Light, Compact, Functional!
The Nuvo Lite is by far the most innovative evolution in our pursuit to provide the absolute best to our customers.
We’ve revolutionised the Nuvo by making it lighter and more compact, but with more functionality and benefits.
www.nidekmedical.com
Oxygen Concentrator
Light Weight
Oxygen Concentrator
Nuvo Lite 3
230 Volt / 50 Hz
Standard Model Part Number
OCSI Model Part Number (Oxygen Concentration Status Indicator)
935
Average Power Consumption
180 Watts
Oxygen Concentration
90% (+6.5% / -3%) at 3 LPM
Liter Flow
0.125 to 3 LPM
Sound Level
40 dBA typical Outlet Pressure
7.0 PSI
Weight 32 lbs / 14.5 kg
Dimensions
14”W x 9”D x 23”H
36 cm x 23 cm x 58.5 cm
Additional Features:
Lockable Flow Control Valve
Metal Outlet Fitting
Resettable
Circuit Breaker
www.nidekmedical.com
Light Weight 2862
Oxygen
Light, Compact, Functional!
The Nuvo Lite is by far the most innovative evolution in our pursuit to provide the absolute best to our customers.
We’ve revolutionised the Nuvo by making it lighter and more compact, but with more functionality and benefits. www.nidekmedical.com Concentrator
Light Weight
Oxygen Concentrator
Nuvo Lite 115Volt / 60 Hz
Standard Model Part Number
520
OCSI Model Part Number (Oxygen Concentration Status Indicator)
525
Average Power Consumption
330 Watts
Oxygen Concentration
90% (+6.5% / -3%) at 5 LPM
Liter Flow
0.125 to 5 LPM
Sound Level
45 dBA typical
Outlet Pressure
7.0 PSI
Weight
32 lbs / 14.5 kg
Dimensions
14”W x 9”D x 23”H
36 cm x 23 cm x 58.5 cm
Additional Features:
Lockable Flow Control Valve
Metal Outlet Fitting
Resettable Circuit Breaker
Nuvo Lite 230 Volt / 50 Hz
Standard Model Part Number
OCSI Model Part Number
(Oxygen Concentration Status Indicator)
925
Average Power Consumption 300 Watts
Oxygen Concentration
90% (+6.5% / -3%) at 5 LPM
Liter Flow
0.125 to 5 LPM
Sound Level
45 dBA typical
Outlet Pressure
7.0 PSI
Weight
32 lbs / 14.5 kg
Dimensions
14”W x 9”D x 23”H
36 cm x 23 cm x 58.5 cm
www.nidekmedical.com
Light Weight 2862
Oxygen Concentrator
Large Flow Rates at High Pressures
Light
The strongest members of the Nuvo family, the Nuvo 8 and 10 provides large flow rates at high pressures, giving you expanded opportunities to provide for your patients.and benefits.
www.nidekmedical.com
Weight
Oxygen Concentrator
Nuvo 8 115 Volt / 60 Hz
Standard Model Part Number
580
OCSI Model Part Number (Oxygen Concentration Status Indicator)
585
Average Power Consumption 500 Watts
Oxygen Concentration
90% (+5% / -3%) at 8 LPM
Liter Flow
2 to 8 LPM
Outlet Pressure
15 PSIG (1.2 BAR)
Weight 54 lbs / 24 kg
Dimensions
16”W x 16”D x 28”H
39 cm x 40 cm x 71 cm
Additional Features: Built on the Reliable Nuvo Platform
Easy Access to filter and hour meter
Superior Grade of Molecular Sieve
Nuvo 8 230 Volt / 50/60 Hz
Standard Model Part Number
980
OCSI Model Part Number (Oxygen Concentration Status Indicator)
985
Average Power Consumption
490/625 Watts
Oxygen Concentration
90% (+5% / -3%) at 8 LPM
Liter Flow
2 to 8 LPM
Outlet Pressure
15 PSIG (1.2 BAR)
Weight 54 lbs / 24 kg
Dimensions
Spring Mounted High Efficiency Compressor
16”W x 16”D x 28”H
39 cm x 40 cm x 71 cm
www.nidekmedical.com
Light Weight 2862
High Efficiency Compressor
The strongest members of the Nuvo family, the Nuvo 8 and 10 provides large flow rates at high pressures, giving you expanded opportunities to provide for your patients.and benefits.
www.nidekmedical.com
Oxygen Concentrator
Light Weight
Oxygen Concentrator
Nuvo 10 115 Volt / 60 Hz
Standard Model Part Number
OCSI Model Part Number (Oxygen Concentration Status Indicator)
595
Average Power Consumption 700 Watts
Oxygen Concentration
90% (+5% / -3%) at 10 LPM
Liter Flow
2 to 10 LPM
Outlet Pressure
20 PSIG (1.38 BAR)
Weight 54 lbs / 24 kg
Dimensions
16”W x 16”D x 28”H
39 cm x 40 cm x 71 cm
Additional Features: Built on the Reliable Nuvo Platform
Easy Access to filter and hour meter
Superior Grade of Molecular Sieve
Spring Mounted High Efficiency Compressor
Nuvo 10 230 Volt / 50 Hz
Standard Model Part Number
OCSI Model Part Number (Oxygen Concentration Status Indicator)
1005
Average Power Consumption
600 Watts
Oxygen Concentration
90% (+5% / -3%) at 10 LPM
Liter Flow
2 to 10 LPM
Outlet Pressure
20 PSIG (1.38 BAR)
Weight 54 lbs / 24 kg
Dimensions
16”W x 16”D x 28”H
39 cm x 40 cm x 71 cm
www.nidekmedical.com
Light Weight 2862
Oxygen Concentrator
A Reliable Modular Platform
The Max 30 provides up to 30 liters of oxygen per minute and is ideal for small hospitals, laboratories and veterinary clinics.
www.nidekmedical.com
Light Weight
50 PSIG (3.4 BAR)
Weight 200 lbs / 90 kg
Dimensions
24”W x 20”D x 45.5”H
61 cm x 51 cm x 116 cm
Additional Features:
Cylinder Filling Stations
Anesthesia Machines
Small Hospitals
Laboratories
Veterinary Clinics
Recovery Ventilators
Oxygen Therapy
www.nidekmedical.com
Light Weight 2862
Oxygen Concentrator
50 Hz Standard Model Part Number
THE MAX 30 230 Volt /
3005 Average Power Consumption 12 Amps Oxygen Concentration 93% (+ / -3%) at 30 LPM Liter Flow
2 to 30 LPM Outlet Pressure
Oxygen Concentrator
Portable Oxygen Concenrator
Introducing the Nano, a pulsed-dose & battery-operated Portable Oxygen Concentrator (POC) capable of supplying highly purified oxygen for on-the-go users of supplemental oxygen.
www.nidekmedical.com
Light Weight
Oxygen Concentrator
NANO Portable Oxygen Concentrator 100 to 240 VAC 50 to 60Hz
Model Part Number 855
Average Oxygen Content 90% (+6% / -3%) at all setttings
Rechargeable Battery “14.4 VDC Voltage / 6.8Ah Rated Capacity”
Breathing Frequency 10 to 40 BPM
Weight 4.7 lbs / 2.1 kg
Dimensions 8.3”W x 3.5”D x 6.5”H 23 cm x 9 cm x 17 cm
Additional Features:
Light Weight! Take it Anywhere! Easy Touch Button Controls!
Convenient Carrying Bag Included!
www.nidekmedical.com
Light Weight 2862
Flow Setting Flow Setting Battery Discharge (hours) 1 210 3.5 2 420 3.25 3 630 2.5 4 840 2.15 5 1000 1.5
