S.S HANDRAIL
20MMØ S.S PIPE
40MMØ S.S BALUSTER
20MMØ S.S PIPE
50 20 20
DETAIL OF SS HANDRAIL
50MMØ S.S HANDRAIL
40MMØ S.S BALUSTER IN ALTERNATE TREAD
20MMØ S.S PIPE
TREAD FINISHED WITH POLISHED GRANITE STONE SLAB
POLISHED GRANITE STONE SLAB
3NOS,10MMØ MS BOLT COVERED WITH SS CAP TO FIX BASE PLATE TO BRICK STEP
40MMØ S.S BALUSTER
100MMØ 8MM THK. SS BASE PLATE
DETAIL OF BASE PLATE
TREAD FINISHED WITH PRE POLISHED GRANITE STONE SLAB
10MM X 10MM NON SLIPPERY 'V' GROOVE
RISER FINISHED WITH POLISHED GRANITE STONE SLAB
NON SLIPPERY GROOVE DETAIL
50MMØ S.S HANDRAIL
40MMØ S.S BALUSTER IN ALTERNATE TREAD
20MMØ S.S PIPE
100MMØ 8MM THK. SS BASE PLATE FIXED WITH 3NOS OF BOLT WITH SS CAP
100MMØ 8MM THK. SS BASE PLATE FIXED WITH 3NOS OF BOLT WITH SS CAP
20MM THK. CEMENT MORTAR
RCC WAIST SLAB AND BRICK STEP
DETAIL OF STEPS
DETAIL OF FIXING BALUSTER ON TREAD
TOILET FITTING LAYOUT
