TIMOTHY
CHRISTIAN MURPHY
DESIGN PORTFOLIO
I. STAGE 5 TECHNICAL SUPPORT
COMMERCIAL PROJECT
WITH ORMS, LONDON, UK
SKETCH
DEVELOPMENT AND TECHNICAL SECTION DETAIL
LIVING WALL ON CYCLE STORE WITH POLYCARBONATE
TRANSLUCENT ROOF SYSTEM
LIVING WALL ON CYCLE STORE
WITH PROFILED METAL PANEL INTERFACE
SKETCH DEVELOPMENT AND TECHNICAL PLAN-CUT DETAIL
EXTERIOR ELECTRICAL RISER WITH INTEGRATED BENCH SITUATION SKETCH AND TECHNICAL SECTION DETAIL
II. WORKING WITH PURBECK STONE
MATERIAL RESEARCH AT WINSPIT QUARRY
THESIS PROJECT AT AUB
III. RESIDENTIAL PROJECT
TIMOTHY CHRISTIAN MURPHY
WITH BALL ARCHITECTURE, BOURNEMOUTH, UK
ORANGERY
STAGE
EXTENSION IN BOURNEMOUTH RIBA
0-3 CONCEPT AND PLANNING DRAWINGS
ORANGERY EXTENSION IN BOURNEMOUTH
RIBA STAGE 0-3 CONCEPT AND PLANNING DRAWINGS AND RHINO MODEL
IV. RESIDENTIAL PROJECT
TIMOTHY CHRISTIAN MURPHY
WITH 2MA, TOLEDO, OH, USA
V. RESIDENTIAL PROJECTS
TIMOTHY CHRISTIAN MURPHY
INDEPENDENT
PERGOLA AND BACKYARD EXTENSION DETROIT, MI, USA
SIMPLE NEW BUILD IN BOURNEMOUTH, UK
DATE: 07/12/2022
ISSUED FOR TENDER
ARCHITECTURAL DESIGNER: TIMOTHY CHRISTIAN MURPHY @TIMOTHYCHRIST_
EMAIL: TIMOTHYCHRIST@ICLOUD.COM - PH:07990587229
GENERAL NOTES
1.THESE DRAWINGS ARE FOR TENDER PURPOSES ONLY AND NOT TO BE USED AS CONSTRUCTION DOCUMENTS.
2.AT THE TIME OF AN ACCEPTED BID CONSTRUCTION DRAWINGS TO BE CREATED AND ISSUED BY THE ARCHITECT AT THE REQUEST OF THE OF THE CONTRACTOR SHOWING DETAILS AND SPECIFICATIONS AS NEEDED.
PROJECT REDHILL
3.ANY DETAILED CONSTRUCTION DRAWINGS AND DOCUMENTS FOR PROJECT REDHILL CAN ONLY CREATED WITH THE CONSENT OF THE OWNER WHO HAS ACCEPTED THE BID OFFER.
4.ANY CONTACT WITH THE ARCHITECT DURING TENDER MUST BE MADE WITH THE KNOWLEDGE AND CONSENT OF THE OWNER.
5.A STRUCTURAL SURVEY OF THE EXISTING BUILDING AND FOUNDATION MUST BE CARRIED OUT BEFORE CONSTRUCTION BEGINS. OTHER SURVEYORS, SUCH AS TREE SURVEYORS ETC., MAY BE NEEDED.
6.EXTENSION
OF THE TENDER PACKAGE. ANY DEVIATION FROM THIS STRATEGY MAY ONLY TAKE PLACE WHERE STRUCTURAL SURVEY FINDS THAT THE EXISTING STRUCTURE IS INADEQUATE. A STRUCTURAL ENGINEER WILL ASSESS AND APPROVE
CHERRIE'S DRIVE ENSBURY PARK ROAD
CONSTRUCTION TO KEY INTO
REUSE AS MUCH OF THE EXISTING BUILDING STRUCTURE AS POSSIBLE IN LINE WITH THE DRAWINGS INDICATION
ANY CIVIL/STRUCTURAL ENGINEERING ISSUES SUCH AS, NEW STEEL CONSTRUCTION, FOUNDATION DESIGN, ETC., AS THE CONTRACTOR AND ARCHITECT SEE FIT. GENERAL CONTRACTOR MAY RECOMMEND AND APPOINT SUBCONTRACTORS FOR ANY TASK ASSOCIATED WITH CONSTRUCTION BEFORE AND DURING THE BUILD WITH THE CONSENT OF THE OWNER AND ARCHITECT.
AND
16 REDHILL AVENUE, BH92SN, BOURNEMOUTH, DORSET, UK SITE
SHEET A0.1 - PROJECT OVERVIEW
PLAN CUT SCALE: 1:50
VI. INDUSTRIAL PROJECTS
TIMOTHY CHRISTIAN MURPHY WITH MATRIX TECHNOLOGIES
MAUMEE, OH, USA
INDUSTRIAL CHEMICAL PLANT DESIGN WYANDOTTE, MI, USA
INDUSTRIAL WAREHOUSE, DETROIT, MI, USA
HVAC PRODUCT OFFGASSING VENT SYSTEM AND FACILITY DESIGN
VII. PLYWOOD FURNITURE SERIES
DEVELOPED FOR MOMENTUM FESTIVAL EXHIBITION
TOLEDO, OH, USA
VIII. WILDFIRE ERV DESIGN
TIMOTHY CHRISTIAN MURPHY
WITH SPARTAN MOTORS MI, USA
