Dew Point Transmitter

Dew Point Transmitter Meter is designed to measure the performance of drying systems for air, nitrogen and other compressed gases. This Model is ideal for monitoring medical, commercial and industrial applications including plastics resin dryers, breathing air, pneumatic tools, instrument air, and spraying/coating applications.

It measures dew point by utilizing microprocessor circuitry to convert sensor signal by the use of psychometric equations. Assembled in a rugged hand-held IP- 65 with quick disconnect tubing couplings and an internal sensor manifold. An orifice maintains line pressure for true pressure dew point readings.

Applications:

Special Features:

■

Petrochemicals

■

Analog Output 4-20 mA for Dew Point.

■

Utilities SF6 etc.

■

Condensation Insensitive

■

Compressed Air

■

Fast Adjustment time

■

Medical

■

Pressure Resistant up to 350 bars (Special Version)

■

Nitrogen gas at the time of filling in the Transformers

■

R5485RTU

■

Transportation Aerospace

■

■

Semiconductor

Higher resolution of the Sensor aligned history Graphical data Sensor Diagnosis on site with modbus device.

■

Heat Treating

■

■

Natural Gas

Press we dew point [°Ctd.]

■

Industrial Driers

Temperature [° C]

■

Pharmaceuticals

+Rel. humidity [& RH]

■

Alternative fuels

Moisture content V / V @pmV / V)

■

Military Environment

■

Ozone Generation

■

Freeze Drying

■

Readable via Modbus:

Measurement Parameter

Dew Point

Measuring Units

°C

Measuring Range

(-) 100 °C to (+) 30 °C (-) 80 °C to (+) 30 °C (-)60 °C to (+) 30 °C (-) 40 °C to (+) 30 °C

Display Type

Local LED Display

Sample Temperature

99.999°C

Instrument Type

Field Mounted

Sensor Type

Capacitive Thin Polymer

Sensor Guard

Sintered Stainless steel cap

Sensor Connector

NPT

Analog Output

3 wire 2 wire 4.20 mA (As Customer Requirement

Calibration

Calibration through Software

Response Time(T90)

-20°C to +30°C - 90 Sec -30°C to +20°C - 30 Sec

Measurement Accuracy

± 2%

Load

12 v DC : Max. 100Q, 30V DC: 950Q

Measurement Type

Continuous Measurement

Weight

300m(+50 m) to ether with sensor & Transmitter

External Supply Voltage

Low Power 124V DC (Tolerance 30V)
