Architecture | Design | Imagine

PORTFOLIO

S chool of P lanning and A rchitecture New D elhi

VIJEET SHAH

VIJEET SHAH

He/Him

Student

School of Planning and Architecture Delhi SPA Delhi

A curious student of life who likes to explore, create and A believer in creating a positive impact on society and the environment by virtue of design, management and teamwork.

E-mail : shah.vijeet.design@gmail.com

Linkedin : vijeet-shah-design

School of Planning and Architecture, New Delhi

WORK EXPERIENCE

A Plus Design Associates

Internship

Worked on Design and development of Houses, High rise apartments, Retail malls, Factory layouts. Working drawings and 3d visualization for multiple projects

EDUCATION

Pursuing Bachelor of Architecture

4th year

School of Planning and architecture Delhi

Rank 5 in a batch of 120 students

CGPA : 8.64

India Canada Research Studio Collaborative (ongoing)

School of Planning and architecture Delhi, Laurentian University Ontario

Summer Semester joint design exercise

XII grade CBSE : 96.2% Gold Medalist

Delhi Public School, Noida

German Course in Hanover, Germany Sponsered

Goethe-Institut

WORKSHOPS & COURSES

India Canada Research Studio

Laurentian University Ontario

Summer Semester joint design exercise

Regenerative processes

Ar. Gaurav Shorey, Ms. Shamita Chaudhary

Urban Landscape Architecture

Elective

Designing with Bamboo

Elective

RESEARCH

Urban Biodiversity regeneration

Seminar 2022

Guide : Ar. Soumya Uttam

Analysing the effects of colour in Public Spaces

Guide : Thomas Pegu

Studying the use of Cob as a sustainable Passive Building material

Guide : Prof. Bandana Jha

ACHIEVEMENTS

2021 - 22

Co-ordinator - SPAkriti Installation Society

Managed the designing and creation of various installations and interactive sculptures at SPA Delhi. Position held for 1 year.

Top 10 - HUDCO Trophy

NASA India

Low cost Housing in Bamboo

Runner up - Rethinking Prisons

Arch8 competition

Volunteer - NASA India Annual Convention

Part of managing team in convention 2020 at Bangalore, India

Shortlisted - ANDC Trophy

NASA India

Gold Medal - XII Grade

DPS Noida

For being a scholar for 7 consecutive years

German Workshop in Germany

Goethe-Institut

Selected by school to attend

SKILLS

Team Management

- NASA Convention - SPAkriti society Head

Creative Thinking, Conflict Resolution, Time Management

Autodesk Autocad

Autodesk Revit

Adobe Photoshop

Adobe Illustrator

Sketchup 3D

Rhino 3D

Lumion Rendering

Ladybug analysis

Microsoft Office

English

Hindi

German

2019 Present 2021 2022 2017
2022 2022 2022 2022 2022 2021 2020 2022 2021 2020 2021 2019 2017
Software
Soft Skills
Language
ART AND CRAFT CENTRE
India
TOWER AND RETAIL Gurgaon, India RESIDENCE Delhi, India BUS STOP India CENTRE FOR EXCELLENCE Hyderabad, India INTERNSHIP WORKS Noida, India MISCELLANEOUS MIND MAPS 01 02 03 04 05 06 07 08
Delhi,
OFFICE

HUNAR CRAFT CENTRE

CULTURAL ARCHITECTURE

Location: Delhi, India

Semester 4

Guides: Prof. Jatinder Kaur, Ar. Suparna Ghosh

Site area 12700 m2

Floor area 4730 m2

Located at the Heart of Delhi, Hunar Craft centre aims at reviving dying crafts in India by teaching and propagation. Deriving its design from the mughal architecture of Delhi, the centre is a catalyst for public activities and for practicing unique crafts in Workshops and exhibits.

A museum for these dying crafts, a cafeteria, the worshop spaces are planned along the lines of Old Delhi, with numerous courts and paths connecting them.

Public Space History Inspired planning Biophilia Passive Cooling Techniques 01 1 2 3 4 5 1. Site approach 2. MG road 3. DTC Office 4. Old Delhi Historic Fort wall 5. Cricket Stadium

Reminiscent of its glory in the Mughal Era, Shahjahanabad stands today decaying and 'modernized'. This design aims at portraying what the streets and chowks of Shahjahanabad once were, learning from planning and techniques of vernacular sustainability.

By analysing tombs, gardens and city planning a deep understanding is developed to create a series of open, semi open and closed spaces that impart climatic and visual appeal

Shahjahanabad City Plan ca. 1800 AD

ANALYSIS OF HISTORIC DESIGN

Circulation

Two orthogonal, Decentralized paths to have larger open spaces

Taj Mahal

Open - Close

Shifting Focal built mass to corner

HISTORY MEETS PRESENT
* not to scale
Taj Mahal Humayun Tomb Humayun Tomb Akshardham Akshardham Applied Applied

Understanding street and building scale for a small area, for the quality of sunlight received, public activities and different spaces - verandahs, jharokhas etc. - and planning clusters accordingly in the craft centre.

FORM DEVELOPMENT

Learnings from historic design were applied along with other concepts/strategies to arrive at the final form and campus planning.

Axes

from history learnings

Playing with levels and voids to evolve into a dynamic space

Water axis Green axis

Creating a landscaped Charbagh mughal garden

derived Placing forms around the central court
CRAFT MUSEUM DROPOFF PARKING CRAFT MUSEUM CRAFT MUSEUM GIFT SHOP MUSEUM COURT SUNKEN COURT RAMP DN TO EXHIBIT AMPHITHEATRE WORKSHOP WORKSHOPS COURT SITOUT SPACE WORKSHOPS COURT WORKSHOP WORKSHOP WORKSHOP WORKSHOP WORKSHOP CAFETERIA UP ADMIN EXHIBITION EXHIBITION RAMP UP 1:10 EXHIBITION BELOW
PLAN 0 5m 10m 20m 50m
GROUND FLOOR

- A vault roof decreases solar gain in Summer and increases it in Winter.

MUTUAL SHADING - No external shading device required as buildings shade each other

EVAPORATIVE COOLINGWater bodies placed near buildings cool down the interiors as well as open

SITOUT
Passive cooling techniques were applied to the built and open spaces,
VIEW OF EXHIBITION COURT

CENTRE FOR EXCELLENCE

STARTUP HUB, EXPOSITION CENTRE

Location: Hyderabad, India

Semester 5

Guides: Prof. Sugga, Ar. Amardeep

Total area

14400 m2

Coworking & learning 6600 m2

Entertainment area 7800 m2

Part of a competition held by the Telangana government, the Centre for Excellence aims at developing an Ideation and Creative hub for the city of Hyderabad. The design, based on concepts of sustainability and activity centric design, takes nature and people to mutually exist in a series of inspiring spaces.

Public Space Water Conservation Interactive spaces Unbound spaces 02
1 2 3 4 5
1. Rajendrnagar Road 2. Kismatpur Road 3. Musi River 4. temple 5. Water Institite

LEVELS FOR ACTIVITY

The Site has a downhill profile with a maximum level difference of 20m across. Utilizing the natural terrain of the site, and analysing slopes and water flow, levels were created, each activated publically by a function or space spilling into it

The idea was to create one continuous form broken into fragments for easier circulation and better response to the Terrain

One continuous form with Courts between

Large court near Exposition and Auditorium to accomodate quantum of people

Fragmenting for circulation and mutual shading

Terraces, greens and water bodies for enhanced experience and sustainability

542 m Site Terrain 522 m
EXPOSITION HALL 1 EXPOSITION HALL 2 EXPOSITION PLAZA ENTRY PLAZA FOOT PATH CYCLE PATH RAJENDRANAGAR ROAD AUDITORIUM CAFETERIA ADMIN F&B F&B SPILLOUT SPILLOUT POND AMPHITHEATRE DROPOFF GROUND PLAN

LANDSCAPED TERRACES

Using natural contours to create levels, and leaving existing vegetation undisturbed.

MUTUAL SHADING

Applying the vernacular concept to create shaded, usable open spaces for the people.

BRINGING OUTDOORS CLOSER

Having no physical barrier for landscaping in breakout spaces around the incubation and Exposition.

WATER CATCHMENT

Contours were analysed to place catchment ponds, thus preventing runoff and flooding from rainwater.

CONCEPTS IN SECTION
LIBRARY SPILLOUT POND POND SPILLOUT INCUBATION HUB DROPOFF SPORTS 0 50m 25m 100m
VIEWED FROM F&B OUTLET
LIBRARY

Vehicular circulation is kept minimum at ground level. The Dropoff for exposition and Auditorium is created at the Basement level, connected above by stairs and lifts.

This creates a sunken court, hiding the parking by trees and landscape.

Exhibition Gallery SECTION AA'
SECTION AT EXPO DROP-OFF
SECTION BB' Basement Parking Basement Drop-off Amphitheatre Cafeteria Expo Entry Court Exposition space Incubation Spill-out SUNKEN DROP-OFF

Incubation Hub

Incubation Spill-out Catchment pool

Sports facilities

CAFETERIA TERRACE

The positioning of the cafeteria places it in the middle of the site, easily accessible from the Exposition as well as the incubation hub.

The exhibition galleries on level one of the expo look out into the landscape terraces, connected throught the cafe.

SECTION AT EXPO AND CAFE
Skybridge from incubation to Library Green Break-out spaces
A B' A'
0 50m 25m 100m
AMPHITHEATRE, EXPOSITION AND AUDITORIUM

Location: Gurgaon, India

Semester 6

Guides: Prof. Sugga, Ar. Amardeep

Total area 30340 m2

Commercial area 21600 m2

Residential area 8740 m2

Situated at the transit-oriented Development Zone of a major commercial hub in Gurgaon, India, this project aimes to create an interactive public and commerce centric design integrating both concepts in a series of plazas and voids with vibrant atmospheres. A sense of playfulness is brought through with levels, seating and stairs and greens.

03
Public Space Colour Psychology Biophilia Green systems 1 2 3 4 5 6 1. Site approach 2. Green Belt 3. Dwarka expressway 4. Internal Road 5. Residential area 6. Commercial area

Retail spaces, historically, were the focal point in a city, hubs of public activity and celebrations. Modernism commercialized these hubs and constricted public along one predefined path doing only one activitywalk.

This design aims to bring back the relationship of retail and public through mixed use zoning and rethinking retail circulation.

Creating connections and Retail zones for easy access and viewability of shops

Generating interest though paths to make circulation energetic and shaping blocks accordingly

Stacking volumes in 3d such to create terraces and open break out spaces

Creating public spaces and walks on each floor

Placing the high rise to the West to reduce heat gain at lower floors

Narrow floor plates to have ample daylight penetration and orienting North-South for glare-free Sunlight

Defining Office and Residential with Common Terrace for recreation

Wrapping a second porous skin on 3 sides passively reducing heat gain. North has no Sun or heat gain and thus is kept clear

Designing for vertical Connections and interaction with seamless Plazas between floors at Retail and offices

Retail Block 12000 sq.m. Office Block 9600 sq.m. Residential
8740
A VERTICAL PUBLIC PLAZA
Block
sq.m.
+ +

RESIDENCES

TERRACE

OFFICE SPILLOUTS

Adding a third dimension to planar spillout spaces in the offices

OFFICES

THIRD FLOOR

FOOD COURT,PUBLIC SPACE

SECOND FLOOR

RETAIL

FIRST FLOOR

RETAIL

GROUND FLOOR

RETAIL, PUBLIC SPACE

BASEMENTS

SUPERMARKET, PARKING

FOOD COURT TERRACE

Making the Food Court seating interactive by adding steps, also serving as an amphitheatre

PUBLIC PLAZA AT GROUND

Greens, vibrant colours, seating and the presence of people make the ground floor the most happening space

UP UP FROM B1 UP FROM B1 PUBLIC PLAZA SHOP SHOP SHOP SHOP SHOP SHOP SHOP SHOP SHOP SHOP SHOP AHU FIRE STAIRCASE FIRE STAIRCASE WASHROOMS DROPOFF DROPOFF PEDESTRIAN ENTRY ENTRY TO PARKING -4500 MM ± 00 MM DOWN TO B1 UP DN GREENS GREENS GREENS GREENS GREENS LANDSCAPED STEPS LANDSCAPED STEPS CABIN LIFTS DN SHOP SHOP UP UP UP DN DN DN AHU SHOP SHOP SHOP SHOP SHOP SHOP SHOP SHOP SHOP SHOP SHOP 2 6 1 4 3 3 GROUND FLOOR PLAN FIRST FLOOR PLAN 0 0 5m 5m 10m 10m 20m 20m 50m SHOP
1. Vehicular Entry 2. Pedestrian Entry 3. Vehicular Exit 4. Vehicular Ramps 5. Main Road
SHOP SHOP SHOP SHOP FIRE STAIRCASE DROPOFF ± 00 MM DOWN TO B1 UP DOWN TO SUPERMARKET DN UP UP UP DN DN DN AHU LOBBY LOBBY GREENS LANDSCAPE STEPS LANDSCAPE STEPS KIOSKS KIOSKS SEATING FOOD OUTLET FOOD OUTLET FOOD OUTLET FOOD OUTLET FOOD OUTLET RESTAURANT RESTAURANT 1 5 4 3 THIRD FLOOR PLAN
6. Internal Road
+5500MM +11000MM +16500MM +22500MM +26500MM +70500MM +76500MM +102500MM +116000MM SECTION SECTION AT ENTRY TO SUPERMARKET SECTION AT LANDSCAPED COURT Steps to Supermarket Drop off Lifts Landscaped Court Pedestrian Plaza 0 5m 10m 20m 50m 0 10m 5m 20m

PLANTER COURSE

LANDSCAPE STEPS

GREEN FACADE

STEEL WIRE MESH

M.S. BOX SECTION FRAME

75 X 150MM

SEATING ALONG PLANTER

COMPOSITE BEAM 450 X 450MM I GIRDER IN RCC

COMPOSITE SLAB

FALSE CEILING

LANDSCAPING

SUNKEN SLAB

Based on the surroundings and context, the user groups were first identified as - single occupant, couple, small family/high income couple. Accordingly 3 residential units were designed to meet the lifestyle and needs of the users.

DAYLIGHTING ANALYSIS

It was found that the East and West directions have direct sunlight penetration and would impact the climatic comfort of occupants. South too has some degree of heating from direct radiation.

Having a skin on the South, East and West reduces the heat gain drastically, passively cooling the spaces inside. North remains open as there is no direct heat gain from there.

RESIDENTIAL WING
Family unit base floor
63 sq.m.
Exploded Isometric conceptual massing Typical Floor plan 2
Circulation Core Single Unit Couple Unit Family Unit
20
Couple
63
Single
38.6
Typical Floor plan 1
Family unit Loft floor
sq.m.
unit
sq.m.
unit
sq.m.

POLYCHROMA BUS STOP

PUBLIC TRANSIT NODE

Location: India

Semester 5

Guides: Prof. Sugga, Ar. Amardeep

The brief was to rethink the purpose and functionality of a bus stop and create a versatile unit that can be used as a model for new age transit nodes anywhere.

Basing the plan on circulation of passengers and integrating e-bike stands as last mile connection, the bus stop is designed to look minimal and feel light and airy, not disturbing any of its surroundings. It also understands human psychology and colour response in creating a space open for all, providing the city a micro-space for people to use and enjoy.

Renewable
Rainwater harvesting Universal Access Public Node 05
Passive Cooling
energy

ARRIVAL DEPARTURE

GROUND PLAN B A

MOVEMENT PATTERN

Creating an experience based on movement pattern arrival,departure, e-bike.

ROOF

CREATING SPACES

Converging arrival space, quiet enclosed seating

ARTICULATION

E-bikes on the left, ATM/ small kiosk and adding greens to act as a catalyst for public activity

COLOUR PSYCHOLOGY

Arrival - warm, exciting, Departure - cool, calming, E-bike stand - energetic

The Form of the roof stands out as the defining feature. Minimal, Functional. The form opens up to the South to let in Sun in winters and block it out in Summers.

SECTION A

RAINWATER HARVESTING & PASSIVE COOLING

The roof is double layered at certain places creating a void between 2 layers. This void is used for overhead storage for water harvesting , as well as contributing to the passive cooling

The void blocks radiation heat and the presence of water would cool down the microclimate.

SECTION B

SOLAR ENERGY

As most parts of India receive sufficient Sun hours, required for solar energy generation, photovoltaic cells can be installed. These can be place over the roof tanks, thus reducing evaporative losses or heating.

Analysing area and requirements of the bus stop, 10 panels of 2.5 sq.m. each shall be installed.

Section BB’
FORM DEVELOPMENT
+4850MM +4050MM +3000MM +2350MM +450MM ±00MM +4850MM +4250MM +3000MM +2350MM +450MM ±00MM ATM ARRIVAL AREA
ATM/KIOSK
Water Tank +4850MM +4050MM +3000MM +2350MM +450MM ±00MM +4850MM +4250MM +3000MM +2350MM +450MM ±00MM ATM ARRIVAL AREA ATM/ KIOSK Water Tank
E-bike Stand Arrival Court Departure court
and
seating

INTERNSHIP

A PLUS DESIGN ASSOCIATES, NOIDA

MAY 2021 - AUGUST 2021

Architect: Ar. Kailash Aggarwal

Designed residences, manufacturing units, Retail spaces, apartment units and more as part of training. Developed skills of communication with team-mates and clients, developed understanding of site works, management and working drawings

EXPERIENCE

• Teamwork and individual work on various projects

• Worked directly under Principal Architect

• Involved in client meetings and presentations

• Prepared Working drawings and Submission drawings

• Designed a Bungalow from preplanning till construction and interiors.

PROJECTS WORKED ON

• Individual Residences

• High-Rise Apartments

• Row housing

• Commercial malls

• Factories and Warehouses

• Interior Designing

• Drafting on AutoCAD

• 3D modelling and rendering

INDIVIDUAL HOUSING

LVL- 1.50 M LVL+0.750 M LVL+1.80 M LVL+1.80 M LVL +1.20 M LVL +1.80 M LVL +1.80 M LVL +1.65 M LVL+0.0 M LVL+0.300 M LVL+1.200 M LVL ± 0.00 M LVL+1.80 M LVL+1.80 M UP UP LVL- 1.50 M LVL ± 0.00 M UP COMMERCIAL BUILDING - GROUND PLAN

RESIDENTIAL FLOOR PLAN

DN. KITCHEN 3950 X 2865 1925 WIDE BALCONY BEDROOM 4955 X 3485 DRESS 1690 X 2855 TOILET 2535 X 2755 BEDROOM 3365 X 3775 ENTRANCE LOBBY 1825 X 2580 PW.ROOM 1385 X 1480 TOILET 2415 X 2715 BEDROOM 3365 X 3350 1600 WIDE BALCONY TOILET 1740 X 2290 C.B. 1500 WIDE UTILITY BALCONY JACUZZI 1800 X 1800 C.B. BALCONY 6990 X 3835 LIFT CORRIDOR 2450 WIDE LIFT 2005 X 2320 LIFT 2005 X 2320 UP DINING AREA 7235 X 3350 DRAWING ROOM 3650 X 3875 DN. UP LIFT 1970 X 2780 LIFT 2320 X 2780 UP ELECTRICAL SHAFT BEDROOM 4660 X 3350 DRESS 2625 X 1840 TOILET 2825 X 1840 C.B. PUJA ROOM C.B. BEDROOM 3665 X 6380 T.V. LOUNGE 3350 X 6445 TOILET 3065 X 4520 BEDROOM 3350 X 4820 C.B. TOILET 1895 X 2450 1525 WIDE PASSAGE DRAWING/DINING 8830 X 8210 BAR ENTRANCE LOBBY 2560 X 3040 UTILITY 2475 X 2480 1985 WIDE UTILITY BALCONY TOILET 1370 X 1480 PW.ROOM 1400 X 1480 KITCHEN 4240 X 3020 TOILET 2495 X 1555 BEDROOM 4210 X 3150 BALCONY 14285 X 4230 JACUZZI 1800 X 1800 TERRACE GARDEN SAUNA 1500 X 1000 F.H.C. SHAFT LV SHAFT KITCHEN 3950 X 2865 1925 WIDE BALCONY UTILITY 2155 X 2480 BEDROOM 4955 X 3485 DRESS 1690 X 2855 TOILET 2535 X 2755 BEDROOM 3365 X 3775 ENTRANCE LOBBY 1825 X 2580 TOILET 1385 X 1480 PW.ROOM 1385 X 1480 TOILET 2415 X 2715 BEDROOM 3365 X 3350 1600 WIDE BALCONY TOILET 1740 X 2290 C.B. 1500 WIDE UTILITY BALCONY JACUZZI 1800 X 1800 C.B. BALCONY 6990 X 3835 DINING AREA 7235 X 3350 DRAWING ROOM 3650 X 3875 V 10 V 20 V 30 V 40 V 50 V 60 V 70 V 80 V 90 V 100 V 110 V 120 V 130 V 140 V 150 V 160 V 170 V 180 V 190 V 200 V 210 V 220

MISCELLANEOUS

MEASURED DRAWINGMeasuring and documenting Historic Chhatris at Bada Bagh, Jaisalmer. Created Hand drafts and AUTOCAD drawings of Chhatris. Rendered using Pencil Colours.

ELEVATIONS

SECTION
UDAIPUR, INDIA | 16 July 2022

ABSTRACT RENDERING - COMPETITION ENTRY

Honourable Mention

MIND MAPPING

Using Mind Maps to analyse a given situation and space to develop a deeper understanding. This is then used to conceptualize design ideas.

Town Hall

The main Chowk of the city

Chowk

Central open space in a neighbourhood or haveli

Located at the centre of a bustling market, it stands as a unifying element.

Mohalla

A closely knit neighbouhood that has maximum interaction between residents.

Gali

Streets that mutual shade the public space below for activity all day.

Festivals and public gatherings in the city take place at this node.

Red Fort Jama Masjid
Religious Nodes
OLD DELHI MIND MAPPING
Chaukhat

Understanding development in Ahmedabad using a timeline and analysing the vernacular elements of the city.

AHMEDABAD - HUDCO DESIGN TROPHY

Turn static files into dynamic content formats.

Create a flipbook
Issuu converts static files into: digital portfolios, online yearbooks, online catalogs, digital photo albums and more. Sign up and create your flipbook.
Vijeet Shah | SPA Delhi | Architecture Portfolio | 2019-22 by Vijeet shah - Issuu
