SolarisKit - The New Way to Turn Sunlight Into Hot Water

The new way to turn sunlight into hot water

Solar heating solutions for HOMES

BUILDINGS

GLAMPING

POOLS

LOWER ENERGY COSTS | REDUCE CARBON EMISSIONS | IMPROVE BUILDING SUSTAINABILITY

Heating water is energy and carbon intensive

3,400 kWh of energy1

1,240 kg of carbon2

Heating water is an energy intensive process, typically met using electricity or gas.

A household of four will typically consume approximately 200 litres of hot water per day. This adds up to 3,400 kWh of energy and up to 1,240 kilograms of carbon every year.

1 2

02

Assuming 200 litres of hot water consumed every day without absence Calculated based on a grid carbon intensity factor of 367 gCO2e

6

D

5

HARNESSING THE ENERGY 4 3 FROM THE SUN IS THE IDEAL WAY TO HEAT WATER, LOWERING ENERGY COSTS AND CARBON EMISSIONS. Save money

C

Reduces carbon emissions

Enhances building sustainability B

03

But current solar hot water solutions are

Unattractive design Large, bulky, and visually obtrusive, current designs are not adequate for flat-roof buildings

04

Reach excessive temperature Can reach excessive temperatures, reducing system lifetime and safety

Complex installation Designed for northern colder climates, not sunny equatorial regions like the Middle East

YOU SHOULDN’T HAVE TO COMPROMISE BUILDING’S AESTHETICS

BY INSTALLING A SOLAR HOT WATER SOLUTION.

05

MEET SOLARISKIT

the new and attractive solar heating solution

Modern and attractive design

06

Safe temperature (always)

Simpler to install

The SolarisKit solar heating solution is uniquely suited for flat-roof and ground installations

A unique prismatic design solar collector to convert solar energy into heat

Attractive & discrete Modern design and low profile compared to flat-plate solar collectors

Multiple Applications Multiple solar collectors can be easily combined to suit multiple applications

Easy to Install Compatible and safe to use with plastic piping and ‘push-fit’ style components

Low maintenance SolarisKit solar collectors will never heat water above 70oC making it a long lasting and low maintenance solution

The SolarisKit solar collector efficiently converts solar energy to heat water using a new prismatic design that offers several key benefits over current solar heating solutions available.

07

How the SolarisKit solar collector works 1.

2.

3.

4.

08

SUN ENTERS SOLAR PRISM The SolarisKit solar prisms are positioned where it is sunny (e.g., roof). The unique prismatic shape allows passive tracking of the sun

1.

ABSORPTION OF SUNLIGHT Solar radiation is absorbed by the SolarisKit solar collector absorber, increasing its temperature.

Internal aluminium reflectors direct sunlight onto absorber.

4.

COLD WATER IN Cold water is circulated through the solar collector using a small pump. As water travels through the absorber, it is heated via forced convection.

2.

HOT WATER OUT Carbon free hot water then exits from the collector via the outlet port fitting. Metric and imperial size fittings available to suit your needs.

3.

SolarisKit is the ideal solar heating solution for

Households & commercial buildings

Glamping, Tiny Housing, & Off-Grid sites

Pools, hot tubs and SPA heating 09

THE SOLARISKIT

solar collector is the world’s first flat-packed solar thermal collector.

Assembled in 30-minutes

No tools needed.

10

Advantages of SolarisKit’s flat-packed solar collector

Cheaper to ship

Easier to ship

Safer to ship

170 mm

10.4 kg

55

0m

m

550 mm 11

The complete solar hot water solution SolarisKit can provide the complete solar hot water solution including solar collectors, pump, solar controller, thermal storage, and all the fittings needed. Our 12V solar controller solution is uniquely suited to both on and off grid applications.

SOLAR COLLECTORS

1.

SolarisKit Solar Collectors

onvert solar energy into heat C Solar Keymark Certified Pressure rated to 5bar WRAS approved

Temperature sensor

1.

PUMP AND SOLAR CONTROLLER Hot water

2.

Non return Valve

2.

12V Pump

Temperature sensor

Hot Water Storage Tank

3.

12

1 2V pump and solar controller provides fully automatic control of system Consumes <15W of electricity Ideal for ON/OFF Grid Simple to install and operate

THERMAL STORAGE TANK Cold water supply

3.

I nsulated storage tank Copper/Stainless Steel available British Made and Certified Backup heating element included

SolarisKit installation completed with Kampgrounds of America in the USA.

13

Predicted energy savings around the world Using only six SolarisKit solar collectors (Area = 1.74m2) to provide 150L of hot water per day, significant energy savings can be achieved for different climates.

97% Abu Dhabi, UAE

76%

2,450 kWh saved 569kg carbon savings

San Diego, USA

2,250 kWh saved 522kg carbon savings

1

14

82% Rio de Janeiro, Brazil

95% Ho Chi Minh, Vietnam

2,060 kWh saved 477kg carbon savings

1,420 kWh saved 330kg carbon savings

Performance based on daily hot water demand of 180 litres per day.

Energy analysis carried out using Polysun software

Monthly energy savings with Solariskit HO CHI MINH, VIETNAM

100 90 80 70 60 50 40 30 20 10 0

Solar Friction (%)

Solar Friction (%)

SAN DIEGO, USA

JAN

FEB MAR APR MAY JUN

100 90 80 70 60 50 40 30 20 10 0

JUL AUG SEP OCT NOV DEC AVG

JAN

100 90 80 70 60 50 40 30 20 10 0 JAN

FEB MAR APR MAY JUN

JUL AUG SEP OCT NOV DEC AVG

RIO DE JANIERO, BRAZIL

Solar Friction (%)

Solar Friction (%)

ABU DHABI, UAE

FEB MAR APR MAY JUN

JUL AUG SEP OCT NOV DEC AVG

100 90 80 70 60 50 40 30 20 10 0 JAN

Energy performance calculated using Polysun simulations and Meteonorm climate data

FEB MAR APR MAY JUN

JUL AUG SEP OCT NOV DEC AVG

15

Designed, tested, and made in Britain SolarisKit is an award winning cleantech company based in Scotland where it designs, tests, and manufactures its unique range of solar thermal collectors.

SolarisKit is ISO9001 registered and its solar collectors are proudly manufactured in Britain. Components are precisely laser cut and checked to ensure all solar collectors are made to specification.

Located at the Michelin Scotland Innovation Parc, SolarisKit carries out design, rapid prototyping, and manufacturing of its solar thermal product range by its highly experienced team of engineers.

16

The SolarisKit solar collector has been stringently tested to European standards EN 12975 and Solar Keymark certified.

The rigorous Solar Keymark certification is increasingly adopted around the world.

The SolarisKit solar collector offers a new solar heating solution that is modern and attractive

17

Work with SolarisKit to design and supply your next solar heating solution With SolarisKit, designing, sourcing, and installing your solar hot water solution is easy. Our highly experienced team covering engineering, installation, and manufacturing are here to support you and your Project from start to finish. Get in touch today and let’s get started.

Get in Touch Today Visit https://solariskit.com or email sales@solariskit.com

18

1.

Schedule a call today by visiting https://calendly.com/solariskit and tell our team about your project and hot water needs

2.

SolarisKit will design and model the ideal solar heating solution for your project providing you with estimated annual energy and carbon savings

3.

SolarisKit will design and model the ideal solar heating solution for your project providing you with estimated annual energy and carbon savings

480 mm

540 mm

Collector specifications

Collector model no.

S400

Shipping dimensions

550 x 550 x 170mm

Shipping weight

10.4kg

Product dimensions (assembled)

540 x 540 x 480mm

Collector area

0.3m2

Collector weight

8.5kg

Product certification

Solar Keymark (EN12975/ISO90806)

Stagnation temperature

70oC

Pressure rating

5bar

Fluid volume

1.2L

Absorber material

Cross linked polyethylene with UV stabilised oxygen barrier

Collector side panel material

High transmission solar glass, tempered

Warranty

5 Years

Pallet quantity

52

20ft / 40ft container qty

520 / 1040

540 mm 19

SolarisKit is on a mission to unlock the vastly untapped potential of solar energy across the globe. With nearly 70% of Earth’s population living in the equatorial regions of the planet, solar energy is the ideal way to provide affordable, clean heat to billions of people.

SolarisKit has now shipped solar collectors to six continents and supported installations in Rwanda, Zambia, Kenya, Malawi, and Ghana. We are currently working with Strathmore University to establish East Africa’s first solar thermal centre of excellence, a training centre which will train solar hot water installers and the development of new solutions to increase energy access in the global south.

Get in touch today hello@solariskit.com +44 747 049 3134 solariskit.com Unit 3 Fulhame Building Michelin Scotland Innovation Parc Dundee DD4 8UQ United Kingdom
