Electrical Review - September 2017

Page 1

Informing the electrical industry for over 140 years

September 2017 Volume 250 | No 9 www.electricalreview.co.uk

A growing market

Test & measurement The last resort

Technology to market :RUOG¡V Ă€UVW digital distribution transfomer



CONTENTS | 3

04 NEWS A burning issue

10 GOSSAGE Gossage:gossip

12 UPS Achieving data centre type UPS protection for mid size server rooms

32

EDITOR: Elinore Mackay 020 8319 1807 elinorem@electricalreview.co.uk

EURODOBLE Q&A

PRODUCTION MANAGER Alex Gold 020 7933 8999 alexg@sjpbusinessmedia.com SALES MANAGER Sunny Nehru 020 7933 8974 sunnyn@sjpbusinessmedia.com ACCOUNT MANAGER Amanda McCreddie 020 7933 8972 Amanda@electricalreview.co.uk PUBLISHER Wayne Darroch PRINTING BY Buxton Paid subscription enquiries Tel: +44 (0) 1635 879361 electricalreview@circdata.com SJP Business Media PO Box 6009, Thatcham Berkshire, RG19 4QB, UK

16 TECHNOLOGY TO MARKET World’s first distribtion transformer

36 TEST & MEASUREMENT

Subscription rates: UK £191 per year, Overseas £216 Electrical Review is a controlled circulation monthly magazine available free to selected personnel at the publisher’s discretion. If you wish to apply for regular free copies then please visit: www.electricalreview.co.uk/register Electrical Review is published by

2nd floor, 52-54 Gracechurch Street London EC3V 0EH 020 7933 8999 Any article in this journal represents the opinions of the author. This does not necessarily reflect the views of Electrical Review or its publisher – SJP Business Media ISSN 0013-4384 – All editorial contents © SJP Business Media Jan-Dec 2015 5,784

Follow us on Twitter @elecreviewmag

26 OMICRON No need for heavy weights

41 PRODUCT WATCH

Join us on LinkedIn http://linkd.in/H1viOF

www.electricalreview.co.uk


4 | NEWS

A burning issue A story regarding a scalding incident that resulted in loss of life has recently resurfaced on national media. Sadly, a woman was severely scalded when using a shower in her hotel room and she subsequently died from her related injuries Regrettably, this is not an isolated incident and severe scalding incidents continue to occur on a regular basis. Data on hospital patient care activity –published every year by NHS England– shows that there were 718 admissions from contact with hot tap-water in the year 2015-16, up from 672 in the previous year. Despite similar numbers of admissions for the past seven years, the most worrying statistic is that almost half of these incidents affected children up to the age of 14. Unfortunately, it is young children who, along with the elderly, are the most vulnerable to severe injury because they have thinner and more sensitive skin. The severity of injury that contact with hot water can give should not be underestimated: water temperatures of 60 degrees can cause third-degree burns in only five seconds of contact with the skin of an adult. There is no doubt that temperature control is necessary to avoid catastrophic accidents like this one. The most effective way of achieving this is by using thermostatic mixing valves (TMVs). TMVs are located within or near the sink, bath or shower units and are designed to accurately control water temperature by mixing hot and cold water to produce the required blend and maintain it at the user-selected or pre-determined safe temperature. The control is carried out by a thermally sensitive mechanism within the valve, which also plays a crucial role in preventing scalds by avoiding sudden increases

Electrical Review | September 2017

in water temperature. This is achieved by shutting down the flow of hot water in instances where cold water pressure unexpectedly drops. The use of TMVs reduces the hot water discharge temperatures to between 37 – 46°C, therefore drastically reducing the chance of scalding. The importance of this safety feature has long been realised by the Department of Health (DH). The Health Technical Memorandum (HTM) 04-01 –Safe water in healthcare premises– was published in 2006 and requires the use of Type 3 TMVs in all UK care establishments (e.g. hospitals, nursing homes and care homes), in all areas where patients and visitors may have access to. Type 3 refers to TMVs with superior thermal performance, which are subjected to strict third-party testing to ensure the requirements of HTM 04-01 are met along with associated performance specification D08. This is carried out under the TMV3 certification scheme currently managed by Buildcert. Such stringent requirements clearly reflect the DH’s intent to provide the highest safety and protection levels possible from hot water in healthcare premises. Although general commercial facility

owners do not need to consider the greater vulnerability of hospital patients, they do need to ensure all necessary steps are taken to prevent people using their facility from being injured. This is known as the ‘duty of care’, which requires a risk assessment to be carried out to establish how susceptible people are to any dangers, such as scalding, existing within the building and initiating appropriate measures to minimise the risk within the building. Even if no specific recommendations or requirements have been identified in the risk assessment, suggested best practice is for TMVs to be installed in all buildings. Taking such positive action will help to minimise the risk of scalding to building users and help building owners meet their duty of care obligations. Beama encourages all hotel and wider commercial facility owners to review their duty of care and associated risk assessments to make sure that tragic events like this do not happen again. Further information, guidance and frequently asked questions about TMVs and related topics are available in the Water Safety and Hygiene group section at www.beama.org.uk.



6 | NEWS

BESA, ECA and SELECT poll finds many SMEs are not being paid within 30 days Almost two in three (63 per cent) engineering services firms were not paid within 30 days by public sector bodies during the second quarter of this year, according to new survey findings from the ECA, the Building Engineering Services Association (BESA), and SELECT. The figures represent a decline in prompt payment performance on the first quarter of the year, when 55 per cent of businesses were not paid within 30 days by public sector bodies such as local authorities and NHS trusts. In many cases, this directly contravenes government legislation on prompt public sector payment, known as the ‘Public Contracts Regulations 2015’. In addition, four in 10 firms (39 per cent) said over three per cent of their turnover is being held in retentions by firms up the supply chain (see Notes to Editors for more information). Despite the challenging payment climate, turnover among respondents remained strong, with over eight in 10 (81 per cent)

Electrical Review | September 2017

finding turnover increased or stayed the same in Q2, compared to Q1. Looking ahead to Q3, 87 per cent of businesses expect turnover to rise, or remain steady. ECA CEO Steve Bratt commented: “The engineering services sector continues to show resilience despite the ongoing challenges of late payment and cash retentions, and the increasing challenge of rising material and labour costs. “With public sector support – including prompt payment – our sector can deliver key infrastructure projects and provide skilled technical employment. This would support of government objectives for growth and delivering whole-life asset value to the UK economy.” BESA chief executive Paul McLaughlin said: “Despite the political turmoil created by Brexit, it is good to see that our sector remains stable and that contractors are reasonably optimistic about the future. Rising costs and extended payment periods continue to create challenges, but the fact that some building engineering firms have improved their profit margins is testament to their ability to manage risk. “It is, however, vital that the government continues to feed the pipeline of infrastructure work and that companies in our sector hold their nerve. Success will not be spectacular or short-term and it will definitely have to be hard won.” SELECT Managing Director Newell McGuiness added: “Late payment can have a devastating effect on engineering businesses, as well as to the wider economy. Cash flow is vital to ensure apprentice recruitment, employment and up-skilling training continues to grow. In our view, improving the velocity of cash is vital in improving our industry.” Despite business optimism, materials prices continue to rise, with seven in 10 businesses (68 per cent) reporting an increase. In addition, almost half of companies (47 per cent) said labour costs had risen. The sector-wide ‘Building Engineering Business Survey’, sponsored by Scolmore, received 318 responses from SELECT, BESA and ECA members during July. The trade bodies are currently working with construction industry stakeholders and government to secure a sector deal which will enhance the built environment, while supporting SMEs throughout the supply chain.

Diesel and petrol ban Martin Jones, business development manager for services & solutions at Rexel UK comments on the latest government announcement that Britain is set to ban all new diesel and petrol cars and vans from 2040 “With the announcement last week that the government is aiming to ban all new diesel and petrol cars from 2040, as well as reviewing the use of hybrid vehicles; the drive towards the use of electric vehicles will undoubtedly accelerate at a much faster pace than current levels. “Whilst vehicle manufacturers will obviously take the lead on enhancing their EV offerings, there is still much to be done across UK infrastructure to support the ever-growing use of EV vehicles. “Although at Rexel we have already seen many businesses beginning to invest in EV charging facilities, the current facilities available does not support an increased number of EV vehicles on the roads. As a result, it won’t be long before the government starts introducing measures requiring businesses to offer EV charging facilities. “With the pressure now on to meet this new government target, there is a real opportunity for consumer facing businesses, and indeed commercial operations, to stay ahead of the game and ensure they are prepared for the 2040 target. By taking a planned approach to EV, businesses can not only avoid having to make a ‘panic’ investment when any future legislation is put into place, but they can also reap rewards in the short term. “EV solutions also offer many benefits to businesses looking to attract customers, particularly those who are already seeking more sustainable options. As well as offering a point of differentiation in the eyes of end users, it can also offer a commercial opportunity for the business itself. “By being able to market themselves as ‘electric vehicle friendly’, a location will automatically become more attractive to the increasing number of drivers already using or planning to purchase an electric car. However, more importantly, the flexibility available within today’s charging points means that businesses can set or change the charging price to suit their own requirements, allowing them to secure a return on investment and even generate a profit, all within a period of time of their choosing.”


Has your ESOS report identified lighting as a key savings source? REDUCE YOUR LIGHTING ENERGY CONSUMPTION BY WITH NO CAPEX

SYL

84%

Combine the very best LED savings (-50%) with the best in class integrated control system (-68%) achieving the highest score for lighting control on BCO and BREEAM. Easily achieve the above savings with SylSmart controlled luminaires from Feilo Sylvania. We are proud to offer you a simple and cost effective solution for your lighting needs. By installing our range of SylSmart enabled luminaires; upgrading your building’s lighting scheme has never been easier. Once installed with just a simple mains connection, the luminaires automatically configure themselves to communicate with their neighbouring luminaires, resulting in installation costs typically 25% lower than other controlled lighting installations and with no commissioning required ensures your building is ready to use as soon as the luminaires are connected. The system is fully retrofittable with no control cabling required and integrates easily with your building management system.

MAKING THE SOLUTION BUDGET NEUTRAL Don’t let the thought of financing a project hold you back. Feilo Sylvania’s LOGIC Finance Solution enables you to realise your project. LOGIC is budget neutral with no large up-front costs, just simple, manageable, monthly re-payments – typically lower than your existing lighting costs with the additional benefit of saving long after the finance term ends, enabling you to focus on your business.

Example OPEX

Finance

Existing Monthly Costs New Monthly Costs

Contact us today to see how we can help you to start saving tomorrow!

www.feilosylvania.com

Tel: 0800 440 2478

info.uk@feilosylvania.com

Cost


8 | NEWS

Electrician highly commended in Britain’s Top Tradesperson contest An NICEIC registered electrician from Wigan narrowly missed out on the top prize in a contest to find the nations’ best tradesperson. Karl Mather, owner of KDM Electrical, was awarded highly commended during this year’s Britain’s Top Tradesperson competition as organised by Screwfix. He was one of eight tradespeople who made it through to the Grand Final at Wembley after more than 5,000 tradesfolk entered the highly competitive contest. He said: “I’m over to moon to have been highly commended in this competition. I was able to showcase the variety of electrical challenges I’ve achieved for my customers, but also how important it is for me to support those in need. I met a great bunch

of tradespeople at the final, who all really knew their stuff so I’m thrilled to have been given this award.” Karl impressed the judges with his wealth of knowledge and willingness to go above and beyond for his customers. Over the years Karl has supported those in need and regularly does a lot of selfless activities for charities. Screwfix’s Marketing Director, Graham Smith, added “Karl stood out with his ethos of going the extra mile and this was clearly shown through his high standard of work and going above and beyond to support individuals in need.” Karl hit the headlines earlier this year when he paid for and fitted a new heating system for an elderly couple who could not

afford to replace an old heater. Emma Clancy, CEO of NICEC added: “It is not surprising that Karl was highly recommended. He is a credit to the industry and his dedication and genuine care for his customers really make him a stand out tradesperson. I am proud to have him as a NICEIC registrant.”

Know your numbers and keep the silent killer at bay As many as 7 million people in the UK are living undiagnosed and therefore unaware that they are at risk of high blood pressure – often called the silent killer. In support of Know Your Numbers Week, ECIS, the employee benefits company for the construction industry, is urging workers to get their blood pressure checked and take any necessary action to reach and maintain a healthy blood pressure. There are many factors that can contribute to high blood pressure; not doing enough physical activity, being overweight or obese, having too much salt in your diet, regularly drinking too much alcohol as well as having a family history of high blood pressure. In the UK nearly 30% of adults

Electrical Review | September 2017

suffer from high blood pressure. Vicki Leslie, client relationship manager for ECIS, comments, “Whilst this isn’t a new problem, our modern lifestyles can make us more susceptible than ever to high blood pressure and the effects can be severe with sufferers up to 3 times more likely to develop heart disease or have a stroke2. As high blood pressure often has no symptoms, many people are simply unaware they have it. This highlights the importance of having your blood pressure measured by a nurse or doctor as part of a healthcheck, particularly if you are over 40. A blood pressure check is standard procedure in the Health Assessments ECIS offers as part of the employee

benefits schemes we run for trade bodies in the contracting sector. “The good news is that small lifestyle changes can go a long way to maintaining a healthy blood pressure level. Simple changes such as increasing mobility and exercise, reducing salt intake, cutting down on alcohol and eating a healthy, balanced diet can make a big difference to blood pressure levels. Knowing your numbers is the starting point from which you can take any action necessary to reduce your risk. Therefore this September we’re encouraging all construction workers to get their blood pressure checked and get in the know about any underlying health issues.”



10 | GOSSAGE

GOSSAGE Christmas cheer

South of the wall

So farewell then to Vincent de Rivaz. Mr de Rivaz has been with the French state-backed energy giant Electricité de France for the past forty years. and has stood at the helm of the UK business since 2002. At first he was chief executive of the London Electricity Group before it merged with Seeboard and the Eastern Network to become EDF Energy in 2003. His appointment coincided with Prime Minister Tony Blair launching the first energy policy government White Paper for almost forty years, stating that there was little or no future for nuclear power. That policy altered 180 degrees, and by 2006 Blair was instead promising a vast new nuclear programme now estimated by energy finance expert professor Steve Thomas of Greenwich University to cost over £125bn. Subsequently de Rivaz has spent practically all of the ensuing period locked in negotiations over the Hinkley Point C new nuclear project, which received ostensible government approval in September last year. And may, or may not, be completed by 2024. Mr de Rivaz’s retirement will apparently start just before this Christmas. This is fortuitous. It was after all he who so famously promised Blair, and all the rest of us, that we would be able to be cooking our 2017 Christmas turkeys with electricity generated at Hinkley Point C. I understand that the de Rivaz family is planning a distinctly abstemious Christmas this year.

U S President Donald Trump is proposing a radical way to fund his proposed Mexican border wall: cover it in solar panels. Yes, this is the same Donald Trump who has spent years criticising renewable energy as uneconomic, and is pulling his country out of the Paris climate agreement. But it seems he now wants to add solar panels to his proposed barrier along the US–Mexico border in Texas. The president believes the panels would transform the wall, which he envisages would be 40 to 50ft high, into “beautiful structures”. But there are many areas along the border where it will be physically impossible to build a wall, with or without solar panels. Even if the government could do so, the wall’s configuration is not appropriate for a solar farm. There are no photovoltaic power stations - solar panel farms - that are arranged in a line. That is because it is inefficient to disperse panels like that. But the key point seems to be that, to be effective and face in a productive direction, all of the solar panels would have to be placed on the Mexican side of the border. And the Mexican government is entirely opposed to the entire project. Nonetheless Trump apparently has told congressmen from his Republican party that they should talk about his solarpanelled wall positively, “just as long as they say it was his idea.” To those who query whether, given how few people live close by the border, such a project could ever be costeffective, Trump may have an idea as to how any surplus electricity might be used. “I imagine that solar powered electric chairs would be popular in states that still have the death penalty.”

Third time lucky? Just to prove that all is not completely doom and gloom in the wonderful world of the Great God Atom, you may be interested to learn that the Bulgarian government is seeking private investors to revive the Belene nuclear power project. This had been cancelled, for the second time, in 2012. This led to the Bulgarian government ending up having to pay €620m in December 2016 to the Russian nuclear group Atomstroyexport (part of Rosatom) as compensation for having cancelled the €10bn project. But now the government is considering privatising the project. They are confident that – uniquely in Europe - the entire project can be built without state guarantees or mandatory long-term power purchase contracts. Apparently our old friends the China National Nuclear Corporation (CNNC) has expressed its interest in investing in the project. And the Industrial and Commercial Bank of China (ICBC) has announced that it might consider financing Belene. Might this be a case of third time lucky? After all, construction of the Belene power plant was started all of thirty years ago, back in 1987 by the Communist government, but was stopped in 1991 under pressure from ecological movements, objections from neighbouring countries and a new, rather less profligate, nonCommunist government. Then the project was revived in 2002, and Atomstroyexport was selected in 2006 to build two 1,000 MW VVER-1000 reactors. However, the €10bn project failed to attract any external investors. It in turn was cancelled in 2012 due to financial constraints combined with American and European concerns over its energy dependence on Russia. This prompted Atomstroyexport to file a lawsuit against the Bulgarian Government claiming €1bn in damages. In June 2016, an international arbitration court ruled that Bulgaria should pay compensation of €620m for the nuclear equipment it ordered from the Russian company before cancelling the project. If at first you don’t succeed, try again?And again? And again?

Pity the poor Helms-man The Oxford academic Dieter Helm has until October 31 - precisely thirty working days - in which to produce and present his muchtrumpeted Report to Government on the costs of electricity. He is explicitly barred from making recommendations on any future tax changes ,or upon the status of individual projects like Hinkley Point C. All this hasn’t stopped the world and his brother from rushing in to tell him what to write. They are wasting everyone’s time. From past experience, I am confident Mr Helm will have established precisely what answers his paymasters are seeking before he started work. Electrical Review | September 2017



12 | UPS

Achieving data centre-type UPS protection for mid-sized server rooms While data centres and other large-scale applications unequivocally require UPS power protection, the same is also true for smaller applications such as mid-sized server rooms, communications centres or industrial control rooms. The scale of their ICT activities may be reduced, but the consequences of a disruption could be just as severe for the users involved. In this article, Alan Luscombe, director at Uninterruptible Power Supplies, a Kohler company, discusses how to bring data centretype UPS protection to server rooms and other smaller ICT installations

A

s most modern data centres contribute critically to their owners’ business continuity, it’s unsurprising that they rely on UPSs to assure clean, uninterrupted power at all times. Given the possible consequences of a power problem, these systems are usually implemented with the best available technology; typically including redundant units to maximise availability, together with online doubleconversion topology to fully protect the load from any power problems. In today’s drive for greener environments and cost savings, high efficiency is also essential. Additionally, these UPSs will have been sourced from suppliers proven to be effective maintenance and support partners, as uptime depends on these factors as much as on the equipment installed. But what about smaller ICT users like server rooms or communications centres? With business activity and installation size less than a data centre’s, their budget, manpower and space resources are correspondingly reduced. However, their need for protected power remains just as critical. Fewer people may be affected if a server room rather than a large data centre is compromised by power problems, but for those that are, the consequences may be just as severe. Fortunately, though, answers are available. It is possible to purchase UPS solutions, in terms of both hardware and support, that are scaled to midsized server room requirements while offering the same protection levels as available to their larger Electrical Review | September 2017

data centre counterparts. To understand how such marriages can be made, we can start by looking at the UPS requirements and constraints that characterise server rooms; some are the same as for data centres, but others differ. With this profile in mind, we can then review one solution that is currently available.

SCALING FOR SERVER ROOMS An essential and primary consideration should be the UPS’s topology. Server rooms, as data centres, should use dualconversion, online solutions, as these

Secure protection against main-borne disurbances alone secure full protection against all possible mains-borne disturbances as well as complete power blackouts. Dualconversion UPSs are so-called because of their two conversion stages; a rectifier for AC/DC, and an inverter for DC/AC. In online configurations, incoming utility power, when present, always passes through these two stages before reaching the load, which is connected to the inverter output. The UPS components continuously shield the load from mains-borne noise and transient voltage excursions, as well as providing a constantly well-regulated supply.

If the mains does fail, the inverter continues to support the load without interruption, by drawing power from the UPS battery. Flexibility in battery configuration is therefore desirable, to set up a battery autonomy to support a load of known size for a given time, or to provide a grace period either for a generator to start up, or for the load to be shut down safely. Offline systems, by contrast, connect the raw mains directly to the load during normal operation, exposing it to damage from any incoming voltage aberrations, as well as subjecting it to a short-duration but finite supply break during any transfer to the inverter output. As the UPS fulfils its role in providing protected power, its own availability is essential in server rooms, just as in larger data centre applications. Redundancy should be designed in wherever possible, as this significantly elevates availability. If single points of failure are eliminated, the UPS system can become resilient to component or even unit failures, providing uninterrupted and continued support for the load with its remaining capacity. Data centre UPS systems often have a modular design, where one or more modules – each a complete, self-contained UPS unit - are assembled into a 19” racking frame. Because each module adds incrementally to the overall capacity, N+1 redundancy can be achieved easily and cost-effectively. This modular approach yields two further benefits; scaling to meet changing demand becomes easy, and



14 | UPS

maintenance can be performed without interrupting power to the load, simply by swapping a module. These redundancy, scalability and maintainability benefits are just as desirable for server rooms, but such premises’ more limited size may preclude the space overhead of racking system cabinets. If so, a better alternative is to use free-standing units, provided they have a compact footprint and can be paralleled together.

A PRACTICAL SERVER ROOM UPS SOLUTION At this point, a profile of a UPS system with data centre-type capabilities, but scaled to server room constraints, begins to emerge. UPSL Ltd.’s PowerWAVE 5000/TP, as shown in Fig.1, gives a practical example of this profile. Physically, it is a low-weight threephase tower system, offering capacities from 10 kVA to 50 kVA. It achieves a power density of up to 100 kW/m2 from a footprint of just 0.4 m2 at 50 kVA; ratings

The UPS provides full load protection

that suit it well to a space-limited server room environment. The UPS provides full load protection through its dual conversion online topology, and high availability through using redundant critical circuits which duplicate all its internal critical components and circuitry, and eliminate single points of failure. Up to 20 units can be paralleled, to increase unit-level redundancy and allow easy scaling. Redundant units can also be maintained without interrupting power to the system. Each PowerWAVE 5000/TP UPS offers a choice of cabinet dimensions, allowing users to accommodate their ideal battery size. Autonomy can be further extended with additional battery cabinets, which match the UPSs in appearance. Maintenance-free VRLA or NiCad batteries can be used. Energy use and running costs are minimised as the transformerless UPS Electrical Review | September 2017

UPS Ltd.’s PowerWAVE 5000/TP, designed for mid-size server rooms, networks, telecommunication systems and industrial processes

achieves an efficiency of up to 95.5% over a wide load range. Further savings arise through ripple-free and optional temperature-controlled battery charging, which protects batteries and extends their life-time performance. The UPS also has electrical characteristics that enhance its desirability in server room environments. An input power factor of near unity reduces input cable and fuse sizes, while an outstandingly low THDi of <3% saves unnecessary over-sizing of gen-sets, cabling and circuit breakers. Input component lifetimes are extended, while interference with nearby equipment is eliminated. Users can ensure the PowerWAVE 5000/TP sustains its availability and performance levels through setting up an appropriate maintenance contract with the supplier. This can include both regular visits and an emergency callout plan with

a guaranteed response timeframe. Special arrangements can be made with UPS Ltd. for battery maintenance, and a remote monitoring service can also be included. Each contract can be tuned to a particular installation’s requirements, but, overall, cover to 24 hours a day, 365 days a year can be arranged.

CONCLUSION Server rooms, and similarly-sized applications such as communications centres and industrial control rooms, are smallerscale than data centres, yet they require the same level of power protection and security. Power quality and continuity, availability, efficiency, maintainability and scalability all remain as essential attributes of the UPSs they use. In this article, we have seen how a modern UPS system can meet all these requirements while being scaled to a server room type environment.



16 | TECHNOLOGY TO MARKET

World’s first digital distribution transformer Reliability, performance and service life were central considerations when ABB launched the TXpert distribution transformer in March

The TXpert transformer has inbuilt local diagnostics and communication

T

he new transformer is the first of its kind as it integrates sensors to monitor lifetime performance. It will enable operators to improve their asset monitoring, avoid transformer failure, predict outages and initiate condition-based asset management. Power grids are undergoing an unprecedented transformation both on the supply and demand side. There are many new sources of energy including wind and solar photovoltaic distributed around the grid. In addition, new demand loads like data centres and electric vehicles call for a more flexible grid, driving the need for greater digitalization and automation.

Electrical Review | September 2017

In this context, intelligent products that can communicate will be essential component in the convergence of information and operational technologies. As a distribution transformer, the TXpert is ideally suited to applications such as residential and commercial utility supplies, integrating renewable power, or managing power distribution for oil, gas and chemical facilities or data centres.

SENSORS AND COMMUNICATION Performance data collected from the sensors is stored and analysed locally inside the transformer, offering insights on how it is operating. Operators such as utilities,

industries and data centre managers will then use this vital information to make key decisions on the operation and maintenance of their transformers. The data will also provide insights to support the management of the asset throughout its life, including activities such as optimising maintenance schedules and system performance, as well as planning asset replacement. Sensors embedded in the TXpert monitor for key performance indicators including ambient temperature, top-oil temperature, oil level, pressure, moisture, voltage and current, as well as the option of a hydrogen sensor. A local analytical unit provides operators with an estimate of the transformer lifetime and impact of Total Harmonic Distortion (THD). The unit can also be extended to feature additional algorithms. The unit stores the fully encrypted data for up to 20 years. In terms of communication, maintenance and operational staff can download data locally via an embedded Wi-Fi router. The internal Wi-Fi is capable of connecting to several communications mediums using standard protocols and best practices in cyber security. Operators can configure the transformer to connect with remote control centres via mobile telecoms network such as LTE or GSM, a private utility Wireless Mesh or a Wide Area Network (WAM). When wide area communications are enabled, real-time data is available to transmit network conditions. Being compatible with the IEC 61850 smart grid protocol, the TXpert is also designed to help operators future-proof their networks. “Distribution transformers are vital components in the electrical value chain. This latest innovation extends our digital portfolio and ABB Ability based offering, and reinforces our positon as the world’s



18 | TECHNOLOGY TO MARKET

A transformer at Lynemouth Power Station was the UK’s first to feature ABB’s Transformer Intelligence

leading transformer manufacturer,” said Claudio Facchin, President of ABB’s Power Grids Division. “It also reiterates our Next Level strategic focus on enabling a stronger, smarter and greener grid.” The TXpert digital transformer is part of the ABB AbilityTM digital offering that uses cloud computing and connected devices to generate actionable data for a broad range of customers.

TRANSFORMER INTELLIGENCE TXpertTM is part of ABB’s Transformer IntelligenceTM portfolio. The sensor-based technology is designed to optimise and enhance the operation of power transformers from 11 kV all the way up to 400 kV. The ultimate objective of transformer intelligence is to enhance performance, reduce costs and extend lifetime. It includes state-of-the-art sensors, monitoring platforms and software tools and will Electrical Review | September 2017

be a catalyst for enhancing distribution transformer performance, improving predictability and increasing reliability. Two technologies form the basis of Transformer Intelligence. The first is

Distribution transformers are vital components CoreTec, a modular and expandable system that can be installed to any brand of transformer in new and retrofit applications and requires just a few sensors. It is straightforward to operate and a userfriendly web interface displays a large number of operational parameters.

The second is CoreSense sensors, which continually monitor hydrogen and moisture levels in transformer oil to act as an early warning system. The sensors are based on a thermal pump design that has no moving parts, therefore reducing the maintenance requirements. Combining CoreTec with the data from CoreSense and other sensors is designed to give operators of transformers confidence in the health of individual transformers and fleet and enable them to schedule maintenance only when required. Traditionally, transformer condition analysis requires techniques such as Dissolved Gas Analysis. While this is very effective for detecting fault conditions, oil sampling can only be done intermittently. By adopting Transformer Intelligence as a complementary technique to laboratory analysis, operators can develop deep knowledge of the condition of their assets.



20 | COMPLIANCE

EMC and functional safety One of the biggest problems faced by all electrical and electronic equipment is that of electromagnetic interference (EMI). However, what’s peculiar is that, despite the rising use of devices that are susceptible to EMI, until recently there have been no clear guidelines for EMC as regards functional safety. Here, Keith Armstrong, worldwide EMC specialist at EMC Standards, looks at how engineers can ensure that EMI will not cause excessive functional safety risks

A

ll electrical and electronic technologies emit electromagnetic (EM) disturbances that can interfere with the correct operation of radiocommunication equipment or other electronics. Modern technologies are particularly likely to cause such disturbances, worsening the EM environment that electronic devices are exposed to. EM disturbances can cause problems to electronic equipment, ranging from degraded functionality all the way to complete failure. The discipline of controlling the limits of EM emissions and the levels of immunity is known as electromagnetic compatibility (EMC). EMC is increasingly becoming more valuable in electrical and electronic engineering. As we continue to integrate more electronic technology into our lives and into our businesses, from computers and mobile phones to variable speed drives (VSDs) and programmable logic controllers (PLCs), we are also seeing a rapid increase in the use of electronics in safety-related applications. Engineers and their managers are all under pressure to make sure that the equipment and systems we use in our businesses do not expose people to excessive safety risks. Despite the fact that most of us understand the importance of protecting devices against electromagnetic interference (EMI), there is often confusion about exactly what constitutes good EMC from the point of view of ensuring that EMI does not cause excessive functional safety risks.

GOOD EMC VS EMC COMPLIANT Many people think that all that is necessary Electrical Review | September 2017

for good EMC is for equipment and systems to meet the EMC Directive and be CE marked. Unfortunately, neither the EMC Directive nor its harmonised EMC standards cover EMC-related functional safety, and this is clearly stated in the EMC Directive. Also, most of the safety standards that are harmonised under the Low Voltage Directive do not cover EMCrelated functional safety and some don’t even cover functional safety at all. The Machinery Safety Directive and its harmonised safety standards attempt to

Avoid excessive functional safety risks

cover the EMC issues for machine safety, but eventually fail by referencing the EMC Directive and its standards, which do not cover safety issues. Because of the lack of coverage of this increasingly important issue by existing EMC or safety standards, issues of EMC-related safety are falling short of a sufficient solution. Since the commercial pressures on manufacturers are such that they are unwilling to go further than what they perceive, often incorrectly, as being their minimum legal obligations, the resulting safety risks are uncontrolled. Although some IEC standards and technical reports have subsequently addressed these issues, they are not yet widely understood or used. They are also

not explicitly harmonised under any EU Directives and unlikely to be so for many years yet.

EM IN EFFECT As an example of an increasingly common EM disturbance, consider the possible proximity of mobile radiocommunications to a safety-related electronic system. The EMC Directive’s immunity standards require normal functional performance to be maintained when exposed to radio-frequency (RF) fields at either three volts per metre (V/m) for residential, commercial and light industrial environments or ten V/m for normal industrial environments. However, what do these V/m levels mean in real life for the proximity of mobile radio-communications? Let us imagine that an engineer is using a mobile phone in a residential area with poor reception. If this were to have two watts of RF power, then we might expect any safety-related electronic systems in the area to maintain functional performance if the engineer was between roughly 2.5m and 5m from the system. In a normal industrial environment, however, it would be necessary to maintain functionality between 0.8m and 1.6m. In this situation, if the engineer operated a connected PLC while using his mobile phone, he would obviously be much closer than 0.8m so the field strengths could exceed 10V/m and the equipment could suffer from degraded functionality. This could range from false data, such as ignoring a limit switch, to total failure of the operating system. To ensure functional safety from an EMC perspective, it is critical that engineers carry out an effective hazard and risk



22 | COMPLIANCE

assessment. This should consider what EM disturbances the apparatus may be exposed to, how the equipment’s own EM emissions impact other devices, what the health and safety implications of a disturbance are and the confidence that the design will not permit EMI to cause excessive safety risks over the entire lifecycle. EMI is set to be one of the biggest challenges that engineers will face in

Electrical Review | September 2017

the future as more devices come into widespread use and confusion over functional safety persists. While the IET’s 2013 guidance will be published in early 2017 as their important new Code of Practice on “Electromagnetic Resilience in support of functional safety”, engineers should not delay in learning more about this important issue. Information about EMC and the IET’s

2013 guidance can be accessed from the EMC/EMI risk management section of the EMC Standards website, alongside many helpful and informative articles and presentations. It is only by following the IET’s 2013 guidance (or modern guidance developed from it, such as the IET’s new Code of Practice) that engineers can ensure that equipment and systems are functionally safe as regards EMI.





26 | ADVERTISEMENT FEATURE

No need for heavy weight protection testing systems

T

he dynamics of the anticipated future developments of protection relays is expected to take place more in the realm of software, so the time was ripe for presenting a new test set. There was ample potential for a raft of improvements and new features, and finally there was a gap to be filled in terms of mobility.

the closed case. The case offers enough storage space for the necessary accessories. An additional accessory soft bag can be pulled over the extendable handle and placed on the closed case. For particularly mobile applications, and those who like their transport aids to be as light as possible, a trolley, which can even be worn as a backpack, is available as an alternative.

CMC 430 – A LOT OF INNOVATION IN A SMALL SPACE

OUTPUT STATUS SIGNALING

Deliberate efforts were made to reduce the weight of the new CMC 430. The result is a multi-phase secondary test set weighing a mere 8.7kg – currently the lightest in the world. It is comfortable to carry, easy to use and accepted as cabin baggage by airlines. It supplies three current outputs, six binary/analog inputs and generally focuses on applications in the area of Inom = 1A (test current = 3 x 12.5 A). High accuracy is important when testing certain protection functions, such as detecting earth faults or the direction of faults near the installation location. Accuracy regarding amplitude, phase, frequency, and the derived variables power (P, Q, S) and energy (Wh, varh) is essential when calibrating meters, measuring transducers, and other measuring instruments. All the tests so far have shown that the CMC 430 is more accurate than all previous CMC models, at least with a defined load range. The internal system timing is provided by a quartz clock, with a maximum drift of only 4.6ppm (0.00046%) in 20 years. The frequency and phases of the analog variable outputs and the time stamp for recording binary and analog signals use this reference. This also applies to any possible external time base. This is necessary for synchronised testing or calibrating measuring instruments with a time reference, such as a PMU (phasor measurement unit). The accuracy of the simulated active and reactive power is crucial for calibrating power measuring transducers and meters. The test objects here are generally in the accuracy class range of 0.2 to 0.5%. The specified maximum error for active power accuracy (valid for one year after factory calibration) is 0.08% of the set value. Under favorable conditions (temperature, current path load > 0.3 Ω) this is typically considerably below this figure.

LEDs show the status of the voltage and current booster outputs, and the AUX DC auxiliary voltage output. In addition, the user can activate an acoustic signal to indicate the “Outputs active” and “Overload” statuses audibly as well as visually. The user is warned in advance of the impending output of a preset DC auxiliary voltage for 20 seconds both visually and audibly. These indicators give a better overview of the test progress.

IMPROVED STURDINESS AND HANDLING The new in-house housing design, with reinforced corner and edge protection and all connections and control elements mounted at the front, puts a desire expressed by many customers into practice. The unit can be used vertically, sideways or in the classic horizontal position (fig. 1). The shock-absorbing rubber corner elements protect the system against mechanical influences. The new multi-purpose carrying case makes working more enjoyable. The CMC 430 can be kept in its case during testing, can be lifted up and slightly inclined, or placed on the raised case lid. However, this case lid is best used as the place for the control notebook (fig. 2). The case offers enough storage space for the necessary accessories, with an additional soft bag for additional accessories pulled over the extendable handle and placed on Electrical Review | September 2017

SIX VOLTAGES The CMC 430 uses two complete triple voltages (6 x 150 V), with all the outputs having the same neutral “N”. This not only allows the neutral overvoltage from the open delta connection to be simulated as a 4th voltage, but also two complete voltage systems as well. Synchro-Check devices, synchronisers and integrated protection and control systems (for example, SEL 421) with six voltage inputs can therefore be tested without additional voltage amplifiers.

SIX FURTHER DEVELOPED ANALOG/BINARY INPUTS Six measuring inputs insulated from each other (CAT II-600V) with an additional 10 mV measuring range, improved measuring accuracy and higher sampling rates (10 and 40kHz) are further features of the CMC 430. The sampling values of the analog channels are linked with the data from the binary channels (electrical or GOOSE) and up to two SV streams, and continuously sent to the control computer. Calculations and signal visualisation are carried out using the EnerLyzer Live software. The powerful, hybrid measurement functions (analog, binary, GOOSE, and SV) make carrying another instrument unnecessary, which also reduces costs. For applications requiring more than six analog/binary inputs, the ISIO 200 (binary input/output module with IEC 61850 interface) can be connected to the device via an Ethernet connection (automatic configuration with the TU tool ISIO Connect). The measurement shunts C-shunt 1 or C-shunt 10 or a current probe (for example, CP 30) are necessary for recording currents. The CMC 430 is also fitted with four rapid expansion ports for connecting future accessories, such as an external low signal generator for simulating unconventional CTs/VTs.

DC AUXILIARY VOLTAGE WITH HIGH SHORT-TIME OUTPUT POWER For test objects with high short-time inrush currents in the DC supply, the auxiliary voltage output provides a power


ADVERTISEMENT FEATURE | 27

of approximately 120W for a period of about two seconds (permanently available figure is 50W). This is enough to supply practically any protection device if the station supply is not available.

FREE CHOICE OF CONNECTION The CMC 430 controller can be connected by wire using an Ethernet cable or wirelessly over WiFi, although a wireless connection requires a special Mini USB WiFi adapter. This control method offers many advantages when the test set is in an exposed position or when checking wiring. A direct line of sight connection is necessary for a reliable longer-distance WiFi connection.

MEASUREMENTS WITH THE INSTRUMENT The CMC 430 is compatible with the known and legacy software packages from OMICRON like Test Universe 3.20, RelaySimTest or the CMControl P app. The measurement option EnerLyzer Live enhances the CMC 430 by adding powerful hybrid measuring, evaluation, and recording functions (fig. 3). The software integrates the measurement data from the analog and binary inputs and the virtual inputs (GOOSEs) and up to two data streams (sampled values as per IEC 61850-9-2). The data values are continually written to a circular buffer, which allows recordings of up to five minutes in length. The signals can be analysed even while the recording is in progress, and interesting parts can be saved as transient files (COMTRADE IEEE C 37.111-1999).

ABOUT THE AUTHOR Reinhard Kuntner is an experienced electrical engineer with a degree in Computer Science from the University of Innsbruck, Austria. He is the Product Manager for the CMC 430 at OMICRON and was part of the development team over the entire project duration.

ABOUT THE COMPANY OMICRON is an international company providing the electrical power industry with innovative testing and diagnostic solutions. The application of OMICRON products gives users the highest level of confidence when making condition assessments of primary and secondary equipment on their systems. www.omicronenergy.com

www.electricalreview.co.uk


28 | EVENT PREVIEW

We take a look ahead to UK Construction Week, with a particular focus on the areas of interest to the electrical sector.

U

K Construction Week returns to Birmingham’s NEC on 10th-12th October, incorporating nine shows under one roof, including Energy 2017, HVAC 2017 and Smart Buildings 2017. Free to attend, it is the UK’s largest construction trade event, spanning three days, and is expected to attract around 30,000 trade visitors. An invaluable experience for every trade visitor, offering a wide-ranging programme, UK Construction Week works with industry leaders and organisations to address policy issues, develop skills and personal development, and seek out, recognise and reward talent and ability. More than 600 exhibitors will be showcasing the latest products, including world exclusives, dedicated seminar theatres will cover key industry talking points, and there will be ample opportunity to develop skills and recognise and award talent and ability. There is plenty of fun to be had as well, with a Beer & Ale Festival, Casino Night and Dodgeball Tournament all taking place on site.

Smart Buildings 2017 is the go-to event for the smart buildings industry for electricians, engineers, installers and much more. Amongst the broad spectrum of topics covered will be workplace technology, access and security controls, home entertainment systems, climate control, lighting and shading controls and the increasingly popular ‘Internet of Things’. Recognising the increasing influence of the smart buildings sector, a number of prominent organisations have announced their support for Smart Buildings 2017, including The Royal Institute of British Architects (RIBA), the Electrical Contractors’ Association (ECA) and the Building Controls Industry Association (BCIA).

SAFETY AND QUALITY IN BUILDINGS – FREE CPD WORKSHOPS

Energy 2017 will explore the significant reduction of costs through energy saving ideas with the show tailored to meet the needs and requirements of engineers, installers, contractors and specifiers. Certas Energy, g2 Energy, nPower, Energy and Solisco are just a small selection of those who are exhibiting at Energy 2017. The Renewable Energy Association (REA) is one of the official content partners of Energy 2017 and will deliver a programme of insightful talks revolving around biomass, wind and solar at the specially designed REA theatre, sponsored by WElink.

HVAC 2017 is an event dedicated to heating, ventilation and air-conditioning and hosts a wide selection of the industry’s leading brands. It will focus on renewables, innovation and power solutions within the building environment and explore the reduction of costs through energy saving ideas. The show is tailored to meet the requirements of engineers, contractors, installers, architects and specifiers within the building engineering sector and is backed by industry leaders including BESA, FETA, CORGI, HEVAC, GSHPA and BCAS. Electrical Review | September 2017

UK Construction Week will bring the leading authorities together to deliver FREE CPD advice and guidance on key issues including: • Post Grenfell: Essential Guidance on Buildings Safety & Fire Prevention (A definitive update on building regulations) • Fire Prevention (Guidance on Sprinklers, Fire Doors, Dampening) • Flammable Building Materials (Cladding and other materials – latest advice) • Health & Safety (Do you know your responsibilities and how to avoid prosecution) • Improving Safety through Technology These CPD workshops are tailored for professionals responsible for building safety. Ensure you book your place early as spaces are limited. If you’d like to register your interest in the meantime, please do so by email: info@ukconstructionweek.com
