SOFIA PERRO A MENSI ARCHITECTURE PORTFOLIO
MSP
CONTENT ARCHITECTURE 01 SUGAR ROOTS KITCHEN 02 PROSPECT NEW ORLEANS 03 ART CENTER COASTAL CAROLINA 04 MIDPOINT 05 ART CENTER COASTAL CAROLINA WORK SAMPLE 06 712 CONGRESS ST 07 BEAUFORT EYE CENTER 08 BEAUFORT PLAZA 09 SMILEY RESIDENCE 10 KITCHEN STANDARD DETAILS 11 WINDOW, CW, SF AND PLAN DETAILS 12 FACADE STUDIES MIXED MEDIA
ARCHITECTURE
SUGAR ROOTS KITCHEN
Small Center’s design/build team worked with Sugar Roots Farm to design and fabricate an outdoor teaching space and future kitchen area. The large pavilion addresses existing issues of water management and provides a space for expanded programming on the educational farm. Connecting people of all ages to our food systems and local ecologies is at the core of what Sugar Roots Farm does each day on their site. The aim of our partner organization is to teach and practice intentional land stewardship to ensure that future generations will have the skills and resources to grow and eat nourishing, fresh foods. This project was created in conjunction to a group of students ranging from undergraduate to graduate level and was led by a license architect.
01 SITE PLAN 12' 20' 8' 4'2'0' FLOOD PRONE AREA BIOSWALE 500 GL CISTERN BELOW GRADE DRAINAGE PIPES poly-carbonate metal roof rope screen + steel frame (2) 2x12 wood joists (3) 2x12 wood beams (2) 2x4 v-columns & saddles concrete foundation boardwalk with concrete footings brackets 4x4 steel columns, saddles, plates, x-bracing 4'2' 12' 0' FRONT ELEVATION 20'
6''x6''x11' steel column 2''x4'' wood column X-type bracing system X-type bracing system Three rows of 2''x12'' timber beams The Final Structure Diagram The Albert and Tina Small Center for Collaborative Design The Albert and Tina Small Center for Collaborative Design The Albert and Tina Small Center for Collaborative Design The Albert and Tina Small Center for Collaborative Design
PROSPECT NEW ORLEANS
Prospect New Orleans is a citywide contemporary art exhibition in the US with a decade-long history. Every three years, they bring new art to an old city by inviting artists from all over the world to create projects in a wide variety of venues spread throughout New Orleans. The intent of this project is to provide a headquarters for Prospect NOLA as well as provide a co working space for the city where creativity is at the center of the work space. The building layout utilizes the atrium to showcase an sculptural staircase that leads the circulation throughout the building and links its function to the arts. Similarly, the facade is created by using undulated shaped panels made out of terraco a that bring out the artistic nature of the building while also providing function.
02
CAMP STREET LEVEL 1/16” CAMP STREET LEVEL 1/16” 0” PRIVATE OFFICE CAMP STREET LEVEL 1/16” 0” BREAK ROOM LOUNGE CAMP STREET LEVEL ANDREW HIGGINGS BLVD 1/16” 0” CAMP STREET LEVEL 1/16”
MODULAR ARCHITECTURE
Home ownership has always been the keystone for the fulfillment of the American Dream. Throughout time, ownership has granted a sense of security for the individual and with that inspiration for the future. This research proposes a study into modular forms of construction and pre assembly techniques in order to create a more cost-effective home with the goal of providing housing to the larger population. A comparative approach will be conducted between different construction typologies, in lieu of construction methods to determine which approach would bear the best results keeping in mind the politics, economics, and zoning requirements within the city of New Orleans and more specifically in Hoffman Triangle.
The modular system is based on typologies of modules separated in three categories. Private modules - bedrooms - communal modules - living room, kitchen, adaptive space - and service modules - bathrooms, utility room, hallways and stairs. The modules are constrain to a width of 12 feet and a height of 15 feet. The length of the modules varies dependent upon the typology.
03 An internal floor is installed. Raised over installations in the floor. Frames for doors and windows are mounted. Fire proofing and interior wall finishes are finalized.. The finished floors are installed within the module Moisture barrier and finishes are installed in the bathrooms. Windows and doors are mounted simultaneously. Interior fixtures are installed at the same time exterior finishes are being completed.
CONSTRAINS
The modular system is constrained in size due to the transportation methods utilize to deliver the home. Roads in the United states allow a max of 12 feet in width before is consider an oversized load which in return increases the price of transportation.
Height is also constrained to a max of 15 feet due to the transportation system and overpasses making this the max height a module could have.
The length of the module is the most flexible of the dimensions with a max length of 48 feet.
This constrains were taken into account when designing the modules.
U D
MID POINT
A successful building creates a sense of belonging giving people a place where they can feel at home while being engaged with the outside world. The purpose of the building is to cultivate a sense of community through its mixed used program of both public and private. Using the concept of “bodega” as the driving force, the public is invited to explore the building as well as the site. A co working area is also proposed for both public and private use as a way to give a working environment for whoever needs it. Finally, outdoor areas are in placed to allow for a be er interaction between the locals and the visitors making it the last element that creates a community building in downtown Savannah
04
COMMERCIAL AREA
CREATE SPACE FOR POCKET PARK RESIDENTIAL ENTRANCE
TOWER FINAL FORM Commercial Commercial hospitality Parking garage Religious building Green spaces Site Commercial residential
CO WORKING SPACES
RESIDENTIAL
ART CENTER COASTAL CAROLINA
Derived from the desire to create a place for the arts for the community of Hilton Head, the project developed as a response for the needs of both the community and the workers. The program allows an integrative development of the visual arts, teaching studios, gallery and office spaces by creating an architecture that invites people. The center then becomes a place where people come to celebrate the arts, the architecture, and the town of Hilton Head
05
WORK SAMPLE
712 CONGRESS ST 06
BEAUFORT EYE CENTER ADDITION AND RENOV.
07
BEAUFORT PLAZA 08
09
SMILEY RESIDENCE
09
SMILEY RESIDENCE
WINDOW, CURTAIN WALL, STOREFRONT AND PLAN DETAILS
11
2.4 K.1 S1A LOBBYLOBBY T002T002 10 L.1 A527 K.2 4000.00 5/8" 1000.01 2100.04 S1A A526 L.1 ENGINEERENGINEER T006T006 0000 PV.4 EXISTING CONCRETE WALL TO REMAIN CONCRETE FOUNDATION PV.3 ROOMROOM F113F113 COLUMN EMSEMS MASONRY COLUMN S3A EX6 K.1 Project: Scale: Drawn By: Checked By: 1/2" 1'-0" Author EXTERIOR PLAN DETAILS A502 HALL BUILDING 1/2" 1'-0" A502 PLAN DETAIL GRIDLINES 2.4/J LOWER LEVEL 1/2" 1'-0" A502 PLAN DETAL LOBBY T002/ STAIR TS1 LOWER LEVEL PLAN DETAIL GRILINES 7/L LOWER LEVEL 1/2" 1'-0" A502 PLAN DETAIL @ GRIDLINE 7/J- LOWER LEVEL PLAN DETAIL HEALTH DIRECTOR T019A LOWER LEVEL 1/2" 1'-0" A502 E4 PLAN DETAIL @ COL. FIRST FLOOR 1/2" 1'-0" A502 PLAN DETAIL COL. FIRST FLOOR 1/2" 1'-0" PLAN DETAIL @ F113 FIRST FLOOR 1/2" 1'-0" A502 E2 PLAN DETAIL ELEV MACH ROOM T003B LOWER LEVEL M8A ELECELEC F113AF113A C C.1C.2 7/8" SHIM 0001.02 7/8" 3/4" C.1 0.1 C.2 1000.00 STL COLUMN 0001.03 3/8" X1 0.1 AGAINST BEAM BELOW FIRE RETARDANT WD TRIM, CHIEFCHIEF MASONRY MEETINGMEETING T106T106 0.1 1000.01 1000.00 COLUMN 4200.00 1000.05 PANEL 0001.03 X6 T104T104 2.4 1/4" 0001.03 K PUBLICPUBLIC TOILETTOILET (GENDER(GENDER NEUTRAL/NEUTRAL/ MALE)MALE) 2.4 K.1 3000.05 (GENDER(GENDER PUBLICPUBLIC TOILETTOILET (GENDER(GENDER NEUTRAL/NEUTRAL/ MALE)MALE) F.O. MASONRY K.1 3000.05 K.2 2010.00 WD TRIM, BACKPRIMED 0001.13 RETARDANT TRIM, BACKPRIMED 1000.00 2110.00 0001.13 2100.04 0001.06 10 L.1 4.1 4.1 Project: Scale: Drawn By: Checked By: 1/2" 1'-0" 09/07/2023 EXTERIOR PLAN DETAILS A503 HALL BUILDING 1'-0" PLAN DETAIL GRIDLINES 1/B FIRST FLOOR 1/2" 1'-0" A3 PLAN DETAIL GRIDLINES 2.2/C FIRST FLOOR 1/2" 1'-0" A6 PLAN DETAIL GRIDLINES 0.1/C FIRST FLOOR PLAN DETAIL GRIDLINES 0.1/E FIRST FLOOR 1/2" 1'-0" A503 C3 PLAN DETAIL GRIDLINES 0.1/G FIRST FLOOR PLAN DETAIL GRIDLINES 2.4/I FIRST FLOOR 1/2" 1'-0" A503 E3 PLAN DETAIL GRIDLINES 2.4/J FIRST FLOOR 1'-0" A503 PLAN DETAIL GRIDLINES 8/J FIRST FLOOR 1/2" 1'-0" A503 PLAN DETAIL COL. COL. 1/2" 1'-0" PLAN DETAIL BRICK BELOW T.H. CURTAIN WALL PLAN DETAIL APPARATUS BAY BRICK TRANSITION PLAN DETAIL APPARATUS BAY EX3 TO EX4 LOBBYLOBBY K.1 TO BLOCKING 2010.00 1000.01 2110.00 1000.01 0001.13 MANAGERMANAGER T109T109 WD SHIM COLUMN PV.4 PV.3 LOBBYLOBBY P101P101 P100P100 PV.1 PV.6 1000.01 PV.4 PV.2 EDGE BRICK BELOW SF5 4110.02 A525 EX4B EX4 A523 2010.00 FIRE RETARDANT WD TRIM, PTD OPP 4.1 2110.00 EXISTING WALL REMAIN MASONRY EX3 7/8" C.1C.2 1000.01 2010.00 MASONRY ALARM EQUIP 2100.04 0001.08 4000.00 4.1 APPARATUS F.O. MASONRY STL BENT PLATE Project: Date: Scale: Drawn Checked By: 1/2" 1'-0" 09/07/2023 Checker EXTERIOR PLAN DETAILS A504 LYNNFIELD PUBLIC SAFETY & TOWN HALL BUILDING Lynnfield, MA TOWN OF LYNNFIELD 1/2" 1'-0" A504 A1 PLAN DETAIL AT COL. COL. 1'-0" A504 PLAN DETAIL COL. COL. 1/2" 1'-0" A504 PLAN DETAIL GRIDLINE PV.2 FIRST FLOOR 1/2" 1'-0" PLAN DETAIL GRIDLINES PV.1/ PV.3 FIRST FLOOR 1/2" 1'-0" A504 A6 PLAN DETAIL GRIDLINES PV.2/ PV.4 FIRST FLOOR 1/2" 1'-0" PLAN DETAIL P108/ P104 FIRST FLOOR 1/2" 1'-0" PLAN DETAIL R/P109 FIRST FLOOR 1/2" 1'-0" PLAN DETAIL EXISTING CMU WALL INTERIOR SHEAR WALL POLICE PLAN DETAIL COL. COL. C, LEVEL PLAN DETAIL COL. 4/M FIRST FLOOR PLAN DETAIL COL. FIRST FLOOR PLAN DETAIL GRIDLINES 4.1/P FIRST FLOOR N 4.1M S3A MASONRY BELOW (SHOWN DASHED) M MASONRY SEALANT, BOTH SIDES, C EX10 C.1C.2 M8A X1 2.2 C.1 KITCHEN DININGDINING F210F210 C.2 EX10 EX10 M8A COLUMN M MASONRY BRICK N MASONRY 2.3 P200P200 SEALANT, BOTH SIDES, 0001.12 Project: Drawn Checked 1'-0" Author EXTERIOR PLAN DETAILS A505 LYNNFIELD PUBLIC SAFETY & TOWN Lynnfield, MA 1/2" 1'-0" A505 PLAN DETAIL @ COL 4.1/O FIRST FLOOR 1/2" 1'-0" PLAN DETAIL @ COL. FIRST FLOOR PLAN DETAIL COL. 5/M FIRST FLOOR PLAN DETAIL COL. M/F102 FIRST FLOOR C4 PLAN DETAIL AT COL. COL. SECOND FLOOR PLAN DETAIL GRIDLINES 1/C SECOND FLOOR PLAN DETAIL C/FS5 SECOND FLOOR PLAN DETAIL GRIDLINES 2.2/C SECOND FLOOR PLAN DETAIL CO. 3/F210A SECOND FLOOR PLAN DETAIL BRICK BELOW FIRST FLOOR PLAN DETAIL BRICK BELOW FIRST FLOOR PLAN DETAIL GRID 2.3 ATTIC ENTRY TYPE FOR SIZES SEE PARTITION STEEL LINTEL WINDOW AS SCHEDULED PRESSED STEEL FRAME; SEE SCHEDULE CMU 4" TYP. FILL WITH SOLID GROUT 1/8" 1/8" SEALANT TYP. EACH SIDE TYPE FOR SIZES SEE PARTITION WINDOW SCHEDULED PRESSED STEEL FRAME; SEE SCHEDULE CMU FILL WITH SOLID GROUT SEALANT TYP. EACH SIDE 1/8" 1/8" PTD. BLOCK PRESSED STEEL FRAME; SEE SCHEDULE PRESSED STEEL FRAME ANCHOR CLIP PRESSED STEEL FRAME; SEE SCHEDULE CONT. 5/8" GLAZING STOP, TYP. MATCH1/4"ADJ. FRAME DIM GLAZING AS SCHEDULED GLAZING TAPE DOOR SEE DOOR SCHEDULE GLAZING TAPE PRESSED STEEL FRAME; SEE SCHEDULE GLAZING AS SCHEDULED CONT. 5/8" GLAZING STOP, TYP. MATCH1/4"ADJ. FRAME DIM CONT. 5/8" GLAZING STOP, TYP. GLAZING AS SCHEDULED GLAZING TAPE METAL FRAMING SYSTEM PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE DOOR AS SCHEDULED ACOUSTICAL BATT INSULATION 1/2" 1/2" 1/4" 2" 3/8" VARIES SEE PARTITION TYPE FOR SIZES 5/8" GWB TYP. PROVIDE DIAGONAL BRACING OPENINGS LARGER THAN 4'-0" ABOVE FINISH CEILING TYP. CERAMIC WALL TILE WHERE INDICATED (SHOWN AS DASHED) METAL FRAMING SYSTEM PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE ACOUSTICAL BATT INSULATION 1/2" 1/2" 1/4" 2" VARIES SEE PARTITION TYPE FOR SIZES 5/8" GWB TYP. PROVIDE DIAGONAL BRACING OPENINGS LARGER THAN 4'-0" ABOVE FINISH CEILING TYP. CERAMIC WALL TILE WHERE INDICATED (SHOWN AS DASHED) METAL FRAMING SYSTEM PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE GLAZING AS SCHEDULED CONT. 5/8" GLAZING STOP, TYP. GLAZING TAPE ACOUSTICAL BATT INSULATION 1/2" 1/2" 1/4" 2" 2" 3/8" VARIES SEE PARTITION TYPE FOR SIZES 5/8" GWB TYP. METAL FRAMING SYSTEM PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE GLAZING AS SCHEDULED CONT. 5/8" GLAZING STOP, TYP. GLAZING TAPE 1/2" 1/2" 1/4" SEE PARTITION TYPE FOR SIZES ACOUSTICAL BATT INSULATION 2" 3/8" VARIES 5/8" GWB TYP. PRESSED STEEL FRAME; SEE SCHEDULE METAL FRAMING SYSTEM PRESSED STEEL FRAME ANCHOR CLIP SEALANT TYP. EACH SIDE CERAMIC WALL TILE WHERE INDICATED (SHOWN DASHED) VARIES GLAZING SEE FRAME TYPES HOLLOW METAL FRAME; SEE FRAME TYPES SOLID GROUT, TYP. SEALANT TYP. EACH SIDE FLOOR FINISH AS SCHEDULED SIM WITH LAM GLAZING, SEE FRAME TYPES FOR LOCATIONS, TYP PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE PRESSURE TREATED WD BLOCKING W/ IN FRAME CAVITY SECURED TO EXISTING WALL GLAZING SCHEDULED GLAZING TAPE GLAZING STOP, TYP. EXISTING CMU WALL TO REMAIN VARIES METAL FRAMING SYSTEM PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE GLAZING SCHEDULED CONT. 5/8" GLAZING STOP, TYP. GLAZING TAPE ACOUSTICAL BATT INSULATION 5/8" GWB TYP. METAL FRAMING SYSTEM PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE GLAZING AS SCHEDULED CONT. 5/8" GLAZING STOP, TYP. GLAZING TAPE 1/2" 1/2" 1/4" SEE PARTITION TYPE FOR SIZES ACOUSTICAL BATT INSULATION 2" 3/8" VARIES SHEATHING WOOD FINISH CLIPS H 5/8" GWB TYP. PRESSED STEEL FRAME; SEE SCHEDULE METAL FRAMING SYSTEM PRESSED STEEL FRAME ANCHOR CLIP SEALANT TYP. EACH SIDE DOOR SEE DOOR SCHEDULE GLAZING AS SCHEDULED CONT. 5/8" GLAZING STOP, TYP. J 10 PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE PRESSURE TREATED WD BLOCKING W/ IN FRAME CAVITY SECURED TO EXISTING WALL GLAZING AS SCHEDULED GLAZING TAPE GLAZING STOP, TYP. EXISTING CMU WALL TO REMAIN PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE PRESSURE TREATED WD BLOCKING W/ IN FRAME CAVITY SECURED TO EXISTING WALL GLAZING AS SCHEDULED GLAZING TAPE GLAZING STOP, TYP. EXISTING CMU WALL TO REMAIN 1/2" 1/2" METAL FRAMING SYSTEM PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE GLAZING AS SCHEDULED CONT. 5/8" GLAZING STOP, TYP. GLAZING TAPE ACOUSTICAL BATT INSULATION 5/8" GWB EQ VARIES EQ TYPE FOR SIZES 5/8" SEE PARTITION STEEL LINTEL DOOR SCHEDULED PRESSED STEEL FRAME; SEE SCHEDULE CMU FILL WITH SOLID GROUT 1/8" 1/8" COORD. FRAME WIDTH W/ FURRING. SEE WALL TYPE, TYP. PTD. BLOCK PRESSED STEEL FRAME; SEE SCHEDULE PRESSED STEEL FRAME ANCHOR CLIP COORD. FRAME WIDTH W/ FURRING. SEE WALL TYPES. EXTERIOR CMU THERMALLY BROKEN PRESSED STEEL FRAME; SEE SCHEDULE MORTAR CONTROL MESH SEALANT TYP. EACH SIDE, BACKER ROD ON EXTERIOR REQUIRES DOUBLE STEEL LINTEL AT HEAD BRICK MASONRY VENEER SEE PARTITION TYPES FOR SIZES FLASHING TYPICAL (2) LAYERS 5/8" GWB TYP. PRESSED STEEL FRAME; SEE SCHEDULE METAL FRAMING SYSTEM PRESSED STEEL FRAME ANCHOR CLIP SEALANT TYP. EACH SIDE 2" 1/2" 1/2" TYPE FOR SIZES 5/8" GWB TYP. PRESSED STEEL FRAME; SEE SCHEDULE METAL FRAMING SYSTEM PRESSED STEEL FRAME ANCHOR CLIP SEALANT TYP. EACH SIDE DOOR AS SCHEDULED 08 1110.01 METAL FRAMING SYSTEM PRESSED STEEL FRAME; SEE SCHEDULE SEALANT TYP. EACH SIDE DOOR SCHEDULED ACOUSTICAL BATT INSULATION 1/2" 1/2" 1/4" EQ. EQ. SEE PARTITION TYPE FOR SIZES 5/8" GWB TYP. Project: Date: Scale: Drawn By: Checked By: Copyright 2018, Tappé Architects, Drawing Issue Record: 3" 1'-0" A2204.00 09/07/2023 Author Checker HOLLOW METAL FRAME DETAILS A522 LYNNFIELD PUBLIC SAFETY & TOWN HALL BUILDING 55 Summer Street Lynnfield, MA TOWN OF LYNNFIELD 3" 1'-0" A522 C6 CMU HEAD DETAIL @ INTERIOR WINDOW 3" 1'-0" A522 B6 CMU SILL DETAIL @ INTERIOR WINDOW 3" 1'-0" A522 D6 CMU WINDOW JAMB @ INTERIOR 3" 1'-0" A522 B1 INTERIOR DOOR HEAD/MULLION DETAIL 3" 1'-0" A522 A1 INTERIOR WINDOW MULLION DETAIL 3" 1'-0" A522 A6 STEEL STUD HEAD DETAIL @ INTERIOR DOOR 3" 1'-0" A522 A5 STEEL STUD HEAD DETAIL @ INTERIOR WINDOW 3" 1'-0" A522 C5 STEEL STUD INTERIOR WINDOW HEAD DETAIL 3" 1'-0" A522 B5 STEEL STUD INTERIOR WINDOW SILL DETAIL 3" 1'-0" A522 D5 STEEL STUD JAMB W/ LAYER GWB INTERIOR WINDOW 3" 1'-0" A522 C1 TYPICAL INTERIOR WINDOW SILL DETAIL 1'-0" A522 D3 EXISTING CMU WINDOW JAMB @ INTERIOR 1'-0" A522 A2 METAL STUD CEILING HEAD @ INTERIOR WINDOW 1'-0" A522 B2 STEEL STUD WITH WOOD FINISH INTERIOR WINDOW SILL DETAIL 1'-0" A522 C2 JMB INT. HM FRAME DOOR 3" 1'-0" A522 A3 JAMB INT. HM FRAME @ CORNER 1'-0" A522 C3 EXISTING CMU WINDOW HEAD @ INTERIOR 3" 1'-0" A522 B3 EXISTING CMU WINDOW SILL @ INTERIOR 1'-0" A522 D2 STEEL STUD HEAD W/ LAYERS GWB 3" 1'-0" A522 E1 CMU HEAD DETAIL @ INTERIOR DOOR 1'-0" A522 E2 CMU DOOR JAMB @ INTERIOR DOOR 1'-0" A522 E3 CMU WALL VENEER MASONRY HEAD DETAIL 3" 1'-0" A522 E5 STEEL STUD JAMB W/ LAYERS GWB 3" 1'-0" A522 E6 STEEL STUD JAMB W/1 LAYER GWB 3" 1'-0" A522 D1 HEAD @ INT. HM FRAME W/ DOOR
WINDOW, CURTAIN WALL, STOREFRONT AND PLAN DETAILS
11
MATCH COLOR WINDOW BENT PLATE 2010.00 3/4" EDGE TRIM BEYOND TRIM, 0001.06 0001.12 BLOCKING 4020.01 0001.01 3/4" 0001.15 2010.00 FIRE RETARDANT TRIM, 3/4" 3/4" 4020.01 2100.04 1000.00 0001.07 0001.10 0001.01 1000.01 7/8" 0001.10 0001.12 0001.15 0001.14 M.O. 1/2" 4020.01 CONT. WRAPPED INTO WINDOW OPENING 0.1 2010.00 SUPPORT HEAD WD PANEL CONT. WRAPPED INTO WINDOW OPENING 0.1 0001.15 0001.06 4020.01 2010.00 0.1 4020.01 1000.01 0001.13 0001.12 0001.13 0001.15 0.1 ALIGN BACK GLAZING FRONT FILL CAVITY Project: Scale: Drawn By: Checked By: 1'-0" Author WINDOW DETAILS A523 HALL BUILDING ALUMINUM OPERABLE WINDOW HEAD DETAIL EX4 1'-0" C3 ALUMINUM OPERABLE WINDOW JAMB DETAIL EX4 ALUMINUM OPERABLE WINDOW SILL DETAIL EX4 FIXED WINDOW HEAD DETAIL MASONRY CMU WALL FIXED WINDOW SILL DETAIL MASONRY CMU WALL 1'-0" FIXED WINDOW JAMB DETAIL MASONRY CMU WALL ALUMINUM DOUBLE HUNG OPERABLE WINDOW HEAD DETAIL EX7 ALUMINUM DOUBLE HUNG OPERABLE WINDOW SILL DETAIL EX7 1'-0" ALUMINUM DOUBLE HUNG OPERABLE WINDOW JAMB DETAIL@ EX7 1'-0" ALUMINUM DOUBLE HUNG WINDOW JAMB CENTER TRIM 1000.01 0001.13 7/8" STRIP OVERLAP WINDOW FLANGE 0001.14 1000.01 0001.15 0001.12 1000.05 0002.09 0001.10 0001.07 1000.01 1000.05 4020.01 0001.15 Project: Scale: Drawn Checked indicated Author WINDOW DETAILS A524 LYNNFIELD PUBLIC SAFETY & TOWN Lynnfield, MA 1'-0" ALUMINUM OPERABLE WINDOW HEAD DETAIL EX8 1'-0" A524 C6 ALUMINUM OPERABLE WINDOW JAMB DETAIL EX8 ALUMINUM OPERABLE WINDOW SILL DETAIL EX8 1'-0" ALUMINUM DOUBLE HUNG OPERABLE WINDOW HEAD DETAIL EX10 ALUMINUM DOUBLE HUNG OPERABLE WINDOW SILL DETAIL EX10 1'-0" ALUMINUM DOUBLE HUNG OPERABLE WINDOW JAMB DETAIL EX10 ALUMINUM DOUBLE HUNG OPERABLE WINDOW MEETING RAIL LOWER LEVEL 21/32" TH&PD LOWER LEVEL 1/2" FLASHING 0001.12 TH&PD FIRST FLOOR 104' 21/32" 3000.00 0001.13 1/2" ANGLE2100.04 COLUMN REFER BEAM 0001.15 FASTENED BOX BEAM 1/2" EDGE 5/8" 0001.07 0001.10 GROUT ENTIRE SLOT SOLID 0001.14 0001.15 2110.00 COUNTER QF201 0001.13 2110.10 5100.00 1000.00 STRUCTURAL DWGS 4200.01 0001.08 2110.00 M ALUM. STOREFRONT SYSTEM SEALANT AND BACKER ROD CAVITY WITH FOAM SEALANT GYPSUM SHEATHING POLYISOCYANURATE 2110.00 FIRE STATION FIRST FLOOR PV.2 0001.13 STL BENT PLATE 2110.10 METAL FLASHING TO MATCH COLOR OF STOREFRONT 1000.00 O.C. SPACING PV.4 PV.2 4110.02 2100.01 1/2" K.1 PV.3 PRESSED STEEL FRAME; X5 Project: Date: Scale: Drawn By: Checked By: indicated 09/07/2023 CD STOREFRONT DETAILS A525 HALL BUILDING 55 Summer Street Lynnfield, MA TOWN OF LYNNFIELD 1'-0" ALUMINUM STOREFRONT SILL DETAIL MAIN ENTRY ALUMINUM STOREFRONT HEAD DETAIL MAIN ENTRY 1'-0" A525 ALUMINUM STOREFRONT JAMB DETAIL CORNER MULLION 1'-0" A525 A1 STOREFRONT SILL AT MASONRY CMU WALL 1'-0" A525 STOREFRONT HEAD DETAIL METAL PANEL 1'-0" STOREFRONT JAMB DETAIL AT MASONRY METAL PANEL REVEAL DETAIL 1'-0" STOREFRONT HEAD DETAIL VESTIBULE T001 INTERIOR 1'-0" A525 ALUMINUM STOREFRONT SILL DETAIL CONCRETE SLAB 1'-0" A525 C4 ALUMINUM STOREFRONT HEAD DETAIL POLICE VESTIBULE P100 1'-0" A525 ALUMINUM STOREFRONT JAMB DETAIL CORNER MULLION POLICE VESTIBU P100 1'-0" A525 ALUMINUM STOREFRONT HEAD DETAIL DOOR GLAZING 1'-0" A525 ALUMINUM STOREFRONT JAMB DETAIL @ DOOR GLAZING 1'-0" A525 ALUMINUM STOREFRONT JAMB DETAIL @ EXISTING BRICK WALL 1'-0" A525 ALUMINUM STOREFRONT JAMB DETAIL @ INTERIOR WINDOW 1'-0" INTERIOR WINDOW SLOPE 0001.15 4110.02 0001.14 0001.03 MASONRY K.2 4110.01 4110.01 0001.13 0001.13 114' 21/32" PV.1 1000.01 1000.00 4200.01 BEAM SPACING LEVEL 114' 21/32" 1000.00 BENT PLATE METAL FLASHING MATCH COLOR STOREFRONT CHANNEL, 0002.03 4200.02 1000.00 1000.00 F.1 0001.13 0001.15 BOX BEAM SUPPORT HEAD 1000.00 WRAP INTO OPENING 1/2" 4200.02 STOREFRONT 2100.04 ANGLE 0002.03 0001.06 PV.6 1000.01 100' 21/32" PV.2 PV.6 Project: Date: Drawn By: Checked Copyright TappéArchitects, A2204.00 Author Checker STOREFRONT DETAILS A526 LYNNFIELD PUBLIC SAFETY & TOWN 1'-0" ALUMINUM STOREFRONT SILL DETAIL MASONRY 12" CONCRETE STEM ALL 1'-0" A2 ALUMINUM STOREFRONT JAMB DETAIL MASONRY 1'-0" ALUMINUM STOREFRONT HEAD DETAIL @ METAL PANEL METAL STUD 1'-0" A526 ALUMINUM STOREFRONT HEAD DETAIL@ METAL PANEL ALUMINUM STOREFRONT HEAD DETAIL INTERIOR S3B ALUMINUM STOREFRONT HEAD DETAIL METAL PANEL 1'-0" ALUMINUM STOREFRONT HEAD DETAIL VESTIBULE T100 1'-0" ALUMINUM STOREFRONT HEAD DETAIL POLICE ENTRY 1'-0" ALUMINUM STOREFRONT SILL DETAIL POLICE ENTRY 1'-0" ALUMNIM STOREFRONT JAMB DETAIL POLICE ENTRY 7 1/2" 1/2" EX1 EX1 07 0001.14 0001.13 R.O. TO F.O. BLOCKING 1000.01 4410.01 4410.01 PRIMARY SEAL, TYP. 0001.13 0001.15 0001.12 2100.04 0001.09 SEALED INTO BACK OF CW GLAZING POCKET CLAMPED IN PLACE W/POCKET FILLER 4410.01 EXT TRIM 2110.00 1/2" 0001.06 WRAP AROUND AND INTO CW OPENING 4410.01 FILL CAVITY ALIGN BACK OF GLAZING W/FRONT OF SHEATHING 10 L.1 1/2" R.O. TO F.O. 09 5713.01 SEE RCP 07 2100.04 07 0001.06 WRAP AROUND INTO CW OPENING 07 0001.12 07 0001.13 06 1000.01 PRIMARY SEAL, TYP. 07 0001.09 SEALED INTO BACK OF CW GLAZING POCKET CLAMPED IN PLACE W/ POCKET FILLER 07 0001.13 05 1000.00 STL BENT PLATE 05 1000.00 STL CHANNEL 08 4110.01 08 4110.01 06 4200.01 FIRE RETARDANT BACKPRIMED WOOD TRIM 5/4" 09 2110.00 3" 08 4410.01 07 0001.08 FACE OF BRICK BEYOND 07 0001.08 07 0002.03 07 0002.09 THRU WALL MTL FLASHING EX2 EX4e L.1 07 0001.13 FILL CAVITY 08 4410.01 0.125" BREAK METAL PANNING SEALED INTO GLAZING POCKETS OF CW FRAMES, TYP. FINISH TO MATCH CW FRAMES CONT. SILL HEAD FRAMES MITERED @ CORNERS, TYP. CW FRAMES FASTENED TOGETHER W/ CONT. ALUM ANGLES 07 0001.13 08 4410.01 1/2" 1/2" 08 4410.01 07 2100.04 L.1 1/2" BLOCKING 04 0001.03 PROVIDE ANCHORS END OF JOINTS, TYP. 07 0001.13 08 4410.01 07 0001.06 07 0001.13 07 0001.13 08 4410.01 EXT. TRIM SEALED INTO BACK OF CW GLAZING POCKET CLAMPED PLACE W/ POCKET FILLER PRIMARY SEAL, TYP. WRAP AROUND INTO CW OPENING 05 1000.00 STL CHANNEL EX1A 07 0001.14 07 2100.04 07 0001.09 06 1000.01 EDGE OF BRICK BEYOND EDGE OF JAMB EXT BEYOND 2" L.1 7 EX4 PREFORMED SILICONE SEALANT EXTRUSION SEALED INTO BACK OF CW GLAZING POCKET CLAMPED IN PLACE W/ POCKET FILLER PRIMARY SEAL, TYP. 07 2100.04 K.1 R.O. TO F.O. BLOCKING 06 1000.01 09 2110.00 06 4200.01 06 1600.01 07 0002.03 07 0001.06 07 0001.08 06 1600.01 06 2010.00 08 0001.00 07 0001.13 WRAP INTO CW OPENING 08 0001.05 07 0001.15 07 0001.13 07 0001.12 05 4000.00 08 4410.01 7 2100.04 2110.10 0001.06 WRAP AROUND INTO CW OPENING 07 0001.12 07 0001.13 0002.09 PRIMARY SEAL, TYP. SEALED INTO BACK OF CW GLAZING POCKET CLAMPED PLACE W/ POCKET FILLER 0001.13 0001.00 STL CHANNEL 05 1000.00 STL BENT PLATE 0001.09 4200.01 FIRE RETARDANT BACKPRIMED WOOD 08 4110.01 1/4" 5" 09 2110.00 1000.01 1/2" 4410.01 7 0001.13 0001.06 EXT. TRIM PREFORMED SILICONE SEALANT EXTRUSION SEALED INTO BACK OF CW GLAZING POCKET CLAMPED IN PLACE W/ POCKET FILLER WRAP AROUND INTO CW OPENING 1000.00 STL CHANNEL 0001.00 4410.01 4410.01 0001.13 0001.12 2100.04 1000.01 3/4" EX6 BLOCKING EDGE OF JAMB EXT BEYOND 0001.04 0001.05 PRIMARY SEAL FOAM SEALANT 1/2" 0001.13 0001.13 SEALED INTO BACK OF CW GLAZING POCKET CLAMPED IN PLACE W/ POCKET FILLER WRAP AROUND AND INTO CW OPENING PRIMARY SEAL, TYP. 3000.00 0001.06 0001.12 1000.01 4410.01 1/2" 0001.15 4110.01 4110.01 EXT. TRIM 0001.09 R.O. TO F.O. BLOCKING CONCRETE WALL SEE STRUCTURAL EX6 07 0001.07 07 0001.08 S1A 2" 07 0001.14 ALIGN BACK OF GLAZING W/FRONT OF CONCRETE 7 MIN MIN 1/2" 07 2100.04 07 0001.06 WRAP AROUND INTO CW OPENING 07 0001.12 07 0001.13 06 1000.01 PRIMARY SEAL, TYP. 07 0001.09 SEALED INTO BACK OF CW GLAZING POCKET CLAMPED IN PLACE W/ POCKET FILLER 07 0001.13 05 1000.00 STL BENT PLATE 05 1000.00 STL CHANNEL 08 4110.01 08 4110.01 FIRE RETARDANT BACKPRIMED WOOD TRIM 5/4" 09 2110.00 08 4410.01 07 0001.08 FACE OF BRICK BEYOND 06 2010.00 Project: Date: Scale: Drawn By: Checked By: Copyright 2018, Tappé Architects, Inc. Drawing Issue Record: 3" 1'-0" A2204.00 09/07/2023 SP DG/CD CURTAINWALL DETAILS A527 LYNNFIELD PUBLIC SAFETY & TOWN HALL BUILDING 55 Summer Street Lynnfield, MA TOWN OF LYNNFIELD 1'-0" A527 C5 ALUMINUM CURTAINWALL JAMB DETAIL @ MASONRY METAL STUD WALL 1'-0" A527 B5 ALUMINUM CURTAINWALL HEAD DETAIL @ METAL PANEL 8" METAL STUD WALL 3" 1'-0" A527 A1 CURTAIN WALL CORNER MULLION JAMB DETAIL 1'-0" A527 A5 ALUMINUM CURTAINWALL SILL DETAIL @ MASONARY 6" METAL STUD 3" 1'-0" A527 C3 ALUMINUM CURTAINWALL JAMB DETAIL @ FIRE RETARDENT WOOD 8" METAL STUD WALL 3" 1'-0" A527 B3 ALUMINUM CURTAINWALL HEAD DETAIL @ FIRE RETARDENT WOOD 6" METAL STUD WALL 3" 1'-0" A527 A3 ALUMINUM CURTAINWALL SILL DETAIL @ MASONRY 8" METAL STUD 3" 1'-0" A527 B1 ALUMINUM CURTAINWALL JAMB DETAIL @ MASONRY METAL STUD 3" 1'-0" A527 C1 ALUMINUM CURTAINWALL HEAD DETAIL @ METAL PANEL 8" METAL STUD WALL & GUTTER
FACADE STUDIES
12
R2L: ARCHITECTS Northcap Center 02 New Addition - Option 1C December 12, 2022
MEDIA MIXED & DIGITAL
3 D P R I N T D I G I T A L M E D I A
MSP 305.335.4298 | sofiaperrotta26@gmail.com
