PORTION CONTROL DEFINED THE DEPOSITORS SERIES
PRECISE PORTION CONTROL MEANS NO PRODUCT WASTE!
UNI-SPRAYER • Dimensions: 13 x 19 inch/ 33 x 48 cm • Interchangeable tips for different products and spray patterns • Independent pressure control for tank and atomizing air; can be used with or without atomizing air • Food grade light and flexible braided hose (1.20 m) • Optional flocker nozzle can spray products with small particulates like jam or marinara • Spray pan release oil, egg wash, milk, simple syrups or sauces Operator dependent Trigger dependent Maximum: 100 psi (6.9 bar) SPEED 5 US gallon (19 liter) tank* PARTICLE SIZEDEPOSIT RANGE AIR POWER Up to 1mm with flocker nozzle HOPPER CAPACITY
Our depositors can help with your cake, muffin and cupcake batters, chunky fillings, soups, stews, ready meals, sauces, delicate mousse fillings as well as pet food and cosmetics portioning. Unifiller prides itself on creating equipment that can be used on any production floor, big or small, with various configurations to suit your needs. BENEFITS: • Automate - eliminate manual effort • Prevent strain and injury • Tool free cleaning for quick change-over • Full washdown for minimal downtime • Stand alone or configure into an automated line • Versatile - use with various attachments BAKERY FOOD
BAKERY BAKERY FOOD FOOD Up to 140 deposits/min. Up to 140 deposits/min. 0.25 oz (7 ml) to 18 oz (530 ml) 0.25 oz (7 ml) to 18 oz (530 ml) 3 CFM @ 80 psi (85 L/min @ 5.5 Bar) 4 CFM @ 80 psi (113 L/min @ 5.5 Bar) SPEED 6 US gallon (23 liter) 6/14 US gallon (23/52 liter) PARTICLE SIZEDEPOSIT RANGE AIR POWER Up to 3/4 inch (19 mm) Up to 3/4 inch (19 mm) HOPPER CAPACITY SPEED PARTICLE SIZEDEPOSIT RANGE AIR POWER HOPPER CAPACITY COMPACT SERIES DEPOSITOR • Dimensions: 38 x 28 inch/ 97 x 71 cm • 5 product cylinder sizes and 2 hopper sizes available • Four machine models - Table Top, Mobile, Powerlift, Dual Compact • Removable depositing table for adaptability • Great for facilities with limited space • Powerlift model has one touch lowering and raising for easy filling ELF 400 — ENTRY LEVEL FILLER • Dimensions: 15 x 26.5 inch/ 38 x 67 cm • Fits conveniently on most tables or counters • 4 product cylinder sizes and 2 hopper styles available; hopper can be ordered as conical or cylindrical • Three different package models or configure to order • Can be quickly disassembled for cleaning in seconds, with no tools
iSPOT DEPOSITOR (DIRECT FROM BOWL)
Dimensions: 29 x 32 inch/ 74 x 82 cm
• 2 product cylinder sizes, optional pail shelf available
• Can be used with a container up to 23 “ (58 cm) depth (up to 80 quart Hobart bowl)
• Equipped with ergonomic hand held nozzle with 5 ft (152 cm) food grade hose, can be fitted with all standard bakery tips
Perfect for depositing relatively viscous liquid products directly from a bowl or pail
DEPOSITOR (DIRECT FROM BOWL)
Dimensions: 32 x 33 inch/ 80 x 82 cm
2 product cylinder sizes, optional pail shelf available
Can be used with a container up to 23 “ (58 cm) depth (up to 140 quart Hobart bowl)
Equipped with ergonomic hand held nozzle with 5 ft (152 cm) food grade hose, can be fitted with all standard bakery tips
Perfect for depositing relatively viscous liquid products directly from a bowl or pail
Up to 120 deposits/min. 0.25 oz (7 ml) to 18 oz (530 ml) 4 CFM @ 80 psi (113 L/min @ 5.5 Bar) SPEED N/A PARTICLE SIZEDEPOSIT RANGE AIR POWER For Smooth Products Only HOPPER CAPACITY Up to 100 cycles/min. 2.4 oz (70 ml) to 36 oz (1060 ml) 4 CFM @ 80 psi (113 L/min @ 5.5 Bar) SPEED N/A PARTICLE SIZEDEPOSIT RANGE AIR POWER For Smooth Products Only HOPPER CAPACITY iFILL
•
•
•
•
•
•
•
BAKERY BAKERY FOOD FOOD
UNIVERSAL 1000i SERIES DEPOSITOR
BENEFITS:
Universal
INCLUDES:
The Universal 1000i is equipped with a unique powerlift that allows for one touch lowering and raising of the hopper for easy filling access and adjustable working height to a desired comfort level without the need for heavy lifting.
• Dimensions: 27 x 60 inch/ 69 x 152 cm • 4 product cylinder sizes available • One turn speed adjustment dial • All food contact parts are dishwasher safe • Tool free, quick cleaning and change-over design • Can be fitted with multiple attachments • Can deposit viscous liquids either with or without chunks • Available as Universal 2000i or Servo SPEED PARTICLE SIZEDEPOSIT RANGE AIR POWER HOPPER CAPACITYELECTRICAL SYSTEM
• Removable depositing table, foot pedal, quick start guide and spare parts kit As a Servo depositor, the
is capable of a wider deposit range with touchscreen controls for recipe storage Up to 140 deposits/min. 0.5 oz (14 ml) to 36 oz (1060 ml) 4 CFM @ 80 psi (113 L/min @ 5.5 Bar) 14 US gallon (52 liter) Up to 3/4 inch (19 mm) N/A BAKERY FOOD
Up to 120 deposits/min. 0.15 oz (5 ml) to 36 oz (1060 ml) 2 CFM @ 80 psi (57 L/min @ 5.5 Bar) SPEED 14 US gallon (52 liter) PARTICLE SIZEDEPOSIT RANGE AIR POWER Up to 3/4 inch (19 mm) HOPPER CAPACITY PRO 1000si SERVO DEPOSITOR • Dimensions: 27 x 55 inch/ 69 x 139 cm • 4 product cylinder sizes available, allowing for smaller accurate deposits • PLC control system in a stainless steel control panel • 6 programmable modes for depositing, recall 100’s of recipes at the touch of a button • Equipped with a cycle and total deposit counter • Maintain greater control and accuracy with each deposit • Electrical: 220 VAC, Single Phase, 20 A, 50-60 Hz PRO 1000i DEPOSITOR • Dimensions: 27 x 55 inch/ 69 x 139 cm • 4 product cylinder sizes available with an integrated tool tray • One turn speed adjustment dial, precision height adjustment • Designed to work over conveyors • Can deposit viscous liquids either with or without chunks • Also Available: Servo, Dual, Triple Configurations Up to 140 deposits/min. 0.5 oz (14 ml) to 36 oz (1060 ml) 4 CFM @ 80 psi (113 L/min @ 5.5 Bar) SPEED 14 US gallon (52 liter) PARTICLE SIZEDEPOSIT RANGE AIR POWER Up to 3/4 inch (19 mm) HOPPER CAPACITY BAKERY BAKERY FOOD FOOD
PRO 2000i DEPOSITOR The Pro 2000i is a heavy duty depositor capable of large volume deposits for cheesecake batters, muffin batter, mousse, cake batter, fruit pie fillings, meat pie fillings, deli salads, stews, chili and so much more. BENEFITS: • Dimensions: 27 x 56 inch/ 69 x 142 cm • 4 product cylinder sizes available; with an integrated tool tray • One turn speed adjustment dial • Large openings and passages for depositing large chunks • Perfect production line depositor • Precision height adjustment for individual operators or over a conveyor • Quick connect stainless steel fittings on face plate • Also available: Servo and Low Level Models Up to 110 cycles/min. 1.3 oz (40 ml) to 93 oz (2750 ml) 6 CFM @ 80 psi (170 L/min @ 5.5 Bar) SPEED 21 US gallon (79 liter) PARTICLE SIZEDEPOSIT RANGE AIR POWER Up to 1 1/2 inch (38 mm) HOPPER CAPACITY N/A ELECTRICAL SYSTEM INCLUDES: • Foot pedal, quick start guide, spare parts kit BAKERY FOOD
MULTISTATION
The MultiStation is the perfect alternate solution to traditional confectionery gearwheel depositor. A compact machine
precise multi-piston depositing using servo-driven
Perfect for clean depositing of relatively viscous to liquid products with or without chunks such as batters, fruit fillings, sauces, delicate mousse fillings, salad dressings, soups, and dairy products.
BENEFITS:
• High speed production rates
• Accurate portion control through each nozzle port
• Smaller minimum portions than pneumatic depositors
• Deposit chunks and particulate without damage
• Gentle portioning with less damage on fragile, delicate products
• Tool free, quick change design makes for minimal sanitation and maintenance requirements
• Integrated conveyor lift motion with each deposit
Up to 120 cycles/ min. 0.2 oz (5 ml) to 8.7 oz (255 ml) 4 CFM @ 80 psi (141.5 L/min @ 6.9 Bar) SPEED 11 US gallon (42 liter) PARTICLE SIZEDEPOSIT RANGE AIR POWER Up to 1/2 inch (13 mm)
DEPOSITOR
that will provides fast,
technology.
HOPPER CAPACITY SYSTEM INCLUDES: • Programmable touch screen color display with storage for 100 recipes; M600 (6 port) and/ or M800 (8 port) configuration 220 VAC, Single Phase, 15 A, 50-60 Hz ELECTRICAL Our Best Selling Machine!
BAKERY FOOD FEATURES: • Dimensions: 53 x 37 inch/ 135 x 94 cm • 3 product cylinder sizes: 1.25“ (3.2 cm), 1.75” (4.5 cm), 2” (5 cm) • Ability to fit various types of pans and trays up to 18” (46 cm) wide • Built in pan sensor • Seven selectable deposit modes: - 360 Mode - Continuous Mode - Éclair Mode - Multi Deposit Mode - Multi Spread Mode - Single Deposit Mode - Spreader Mode
M SERIES DEPOSITOR
BENEFITS:
BETWEEN
AND
DIFFERENCES
M2
M3: • The M2 has a smaller minimum deposit size, particulate allowance (3/4 inch or 19 mm) as well as air and hopper capacity
The perfect solution for dual or triple lane production systems; ideal for working over vacuum form, fill and tray sealing lines! Our M Series Depositors promise clean depositing of viscous to liquid products and 3 product cylinder sizes available to meet your portion requirements.
• M2 Dimensions: 27 x 48 inch/ 69 x 122 cm | M3 Dimensions: 62 x 41 inch/ 158 x 105 cm • M2 - 5 product cylinder sizes, M3 - 3 product cylinder sizes • Cantilever frames allow the machine to fit under most tray sealing lines • Accurate, individual portioning from each product cylinder • One turn, speed adjustment dial • M2 is available as Pneumatic or Servo Models • Quickly deposit into single cavities, 2 x 2 pouch fill, round pans or sheet pans • Integrates easily with a conveyor or production line SPEED PARTICLE SIZEDEPOSIT RANGE AIR POWER HOPPER CAPACITYELECTRICAL N/AUp to 120 cycles/min. 0.7 oz (22 ml) to 38 oz (1136 ml) 6 CFM @ 80 psi (170 L/min @ 5.5 Bar) 34 US gallon (129 liter) Up to 1 inch soft cubes (25 mm) BAKERY FOOD Our M2 machine can be fitted over-top our Sheet Cake Icing Line, scan QR code for video
SERVO MULTI
MULTI
Up to 120 deposits/min 0.25 oz (7 ml) to 18 oz (530 ml) 6-8 CFM @ 80 psi (113-170 L/min @ 5.5 Bar) SPEED 16 US gallon (60 liter) PARTICLE SIZEDEPOSIT RANGE AIR POWER Up to 3/4 inch (19 mm) cubes HOPPER CAPACITY
DEPOSITOR • Dimensions: 38 x 55 inch/ 97 x 140 cm • 5 product cylinder sizes, 4 different configurations available • Optional heated hopper, PLC control for recipe storage and conveyor line integration • Choose from 4 to 8 nozzles across setup with selectable dive action nozzle bridge, quick release components • Perfect for mini cakes, cookie icing, rope depositing, multi row depositing or the filling of pans, shells, single cavities, round pans or sheet pans Up to 75 cycles/min. 0.3 oz (10 ml) to 9.9 oz (292 ml) 5 CFM @ 80 psi (141.5 L/min @ 5.5 Bar) SPEED 16 US gallon (60 liter) PARTICLE SIZEDEPOSIT RANGE AIR POWER Up to 1/2 inch (13 mm) HOPPER CAPACITY BAKERY BAKERY FOOD FOOD
DEPOSITOR • Dimensions: 46 x 47 inch/ 117 x 120 cm • 5 product cylinder sizes available; 4,6,8,10 and 12 port configurations • Integrated bridge with computer controlled 1.75” (4.4 cm) diving nozzle actuation • Uses less compressed air as a servo driven (electronic) depositor • Programmable touch screen display, 6 selectable deposit modes • Capable of smaller minimum portions than pneumatic depositors • Electrical: 220 VAC, Single Phase, 20 A, 50-60 Hz
BENEFITS:
RP DEPOSITOR The servo-driven RP Depositor is an accurate, high speed and flexible machine for portion depositing and spreading of soft, self-leveling batters, creams, and fillings. Capable of higher maximum production rates than a traditional gear wheel depositor.
• Dimensions: 69 x 40 inch/ 175 x 102 cm • 26” (66 cm) wide machine, maximum spread width of 25” (63 cm) • Configure up to 18 ports across • Icon based, easy to use touchscreen interface with recipe storage • Submerged rotary pistons for less air pockets in deposit portions • Quickly deposit into single cavities, round pans or sheet pans • Integrates easily with a conveyor or production line • Less overall downtime with fewer parts to maintain, full wash down SPEED PARTICLE SIZEDEPOSIT RANGE AIR POWER HOPPER CAPACITYELECTRICAL SYSTEM INCLUDES: • One set of custom tooling 220 VAC, Single Phase, 15 A, 50-60 Hz Up to 140 cycles/min. 5.8 oz (172 ml) to 117 oz (3460 ml) 4 CFM @ 80 psi (113 L/min @ 5.5 Bar) 29 US gallon (100 liter) Smooth, flowable products up to 1/4 inch (6 mm) BAKERY FOOD
Up to 140 cycles/min. 0.5 oz (14 ml) to 36 oz (1060 ml) 4 CFM @ 80 psi (113 L/min @ 5.5 Bar) SPEED 32 US gallon (124 liter) PARTICLE SIZEDEPOSIT RANGE AIR POWER Up to 3/4 inch (19 mm) HOPPER CAPACITY Low design for easy hopper filling WORKSTATION 1000i DEPOSITOR • Dimensions: 31 x 51 inch/ 77 x 129 cm • One turn speed adjustment dial, 4 product cylinder sizes • Stainless steel hopper safety cover - keep product covered and use as a worktable • Telescopic outlet tube included, adjustment range of 33 to 39 inches (84 to 99 cm) from floor level PRO 2000i LOW LEVEL WITH AGITATOR • Dimensions: 25 x 66 inch/ 64 x 168 cm • 4 product cylinder sizes available • Equipped with a safety cover and quick release hopper • Nema 4X washdown drive motor and controller; agitator ensures accurate and even distribution of particulates • Capable of large volume deposits for soups, deli salads, stews, chilis and so much more • Electrical: 220 VAC, Single Phase, 20 A, 50-60 Hz FOOD FOOD Up to 110 deposits/min. SPEED 1.3 oz (40 ml) to 93 oz (2750 ml) DEPOSIT RANGE 6 CFM @ 80 psi (170 L/min @ 5.5 Bar) AIR POWERPARTICLE SIZE Cube measuring up to 1 1/2 inch (38 mm) 63 US gallon (240 liter) HOPPER CAPACITY
Up to 110 deposits/min. SPEED 1.3 oz (40 ml) to 93 oz (2750 ml) DEPOSIT RANGE 6 CFM @ 80 psi (170 L/min @ 5.5 Bar) AIR POWERPARTICLE SIZE Cube measuring up to 1 1/2 inch (38 mm) Optional 21 US gallon (79 liter) HOPPER CAPACITY PRO 2000i KETTLE DEPOSITOR • Dimensions: 22 x 66 inch/ 56 x 168 cm • 4 product cylinder sizes available, optional hopper • Draw directly from kettles and containers with bottom or tangent connections • Able to deposit directly into steam table pans, ready for the blast chiller • High temperature, 2.5” (63 mm) suction hose • Deposit products ranging in temperature of 120° - 180° F (49° - 82° C) PRO 2000i LOW LEVEL DEPOSITOR • Dimensions: 31 x 60 inch/ 77 x 153 cm • One turn speed adjustment, 4 product cylinder sizes • Height adjustable, telescopic outlet pipework • All food contact parts are dishwasher safe for a tool-free and quick disassembly/ change-over design • Deposits chunks or stiff products without compromising the integrity of your product Up to 110 deposits/min. 1.3 oz (40 ml) to 93 oz (2750 ml) 6 CFM @ 80 psi (170 L/min @ 5.5 Bar) SPEED 35 US gallon (132 Liter) PARTICLE SIZEDEPOSIT RANGE AIR POWER Cube measuring 1 1/2 inch (38 mm) HOPPER CAPACITY Large 63 US gallon (240 liter) Hopper shown FOOD FOOD
Shown Above with paddle configuration
QUICK
CONNECT FITTINGS DIVING NOZZLE PRODUCT CYLINDERS
HAND
HELD NOZZLE ACCESSORIES RC HAND HELD NOZZLE SPOUT NOZZLE 100’s OF ATTACHMENTS AND ACCESSORIES • Hygienic quick connect sanitary fittings • Compatible with most of our machines • Patented product safety valves • Heated hoppers, hopper stirrers, sizes available TOP AND SIDE ICING, MIDFILL NOZZLES PHOTO SENSOR HOPPER STIRRER PIE WAND CAKEHEADS SCAN ME
The ELF filling machine is an intuitive piece of equipment that has seamlessly translated our pouch filling from an art into a science. It requires little training to use and is one of the most reliable pieces of equipment in our facility.
MATT RUBIN Trade Secret Chocolates
a
love it!
take a
to
JEAN-PIERRE MARTINEZ
S&S Bakery
Our iSpot Depositor works like a dream. Easy to set up and use, we quickly noticed an increase in production yield
lower labor costs.
JOSHUA FLINT Rachels Tarts Inc.A company of More PRODUCTION. Less DOWNTIME. ✓ Expandable CONFIGURATIONS. ✓ Accurate PORTION SIZES. ✓ 100’s of ATTACHMENTS. CONTACT US TODAY: info@unifiller.com | www.unifiller.com TF: 1.888.733.8444 | 1.604.940.2233 | UK: 01933 676005 Unifiller, a subsidiary of the Linxis Group, is a global leader in specialized equipment for the food, bakery, pharmaceutical, and cosmetics industries. The group consists of leading companies focusing on mixing technologies, ingredient dosing systems and automated portioning systems. Through its various subsidiaries, the Group employs approximately 800 people worldwide. As a partner, Unifiller o ers an extensive line of pumps, depositors, extruders and decorating machines. From compact, portable tabletop machines to fully automated lines, see why so many customers prefer our machines! We own
MultiStation and we
I was able to
3 guy job down
a 1 guy job. It’s easy to use, easy to clean.
and
