LCE121 CAT12 LTE Indoor CPE

LCE121 is an advanced LTE indoor multi service product specifically designed to meet integrate d data, and 802.11b/g/n/ac dual band Wi Fi access needs for residential, business and enterprise users. The product supports advan ced Gigabit networking and dual band Wi Fi AP functionalities. It enables wide service coverage and provides high dat a throughput and networking features to customers who needs easy broadband access, hot spot Wi Fi connectivity.

Leax Arkivator Telecom

Four Bars

(2) Touch reset functions within 1s completed; long press over 10s to restore the factory settings

LCE121 Datasheet

HARDWARE SPECIFICATIONS

Wi-Fi Frequency 2.4GHz/5GHz

Wi-Fi Antenna

Build-in high gain, separate for 2.4GHz,5GHz

Output Power 18dBm/2.4G; 20dBm/5GHz

Topology TOPOLOGY

MHz

(1) Four Bars

(2) Touch reset functions within 1s completed; long press over 10s to restore the factory settings

RF SPECIFICATIONS

(1)
Leax Arkivator Telecom
Capability Operating Temperature -10C 55C Storage Temperature -40C 85C Operating humidity 90% Storage humidity
Environment Specifications Feature
90%
Wi-Fi Channel BW 20 MHz & 40
SPEC DESCRIPTION CHIP SET GCT GDM7243A MT 7621A LTE STANDARD 3GPP RELEASE 11 CAT12 FLASH 1GB RAM 1GB ETHERNET LAN PORT 2 * GIGABIT RJ45 LAN PORT 10/100/1000 AUTO-SENSING, AUTO-MDI/MDIX LED 8 LED INDICATORS (PWR, WI-FI, TEL, MODE, RF SIGNAL*4) SIM 1 USIM/SIM (3FF) RESET/REBOOT BUTTON TACT SWITCH(3) ANTENNA 4 BUILT-IN DIMENSIONS 215MM X 160 MM X 95MM WEIGHT < 500G POWER CONSUMPTION < 12W POWER SUPPLY AC 90~240V DC 12V 2A
FEATURE CAPABILITY SUPPORTED BANDS FDD TDD B1/2/3/4/5/7/8/12/17/ 20/28A/28B B38/41/B42/43/48 CA INTRA/INTER-BAND CA DL 2CA 4X4 MIMO DL 4CA 2X2 MIMO, UL 2CA MIMO DL 2X2 (4CA 256QAM) DL 4X4 (2CA 64QAM) UL 2X2 64QAM TX 1TX, 2TX TRANSMISSION MODE TM1/2/3/4/5/6/7/8/9 OUTPUT POWER@25°C 23±2 DBM RECEIVING FDD SENSITIVITY TDD -100DBM/10MHZ@QPSK -97DBM/20MHZ@QPSK LTE ANTENNA 0.7~1G 4BUILT-IN OMNI ANTENNA LTE 0.7~1G ANTENNA 1.7~2.7G GAIN 3.4~3.8G 3DBI 5DBI 6DBI WI-FI FREQUENCY 2.4GHZ/5GHZ WI-FI ANTENNA BUILD-IN HIGH GAIN,
FOR
OUTPUT POWER 18DBM/2.4G;
WI-FI CHANNEL BW 20 MHZ & 40 MHZ
SEPARATE
2.4GHZ,5GHZ
20DBM/5GHZ
FEATURE CAPABILITY OPERATING TEMPERATURE -10°C -- 55°C STORAGE TEMPERATURE 40°C 85°C OPERATING HUMIDITY 90% STORAGE HUMIDITY 90% ENVIRONMENT SPECIFICATIONS Leax Arkivator Telecom

SOFTWARE SPECIFICATIONS

LANGUAGE SETTINGS: SIMPLIFIED CHINESE, ENGLISH(1)

SUPPORT NAT/BRIDGE/ROUTER MODE

SUPPORT HTTP OR HTTPS WEB SERVER

SUPPORT TWO USERS (ADMIN USER AND NORMAL USER) AND DIFFERENT LIMITATION AND DISPLAY

PEAK THROUGHPUT FDD DL 800MBPS (4CC 256QAM);

UL 150MBPS (CONFIGURATION 2:7 ); TDD DL 560MBPS (4CC 256QAM); UL 30MBPS (CONFIGURATION 2:7 );

LAN 1000MBIT/S

MDI/MDIX AUTO-SENSING

IEEE802.3/3U/3ABCOMPATIBLE

PIN MANAGEMENT, SIM CARD AUTHENTICATION

ENCRYPTION BACKUP OF CURRENT SETTINGS AND RESTORE OF THE BACKUP SETTINGS

DIAGNOSIS RESULTS AND OPERATION LOGS EXPORT

STATISTICS

SUPPORT MULTI-APN

VPN

LINK STATUS (LAN)

TRANSMITTED/RECEIVED PACKETS UP TIME

L2TP V2/V3

PPTP

GRE L2/L3

GRE OVER IPSEC

L2TP OVER IPSEC IPSEC

DEVICE MANAGEMENT

INTEGRITY CHECK

VERSION ROLLBACK

SOFTWARE UPGRADE

HTTP/FTP AUTO UPGRADE

IMAGE ONE VERSION

IMAGE ONE CHECKSUM

IMAGE TWO VERSION

IMAGE TWO CHECKSUM

AUTOMATIC ROLLBACK TO PREVIOUS VERSION WHEN UPGRADE FAILS

FULL IMAGE UPGRADE

MANUAL FIRMWARE UPGRADE

UPGRADE FIRMWARE ENABLE / DISABLE

UPGRADE URL

VERSION FILE

PERIODICAL NEW FIRMWARE CHECK (HR.: 1~744)

START TIME

RANDOM TIME

TR069 SUPPORTS UPLOAD/DOWNLOAD OF THE ACS SPECIFIED FILE

SUPPORT DOWNLOAD OF CPE CONFIGURATION FILE

IPV6/IPV4 DUAL STACK

STATUS(2)

SIGNAL STRENGTH

NETWORK TYPE

NETWORK CONNECTION STATUS

SIM CARD STATUS

OPERATOR NAME, SYSTEM MODE

SUPPORT FULL BAND OR PREFERRED BAND AND FREQUENCY

SUPPORT PCI LOCK (CELL LOCK)

ONLY CARRIER SIM SHALL WORK IN THE CPE

SUPPORT BIP

(1) Multiple languages can be customized

(2) Can be customized

SUPPORT PARAMETER CONFIGURATION & QUERY (1) SUPPORT REMOTE UPGRADE

SUPPORT CPE VERSION UPDATE

SUPPORTS DEBUGGING OPERATIONS

SUPPORT CYCLE MONITOR

PORT MIRROR ENABLE AND DISABLE OPERATION SUPPORTED

SYSLOG SYSTEM LOG FUNCTION SUPPORTED AND CAN BE SENT TO THE PC VIA LAN

DIAGNOSTICS SUPPORT THE PING AND TRACE ROUTE

(1) Can be customized

Datasheet
LCE121
Leax Arkivator Telecom

LCE121 Datasheet

BRIDGE MODE

DATA TRAFFIC FORWARD FORWARD THE DATA TRAFFIC BETWEEN THE LTE NETWORK AND PCS.

P C SUPPORT MAXIMUM , E ACH PC CONNECT TO THE LTE PUBLIC NETWORK VIA ONE APN

TR 069 ONE APN CAN BE ALLOCATED FOR THE MODULE AND THE MODULE CAN BE MANAGED VIA TR-069 OR UPDATE VERSION REMOTELY

PUBLIC IP ALLOCATION PC GET S THE PUBLIC IP FROM THE DHCP SERVER IN THE CPE. THIS IS THE PUBLIC IP THAT CPE GETS FROM LTE NETWORK

MULTIPLE APN UP TO 4 APNS, STATIC ROUTE CAN BE SET FOR EACH APN

ROUTER MODE

LAN 2 IP ADDRESSES ON THE LAN AND FOR 2 DIFFERENT NETWORKS CAN BE SET

WAN WAN IP CAN BE SET DYNAMICALLY OR STATICALLY

ROUTER PROTOCOL CURRENTLY NOT SUPPORTED

DNS CAN BE SET

MULTIPLE APN UP TO 4 APNS, STATIC ROUTE CAN BE SET FOR EACH APN

NAT MODE

NAT SUPPORT NAT FUNCTION

FIREWALL CAN BE ENABLE D OR DISABLED

MULTIPLE APN UP TO 4 APNS SUPPORT, AND CAN SET THE STATIC ROUTER FOR EACH APN

DMZ THE DMZ CAN BE SET.

DHCP SUPPORT THE DHCP SERVER

DNS SUPPORT THE AUTO DNS OR MANUAL DNS CONFIGURATION

WIFI FEATURES

USERS CAN TURN ON/OFF WLAN FUNCTION BY TOUCHING THE WLAN BUTTON OR THROUGH WEB UI.

SUPPORT CONFIGURING WLAN FUNCTIONS THROUGH WEB UI, INCLUDE: SSID, SSID BROADCASTING TURN ON/ OFF, AP ISOLATION, CHANNEL, RATE AND MODE

SUPPORT ENCRYPTION: UN-ENCRYPTED, WEP-OPEN, WEP-SHARED, WPA-PSK (TKIP), WPA-PSK (AES), WPA2PSK (TKIP), WPA2-PSK (AES)

SUPPORT WPS: SUPPORT PBC MODE

WI-FI PROTOCOL SUPPORT: IEEE 802.11 B/G/N/AC

WI-FI SUPPORT MAX. USERS: 32

SUPPORT SSID BROADCASTING

SUPPORT MULTI SSID

SUPPORT WI-FI CHANNEL SELF-ADAPT AND SELECT SUPPORT WDS

FIREWALL FEATURES

FIREWALL CONFIGURATION

ALLOW PING FROM WAN

ALLOW HTTPS LOGIN FROM WAN

HTTPS LOGIN PORT FROM WAN

DMZ IP ADDRESS

REDIRECT ICMP TO THE HOST

SUPPORT THE IP FILTER

SUPPORT THE MAC FILTER

SUPPORT THE URL FILTER

SUPPORT UPNP

SUPPORT THE PORT FORWARDING

VOIP (VoIP or VoLTE but can’t be supported at the same time.)

CALL WAITING

CALL HOLD /RESUME

CALL FORWARD

ON BUSY

CALL FEATURES

NO CONDITION

NO ANSWER

CALL TRANSFER

BLIND TRANSFER

Leax Arkivator Telecom

ATTENDED TRANSFER

EARLY ATTENDED TRANSFER

3-WAY CONFERENCING

DIGIT MAP / DIAL PLAN

CALLER ID DISPLAY/BLOCKING RTP

MONITOR

RTP REDUNDANCY

SBC (SESSION BORDER CONTROL)

REDUNDANCY

SESSION TIMER (INVITE/UPDATE)

CODEC G.711 A/MU LAW

APPENDIX I

APPENDIX II

G.726(16,24,32,40 KBPS)

G.729AB

G.723.1(6.3KBPS / 5.3KBPS)

AMR-NB AMR-WB

G.722

ECHO

CANCELLER

VOICE ENHANCEMENT

G.167 AEC (ACOUSTIC ECHO CANCELLATION)

G.168 LINE ECHO CANCELLER

ADAPTIVE JITTER BUFFER/FIXED

JITTER BUFFER

VAD/CNG/SID

PLC (PACKET LOST CONCEALMENT)

LGC (LINEAR GAIN CONTROL)

GAIN CALIBRATION

MIXER

CALLER ID DTMF CID GENERATION

BELLCORE CID TYPE I/II

GENERATION/DETECTION

ETSI CID TYPE I/II

GENERATION/DETECTION

CID CAS/DTAS/SAS TONES

GENERATION

DTMF GENERATION

OUT-OF-BAND DTMF RELAY (RFC2833)

IN-BAND DTMF RELAY DETECTION

CPT GENERATION

DETECTION

FAX/MODEM

G3/SG3 FAX PASS-THROUGH

T.38 FAX RELAY

V.22/V.32 MODEM PASS-THROUGH

VOLTE

(VoIP or VoLTE but can’t be supported at the same time.)

REGISTRATION REGISTRATION EVENT PACKAGE

NETWORK INITIATED DE-REGISTRATION

IMS COMMUNICATION SERVICE IDENTIFIER (ICSI)

PUBLIC USER IDENTITY IN THE FIRST (OR ONLY) RECORD IN THE ELEMENTARY FILE IN THE ISIM

TEMPORARY PUBLIC USER IDENTITY

DERIVED FROM THE IMSI

AUTHENTICATION

IMS AUTHENTICATION AND KEY AGREEMENT (IMS AKA), SEC AGREE AND IPSEC

ISIM BASED AUTHENTICATION

USIM BASED AUTHENTICATION

AUTHENTICATION AT THE UT REFERENCE POINT

ADDRESS SIP URIS (ALPHANUMERIC) AND MOBILE SUBSCRIBER ISDN NUMBER (MSISDN) BASED IMPU

PHONE CONTEXT” PARAMETER

P-CALLED-PARTY-ID HEADER FIELD

BASIC CALL AMR NB

AMR WB

CALLER ID NAME AND NUMBER DISPLAYED

SUPPLEMENTAR Y CALL FEATURES

ORIGINATING/TERMINATING IDENTIFICATION RESTRICTION

COMMUNICATION FORWARDING

UNCONDITIONAL/ON NOT LOGGED/ON BUSY/ON NOT REACHABLE/ON NO

Leax Arkivator Telecom
LCE121 Datasheet

LCE121 Datasheet

REPLY

BARRING OF ALL INCOMING OUTGOING CALLS

BARRING OF OUTGOING

INTERNATIONAL CALLS EX HOME COUNTRY

BARRING OF INCOMING CALLS WHEN ROAMING

COMMUNICATION HOLD

MESSAGE WAITING INDICATION

COMMUNICATION WAITING

AD HOC 3 PARTY CONFERENCE

THREE WAY SESSION CREATION

COMMUNICATION DIVERSION/ FORWARD (CDIV)

IMS SIP SESSION INITIATED PROTOCOL (SIP) REGISTRATION PROCEDURES

SIP PRECONDITIONS FRAMEWORK SESSION DESCRIPTION PROTOCOL (SDP) OFFER/ANSWER FOR VOICE MEDIA

REAL TIME PROTOCOL (RTP) PROFILE

RTP OVER UDP

RTP CONTROL PROTOCOL (RTCP)

DTMF

GUARANTEED BIT RATE (GBR) BEARER

IETF RFC 4575

PDN TYPE: IPV4V6

P-CSCF DISCOVERY

DSP

PROCESSING

3GPP TS 24.229

3GPP TS 31.103

3GPP TS 26.114

ADAPTIVE MULTI RATE SPEECH CODEC (AMR)

AMR WIDEBAND CODEC

NARROWBAND 8KHZ AND WIDEBAND 16KHZ FRAMEWORKS

DTMF TONE GENERATION AND DETECTION

CALL PROGRESS TONE GENERATION

DUAL MODE DYNAMIC ADAPTIVE/ FIXED JITTER BUFFER

AD HOC 3 PARTY CONFERENCE

(SERVER MODE)

G 711 ALAWVOICE COMPRESSION

G.711 MULAW VOICE COMPRESSION

SILENCE COMPRESSION

G.168 16MS TAIL LINE ECHO

CANCELLATION

PACKET LOSS COMPENSATION AND VOICE ACTIVITY DETECTION

CALLER ID GENERATION (FXS)

10MS, 20MS, 30MS, AND 40MS PACKET SIZ E SUPPORTS

FAX MODEM TONE DETECTION

FAX PASS THROUGH OVER G.711

APPENDIX - DELIVERS

1*ASSEMBLED PRODUCT

1*ETHERNET CABLE, 1M

1*12V/2.0A

1*MANUAL

(1) Detail Delivers need to be defined by customer agreement

Leax Arkivator Telecom

INDOOR CPE

2.4GHZ/5GHZ WIFI, 2GE PORT, VOIP/VOLTE

PRODUCT SPECS

∫ Module Chip: GDM7243A

∫ Bands Support: Band 41/42/43/48

(CBRS support)

∫ Down Link: 4CA 2x2 256QAM or 2CA 4x4 MIMO or 8x4

∫ Up Link: CA, UL SU-MIMO

∫ Antenna: Built-in 4 LTE high gain

∫ Standard: 802.11 b/g/n/ac

∫ Ports: 2GE LAN/RJ11/USB
