Digital microscope magnus hd zip – tagarno

MAGNUS HD ZIP EASY TO USE / MAGNIFICATION UP TO 40X / COST-EFFICIENT

HD 720P 1280X720 CAMERA

MOBILITY

+4 LENS

AUTOFOCUS

ESD VARIATIONS

TAGARNO A/S / SANDØVEJ 4 / 8700 HORSENS / DENMARK +45 76 25 11 11 / MAIL@TAGARNO.COM / WWW.TAGARNO.COM

MAGNUS HD ZIP EASY TO USE / MAGNIFICATION UP TO 40X / COST-EFFICIENT EASY TO USE

EXCELLENT IMAGE QUALITY

ENHANCED COOPERATION

MAGNUS HD ZIP is a simple and userfriendly system. The simplicity and the intuitive control buttons enable you to operate MAGNUS HD ZIP without any training and you do not need any time to adjust to using it.

With HD you get an extremely sharp image with unsurpassed colour rendition.

What you see on the monitor is exactly what is under the camera - without distortion, delay or interference.The built-in autofocus ensures a sharp image regardless of magnification size.

An added bonus of MAGNUS HD ZIP is the multi-viewer option which allows more than one person to view the magnified object at the same time. This feature is ideal for the training of new operators, sparring between operators and supervision sessions. The option of dialogue and cooperation brings new and more dynamic ways of working and easier quality control.

MAGNIFICATION UP TO 40X Providing superb HD image quality, magnification up to 40 times and live imaging at 60 fps, MAGNUS HD ZIP enables you to see small details very clearly.

SYSTEM Magnification: Lens to object distance Weight: Camera resolution: Recommended monitor format: Output: Monitor size: Total power consumption: Standby consumption:

2.2 - 41x on 22" with a +4 lens 250mm/9.8” with a +4 lens 1.9 kg/4.19 lbs HD720p, 1280x720 - 60 HZ Widescreen HDMI Optional 15 W 1.6 W

ACCESSORIES HD 22" and 24” widescreen monitor Mounting arm for monitor

Foot switch Light Kit

XKEY CONTROL BOX Dimensions: Functions:

TAGARNO A/S / SANDØVEJ 4 / 8700 HORSENS / DENMARK +45 76 25 11 11 / MAIL@TAGARNO.COM / WWW.TAGARNO.COM

H: 21mm/0.8”, W: 61mm/2.4”, D: 100mm/3.9” Zoom with auto focus and manual focus Iris adjustment
