Since the discovery of the third photoreceptor in the eye, the focus has been on the blue end of the lighting spectrum (peaking at 460nm in terms of melatonin suppression).
However, research has increasingly revealed the importance of red and infrared wavelengths to human health. In Unseen Benefits (p7) Dr Martin Moore-Ede, who as a Harvard professor led the team that located the suprachiasmatic nucleus, the biological clock in the human brain, looks at its significance.
There are diverse areas where deep red and infrared light have been shown to have beneficial effects. Near infrared light has been found to reverse the deteriorations of mitochondrial function that result from ageing and disease, for example.
A study at the University of Pittsburgh published earlier this year found that exposure to 617nm red light could reduce the size of blood clots with implications for treating and preventing heart attacks and strokes, while
irradiating human skin with 670nm red light for 15 minutes has been found to beneficially affect glucose tolerance.
Ironically, our adoption of energy-saving measures has had unforeseen repercussions in this area. 'We live in an infrared-deprived world,' says Moore-Ede, citing the growing use of IRblocking E-Glass in buildings and LED sources that have little deep red and no infrared (unlike wood fires, candles and incandescent lamps).
The solution though is not exclusively artificial. 'The richest source of near-infrared light is sunlight, or even daylight on a cloudy day,' says Moore-Ede.
