “High Power SIN“

Shock Wave Tecar Transdermal Delivery 16

Tecar

Transdermal Delivery Shoch Wave

17

TECAR CRV TECAR CRV is the first energetic device in the world able to control, manage and quantify the radiofrequency by applying it at the organism healing process.

It uses the condenser physical principle with voltage control and measurement, current and resistance, quantifying the energy absorbed by the tissue in Joule per cm2, allowing the operator to register the therapies.

The medical need to treat through a physical principle requires the quantification of the treatment, making it statistically reproducible in time.

The device displays and saves the data collected in order to put them in the medical chart.

The operator can choose the operating modes for superficial or deep tissues and to vehiculate active ingredients by intraand extracellular way.

The ergonomic handpieces use biocompatible and sterilizable AISI steel for the treatment in diameters of 30 and 60 nm as delivery surface, while the handpiece W200 allows the measurement of water quantity in the tissues, Celsius degrees and microscope from 1 to 400 magnifications.

18

19

Technology SIN and TECAR CRV are medical devices that use the physical principle of the condenser in endogenous radiofrequency with delivery modes for superficial/deep tissues, transdermal delivery and SIN method.

The devices range is composed of three devices able to combine the different delivery modes.

SIN and TECAR CRV are technologically advanced: they use a computerized logic to store and control data coming from control systems and energy supply, with microprocessor ARM 9, TFT 10.2� high definition display to set the parameters.

The high conduction occurs with USB and monopolar connections.

The ergonomic handpieces use biocompatible and sterilizable AISI steel for the treatment in diameters of 30 and 60 mm as delivery surface, while the evaluative handpiece W200 allows measurements of the amount of water in the tissues, Celsius degrees and microscope from 1 to 400 magnifications to display.

20

Delivery mode

Transdermal Delivery Mode Combined action of TECAR and Transdermal Delivery.

It allows the operator to use electroporation with high density of absorption, which is indispensable for pathologies both in acute and chronic phase.

It emits monopolar pulses at 480 KHz and 10 Hz, allowing the operator to choose the depth of the tissues to be crossed up to the desired spot. Specific hydrosoluble active ingredients are used.

Superficial Capacitive Reactance Mode It allows the energy to propagate in superficial tissues.

It is used on skin and muscle tissues to obtain oxygenation and lymphatic drainage.

Deep Resistive Reactance Mode It allows the energy to propagate in the deep or more resistant tissues. It obtains a stimulation of the skin, myofascial, muscle and osteoarticular tissues.

SIN Mode The synergy of 3 actions: chemical, energetic and mechanical.

The emission frequencies achieve a stimulation of the intercellular and extracellular processes producing an increase of blood flow in the microcirculation due to the dilation of arterioral wall, venules relaxation and yielding of precapillary sphincters, increasing the blood flow in capillaries physiologically closed.

21

Operative Mode

Control system SIN and TECAR CRV are the first devices able to quantify the energy absorbed in Joules per cm2 allowing the operator to evaluate the suitable energy dosage to be applied to the desired therapy.

This technology creates an epochal change establishing different parameters for the use and application of physical principles applied to the body for a therapeutic process.

SIN and TECAR CRV display all emission and response parameters monitoring actively and immediately the energetic propagation that crosses the body by correcting excessive thermal effects.

(SIVSEA patent).

22

SIN and TECAR CRV use SCE system that allows to display and parameterize the real and nominal energy of the body, necessary to establish the correct energy emission.

(SCE patent).

Diagnostic Mode

Data Detection The data detection system, through the evaluative handpiece W200, allows the operator to monitor the treatment by photographing the area to be treated before, during and after the treatment.

Furthermore, the evaluative handpiece allows to measure the amount of water in the tissues, Celsius grade and miscroscope from 1 to 400 magnifications .

SIN and TECAR CRV show on the display the amount of water present in the tissues.

SIN, and TECAR CRV show on the display the temperature of the treated tissue .

23

BIO Foresi BIOFORESI medical device is a transdermal delivery for hydrosoluble molecules.

BIOFORESI device is used to vehiculate OZONATED GEL, PRP, STEM CELLS and SYNTHETIC DRUGS (OF PLANT ORIGIN or HOMEOPATHIC), even with important molecular weights with intraand extracellular path.

BIOFERESI device uses two high frequency electrical pulses as carrier: 500.000 HZ and 10 HZ, both in polar mode.

The device is able to control the energy absorbed by different anatomical tissues and quantify it; it is an important means to register the application.

The parameters settable by the physician are:

24

•

Energy: Watt

•

Joule/cm²

•

Setting up of the parameter for energetic absorption

•

Effective and default time

•

Medical chart with USB support

•

Thermal and moisture skin detection with handpiece W200

•

Skin state detection with enlarger 200:1

•

Detection of electricity conduction (homeostasis)

•

Detection of electricity resistance

25

TECAR 905 TECAR 905 is a medical device that uses monopolar diathermic radiofrequency with real time emission control by using SCE and SIVSEA patents.

SIVSEA (Evaluation Stimulation System with Collection of Energy Data emitted and absorbed by the body) integrating and displaying the data with impedance, is combined with SCE device that controls and highlights the real energy absorbed by the body.

The operator can set both superficial capacitive and deep resistive mode with reactance control, independently from the electrode.

The device has a freqeuncy of 480 KHz and a power output of 80 Watt, both for capacitive and resistive.

Superficial capacitive mode: The signal is supplied with suitable interruptions in order to allow a charges reorganization and then a recall on the handpiece area. Thus, the conduction is less linear and more superficial.

Deep resistive mode: The therapeutic signal is supplied in unaltered way in order to obtain a continous recycling of the elctrolytic charges achieving a linear conduction.

26

27

3 Tecar BOX is the first medical device that uses non-ionizing radiation and micro-pulses to achieve a synergic effect on the cell, combining nutritional and energetic actions.

Tecar BOX is the high-frequency therapeutic method that accellerates the process of pharmacological absorption with high molecular weight, by transepidermal way with intercellular path.

This occurs by diffusion in the extracellular fluid with a homogeneous means from a chemical composition point of view. The intercellular path facilitates the penetration of the substance through the aid of an external action: the electrical pulse.

Tecar BOX performs simultaneously an energy activity both on superficial and deep cells achieving an endogenous biostimulation by activating the electrolyte charges of the body.

The intense movement of the charges occurs 480.000 times per second, generating a cell hyperactivity absorbing and dissipating energy to the surrounding tissues.

Tecar BOX emits monopolar pulses at 480 kHZ and 10Hz allowing the operator to choose the depth of the tissues to be crossed up to the required spot.

Tecar BOX reaches and maintains the maximum comfort for the patient thanks to an impedance system that controls, adapts and stabilizes the energy signal.

Tecar BOX is designed to adapt in real time the modifications of the crossed tissues.

28

29

Range of diathermy and multifunction devices

200 W

200 W

200 W

✔

✔

✔

✔

Manual

Manual

Manual

Manual

Transdermal Delivery Mode

✔

✔

✔

✔

Superficial Capacitive Mode

✔

✔

✔

Deep Resistive Mode

✔

✔

✔

SIN Mode

✔

SIVSEA patent

✔

✔

✔

✔

SCE patent

✔

✔

✔

✔

Data-detection handpiece

✔

✔

✔

✔

SIN bipolar handpiece diam. 70 mm

✔

Energy in Joule per cm2

*Compatible accessories

Delivery mode

* * * * * * * * 30

200 W

Power

*

✔

✔

TECAR bipolar handpiece High Power bipolar handpiece diam. 75 mm

✔

✔

✔

Ultrasoundtherapy handpiece 1 MHz SIN bipolar handpiece diam. 45 mm

✔

✔

✔

✔

TECAR Light bipolar handpiece diam. 70 mm High Power SIN bipolar handpiece O3 bipolar handpiece

✔

905

TECAR 905 200 W

3

LAB

80 W

80 W

30 W

30 W

Manual

Manual

Manual

Manual

✔

✔

✔

✔ Manual

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔

✔ ✔

✔

✔ 31

What is Laser High Dose method The range of High Dose Therapy Laser by Winform is among the most reliable in the world. Winform technology is characterized by high dose energy transfer in short times on wide surfaces of the human body.

Quality and Precision Winform range of products has been developed with a purpose: give the best every day. Quality and Precision are shown in every detail. The value of these products is to discover, day by day, how each wavelength is emitted to obtain the best satisfaction according to the best result.

Technology The lasers quality comes from the application of a concept: supply high doses of energy in short times monitoring very well the thermal effect according to the modifications of the tissues crossed.

Laser High Dose: the lasers energy, delivered by a single source, is directed to a liquid optic fiber; it ensures high brightness and light uniformity by giving the tissue an appropriate therapeutic peak. The energy supplied and delivered to the tissue per second differs according to the devices, covering surfaces from 8 mm to 40 mm of diameter with a zoom in order to maintain focus and brightness at every diameter.

32

Laser High Dose: the delivery modes are continuous, modulated or Duty Cycle (Ultra-Pulsed). The Duty Cycle is the delivery mode with the highest biostimulation effect on tissues, respecting them and controlling the thermal effects produced.

Laser High Dose: Winform lasers use energy with wavelengths within the therapeutic window, ranging from 810 to 1064 nm. The absorptions are determned by the wavelength that interacts in several ways with the chromophores present in the tissue (water, hemoglobin, melanin, proteins and nucleic acids).

Laser High Dose: the high transfer of energy in short times on wide body surfaces, increases considerably the therapeutic and biological effects to the tissue; it causes not only biochemical reactions on the cell membrane but also inside the mitochondria, inducing various effects such as dilation, increase of lymphatic drainage, metabolic stimulation, slight change of intra- and extracellular pH, anti-inflammatory, antiedema with increased absorption of interstitial fluids but also photomechanical effects of electrolyte charges mobilization inside the biological tissue.

The laser therapy is an effective treatment due to its ability to enhance the maintenance or reactivation of biological systems under suitable homeostasis conditions and for its ability to start or expand the body regeneration systems. Injuries or other chronic diseases may have a deleterious effect on cellular systems and, thus, may compromise the ability of cells to work normally or to repair the tissue if it has been damaged. When the cell membranes have been damaged, the laser therapy increases the movement of ions and other particles through the cell membrane. Hence, it has a positive effect on cell ability to keep or reactivate the correct operation, in order to maintain the cell enzyme systems and restore the proper balance of protein, carbohydrates or ions in order to allow the cell to work normally.

33

Laser biological effects

The laser radiaton, penetrating the tissues, causes biochemical reactions on the cell membrane and within the mitochondria inducing several effects including: •

Vasodilation, with a consequent increase of local heat, increase in cell metabolic demands, neuro-vegetative stimulation and modification of the intracapillary hydrostatic pressure;

•

increase of lymphatic drainage, increase of the effectiveness of the sodium/ potassium pump, ionic transmembrane stabilizations, more absorption of interstitial liquids; activation of microcirculation thanks to a more nutritional intake with rebalancing of the functional balance;

•

Metabolic stimulation, accelerates the process of transformation of ATP into ADP+P+E and of electrolytic exchange between intra- and extra-cellular environments, increasing the conentration of nucleic acids and amino acids;

•

Slight modification of intracellular and extracellular pH.

The pain management is obtained thanks to the analgesic action that is induced by the perception thresold of the algotrope nerve endings and the release of endorphins.

The anti-inflammatory, anti-edema, eutrophic and stimulating effect for the cellular tissue is given by the increase in blood flow due to capillary and arteriolar vasodilation.

The increased effect of interstitial fluids absorption, with consequent reduction of edema and activation of cell replacement, is due to the change of hydrostatic intracapillary pressure.

The therapeutic effect depends on the interaction of the laser light with the biological tissue concerned: each type of laser emits light at a specific wavelength that interacts in different ways with the chromophores present in the tissue.

Some chromophores are already present in the tissue (water, hemoglobin, melain, proteins, nucleic acids) whereas others may be injected, fixing themselves in the tissue to make it photosensitive.

34

The penetration of the laser light into the tissue depends on the emission wavelength and on optical features, concentration and depth of the chromophores.

Wavelength

Laser type

Proteins and Nucleis Acids

200/500 nm

Excimer

Melanins

400/600 nm

Argon

From 10.000 nm

CO2

From 600 to 1200 nm

I.R. - YAG - Diode

Water Therapeutic Window

From the treatment depth point of view, it is really interesting to focus on the last wavelength section, the so-called “Therapeutic Window“.

Here, the water is absorbed in a very high percentage and laser radiations penetrate the tissues without any interaction with specific chromophores.

Hence, it is deduced that the laser penetration level depends on the emission wavelength and laser power.

Depth and Absorption Each laser emits its own beam at a well defined wavelength and, obviously, each different type of laser has the ability to reach a certain depth in target tissues.

Laboratory experiments conducted in several Universities have shown an increase of oxygen absorption by cell cultures subjected to irradiation with laser energy of different wavelenths. In particular, the activation occurs in two areas of the “wavelength spectrum”: between 600 and 1200 nm”.

Absorption and Dispertion From “Physics“ point of view, the laser beam, passing through the biological structure, interacts with two mechanisms: absorption and dispertion.

In fact, the cell of living tissues is shown as a semitransparent system (a sort of glass bowl with a semi-opaque content) that holds a certain amount of energy leaving the excess, that hits partly for “reflection“ and partly for “crossing“ and transfer towards the underlying layers.

35

Penetration and Incidence

Although the impact of the laser beam with the skin is perpendicular (and the photons are parallel), as the tissue penetration gradually occurs (due to dispertion effect) the section of the irradiated tissue becomes conical and irregular because of the different density of the structures crossed.

Type of absorption: Lunghezza d’onda (nm) 200

300

400

500

600 700

900

1100

1400 10600

810 nm 32%

10%

65%

65%

78%

20%

+

5%

Epidermide

28%

Derma

810 nm: 65 + 21 = 86% of the energy stops on the surface -> PAIN (nociceptors on the surface)

8%

17%

21%

Sottocute Miofasciale

= 86% energia in superficie

Lunghezza d’onda (nm) 200

300

400

500

600 700

900

1100

1400 10600

975 nm 32%

10%

45%

65%

78%

20%

Epidermide

28%

+ 5% 21%

Derma

975 nm: 45 + 17 = 62% of the energy stops on the surface -> acts at melanin level

8%

17%

Sottocute Miofasciale

= 62% energia in superficie

Lunghezza d’onda (nm) 200

300

400

500

600 700

900

1100

1400 10600

1064 nm 32%

10%

65%

78%

20%

28%

65%

Epidermide

+ 5% 21%

17%

Derma

8%

Sottocute

= 55% energia in profondità

36

Miofasciale

1064 nm: 28 + 17 = 45% of the energy stops on the surface -> 55% reaches the depth CHRONIC PATHOLOGIES

These graphics allow to notice that the increase of the wavelength is not strictly linked with an increase in the level of absorption by the tissues. As can be seen, most of the absorbed energy stops in the first skin layer (epidermis and dermis). An extremely important factor is given by the chromophores, or particles that absorb light radiation and make the laser a device of high selectivity and precision for the pathology treatment.

For the same amount of energy delivered, the differences of application by virtue of the wavelength determine the inteaction of the chromophores. The 810 nm wavelength is mainly absorbed by the melanin instead of the 975 nm and 1064 nm that are mainly recognized by the hemoglobin. For the same amount of energy absorbed by tissues and depth, the wavelength inteaction will determine specific and different therapeutic responses.

The biostimulation

The biostimulation is an interaction that occurs at molecular level on cells tissues, changing and influencing the intercellular state and extracellular responses occurring during the inflammatory phases, in order to obtain the furthest expression of wounds healing physiological potential, all aimed for the morphofunctional restoring of an organ.

The term has been introduced in medicine with the discovery of laser properties in order to enhance the outcomes of diseases and healing. These lasers, in order to be distinguished from those with surgical skills (cutting or coagulation), are called “therapeutic lasers“. The term has never been introduced in dictionaries, but is more and mroe used in the current language.

The use of the term comes from the attention of medicine on a surgery biologically guided, where technologies and biomaterials are means to influence the physiological processes in order to obtain faster healing, stimulating tissues regenerative processes. For instance, in dental surgery is important to choose procedures that allow to contain the loss of tissue, especially bone, leading regenerative processes from a qualitative and quantitative point of view, to improve functionally and aesthetically the oral rehabilitations. The totality of these techniques can be defined as “biostimulation“.

37

The connective tissue This section has been introduced as the laser therapeutic action affects the connective tissue.

The laser beam stimulates the fundamental components of the extracellular matrix, such as glucosamine sulfate, chondroitin sulfate and polysaccharides with high moleculatr weight (glycosaminoglycans).

As regards the chondroitin sulfate, exprimental data demonstrate its chondroprotective activity (stimulation of proeoglycan synthesis, inhibition of collagenolytic activity, inhibition of IL-1 effects on the proteoglycans and collagen synthesis, reduction of chondrocyte apoptosis).

The stimulation of chondroitin sulfate makes possible to stop the progression of the structural damage.

Connective Tissue is a type of mesodermal origin tissue that provides structural and metabolic support to organs and other tissues within the organism.

Mature Connective Tissue is classified into: • Connective Tissue Proper; • Special Connective Tissue (Cartilage, Bone, Blood).

Function of Connective Tissues Structural and metabolic support for other tissues and organs in the body: • They carry the vessels and mediate the exchange of nutrients and meta-

bolites; • In the organs, they constitute the coating material; • They support skin and tendons; • They are the framework of the human body; • They function as fat reserve, immunological defense and tissues repair.

38

Composition of connective tissues

All connective tissues are composed of two main constituents: • Cells:

Fibroblasts, Myofibroblasts, Adipocytes, Mastocytes, Macrophages, White blood cells.

• Extra Cellular Matrix

It consists of Ground Substance in which various types of fibers and Structural Glycoproteins are dissolved.

The proportion of each component differs according to the type of connective tissue considered.

Connective Tissue cells The cells of the connective tissue can be divided into three types: • Cells responsible for the synthesis and maintenance of extracellular matrix; • Cells responsible for fat accumulation and metabolism; • Cells with defensive and immune functions.

Extra Cellular Matrix • Ground Substance:

Semi-fluid, amorphous and transparent gel composed of glycosaminoglycans (hyaluronic acid and proteoglycans); • Fibers:

Molecules that provide resistance to traction and elasticity: collagen, reticular fibers, elastin.

• Structural Glycoproteins:

Molecules composed of protein chains linked to branched polysaccharides; their role is not fully understood: fibrillin, fibronectin, laminin, entactin, tenascin.

Connective Tissue cells • Fibroblasts • Support cells • Macrophages • Plasma Cells • Adipocytes • Cartilage

39

Types of laser Solid-state Laser Solid-state lasers use a crystalline or glass rod, which is “doped“ with ions that provide the required energy states. For instance, the first working laser was a ruby laser, made from ruby (chromium-doped corundum). The population inversion is maintained by the dopant chromium or neodymium. In this case, “solid state“ refers to the crystal or glass that provides ions. Neodymium is the most common dopant among the various solid-state lasers, including yttrium orthovanadate (Nd:YV04), yttrium lithium fluoride (Nd:YLF) and yttrium aluminium garnet (Nd:YAG). All these lasers, may produce high powers in the infrared spectrum at 1064 nm. Solid-state lasers are “doped“ crystal rods with rare earth elements or transition elements, such as YAG (yttrium aluminium garnet) doped with neodynium, or sapphire (aluminium oxide) doped with chromium (ruby).

Gas Lasers The active material is at gaseous or vapour state, is made of neutral atoms, ions, molecules and other elements (in particular helium) to facilitate the electric discharge and enhance the energetic profit. Gas lasers are pumped with ultraviolet, electron beam, electric current or chemical reactions.

Among these lasers, there is a mixture of: • atomic gas lasers (He-Ne) • molecular lasers (CO2 vapori di H2O) • ion lases (Argon, Kripton, Xenon, vapori di metallo, Elio-Cadmio)

Laser Diode A laser diode is composed of doped semiconductor material that is placed on a very thin layer of the surface of a crystal rod. The crystal is doped to create a N type semiconductor region and another one of type P, one on top of each other, to achieve a P-N junction, which is a diode. As in other diode lasers, when the diode is directly polarized, the holes of the P region are pumped in the N one, where the electrons are the major carrier of charge. In a similar way, the electrons of N region are pumped in P one , where the holes are the major carriers.

When a hole and an electron are in the same region, they may combine through spontaneous emission, that means the electron may occupy the bandgap state again by emitting a photon with an energy equal to the difference of the electrons state and the hole one that are involved. Some important properties of laser diodes are determined by the geometry of the optical cavity.

The emission wavelength is a function of the energy gap between the semiconductor bandgaps and the ways of propagation of the optical cavity. In general, the maximum gain is achieved for the photons with an energy slightly higher than the gap one. Hence, the ways of propagation closest to the gain peak will predominantly emit.

If the diode is controlled with enough power, there will be a number of additional “side modes“.

The laser diodes work at a fixed wavelength.

Latest technological developments of the Diode In the last few years, the laser diode has had significant developments. The research for the application of these types of laser at industrial level, made possible the development of laser diode with powers higher than 3 KW. For the application of these devices in cutting metals and incise them, is very important, more than the power, the brilliance of the light beam and the perfect incision, because in these cases are necessary very tiny focal spots. These technological developments lead the laser diode to be at the same level of CO2 devices and fiber lasers, substituting them due to their smaller dimensions, lower costs management and more reliability. This technological development achieved with the research and applied in the industrial field, can now be transferred in medical field without dreading any comparison with the most classical laser systems not used yet.

40

Laser Beam emission mode Continuous, Pulsed and Duty Cycle A laser may be classified according to the operative mode, such as continuous or pulsed, depending on whether the output signal is continuous over time or if it is emitted as pulsed light.

Cw = continuous, CWF = pulsed, and pulsed in Duty Cycle

Continuous mode The laser beam is emitted continuously during the time up to the device is switched off.

This type of laser is defined as Continuous Wave (CW).

Pulsed mode The laser beam is emitted in pulsed mode (CWF - Continuous Wave Fluctuation). The Duty Cycle is part of the pulsed mode.

Duty Cycle The Duty Cycle is a form of energy emission, in particular, is an ultrapulsed mode. With the Duty Cycle is possible to provide high energy doses to the organism without overheating, and thus damaging, the tissues.

This is because the gap between one energy pulse and the other is such to allow the tissue to absorb the energy and dissipate the excess; the tissue is then more “ready“ to absorb the next energy pulse.

Consider a square wave. The Duty Cycle is the relationship that exists between the period in which there is the signal and the gap period.

It can be expressed with a percentage value or with a fractional value.

If the Duty Cycle is at 50% (or 1/2) means that the energy signal lasts as long as the gap period.

If the Duty Cycle is at 20% (20/100) means that the signal is at 20% whereas the gap period is equal to 80%.

41

3 CHRONIC Sport is a laser device that uses Ultra Pulse technology to manage the high energy doses absorbed by the crossed tissues.

The 3 emission wavelengths 810 nm, 975 nm and 1064 nm guarantee the best effect thanks to the interaction with more chromophores, such as water, hemoglobin, melanin and proteins.

3 CHRONIC Sport stimulates biochemical reactions on the cell membrane obtaining vasodilation, metabolic and neurovegetative stimualation, intercapillary hydrostatic pressure, lymphatic drainage, sodium/potassium pump stimulation, transmembrane ionic stabilization, microcirculation activation and functional recovery.

The main therapeutic effects induced by 3 CHRONIC Sport are anti-inflammatory, antalgic, anti-edema and biostimulation.

The high penetration depth and the high energy dose led to the tissues make 3 CHRONIC Sport the best performing device for pathologies such as radiculitis (i.e. hernia), inflammation of the tendons, arthrosis, arthritis, etc. The therapeutic processes are registered and provide the correct energy supply.

3 wavelengths

42

43

2 CHRONIC Sport has the ability to transmit simultaneously two specific wavelengths which are mainly absorbed by the hemoglobin.

“810 nm for a very high performance in the reduction of pain management; 1064 nm is the excellence for tissues biostimulation and accellerates the functional recovery activity” YAG pulsed source delivers 22.000 mJ in a second, transferring energy at more than 5 cm of depth able to achieve a therapeutic effect.

The zoom handpiece allows to personalize the treatment area focusing energies to various diameters, covering surfaces from 5 cm2 to 13 cm2 with 4 steps. The device allows to move the optical fibers by keeping the beam in focus.

Easy to use thanks to the graphic touch screen of 5.7” display, with the possibility to personalize the treatment and create a personal database.

2 wavelengths

44

45

YAG Therapy One is the most performing device with a controlled response in semi-cold temperature. Its 1064 nm wavelength is within the therpeutic window and recongnizes the chromophores in the tissue, (above all hemoglobin), with a depth absorption defined “scattering“.

“This laser is ideal for a functional recovery activity, excellent for chronic and acute inflammation and pain management.”

YAG pulsed source delivers 12.000 mJ in a second transferring energy at more than 5 cm of depth able to achieve a therapeutic effect.

High energy technology for the best brilliance.

The zoom handpiece allows to personalize the treatment area focusing energies to various diameters, covering surfaces from 5 cm2 to 13 cm2 with 4 steps. The device allows to move the optical fibers by keeping the beam in focus.

1 wavelength

46

47

Range of Lasertherapy Devices

Power and wavelength

10 W 810 nm 10 W 975 nm 8 W 1064 nm

10 W 810 nm 10 W 975 nm 5W 1064 nm

Power per pulse

7500 mJ

6250 mJ

3

3

15.000 mJ (+/- 20%) to the tissue

13.000 mJ (+/- 20%) to the tissue

Fluency

5307,86 mJ/cm²

5307,86 mJ/cm²

Intensity

212314,4 W/cm²

212314,4 W/cm²

Sources Number Main Performances

SPOT Diameter

Modulation Frequency (Preset e settable)

Fiber

Type of Source

48

13 cm²

13 cm²

1 ÷ 20000 Hz SUPER PULSED

1 ÷ 20000 Hz SUPER PULSED

Liquid Optical Fiber with A.I. diode Not-removable

Liquid Optical Fiber with A.I. diode Not-removable

GaAIAs Semiconductor

GaAIAs Semiconductor

10 W 810 nm 12 W 1064 nm

10 W

6000 mJ

3750 mJ

2

1

12.000 mJ (+/- 20%) to the tissue

7.500 mJ (+/- 20%) to the tissue

6369,43 mJ/cm²

7961,78 mJ/cm²

254777,2 W/cm²

318471,2 W/cm²

5 ÷ 13 cm²

5 ÷ 13 cm²

1 ÷ 20000 Hz SUPER PULSED

1 ÷ 20000 Hz SUPER PULSED

Liquid Optical Fiber with A.I. diode Not-removable

Liquid Optical Fiber with A.I. diode Not-removable

GaAIAs Semiconductor

GaAIAs Semiconductor

49

E-SIT is the first medical device designed to fulfill all needs of muscle and myoneural stimulation with the aid of biphasic and monophasic waveforms, able to carry out stimulation sequences in alternate channels.

E-SIT allows the use of all waveforms, such as Kotz, interference, diadynamic, tens, galvanic, monophasic and biphasic.

Furthermore, E-SIT delivers active ingredients both of plant origin and syntethic, without altering their function and without inducing side effects to the patient. In this case, E-SIT frequencies have the function of active ingredients carrier.

Nowadays, E-SIT represents the evolution of iontophoresis as it allows to delivery active ingredients at low and high molecular weight.

E-SIT, through the electrostimulation program, allows to operate on the following conditions of physiological imbalance and disease according to work methods present in the device and selected by the operator as:

• Hypotrophy/Firming • Multi Frequency Training strengthening and muscle definition • Hemophilia • Urinary incontinence • Strengthening and stretching • Muscle balance and imbalance

Touchscreen

• Shoulder relax, shoulder balance and shoulder retro-positioning • Relax of the lateral static chain • Muscle balance of the lower limb flexion and extension chains • TENS and modulated TENS • Modulated and decontracting TENS

Sequential programs

• Endorphin mode • Modulated and endorphin TENS

50

• Decontracting • Capillarization/Vasodilation

Multy Frequency Training

WS2 Therapy medical device is an ultrasound at digital emission of last generation.

It is equipped with a special and innovative power generator that, by subjecting the transducer to a high frequency alternated electric field, converts electrical energy into mechanical oscillations with variable frequency.

The software allows the operator to manage and set the signal in continuous and pulsed Duty Cycle mode. The Duty Cycle is used to give mechanical increase and vibration, reaching high quality magnetic resonance.

The device uses transducers of 1.0MHz and 3.0 MHz. It is scientifically proven that, for the inverse relationship between frequency and penetration, the ultrasonic waves at low frequencies, have more power of depth penetration into the tissues and a wider focus.

1 MHz frequency penetrates more deeply than a 3 MHz signal and the beam divergence (wave beam) decreases when the frequency increases; hence, a signal with higher frequency has a more focusing beam.

52

The Skin Our skin is a means of communciation because it is what other people see of us and vice versa. Beyond this, it is the largest organ of the human body: in the adult it has an average area of 1.8 m2 and, unlike what is usually believed, it is a dinamic ensable that covers the body, separates and protects it from the external environment.

Penetration ways

hair shaft

sebaceous gland stratum corneum

3 1

2

sweat gland

epidermis

capillary

dermis

nerve ending subcutis arteriole adipose collagene fibroblasts

nerve follicolo pilifero

eccrine sweat gland ghiandole sudoripare eccrine

The outermost layer of the skin, the epidermis, is characterized by wrinkles and furrows and their structure varies according to several factors, such as elasticity, skin appendages arrangement, and, on hands and feet, fingerprints, that distinguish each one of us.

The outer epidermis is mostly composed of keratinocytes, cells with particular resistance to mechanical stresses and with very selective permeability against exogenous substances. The epidermis has melanocytes, which contain melanin that preotects us from sunbeams.

Strictly connected with the epidermis, there is the dermis, which constitutes the substrate for mechanical support and metabolic exchange, supplied by blood and lymph vessels. The dermis is composed of fibriblasts, collagen fibers, elastic fibers and ground substance, the bricks that support the skin architecture: this layer is treated in order to enhance the support and to keep the skin young.

54

Why does the skin get old?

The skin gets old because the collagen and the elastin “bricks“ get smaller and the TEWL increases considerably.

The dermis is a very elastic layer, resistant to traction; it has to be protected, defended and nourished in order to remove the signs of aging.

The ground substance is an amorphous gel that especially contains water. The glycosaminoglycans dissolved, including hyaluronic acid, assemble collagen and elastic fibers; thus, an optimal hydration is essential.

The so-called skin appendages (hairs and glands) have the main function of thermo-regularization and allow the secretion of substances from the body outwards: without them, this step would be minimum because the skin is a waterproof organ.

The hypodermis is the tissue placed between the dermis and the muscular apparatus, formed by adipocytes, round cells that isolate the deepest layers and dampen external stresses.

The skin cannot be considered as a simple coating, but it is a real organ with essential features: it is a sensory organ that supports, protects and maintains constant the body temperature.

For all these reasons, it is important to protect the skin and preserve it the most possible, by using methods that nourish it in a non-invasive method.

55

Inspired by nature

Adjuvants phytocompounds in the treatments Physiotherapy

Dermo Aesthetic

Winform has studied and produced the first line of phytocompounds with more than 500 molecules in specific cocktails, in order to achieve high performance and a nutritional synergy to the pathology obtaining a specific chemical action.

Winform Laboratories characterizes its own production using specific natural products created with renewable and of plant origin raw materials from controlled agricolture; all of them, are compatible with the skin.

All ingredients have already their own eudermic functions, whih improve the physiological state of the skin. They do not contain chemicals, such as paraffin and parabens, which are considered pollutants and may cause allergies or skin irritations.

Winform Laboratories was developed as a branch of Winform Ltd, manufacturer of biomedical technologies, creating the first professional line of phytocompounds.

The sharing of values and the powerful synergy of skills and resources have led to the foundation of Winform Laboratories that develops high quality products in order to improve people’s well-being through biotechnologies.

Winform Laboratories works in dermatology, aesthetic medicine, physiotherapy, and orthopaedics with a full range of innovative synergies.

56

P RO F E S S I O N A L T R E AT M E N T S

Bibliographical notes of the main ingredients Please find here below a few notes on the main properties of the most important vegetal functional substances and of the ingredients that most commonly make up phytocompounds. The notes below are meant for information only.

Aesculus Hippocastanum Extract Extract of horse chestnut seeds

Allantoin Allantonin

Aloe Barbadensis Extract Aloe Bardenis extract

Ananas Sativus Extract Pineapple extract

Arctium Lappa Extract Burdock extract

Arctostaphylos Uva-Ursi Extract Bearberry extract

It is used for its vasoprotective, anti-inflammatory and draining properties of the lower limbs, such as oedema, cellulite and microcirculation defects.

It promotes rapid cell growth, increases the healing speed of wounds and of ulcers. It has moisturizing and antioxidant properties, it promotes the absorption of active ingredients in solution.

Traditionally, Aloe was given cicatrizing, demulcent and dereddering properties. Besides, phytoconstituents of Aloe seem to be able to stimulate the production of collagen and elastin, thereby contributing to the prevention of skin ageing.

It is mainly made up of bromelin, enzyme with a proteolytic and anti-oedema action whose function is that of improving the microcirculation function in general. It has also demulcent and dereddering properties.

Remarkable fungistatic and bacteriostatic activity. It is recommended in case of skin disorders such as furuncles, acne, herpes, burns and seborrheic dermatosis.

The arbutin contained in the extract is responsible for the inhibitory activity on the tyrosinase enzyme; it is therefore responsible for the decrease in melanin synthesis.

Mountain arnica extract

At the level of the skin, it shows anti-ecchymotic, revulsive, hyperaemic, demulcent and decongestive properties.

Ascorbic Acid

Protective action on the connective tissue and on the blood vessels integrity.

Arnica Montana Extract

Abscorbic acid

Ascorbyl Palmitate Ascorbyl palmitate

Ascorbyl Tetraisopalmitate Ascorbyl Tetraisopalmitate

Bellis Perennis (Daisy) Flower Extract Daisy extract

Benzyl Alcohol Benzyl Alcohol

Boswellia Serrata Extract Boswelia Serrata extract

Bromelain Bromelain

Caffeine Caffeine

Calendula Officinalis Extract Common marigold extract

Camelia Sinensis Extract Green Tea extract

It is a type of ascorbic acid (vitamin C) that penetrates rapidly through the skin and the cellular membrane where it performs its antioxidant action, helping to prevent the skin ageing by reducing lipid peroxidation, cellular oxidation and collagen degeneration, for the synthesis of which vitamin C plays a fundamental role.

It helps to prevent skin ageing by reducing lipid peroxidation, cellular oxidation and collagen degeneration, for the synthesis of which vitamin C plays a fundamental role.

It helps the cicatrization of wounds and ulcers. In the synthesis process of melanin, it inhibits the tyrosinase enzyme rivalling the DOPA in its receptive site. It is a component of those depigmenting products that aim at treating and preventing typical disorders of hyperpigmentation.

It is used as a constituent in perfumes, solvent and preservative. It has a good antimicrobial activity against Gram-positive bacteria.

It is recommended in case of articular problems such as rheumatisms, rheumatoid and gouty arthritis.

Recommended in the treatment of several sport injuries such as contusions, contractures, sprain and strains. Its capacity to relieve pain is likely to be linked to its ability to reduce tissue inflammation and oedemas, rather than to a direct analgesic effect.

It is able to stimulate the draining and the removal of stagnant fluids (anti-oedema action), even though the main action of the molecule is that of stimulating the mobilization of fat acids in the fatty tissue (adipolysis).

It is used in different preparations for sensitive, inflamed, acne-like skin with a cicatrizing action, in erythemas, in moisturizing and protective products against irritations caused by mechanical and chemical agents.

Remarkable antioxidant properties that translate into a protective action at the level of the microcirculation and into an anti free radicals action in anti ageing products.

57

Bibliographical notes of the main ingredients Please find here below a few notes on the main properties of the most important vegetal functional substances and of the ingredients that most commonly make up phytocompounds. The notes below are meant for information only.

Camphor Camphor

Capparis Spinosa Extract Caper Bush Buds and Barry extract

Caprylic/Caprictriglyceride Caprictriglyceride/Caprylic

Skin antioxidant, anti inflammatory, antihistamine-like activity, effective in allergic dermopathies.

Thanks to its remarkable soothing properties, it is able to create a lipid film that reduces the water loss of the corneal layer.

Carbomer

It is used as a stabiliser of the watery phase in emulsions and as a waterstructuring element in order to obtain transparent gels.

Cardiospermum Halicacabum

It has anti allergic and anti-inflammatory properties as it produces a cortisone-like effect.

Carica Papaya Extract Papaya extract

Carnitine Carnitine

Centella Asiatica Extract Asiatic Centella extract

Chamomilla Recutita Extract Common Chamomille extract

Chondrus Crispus Extract Chrondus Crispus extract

Citrus Aurantium Dulcis Extract Sweet orange blossom extract

Commiphora Mukul Resin Extract Commiphora Mukul Resin extract

Dextrin Dextrin

Disodium EDTA Disodium EDTA

Echinacea Angustifolia Extract Echinacea extract

Equisetum Arvense Extract Horsetail extract

Ethoxydiglycol Ethoxydiglycol

58

It produces a cooling effect like the one produced by menthol. It is used in cosmetic products for massage, aspersion powders with a cooling and antipruritic action. It has revulsive, firming and toning properties.

It protects against free radicals. Adjuvant to the microcirculation and to blood circulation in general.

Fat acid carrier, it allows mitochondrions to use them in the production of ATP. Besides, carnitine enhances peripheral vasodilation, thereby improving the flux and the supply of oxygen.

Powerful decongestant of the circulatory system, it is used in the treatments of disorders linked to blood circulation. It is used in several preparations for dermo-cosmetic use intended to treat imperfections caused by cellulite, to improve the functionalities of the microcirculation and to keep skin elasticity (stretch marks, wrinkles).

It stimulates the functionality of the microcirculation and the activity of fibroblasts thus favouring the synthesis of collagen, of elastic fibres, and of hyaluronic acid and therefore favouring the epidermal and dermal repair.

Carrageenans in the Chondrus have anti-inflammatory and soothing properties. Its hydrophilic and emollient properties ensure the hydration and the protection of the corneal layer.

Antimicrobial properties with a highly skin tolerance.

It is made up of two active ingredients: the commipherol and the commipherine that act on two enzymes involved the one in the growth and development of fat cells (lipogenesis), the other in their reduction (lipolysis). It is made up of two active ingredients: the commipherol and the commipherine that act on two enzymes involved the one in the growth and development of fat cells (lipogenesis), the other in their reduction (lipolysis).

It is used in cosmetic products as absorbing agent, binding agent of substances, in particular powders, in order to improve their transdermal delivery. It has natural origins and it is safe.

It is used as a chelating agent.

The extract has a remarkable anti-hyaluronidase and immunostimulant activity that gives the extract firming, regenerative and elasticizing properties.

It speeds up the processes of cicatrisation and reepithelialisation at the epidermal and dermal levels, improving the surface hydration.

It is used for its remineralisation properties, it promotes bone growth. Equisetum is quite helpful in the adjuvant treatment of skin stretch marks thanks to its firming, smoothing and elasticizing properties.

It is used for its solvent properties and for its ability to promote the penetration of active ingredients thanks to its capacity for destabilizing the corneal layer.

This information do not change the intended use of products classified as “class I medical device” defined in the main package and it is derived from: Chang HG, Doerge DR. Antithyroid isoflavones from soybean. Biochem, Pharmacol. 54 (1997), 1087-1096. - Pinero Estrada JE, Bermejo Besco’s P, Villar del Fresno AM. Antioxidant activity of different fractions of Spirulina platensis protean extract. Il Farmaco 56 (2001) 497–500 - Rondini S, et al. Estratti da foglie di Aloe arborescens testa6, 293. - Heggers JP, et al. Beneficial effects of Aloe on wound healing in an excisional wound model. J Altern Complement Med 2000; 2(2), 271-277. - Campanini E. Dizionario di fitoterapia e piante medicinali. Tecniche Nuove, II, Milano, 2004, 108-109.

Ethylparaben Sodium EDTA

Geraniol Geraniol

Ginkgo Biloba Extract Ginkgo Biloba extract

Glycerin Glycerin

Hamamelis Virginiana Extract Witch Hazel extract

Harpagophytum Procumbens Extract Devil’s Claw extract

Helichrysum Italicum Extract Helichrysum extract

Humulus Lupulus Extract Hop exract

Hydrolyzed Hibiscus Esculentus Extract Hibiscus extract

Hydrolyzed Ulva Lactuca Extract Seaweed extract

Hypericum Perforatum Extract St. John’s wort extract

Imidazolidinyl Urea Imidazolidinyl Urea

Kojic Acid Dipalmitate Kojic Acid

It is used as preservative in order to protect products from the microbial contamination.

Fragrance contained in several perfumes that make more pleasant cosmetic products of any kind, from those for cleansing, to those for body care and perfumery.

It has a remarkable anti free radical activity leading to an improvement of the cellular metabolism and prevention of membrane lipid peroxidation. It has also a marked protective action at the vascular endothelium level that leads to a stabilisation of the capillary permeability and therefore to an improvement of microcirculation function.

It has moisturizing, lubricating and emollient properties.

Phlebotonic, astringent, vasoconstrictive, haemostatic, analgesic and anti-inflammatory properties.

Recommended in the treatment of rheumatological disorders (osteodynia, muscular pain, back pain, contusions, cervical pain, rheumatic pain, periarthritis, and tendinitis).

It is mainly used in the treatment of impure skins with a tendency to seborrhoea. Thanks to its protective properties towards the skin, it is also used in soothing preparations.

Antipruritic and slightly anaesthetic properties.

Thanks to its high concentration of natural “biomimetic” oligopeptides, it inhibits the muscular contraction with the consequential cosmetic effect on the skin of “expression lines decrease.”

It promotes the mitochondrial metabolism of human fibroblasts, the synthesis of collagen and elastin.

Excellent astringent properties, useful in the treatment of oily and impure skin.

It is used as preservative in order to protect products from the microbial contamination.

Functional agent with depigmenting action. Used in the preparation of cosmetic products for depigmentation and for the uniformity of the skin tone, useful in the treatment of melasma, lentigo solari, lentigo senili and other disorders of hyperpigmentation of acquired origin.

Laureth-9

Local anaesthetic (analgesic) property, antipruritic agent.

Lavandula Angustifolia Extract

Antiseptic, vasodilative activity, mild sedative for muscular pain.

Lavender flower extract

Lecithin Lecithin

Limonene Limonene

It can be used in order to produce blisters known as liposomes, used in the delivery of active compounds. It has good moisturizing properties; it reduces desquamation and helps to re-establish skin elasticity.

Fragrance contained in several perfumes with a hint of citrus that make cosmetic products of any kind more pleasant.

Linalool

Fragrance contained in several perfumes that make cosmetic products of any kind more pleasant.

Lonicera Caprifolium Extract

It is used for its toning and soothing properties.

Linalool

Honeysuckle flower extract

59

Bibliographical notes of the main ingredients Please find here below a few notes on the main properties of the most important vegetal functional substances and of the ingredients that most commonly make up phytocompounds. The notes below are meant for information only.

Lonicera Japonica Flower/Leaf Extract Japanese honeysuckle flower and leaf extract

Mentha Piperita Oil Peppermint essential oil

Menthol Menthol

Niacinamide Nicotinamide

Octyl Palmitate Octylpalmitate

Octyldodecanol

Remarkable refreshing, toning, purifying properties. Thanks to its antiseptic and antipruritic properties, it is useful in the treatment of dermatosis, furuncles and eczemas.

Used since ancient times, it has refreshing, decongestive, antiseptic and disinfectant properties.

It promotes the increase in ceramides and keratin, the decrease in the transfer of melanosomes to melanocytes (lightening action), the decrease in sebum and in dilated pores. It stimulates the synthesis of collagen.

It is an emollient suitable for its use in every kind of cosmetic preparations, in particular in products for the body for its characteristic of spreadability and its lubricating power.

Octyldodecanol

It is used to make emollient emulsions with a low content of fat phase; it favours the formation of emulsion and prevents the division of phases.

Olea Europaea Leaf Extract

Remarkable antioxidant, astringent, and slightly antiseptic properties.

Olive leaf extract

Oryza Sativa Extract Rice oil

It has a protective activity against skin photo ageing. Excellent emollient and repairing properties.

Ginseng extract

Revitalizing, reactivating action. At the epidermal level, it contributes to the improvement of the microcirculation with a vasoprotective and toning action.

Panthenol

It favours the epidermal regeneration, sedates skin irritations.

Panax Ginseng Extract

Panthenol

Phenoxiethanol

It is used as preservative in order to protect products from the microbial contamination.

Phospholipids

Lipids, one of the major components of the cellular membrane.

Phenoxyethanol

Phospholipids

Pinus Sylvestris Leaf Extract Scots pine leaf extract

Polysorbate 80 Polysorbate 80

Potassium Sorbate Potassium Sorbate

Propylene Glycol Propylene Glycol

Propylparaben Propylparaben

Quercus Robur Root Extract English Oak root extract

Retinyl Palmitate Retinyl Palmitate

Rosmarinus Officinalis Extract Rosemary extract

Ruscus Aculeatus Extract Butcher’s broom extract

60

It is used for its soothing and dereddening properties.

Muscle relaxant activity, antirehumatic and toning activity.

It is used in cosmetics, pharmacy as emulsifier or solubilizer.

It is used as preservative in several cosmetic preparations such as lotions, creams and products for hair.

Humectant usually used in watery systems or emulsions to retain water avoiding its evaporation thus avoiding desiccation of the product.

It is used as preservative in order to protect products from the microbial contamination.

It has the ability to improve cellular respiration and quickly revitalise all the integumentary system.

Form of retinol (vitamin A) esterified with palmitic acid. It is used as active ingredient to slow down the cellular ageing and in the treatment of dry and squamous skins.

Excellent stimulant of scalp and of hair bulbs. Besides, it regulates sebaceous secretion and the production of dandruff.

Trophic and protective properties at the level of blood vessels, remarkable toning action on the vasal wall that translates into a clear improvement of the peripheral microcirculation.

This information do not change the intended use of products classified as “class I medical device” defined in the main package and it is derived from: Chang HG, Doerge DR. Antithyroid isoflavones from soybean. Biochem, Pharmacol. 54 (1997), 1087-1096. - Pinero Estrada JE, Bermejo Besco’s P, Villar del Fresno AM. Antioxidant activity of different fractions of Spirulina platensis protean extract. Il Farmaco 56 (2001) 497–500 - Rondini S, et al. Estratti da foglie di Aloe arborescens testa6, 293. - Heggers JP, et al. Beneficial effects of Aloe on wound healing in an excisional wound model. J Altern Complement Med 2000; 2(2), 271-277. - Campanini E. Dizionario di fitoterapia e piante medicinali. Tecniche Nuove, II, Milano, 2004, 108-109.

Salix Alba (Willow) Bark Distillate White willow distillate

Salvia Officinalis Oil Common sage oil

Serenoa Serrulata Extract Serenoa Serrulata extract

Sodium Dehydroacetate Dehydroacetate sodium

Sodium Hyaluronate Hyaluronate sodium

Sodium Hydroxide Hydroxide sodium

Sodium Phytate Phytate sodium

Sorbitol Sorbitol

Soy Isoflavones Soybean

Spirulina Platensis Extract Spirulina extract

Tartaric Acid Tartaric acid

Tilia Cordata Extract Tilia extract

Tocopherol Tocopherol / Vitamin E

Tocopheryl Acetate Acetate tocopherol / Acetate vitamin E

Trigonella Foenum Graecum Extract Fenugreek

Urtica Dioica Nettle

Xanthan Gum Xanthan Gum

Zea Mays Oil Mais oil

Zinc PCA Zinc PCA

Remarkable anti-inflammatory properties, skin-conditioning agent, conditioning agent for hair, soothing and toning.

Dermo purifying properties, deodorant, stimulant and firming agent, it is used in the treatment of oily hair, oily and impure skin and of relaxed skin.

It is used to treat baldness; it inhibits the enzyme 5-alpha-reductase that transforms testosterone in dihydrotestosterone that is into the biologically active form.

It is used as preservative in order to protect products from the microbial contamination.

The main property of the hyaluronic acid is that of binding a high number of water molecules ensuring skin hydration. It stimulates the synthesis of hyaluronic acid.

It is mainly used as PH regulator.

It is used as chelating agent, very often instead of the edta in the preparation of natural products.

It is used in cosmetics as humectant in order to preserve the product from dehydration, and as hydrating agent to prevent skin dryness.

They favour the stimulation of fibroblasts with an increase in tropocollagen at the dermal level. They also stimulate the natural production of hyaluronic acid with inhibition of collagenase, elastase, metallopreinase.

Several studies have proved its antioxidant activity, it being a powerful scavenger of free radicals and its inhibition of microsomal lipid peroxidation.

It can be found in cucumbers and grape. It impedes carbohydrates from transforming into fat. Its acantholytic action decreases the adhesion of corneocytes and pigmented elements with the consequential lightning effect and the increase in skin brightness.

Useful ingredient in the preparation of emulsions and sera for delicate, sensitive, dry and tending to rash skin.

It prevents the formation of free radicals and it activates the cellular renewal.

It stimulates the surface microcirculation and it acts as a protective shield as it helps to reinforce skin cell walls.

Thanks to its antioxidant activity, it is largely used in cosmetic preparations not only as a protective agent of the skin against the action of free radicals, but also in order to impede the degradation of other components of the preparation itself.

In cosmetics, it shows firming and emollient properties.

Toning and stimulant of the scalp. It is used as toner of the scalp against seborrhoea and hair loss.

It is most common use is that of stabiliser of preparations and for its ability to enhance viscosity.

It has moisturising and repairing properties thanks to its composition rich in unsaturated fat acids and to its nonsaponifiable fraction with a high content of vitamin E and phytosterols.

Antiseborrheic, anti microbial and anti acne properties due to the presence of zinc.

61

Professional Line

Medical Device Class I

Intended use: Phytocompounds are gel-based products made of vegetal substances to be used together with medical electrical devices for diathermy and transdermal delivery in order to minimize friction and improve conductivity during the treatment. Thanks to their compositions, they are also suitable for topical use without rinsing as a preliminary or adjuvant gel to the therapeutic treatment.

Demusco Gel

Available in : Tube of 100 ml Vase of 500 ml

INCI: aqua, dimethyl sulfone, glycerin, alcohol, menthol, glycine soja oil, ricinus communis seed oil, zea mays germ oil, pinus sylvestris twig leaf oil, lavandula angustifolia herb oil, arnica montana flower extract, harpagophytum procumbens extract, maltodextrin, boswellia serrata extract, tocopherol, retinyl palmitate, xanthan gum, tocopheryl acetate, lecithin, ascorbyl palmitate, carbomer, camphor, sorbic acid, benzyl alcohol, potassium sorbate, ethoxydiglycol, tetrasodium glutamate diacetate, dehydroacetic acid, sodium hydroxide, polysorbate 60, citric acid, linalool, geraniol, limonene.

Kela Gel INCI: aqua, hydroxypropyl guar, xanthan gum, sodium phytate, tetrasodium glutamate diacetate, potassium sorbate, benzyl alcohol, sodium glutamate, lonicera japonica flower/leaf extract, dehydroacetic acid, lonicera caprifolium extract.

Available in : Tube of 100 ml Vase of 500 ml

Arnilin Gel INCI: aqua, dimethyl sulfone, laureth-9, alcohol, hydroxypropyl guar, glycerin, harpagophytum procumbens extract, arnica montana flower extract, aesculus hyppocastanum extract, helichrysum italicum extract, calendula officinalis flower extract, boswellia serrata extract, caprylic/capric triglyceride, maltodextrin, lecithin, panthenol, ascorbyl tetraisopalmitate, sorbitol, xanthan gum, ascorbyl palmitate, potassium sorbate, benzyl alcohol, tetrasodium glutamate diacetate, dehydroacetic acid, citric acid, polysorbate 80.

Available in : Tube of 100 ml Vase of 500 ml

62

Be inspired by nature

Adjuvants phytocompounds in the treatments

Condroitin Gel INCI: aqua, dimethyl, sulfone, laureth-9, harpagophytum procumbens extract, sodium chondroitin sulfate, alcohol, caprylic/capric triglyceride, hydroxypropyl guar, panthenol, glycerin, hypericum perforatum extract, equisetum arvense extract, lecithin, sodium hyaluronate, ascorbic acid, sorbitol, polysorbate 80, propylene glycol, potassium sorbate, disodium EDTA, phenoxyethanol, methylparaben, ethylparaben, propylparaben.

Available in : Tube of 100 ml Vase of 500 ml

Fibralin Gel

Available in : Tube of 100 ml Vase of 500 ml

INCI: aqua, dimethyl sulfone, disodium EDTA, alcohol, hydroxypropyl guar, harpagophytum procumbens extract, boswellia serrata extract, arnica montana flower extract, quercus robur root extract, caprylic/capric triglyceride, glycerin, panthenol, centella asiatica extract, maltodextrin, lecithin, calendula officinalis flower extract, hamamelis virginiana extract, chamomilla recutita flower extract, ascorbyl tetraisopalmitate, dextrin, xanthan gum, sorbitol, benzyl alcohol, potassium sorbate, dehydroacetic acid, polysorbate 80.

Bromellin Gel

Available in : Tube of 100 ml Vase of 500 ml

INCI: aqua, dimethyl sulfone, disodium EDTA, glucosamine sulphate, alcohol, carbomer, harpagophytum procumbens extract, bromelain, cardiospermum halicacabum, ananas sativus extract, ruscus aculeatus extract, arnica montana flower extract, lecithin, centella asiatica extract, boswellia serrata extract, polyglyceryl-2 dipolyhydroxystearate, dextrin, glycerin, quercus robur root extract, lauryl glucoside, hypericum perforatum extract, calendula officinalis flower extract, hedera helix extract, ascorbyl tetraisopalmitate, panthenol, maltodextrin, caprylic/capric triglyceride, menthol, laureth-9, benzyl alcohol, dehydroacetic acid, sodium hydroxide, sodium dehydroacetate, polysorbate 80.

63

Professional Line

Medical Device Class I

Centelin Gel

Available in : Tube of 100 ml Vase of 500 ml

INCI: aqua, dimethyl sulfone, disodium EDTA, laureth-9, carbomer, alcohol, glycerin, hydroxypropyl guar, harpagophytum procumbens extract, arnica montana flower extract, panthenol, boswellia serrata extract, quercus robur root extract, phospholipids, centella asiatica extract, lecithin, chamomilla recutita flower extract, maltodextrin, hamamelis virginiana extract, calendula officinalis flower extract, sorbitol, caprylic/capric triglyceride, ascorbyl tetraisopalmitate, benzyl alcohol, potassium sorbate, dehydroacetic acid, sodium hydroxide, polysorbate 80.

Disinfectant San C It is an ozonized natural cleansing agent with a fresh herbal scent. Ideal for the whole body, it is a fundamental aid for the application of following treatments. It cleanses the skin deeply favouring the absorption of beneficial substances.

Bottle of 200 ml

64

INCI: aqua ethoxydiglycol, peg-40 hydrogenated castor oil, glycerin, zea mais, arnica montana, lavandula angustifolia, melaleuca alternifolia, malva sylvestris, chamomilla recutita, calendula officinalis, hamamelis virginiana, azadirachta indica, sorbitol, disodium edta, simethicone, benzalkonium chloride, sorbic acid, parfum.

Be inspired by nature

Adjuvants phytocompounds in the treatments

Dermo Line

Acn-E, purifying gel It improves skin thanks to its natural purifying, antioxidant and antimicrobial action.

Airless dispenser of 50 ml

INCI: aqua, octyl palmitate, hydroxythylcellulose, zinc pca, melia azadirachta leaf extract, arctium lappa extract, glycerin, hydroxypropyl, guar, potassium sorbate, triclosan, sorbic acid, benzyl alcohol, citric acid, phthalimidoperoxycaproic acid, phenoxyethanol, disodium EDTA.

Flaw, anti spot gel Reduction and elimination of imperfections due to skin spots.

Airless dispenser of 50 ml

INCI: aqua, glycerin, maltodextrin, caffeine, kojic dipalmitate, capparis spinosa extract, citrus aurantium dulcis extract, arctostaphylos uva-ursi extract, bellis perennis (daisy) flower extract, arbutina, ananas sativus extract, carica papaya extract, dextrin, camelia sinensis extract, oryza sativa extract, olea europaea leaf extract, panthenol, ascorbyl tetraisopalmitate, aloe barbadensis extract, benzyl alcohol, xanthan gum, carbomer, potassium sorbate, sodium dehydroacetate, sorbitol, sodium hydroxide, dehydroacetic acid, phenoxyethanol, disodium EDTA.

65

Hair Line

Hair Lotion, concentrated lotion It is a lotion for weakened hair. Spread a minimum quantity to dampen the scalp, lightly massage for a few minutes. Alternate Hair Lotion with the treatment of Hair Gel for at least three times a week.

Dispenser of 50 ml

INCI: aqua, isopropyl alcohol, C11-15 pareth-12, ethoxydiglycol, zea mays oil, serenoa serrulata, urtica dioica extract, arnica montana extract, rosmarinus officinalis extract, salvia officinalis oil, hypericum perforatum extract, aloe barbadensis extract, panthenol, sodium hyaluronate, ascorbyl tetraisopalmitate, glycerin, sorbitol, gaultheria procumbens oil, quercus robur root extract, tocopherol, lecithin, lonicera japonica flower/ leaf extract, ascorbyl palmitate, lonicera caprifolium extract, potassium sorbate, sodium dehydroacetate, citric acid, limonene, linalool.

Hair Shampoo, concentrated It cleanses hair and scalp perfectly by a gentle action, respecting the pH and its components. It is highly concentrated; a quantity of only 3 ml should be used per treatment. It does not foam.

Bottle of 150 ml

INCI: aqua, disodium coco-glucoside sulfosuccinate, glycerin, peg/ppg-120/10 trimethylolpropane trioleate (and) lauteth-2, cocamidopropyl betaine, laureth-10, sodium laureth-11 carboxylate, polyquaternium-7, salix alba (willow) bark distillate, zea mays oil, serenoaserrulata, urtica dioica extract, rosmarinus officinalis oil, salvia officinalis oil, lavandula angustifolia oil, sorbitol, aloe barbadensis extract, gaultheria procumbens oil, ascorbyl tetraisopalmitate, panthenol, maltodextrin, lonicera japonica flower/leaf extract, potassium sorbate, sodium dehydroacetate, lonicera caprifolium extract, linalool, limonene.

Hair Gel, 5-alpha-reductase It prevents hair loss and in many cases even androgenic alopecia. It was studied expressly to be perfectly absorbed by the skin and to inhibit 5-alpha-reductase isoforms.

Tube of 100 ml

66

INCI: aqua, ethoxydiglycol, zea mais oil, dydroxyethylcellulose, serenoa semulata extract, urtica dioica, amica montana extract, hypericum perforatum oil, rosmarinus officinalis extract, salvia officinalis oil, sodium hylauronate, ascorbyl tetraisopalmitate, tocopherol quercus robur root extract glycerin, ascorbyl palmitate, aloe barbadensis extract, panthenol, lecithin, lonicera japonica flower/leaf extract, sorbitol, lonicera caprifolium extract, imidazolidinyl urea, potassium sorbate, citric acid, limonene, linalool.

Be inspired by nature

Adjuvants phytocompounds in the treatments

“Professional Line”

ossigenO3

Life Life is an ozone gel formulation composed of active vegetal substances without parabens and preservatives. Its formulation makes it optimal where the operator wants to obtain a wide revitalizing effect.

INCI: AQUA , GLYCERIN , OZONIZED,SUNFLOWER(HELIANTHUSANN UUS)SEED OIL, LAVANDULA ANGUSTIFOLIA HERB OIL, TOCOPHERYL ACETATE, HYDROXYPROPYL GUAR, XANTHAN GUM, SALICYLIC ACID, SODIUM GLUTAMATE ,POTASSIUM SORBATE , BENZYL ALCOHOL, TETRASODIUM GLUTAMATE DIACETATE, LIMONENE, LINALOOL , GERANIOL SODIUM HYDROXIDE

Tube of 100 ml

67

“Professional Line” Face Line - Revitalizing Jaluronico, Anti Age cream or filler gel Progressive action anti age repairing the architecture of facial features.

Tube of 100 ml

INCI: aqua, glycerin, aluminium starch octenylsuccinate, cetearyl alcohol, prunus amygdalus dulcis oil, ethylhexyl palmitate, potassium palmitoyl hydrolyzed wheat protein glyceryl stearate, caprylic/capric triglyceride, centella asiatica extract, panax ginseng root extract, quercus robur root extract, tilia platyphyllos extract, dextrin, commiphora mukul resin extract, boswellia serrata extract, tilia cordata extract, maltodextrin, sodium hyaluronate, ascorbyl tetraisopalmitate, panthenol, aloe barbadensis leaf extract, allantoin, sorbitol, benzyl alcohol, sodium dehydroacetate, bht, dehydroacetic acid, sodium hydroxide.

Deanolo, lifting effect gel It increases skin compactness, tone and elasticity with lifting and remodeling effect on the face contour.

Tube of 100 ml

INCI: aqua, glycerin, tartaric acid, hydroxyethylcellulose, dimethyl mea, commiphora mukul resin extract, panthenol, aloe barbadensis extract, hydrolyzed hibiscus esculentus extract, tilia platyphyllos extract, centella asiatica extract, panax ginseng extract, quercus robur root extract, dextrin, sodium hyaluronate, sorbitol, tilia cordata extract, ascorbyl tetraisopalmitate, maltodextrin, polysorbate 60,allantoin, benzyl alcohol, dehydroacetic acid, potassium sorbate, disodium EDTA, propylene glycol, parfum, benzyl salicylate, butylphenyl Methylpropional, linalool, citronellol.

“Professional Line” Face Line - Collagen Wrinkle, skin-restructuring gel Studies done about this extract have highlighted a stimulation of the fibroblasts activity with an increase of the collagen neosynthesis and protection of the elastin.

Tube of 100 ml

68

INCI: aqua, hydroxyethylcellulose, hydrolyzed ulva lactuca extract, ginkgo biloba extract, chondrus crispus extract, hydrolyzed hibiscus esculentus extract, commiphora mukul resin extract, centella asiatica extract, echinacea angustifolia extract, glycine soja extract, panthenol, niacinamide, retinyl palmitate, lecithin, ascorbyl tetraisopalmitate, maltodextrin, aloe barbadensis extract, tocopherol, ascorbyl palmitate, sorbitol, dextrin, polysorbate 60, benzyl alcohol, potassium sorbate, sodium dehydroacetate, hydroxypropyl guar, allantoin, alcohol denat., dehydroacetic acid, citric acid.

Be inspired by nature

Adjuvants phytocompounds in the treatments

“Professional Line�

Body Line

Phospholipids, localized adiposity It is used for adipose treatments and cellulite (P.E.F.S)

Tube of 100 ml

INCI: aqua, glycerin, lecithin, polysorbate 80, hydroxyethylcellulose, alcohol, soy isoflavones, spirulina platensis extract, caffeine, panthenol, ascorbic acid, carnitine, quercus robur root extract, aloe barbadensis extract, hamamelis virginiana extract, chamomilla recutita extract, calendula officinalis extract, potassium sorbate, sorbitol, allantoin, triclosan, phenoxyethanol, disodium EDTA.

Skintonic, skin firming Firming, stimulant and filling action with lifting effect.

Tube of 100 ml

INCI: aqua, laureth-9, hydroxypropyl cyclodextrin, glycerin, hydroxypropyl guar, tartaric acid, dextri, n trigonella foenum graecum seed extract, humulus lupulus extract, dimethyl mea, glycine soja extract, equisetum arvense extract, hydrolyzed wheat protein, tocopheryl acetate, xanthan gum, maltodextrin, sodium hyaluronate, benzyl alcohol, silica, mentha piperita oil, lonicera japonica flower/leaf extract, polysorbate 60, potassium sorbate, dehydroacetic acid, menthol, disodium EDTA, lonicera caprifolium extract, sodium dehydroacetate, citric acid, parfum, hydroxycitronellal, linalool, limonen, e cinnamyl alcohol, geraniol, anise alcohol.

Stretchmark, stretch marks Effective in the treatment of stretch marks in regenerative phase.

INCI: aqua, sodium ascorbyl phosphate, panthenol, polyglyceryl-2 dipolyhydroxystearate, lauryl glucoside, niacinamide, carapa guaianensis, ginkgo biloba extract, centella asiatica extract, ruscus aculeatus extract, aesculus hyppocastanum extract, equisetum arvense extract, triticum vulgare germ oil, sodium hyaluronate, aloe barbadensis leaf extract, glycerin, dextrin, hydroxypropyl guar, sorbitol, carbomer, benzyl alcohol, phytic acid, maltodextrin, silica, lonicera japonica flower/leaf extract, potassium sorbate, dehydroacetic acid, lonicera caprifolium extract, sodium hydroxide.

Tube of 100 ml

69

Be inspired by nature

Adjuvants phytocompounds in the treatments

“Professional Line�

Body Line

Lasocell Effective for painful cellulite.

Tube of 100 ml

INCI: aqua, dimethyl sulfone, disodium EDTA, glucosamine sulphate, alcohol, carbomer, harpagophytum procumbens extract, bromelain, cardiospermum halicacabum, ananas sativus extract, ruscus aculeatus extract, arnica montana flower extract, lecithin, centella asiatica extract, boswellia serrata extract, polyglyceryl-2dipolyhydroxystearate,dextrin,glycerin,quercusroburrootextract, laurylglucoside,hypericumperforatumextract,calendulaofficinalisflowerextract, hederahelixextract,ascorbyltetraisopalmitate,panthenol,maltodextrin,caprylic/ capric triglyceride, menthol, laureth-9, benzyl alcohol, dehydroacetic acid, sodium hydroxide, sodium dehydroacetate, polysorbate 80.

Extra Cell, fibrotic cellulite Highly effective for edematous and sclerotic cellulite

Vase of 500 ml

INCI: aqua, vitis vinifera seed oil, glycerin, cetearyl alcohol, macadamia ternifolia seed oil, ceteareth-25, cera alba, butyrospermum parkii butter, cocos nucifera oil, sorbitan stearate, melilotus officinalis extract, bromelain, centella asiatica extract, escin, dextrin, lecithin,allantoin, tocopherol, ascorbyl palmitate, hydroxypropyl guar, cananga odorata oil, maltodextrin, xanthan gum, benzyl alcohol, sodium chloride, potassium sorbate, dehydroacetic acid, disodium EDTA, citric acid, dimethicone, linalool, benzyl benzoate, sodium hydroxide, benzyl salicylate, farnesol, geraniol.

MEDICAL DEVICE CLASS I - INTENDED USE Phytocompounds are gel-based products made of vegetal substances to be used together with medical electrical devices for diathermy and transdermal delivery in order to minimize friction and improve conductivity during the treatment. Thanks to their compositions, they are also suitable for topical use without rinsing as a preliminary or adjuvant gel to the therapeutic treatment.

70

Be inspired by nature

Adjuvants phytocompounds in the treatments Technical-professional line

Dren Up, draining cream Effective against cellulite imperfections and against excessive water retention.

Vase of 500 ml

INCI: aqua, vitis vinifera seed oil, glycerin, cetearyl alcohol, macadamia ternifolia seed oil, ceteareth-25, cera alba, butyrospermum parkii butter, cocos nucifera oil, sorbitan stearate, melilotus officinalis extract, bromelain, centella asiatica extract, escin, dextrin, lecithin,allantoin, tocopherol, ascorbyl palmitate, hydroxypropyl guar, cananga odorata oil, maltodextrin, xanthan gum, benzyl alcohol, sodium chloride, potassium sorbate, dehydroacetic acid, disodium EDTA, citric acid, dimethicone, linalool, benzyl benzoate,

HC500 Gel Gel-based product made of vegetal substances to be used together with medical electrical devices for diathermy and transdermal delivery in order to minimize friction and improve conductivity during the treatment.

Vase of 500 ml

INCI: aqua, hydroxypropyl guar, glycerin, xanthan gum, hamamelis virginiana extract, camomilla recutita extract, benzyl alcohol, potassium sorbate, phenoxyethanol, disodium EDTA.

Technical pHisiologic Cream2 , vegetal conductive cream It is a moisturizing cream for massage and diathermy that ensures high performances together with a lower consumption of product. No warming effects. Safer for your hands, it does not contain parabens. Nickel-free.

Vase of 1000 ml

INCI: aqua, arachis hypogaea oil, glycerin, cetearyl alcohol, ceteareth-25, cocos nucifera oil, cera alba, butyrospermum parkii butter, sesamum indicum oil, tocopherol, allantoin, benzyl alcohol, potassium sorbate, sodium dehydroacetate, dimethicone, sodium chloride, disodium EDTA, dehydroacetic acid, parfum, citronellol, hydroxycitronellal, linalool, hexyl cinnamal.

Fisio Cream Chemical, conductive cream Cream-based product made of vegetal substances to be used together with medical electrical devices for diathermy and transdermal delivery in order to minimize friction and improve conductivity during the treatment. Thanks to their compositions, they are also suitable for topical use without rinsing as a preliminary or adjuvant gel to the therapeutic treatment.

Vase of 1000 ml

INCI: aqua, cocos nucifera oil, cetearyl alcohol, petrolatum, ceteareth-25, propylene glycol, butyrospermum parkii butter, polysorbate 60, allantoin, sodium chloride, potassium sorbate, disodium EDTA, citric acid, benzyl alcohol, parfum, phenoxyethanol, methylparaben, butylparaben, propylparaben, BHT.

71

Scientific Research

72

73

Clinical case of tibialis anterior muscle strain therapy A.P., a 27 years old basketball player, complains about pain on the anterolateral face of the left leg after a quick change of direction during a regular championship league match in June 2012.

He went to the doctor: during the inspection are evident redness and swelling on the left tibialis anterior muscle. The doctor recommended him an ultrasound scanning, done on June, 4th 2012; after having checked it, the doctor decided to start six sessions of SIN treatment following the protocol three times a week.

During the acute phase, has been chosen the program P1 with 20% of power using Demusco Gel. The treatment has been done on two proximal spots and on two distal ones, 4 minutes each spot. The handpiece and neutral plate placement has been respected so that the lesion must not find between the two elements.

The injured area has been treated with 4 minutes of program P1, power 20% using the phytocompound EDTA 10% to facilitate the absorption of the hematoma.

After the third treatment, the operator changed the opeating mode, choosing the program P1 with power 60% and Demusco Gel, moving the handpiece on the whole left tibialis anterior muscle and, thus, on the plantar fascia and triceps surae up to the hamstrings muscles, 12 minutes each part.

At the end of the six treatments recommended, the doctor sent A.P. to do a post-surgery rehabilitation ultrasound scanning on July, 6th 2012.

74

Before the treatment with SIN: 2nd-3rd sprain degree of tibialis anterior muscle of the right ankle

After the treatment with SIN: Good cicatrization of the lesion described with clear resolution of interfibrillar edema

After the rehabilitation, A.P. restarted the training after 30 days from the injury and he got back to the field for the official match after 45 days from the injury.

75

The Winning Answer Tibial Sprain

Before the treatment: 2nd - 3rd sprain degree of tibialis anterior muscle of the right ankle

After the treatment: Good cicatrization of the lesion described with clear resolution of interfibrillar edema 76

The Winning Answer Baker’s Cysts

Before the treatment: Baker’s Cysts

After the treatment: Significant size reduction with progressive transformation of exudate with initial retroactive cicatrizing phenomena

77

The Winning Answer Chondropathy

Before the treatment: 2nd degree chondropathy with arthrosynovitis

After the treatment: Clear reduction of synovial effusion

78

The Winning Answer Enthesitis

Before the treatment: Distal enthesitis with 1st sprain degree of radial extensor

After the treatment: Good cicatrization

79

The Winning Answer Medial Gastrocnemius strain

Before the treatment: Female soccer player, 16 years old. Medial gastrocnemius strain of the right leg.

After the treatment: Excellent 2nd - 3rd degree cicatritial resolution of distal myotendinous junction of medial head gastrocnemius with slight detachment of the muscular fascia.

80

The Winning Answer 1st - 2nd sprain degree

Before the treatment: 1st - 2nd sprain degree.

After the treatment: Excellent strain cicatrization.

81

The Winning Answer Treatment for periocular wrinkles The most responsive wrinkles are the perioculars, followed by nasolabial folds and forehead lines. The follow-up after 5 months has shown the maintenance of the results achieved.

Before the treatment: Evident signs of photo- and chrono-aging; the wrinkles are present even at rest.

After the treatment: It is evident a recovery of the skin volume and of the deep structutes; the complexion is more uniform.

Follow up after 5 months: The follow-up after 5 months has shown that the wrinkles are not reappeared. The skin has maintained a uniform, bright and moisturized aspect. The radiofrequency allows to maintain the results obtained because it stimulates the tissue to produce collagen.

82

The Winning Answer Treatment for periocular wrinkles The most responsive wrinkles are the perioculars, followed by nasolabial folds and forehead lines. The follow-up after 5 months has shown the maintenance of the results achieved.

Before the treatment: Evident extended and deep wrinkles; even less deep furrows are present at rest.

After the treatment: Reduction of the width and depth of wrinkles and furrows; the skin is hydrated and smoothed.

Follow-up after 5 months: The follow-up after 5 months has shown that the obtained results are maintained: neither wrinkles nor furrows have reappeared. The radiofrequency has triggered the production of ialuronic and collagen, maintaining a hydrated and elastic skin.

83

The Winning Answer Treatment for melasma and dyschromia The research results have shown that in many cases there have been an acceptable softening up to the disappearance of the hyperchromic lesions, compared to the initial ones. The follow-up after 1, 6 and 12 months has shown the persistence of the results obtained.

84

Before the treatment: Evident deep dyschromia on the right zygomatic malar region.

After 4 sessions: The dyschromia is not evident any more; the disappearance of the blemish has not affected the natural skin texture: the treatment is highly specific.

Before the treatment: Deep facial dyschromia on the forehead. The blemishes are irregulary spread without a clear contour.

After 5 sessions: The dyschromia is completely disappeared leaving no signs: the method allows to lighten the blemish and inhibit its new formation. The tissue adjacent to the blemish has not been damaged (the method is not-invasive and has no side effects).

The Winning Answer Treatment for stretch marks Since the first session, it can be observed a gradual and constant improvement of the lesions, with significant reduction of the erythematous component, dimensions and depth of the single lesions. At the end of the treatment (15 sessions) the enhancement is conspicuous and in many cases decisive.

The follow-up after 2 months has shown the maintenance of the results obtained.

Before the treatment: Many red stretch marks on the abdomen are evident. The erythematous phase indicates that it is possible to act succesfully.

After 15 sessions: The stretch marks on the abdomen have gradually decreased up to their complete disappearance. Scars are not perceived to the touch and the result is natural.

85

The Winning Answer Treatment for the acne

Before the treatment: Evident an inflammation that causes erythema. There are papules and pimples.

After 5 sessions: The inflammation and the erythema are considerably decreased. The treatment has an excellent antiseptic and sebum-regulating action. The skin looks healthier and hydrated.

86

The Winning Answer Treatment for androgenetic alopecia

Before the treatment: It is evident an overall thinning of hair mass and miniaturization. The skin is clearly less supplied by blood.

After 6 months: Significant improvement and increase of the hair diameter. The skin is obviously healthier.

Before the treatment:: Androgenetic alopecia in a woman. It is evident hair thinning and weakening on the central area on the top of the head. As the skin is little supplied by blood, the hair follicle weakens.

After 6 months: Increase of hair density and significant improvement of hair quality (thickness and color). Hair regrowth has been stimulated and even the vascularization is enhanced.

87

The solution to cellulite

SIN is the innovative method for the treatment of cellulite: it allows to reactivate the normal physiological processes of tissue metabolism, transferring biocompatible energy without projection of radiant energy outwards, with consequent revascularization of the damaged areas and restoring of the normal metabolism.

SIN has shown, with ultrasound scanning, that destructures the altered collagen fibers responsible for adipocytes encapsulation, with consequent loss of adhesion with the muscular fascia in order to facilitate the remodeling of the tissue structure determining the disappearance of nodules and restoration of “restitutio ad integrum“.

SIN, with its biostimulating action, is able to interact at molecular level in the cells of the tissues, modifying and influencing the intercellular state and extracellular response with tissues morphofunctional restoration. In particular, it stimulates the fibroblasts of the connective tissue to synthesize the morphologically and functionally suitable type 1 collagen fibers, inducing the adypocites to restore a proper fat metabolism.

Age

Grade

Throcanteric Circumference Before Treatment

29

II

103

98

59

57,5

43,5

42

34

I

90

88

55

52,5

40,5

39

43

II

98

90

56

50

37

35

43

II

94

85

58

50

41

38

45

III

100

90

61,5

56,5

51

48,5

46

III

110

101

63

60

49

40

46

III

105

100

63

60,5

50

47,5

46

III

101

105,7

59,5

54,5

44

43

47

IV

120

110

67

60

47,5

45

54

IV

62

61,5

53,5

53

40

39,4

Throcanteric Circumference After Treatment

Gluteal sulcus Circumference Before Treatment

Gluteal sulcus Circumference After Treatment

Popliteal fossa Circumference Before Treatment

Results of the circumference measurements before and after treatment 88

Popliteal fossa Circumference After Treatment

a) Before the treatment

b) After the treatment

Ultrasound scanning: reduction of hyperechogenicity and thickness of the adipose tissue in the same patient after the treatment:

Enhancement of elasticity and skin toning

A) prima del trattamento a) Before the treatment

B) dopo il trattamento b) After the treatment

For more information:

“Efficacia e tollerabilità della risonanza elettromagnetica armonica. Studio preliminare con sistema non invasivo per il trattamento della P.E.F.S.” M.C. Fortuna, V. Garelli, C. Maxia, A. Iorio, M. Gerardi, F. Di Gregorio, A. Rossi Università La Sapienza di Roma, Università Cattolica del Sacro Cuore di Roma.

Hi.Tech Dermo 2012

89

Researches carried out in collaboration with universities, hospitals and medical studies, confirm TECAR CRV as successful device in aestethic dermatology treatments, such as:

Face

Body

Facial Lifting

Cellulite

Hyperpigmentation

Muscle toning

Skin rejuvenation

Localized adiposity

Skin revitalization

Rejuvenation

Eyes contour

Breast firming

Cheekbones

Skin blemishes

Lips

Culottes de Cheval

Neck Androgenic alopecia

Mathematical Interpretation In the graph have been analyzed the data resulting from the clinical trial of TECAR CRV in the treatment of facial wrinkles, according to logarithmic trend lines to interpret, on the basis of a mathematical model, the upward trend and the stability over time of the results observed.

As evident data, came up that the effect of TECAR CRV biostimulation (red line), even if it has a slow start in the initial phase (axis of x), determines, with the passing weeks, a better growth in terms of effectiveness (axis of y), maintaining the results for over six months after the last treatment.

Efficacia

10

Log. BOTOX

8

Log. FILLER 6

4

2

0

-2 1ª

3ª

5ª

7ª

9ª

11ª

13ª

15ª

17ª

19ª

21ª

23ª

25ª

Settimane

TECAR CRV reaches and maintains maximum comfort to the patient thanks to the impedance meter system that monitors, adapts and stabilizes the energy signal.

It is designed to adapt in real time the changes of the tissues crossed.

90

The Winning Answer Treatment for edematous and fibrotic cellulite, and localized adiposity

Before the treatment: Edematous cellulite with water retention; the hypotonic tissue has a swollen and spongy aspect.

After the treatment: The excess liquids have been drained and the tissue is visibly healthier and firmer. The excess fat is disappeared.

Before the treatment: Localized adiposity and tissue laxity.

After the treatment: 10 sessions with SIN method.

91

Scientific Publication S. Colaiuda, C. Capogrossi, M.C. Fortuna, F. Colaiuda, A. Rossi “Trattamento non invasivo del melasma - Utilizzo di un sistema di veicolazione transdermica a rilascio rapido” Pubblicato su: Hi.Tech Dermo 2/2010 Relazione presso: XXXI Congresso Nazionale SIME, Roma 7-8-9 maggio 2010 S. Colaiuda, C. Capogrossi “Trattamento non invasivo delle iperpigmentazioni con sistema Endosit” Relazione presso: 12° Congresso Int. di Medicina Estetica, Milano 14-16 ottobre 2010 S. Colaiuda, C. Capogrossi, M.C. Fortuna, F. Colaiuda, A. Rossi “Trattamento non invasivo del melasma con sistema di veicolazione transdermica a rilascio rapido” Relazione presso: Congresso “Acne Day”, Milano 22-23 ottobre 2010 A. Rossi, M.C. Fortuna, A. Iorio, E. Scali, P. Greco, F. Colaiuda, D. Bianchini UOC di Dermatologia, Sapienza Università di Roma “Trattamento dell’acne mediante utilizzo di radiofrequenza e veicolazione transdermica di un fitocomplesso”

Scientific Publication Dott.ssa M.C. Fortuna, Dott. A. Rossi “Trattamento non invasivo delle rughe del volto con sistema di veicolazione transdermica a rilascio rapido” Relazione presso: XXXII Congresso Nazionale SIME, Roma 6-7-8 maggio 2011 A. Rossi, M.C. Fortuna, A. Iorio, E. Scali “Trattamento non invasivo delle rughe del volto con sistema di veicolazione transdermica a rilascio rapido” A.Rossi, F. Colaiuda, M.C. Fortuna, P. Greco, E. Scali, A. Iorio, Università degli Studi di Roma “La Sapienza” Dip. di malattie cutanee e veneree e chirurgia plastica ricostruttiva Dir. Stefano Calvieri “Trattamento non invasivo delle striae rubrae - Sistema di veicolazione transdermica a rilascio rapido” Pubblicato su: Hi.Tech Dermo 5/2012 A. Rossi, M.C. Fortuna, F. Colaiuda, E. Scali, P. Greco, A. Iorio, V. D. Mandel, V. Garelli Università degli Studi di Roma “La Sapienza” Dip. di malattie cutanee e veneree e chirurgia plastica ricostruttiva Dir. Stefano Calvieri “Trattamento non invasivo delle rughe del volto - Sistema di veicolazione transdermica a rilascio rapido” Pubblicato su: Hi.Tech Dermo 6/2012

Company Mission The wellness industry The physical wellness is a human need that determines the quality of social life which each person belongs to, and it is a status symbol for many. It is identified with health, it is shown with the outward appearance and is everything that surrounds us. The more the social class has evolved both intellectually and economically, the more grows the wellness need in men and women.

Wellness necessities create and diversify the market Society imposes some rules creating inevitably specific and different kind of needs, from medicine to sports and social. Our know-how leads us to take mainly care of the physical recovery phase, dealing with many needs: among the most impellent, there are pain and blemishes that represent a very important part of it.

Our guideline is the achievement of the result eliminating the invasivity and making it accessible to the most.

Winform operates its Business to Business and Business to Consumer activity, optimizing the work of the expert by creating a marketing on large-

94

95

We differentiate from the others for innovation and performance Winform designs and realizes its own medical devices, both electronic and pharmaceutical. It conducts reasearch activity in collaboration with universities and hospitals to ensure the suitability of the product.

The treatment protocols are the result of clinical evidences that take into account cellular stimulation in chemical, energetic and mechanical phases. All physical principles have been studied and developed for medical cicatrization purposes.

We believe that the disease represents the market and the most appropriate therapy is the one that meets the needs of the individual.

Nowadays, the bigger request is the best result with the less invasivity in the cheapest way possible.

It is suitable for everyone and for this reason it is a competitive product: increasing the profitability and differentiating from the competitors. The indications and contraindications are requirements of both values.

It is necessary to quantify and control the energy produced in real time and optimize the cellular stimualtion, in order to obtain the desired performance: this determines the patient safety.

The exclusivity is determined by the therapeutic synergy simultaneously applied.

It represents the most suitable medical strategy in order to establish a balance between the chemical and mechanical energy action required by the cell.

96

We compete with therapeutic protocols available to the marketing providing method exclusivity to our customers.

97

Numbers of the Physiotherapic branch The not-invasive value Even more people decide to treat themselves in a not-invasive way: in order to have some estimates about the not-invasivity, it is sufficient to think that in Europe, this kind of market, has produced 958.5 million euros in 2010.

The same study estimates that this amount will reach 1350.5 million euros in 2017.

98

The branch “Wellness and Personal Care“ produces 5.5 billion euros every year. Among these, 2.2 billion euros come from fitness and sport.

Only in pharmacy, Italians spend 515 million euros every year for muskuloskeletal apparatus therapies.

Chronic Pain • 18,72 billion euros every year: national estimate of the annual expenditure to control the chronic pain; • On European scale, it is estimated about the 1.8/2% of the GNP; • It affects 13 million people in Italy, 56% are women; it is at the second place of the causes for absence from work; • The 53% consults 2 or 5 doctors before starting a specific therapy; • In cases of long persistence, the 50% of patients suffer of reactive depression and the 40% of anxiety disorders; • Drugs for pain management with related contraindications are swallowed by: • the 25% of patients in the South of Italy; • the 42% of patients in the Centre of Italy; • the 52% of patients in the North of Italy; • The 68% of pain prescriptions are due to FANS.

Rheumatology • 20 billion euros every year: estimate of the purchase for Rheumatology therapies (the 2/3 are at the expense of the patient and the 1/3 is at the expense of the National Health Service); • 5 million Italians suffer of it (300 million people in the world); • According to ANMAR (National Association of Rheumatic Diseases) 750.000 people are affected by chronic diseases and more than 3 million suffer of arthrosis; • The 78% are women and it is the fourth reason of disability for females; • The 60% are the elderly, 1 out of 4 is a person under working age.

Inflammations • 1 billion every year: national estimate of anti-inflammatory purchase in pharmacy; • The 84,7% of the prescriptions are for anti-inflammatory (FANS); • The average turnover for each pharmacy due to inflammations is 53.790 € every year.

Edema/Lymphoedema • Between the primary and the secondary (e.g. trauma) lymphoedema, the former affects the 10% of people and the 20% of cases is due to genetic factors; • The 80% of cases, appears before 35 years; • According to the National Health Service, the economic evaluation of this kind of pathology is from 1.100 to 1.300 € per person.

Ankle Sprain • • • • •

It is the most recurring musculoskeletal trauma of the lower limb; Every day, there are 5.000 ankle sprains in Italy; It causes a chronic dysfunction in the 30% of cases and frequent recurrent; More than the 20% come from sport traumas; Sports in which ankle sprain is more recurring than the others are: • Volleyball: 56% of traumas; • Basketball: 55% of traumas; • Football: 41% of traumas; • Endurance running: 40% of traumas;

99

Muscle strains • Incidence in sport activities: from 30% to 40% of traumas; • The 60% are football traumas.

Calcifications • Only in the 30% of cases, the shock wave has a positive effect, without exclusion of hematoma with the risk of growth of intramuscolar bone tissue; • Thousands of patients in Italy are treated with EDTA (in the last 25 years): • Disease regression in the 51% of cases; • Important enhancement in the 25% of cases; • Considerable improvement in the 15% of cases; • In the remaining 10%, there is a slow enhancement but always without contraindications.

Tendinitis e Tendinopathies • The average cost for a therapy starts from about 250 €; • In the 97% of cases, the tendinous degenerations are due to the continous repetition of micro-traumas (manual works are the main cause); • Women between 40 and 50 are the mainly affected: 41% housewives and 19% secretaries; • Tendinitis due to sedentariness increase annually (tendinitis caused by the computer mouse).

Calcaneal Spur • It affects mainly men after 40; • Only the 20% of people do not complain any pain and can live with this abnormality; • The remaining 80% often spends years to find a suitable solution.

Hernia • It is among the most widespread trouble in Italy; • More than 30.000 patients are operated for lumbar disc herniation every year in Italy: 50 people out of 100.000; • The magnetic resonance, reveals a lumbar disc herniation in more than the 20% of patients under 60 without symptoms; • More than the 90% of patients with disc herniation gets better with a conservative treatment; • People at risk are: • Athletes (hernia due to sport activity), the 50% of athletes who suffer of this pathology suspend the sport activity; • Those who do heavy labors: the 24% of workers suffer of backache and a similar percentage suffers of muscle troubles; the 50% of pre-retired people have back troubles; • People who are over-weight, and even more who is in obesity condition (in Italy, the 10.1% of the overall population suffers of obesity) • People who carry on sedentary activities for many hours a day and in wrong positions, causing many micro-traumas for the back.

100

101

Numbers of the Aesthetic branch The not-invasive value Even more people decide to treat themselves in a not-invasive way: in order to have some estimates about the not-invasivity, it is sufficient to think that in Europe, this kind of market, has produced 958.5 million euros in 2010.

The same study estimates that this amount will reach 1350.5 million euros in 2017.

(Ricerca “Western and Eastern European Ultrasound Market� di Frost & Sullivan).

â‚Ź 102

Cellulite • 161 million euros in Italy: UNIPRO quantification for products consumption in 2010, retail prices, VAT included; treatments for massage and liposunction are excluded; • 14 million of women have cellulite in Italy (ISTAT estimate); • According to “Pharma Retail”, the anti-cellulite products “do not have crisis”; • It is the most troublesome beauty problem for the 80% of women; • It is the most important beauty problem among the body products with an annual growth of the 17%.

Edema / Lymphoedema • Between the primary and the secondary (e.g. trauma) lymphoedema, the former affects the 10% of people and the 20% of cases is due to genetic factors; • The 80% of cases, appears before 35 years; • According to the National Healt Service, the economic evaluation of this kind of pathology is from 1.100 to 1.300 € per person.

Stretch marks • 18 million women are affected in Italy (post-pregnancy); • 8 million men are affected in Italy; • Each session of professional treatments cost around 200/300 €.

Wrinkles (skin aging) • 1.1 billion dollars is the world turnover for dermal fillers; • 593 million euros in Italy: UNIPRO quantification for products consumption in 2010, retail prices, VAT included; professional treatments are excluded; • Consumption growth rate: 3% annual; • Starting age of anti-aging products (first signs of appearance): 24-25 years for women whereas the number of men is increasing.

Alopecia / Baldness • 66 million euros in Italy: UNIPRO quantification for “lotions and shock-tratments for hair“ products consumption in 2010, retail prices, VAT included; professional treatments excluded; • It affects mainly men.

Melasma • 15 million euros in Italy: UNIPRO quantification for “depigmenting“ products consumption in 2010, retail prices, VAT included; professional treatments excluded; • It affects mainly women.

Acne • 92 million euros in Italy: UNIPRO quantification for products consumption in 2010, retail prices, VAT included; • For persistent cases, the treatments cost from 100 to 700 €; • The 90% of teenagers are affected; • Increasing of acne-affected under 20.

Obesity • • • •

Percentage of obese people: the10.1% of the overall population; Men are more obese: the 11.1% are men and the 9.2% are women; During the period 2001/2009, the trend is increased: from 8.3% to 10.1%; Obesity is prevalent in the South of Italy: the 11.1% in the South and on the islands; in the Centre 9.6% and in the North 9.7%; • Obesity is prevalent in inverse proportion according to the familiar social class: around the 12% affects the underpriviledged, the 8% affects the middle-high and high class.

103

Enhance your profit Winform Service Portal Winform informs its customer about the new technologies in physiotherapy, orthopaedic and dermo-aesthetic field with the related procedures and solutions in order to direct the customer to the closest centre, Yours.

To be an exclusive Winform partner means to increase considerably the number of performance and the profit.

Ask for your Winform Business Card.

Your Centre Via Garda, 6 20100 Milano (MI) www.winformweb.it

Your Centre Via Garda, 6 30010 Venezia (VE) www.winformweb.it

Your Centre Via Garda, 6 80100 Napoli (NA) www.winformweb.it

Your Centre Via Garda, 6 00100 Roma (RM) www.winformweb.it

Your Centre Via Garda, 6 09100 Cagliari (CA) www.winformweb.it

Your Centre Via Garda, 6 90100 Palermo (PA) www.winformweb.it

104

Increase your turnover with the service “Online Visibility” “Business to Consumer”, an efficent model.

Winform marketing has led to a staggering increase of the label visibility with a consequent growth in contacts with the consumer, Your source of income.

Winform is a suitable reference for the customer who is looking for the solution for his own pathology.

Winform wants to share this important database with Business and Health Workers customers, and create profititability for our best business partners.

How does “Online Visibility“ work?

Online Visibility is an exclusive service furnished by Winform that allows the private user to find out the most suitable representative centre with the geographic search engine.

If you are a health worker and you have asked for the service “Online Visibility“, your business will appear inside the geographic area indicated when signing up.

How can you get “Online Visibility”

Log In and Sign In in the portal www.winformweb.it

Verify that the data filled in the “Profile settings“ are coherent with your business: company name, address, phone number, will be published through the geographic search engine; after that, click on “Confirm Changes“ button.

Click on the link “Online Visibility“ and then on the button “Ask for your Online Visibility“.

A confirming mail will guarantee the activation of the service. * Check in the page “The best centres“ that the result is coherent with yor business, otherwise change the data you have filled in “Account Settings“. *The service is able for Health Workers.

The activation of the servce is allowed only after Winform Srl check.

105

Company Profile Winform is a projecting, manufacturing and commercializing company of medical devices established nearby Venice more than 20 years ago.

Winform is specialized in the development of biomedical technologies and is integral part of a group of sociaties that operate in pharmacological and industrial field with more than 100 employees. It commercializes its products in 12 countries and 3 continents.

Nowadays, Winform is a reference company in orthopaedic rehabilitation and aesthetic medicine with more than 6.000 satisfied customers.

Winform has a production of 40.000 electrostimulators, 1.000 power Laser YAG, 2.000 transdermal delivers, 10.000.000 phytocompounds and 1.000 diathermic endosit methods.

All of this, allows the company to technically and economically compete in the actual and future market, giving business guarantee to all its customers and partners.

106

Winform is a projecting, manufacturing and commercializing company of medical devices established nearby Venice more than 20 years ago.

Winform has a high quality company system and is certified: EN ISO 13485 : 2012 EN ISO 9001: 2008

107

Winform is the first Italian company that organizes university courses based on transdermal delivery mode with ENDOSIT, TECAR, LASER YAG HIGH DOSE in collaboration with the European University of Rome, UniversitĂ la Sapienza, and Bologna University, both for physiotherapy and dermatology.

Our research centre collaborates with several universities and medical centres in order to improve the mode of interaction with the organism in chemical, energy and biomechanical field, combining biology and clinical medicine.

Only in the recent few years, Winform has invested more than 1.000.000 euros in reasearch.

Some of our partnership in research are: Dermatology Department of La Sapienza University in Rome Sport Medicine Department of Pisa University.

For the future, the company wants to increase the research in orthopaedic rehabilitation and dermatology with aim to chronic pathologies.

The company will shortly complete the technological development that comes from 4 years of studies in urology and veterinary medicine.

Our partners are:

Fornitore Ufficiale FIPAV

Our partners in research are:

Index Multimedial Antology

pag. 01

Energy applied to registered therapeutic processes

pag. 02

What is Transdermal Delivery Mode

pag. 04

What is the Pressure Shock Wave method

pag. 06

What is TECAR mode

pag. 08

W hat is SIN mode

pag. 10

TECAR SIN

pag. 12

SIN Shock Wave

pag. 14

TECAR CRV

pag. 16

BIO Foresi

pag. 22

TECAR 905

pag. 24

TECAR BOX

pag. 26

Range of Diathermy and Multifunction Devices

pag. 28

What is Laser High Dose method

pag. 30

Laser biological effects

pag. 32

Laser YAG 3 Chronic Sport

pag. 40

Laser YAG 2 Chronic Sport

pag. 42

Laser YAG Therapy One

pag. 44

Range of Lasertherapy devices

pag. 46

E-SIT

pag. 48

Ultrasound WS2 Therapy

pag. 50

The Skin

pag. 52

Phytocompounds

pag. 54

Scientific Research

pag. 70

Company Mission

pag. 92

Numbers of the Physiotherapic branch

pag. 96

Numbers of the Aesthetic branch

pag. 100

Enhance your profit

pag. 102

Company profile

pag. 104

www.winformweb.it

Cod.CATWFE2016_rev0 del 16/03/2016

Pictures of products are purely indicative. WinForm reserves the right to upgrade and to make changes to its products as needed.

Medical Engineering Srl 30027 San DonĂ di Piave (VE) - Italy - Via Garda, 6 T. +39 0421 222026 F. +39 0421 225314 info@winformweb.it

www.winformweb.it

Fornitore Ufficiale FIPAV
