4 | NEWS

Toolkit Thursday Winner collects prize

The winner of the #ToolkitThursday selfie competition, Jack Bowers, has collected his prize – a MM2300A Multi-Meter worth £200.

Bowers, 22, collected his prize from the Blackpool branch of City Electrical Factors (CEF) last week, having visited the very same branch on Thursday 4 February 2016 - #ToolkitThursday – to collect his free Klein Toolkit worth more than £250.

These kits are now being given to all JTL electrical apprentices, with Monument Tools continuing to provide kits for JTL’s plumbing apprentices.

On collection of his toolkit in February, Bowers and his fellow learners collecting kits were encouraged to take a ‘selfie’ with their new tools, with the one that received the most retweets and likes being the winner, and earning the individual the Multi-Meter.

Bowers, known on Twitter as Jack Sperrin, saw his photo pick up 37 retweets and 28 likes on Twitter. #ToolkitThursday saw more than 1,000 apprentices pick up their kits from their local CEF branch on the day, with another 350 collecting their toolkits in the week or two following the big day. The event was the first major distribution of Klein toolkits to new apprentices in England and Wales, following the joint partnership between JTL, Klein Tools and Super Rod announced earlier in 2015.

Electrical Review | April 2016

Tickets for powerBall now on sale Tickets for powerBall, the biggest and best party the electrical industry has to offer, are now on sale.

Taking place on Friday 11 November 2016 at the Grosvenor House, Park Lane, London, this year’s event promises to be as spectacular as ever with the internationally acclaimed stage sensation Jersey Boys as the headline act.

Featuring legendary top ten worldwide hits, including Beggin, Bye Bye Baby (Baby Goodbye), Can’t Take My Eyes Off You and Big Girls Don’t Cry, this spectacular performance will introduce partygoers to the history of pop music with one of the most successful bands of the era.

Discover how four New Jersey boys from the wrong side of the tracks invented their own unique sound, were inducted into the Rock & Roll Hall of Fame and sold 175 million records worldwide before they turned 30.

Managing director, Tessa Ogle says: “pow-

erBall is the industry’s biggest and best party of the year. This great event will bring you the best entertainment from the legendary Jersey Boys and will provide an opportunity for industry professionals to get together for a night of fun and games.

“We are also delighted to welcome on board City Electrical Factors as the headline sponsor for this year’s event. Last year’s powerBall was a huge success and made a massive £236,000. We are grateful to everyone who helped us to achieve this tremendous amount and we look forward to welcoming the industry back for another unforgettable night in 2016.”

For further details on tickets and sponsorship packages visit the dedicated website. www.powerball2016.com

NEWS / PEOPLE | 5

30,000 apprenticeship jobs pledged 30,084 new apprenticeships have been pledged by employers as part of National Apprenticeship Week 2016 (14 – 18 March).

From Greene King committing to hiring 10,000 apprentices (up from 2,000 in 2015), Microsoft and partners announcing plans to recruit 4,500, BT pledging 1,000, Deloitte 200 and Kwik Fit 150, pledges have been made by hundreds of businesses around the country. Other companies that have pledged new apprenticeships include BMW, Virgin Media and British Airways.

Traineeships, which give young people the work preparation training, English, maths and work experience needed to get an apprenticeship or other job, also got a boost during the week with employers large and small, including Halfords Ltd and Chelmsford JCP pledging 1,770 traineeship positions.

Skills minister, Nick Boles, said: “This week

I’ve travelled the country meeting apprentices doing the most incredible jobs, from cooking mussels at Rick Stein’s restaurant to fixing helicopters for the Royal Navy.

“Apprenticeships offer working people the jobs and training they need to build a great career. An apprenticeship really can take you anywhere.

“Employers have pledged more than 30,000 new apprenticeships this week. That means over 30,000 more life changing opportunities for working people.”

Now in its ninth year, National Apprenticeship Week is designed to celebrate apprenticeships and the positive impact they have on individuals, businesses and the wider economy. The overarching theme for 2016 was to show how individuals and businesses can achieve their ambitions of ‘rising to the top’ through apprenticeships.

UK Lamp recycling rate leaps ahead in 2015 Recolight, the UK’s leading lighting compliance scheme, has welcomed the publication of the UK’s 2015 national WEEE recycling data. The data, released by the Environment Agency (EA), shows a significant growth in the lamp collection rate in 2015: Commenting on the news, Nigel Harvey, Recolight CEO explains “It is particularly pleasing to see that the 2015 recycling rate bounced back up from 2014. This is probably due, in part, to the recycling of fluorescent waste resulting from major LED integrated luminaire roll outs in business premises across the UK. The lamp recycling rate from 2013 to 2014 saw a drop when, for the first time, the data included LED lamps as well as Gas Discharge Lamps. With very large quantities of LEDs being sold – but very few being returned as WEEE, the inclusion of LEDs inevitably reduced the rate.”

Turning to the luminaire recycling rate, he added “The luminaire recycling rate has increased from 2014 to 2015. However, the tonnage of luminaires collected in 2015 is only 5% higher than in 2014. The rate increase is therefore primarily due to the 12.7% reduction in the tonnage of luminaires reported as put on the market. This reduction is likely to be a result of dual use classification, which

means that any luminaires that could be used by consumers are now out of scope of the WEEE Regulations.”

Recolight launched its luminaire compliance service in 2013, and that has helped to double the luminaire collection rate from 2013 to 2015. Many luminaires continue to be returned as scrap, and not properly reported and recycled as WEEE, and this contributes to the low recycling rate.

Note: The recycling rates above were calculated by dividing the tonnage of WEEE reported by all PCSs, by the tonnage of EEE placed on the market in the same year, for luminaires (category 5) and lamps (category 13). These calculations do not include non-obligated WEEE.

Electrical Industries Charity set for the London Marathon The Virgin Money London Marathon is one of the biggest fundraising events in Great Britain bringing thousands of people together to raise money for different charities. This year the Electrical Industries Charity is proud to announce its ten runners who are all set to take on the 26 mile long challenge and raise money to help those in our industry who need it most.

The Charity’s runners who are taking part in this year’s Virgin Money London Marathon are; Joe Ellis from Edmundson Electrical Ltd; Alun Evans from Phase Electrical; Philip Woolley from Electrical Review; Scott Wildego from R&B Star; Zak Benney and Guy Powney from Edmundson Electrical’s Western Office; Daniel Mullinder, Paul Murphy, Mark Weston from Edmundson Electrical Carlisle and Juan Subira from Schneider Electric.

Show your support for the charity’s runners now and help them to make a difference in people’s lives by making a donation today.

Managing director, Tessa Ogle said: “We would like to wish all of our runners the best of luck. The Virgin Money London Marathon is a fantastic way to raise money for those in our industry when they need it most, and we are thrilled to have so many people running for our charity this year. Last year our runners raised a massive £33,000, and we are looking forward to raising even more this year.”

To sponsor Electrical Review’s Philip Woolley visit http://www.electricalreview.co.uk/ teline-v-blog/10863-keep-on-running-for-eic and click on the sponsorship link!

New laboratory The Lighting Industry Association (The LIA) will opened its new laboratories facility on 8 March 2016.

The facility is the culmination of many years’ of planning with lighting manufacturers, suppliers, retailers and wholesalers and will provide the industry with a cutting edge testing and certification service helping grow exports and improve product compliance.

www.electricalreview.co.uk

6 | NEWS

Electrical Review Smart Lighting Summit Logic Certification approves top UK smart metering academy

Logic Certification has joined forces with the provider of metering services, CH4 Services, helping the firm to become fully accredited to deliver its QCF Level 2 Diploma in Smart Metering Power.

The qualification was first launched in response to an industry need to meet the demand for the installation of 50 million smart gas and electricity meters in 27 million homes by 2020, and is designed to equip learners with all they need to install and exchange gas and/or power smart meters in domestic properties; it is also suitable for existing installers looking to up-skill.

Mark Krull, director at Logic Certification, added: “We are delighted to have assisted CH4 Services in developing their business into the smart metering sector; a move that will help directly address the gap within the sector for trained smart meter operatives.

“Smart meter technology is to play a huge part in the future of our homes, giving consumers the means to better control, and understand, their consumption of energy. What’s important right now is that training facilities are geared up and ready to offer the appropriate smart metering qualifications to support the industry and develop a workforce of highly competent operatives.”

David Burke, business development manager for CH4 Services, added: “We were looking to partner with an awarding body that had the same ethos and culture that mirrored our own, in terms of valuing best practice with a view to producing excellent results from all learners that pass through the academy. After we met the Logic Certification team, we knew they were the kind of people we could, and wanted to, work with.

“Logic Certification’s qualifications fit our strategy moving forward; we’ve had our first batch of learners through who successfully passed, which is a great achievement to learners, trainers and assessors, who have all had to go through a period of learning to become qualified.”

Electrical Review | April 2016

On 19 April 2016 Electrical Review, in response to consistent reader feedback, is hosting its first Smart Lighting Summit. In the same way LED lighting has taken energy efficiency to a new level smart lighting is now allowing a more sustainable approached to how this lighting is controlled. The huge rise in the number of connected devices has helped raise awareness to the ‘Internet of Things’, but how will the lighting industry deal with the electrical infrastructure behind.

Electrical Review has been covering the latest developments in smart lighting controls over recent years, but our readers are now demanding more understanding of how they can deliver smart lighting and the challenges they need to overcome in a face-to-face environment. This event will be an opportunity to meet and network with senior people in the electrical space who will be meeting to learn and gain insights.

The Smart Lighting Summit will be held in one of the world’s most sustainable buildings, The Crystal, London (https://www.thecrystal. org/). The Crystal is home to the world’s largest exhibition on the future of cities and is the world’s most sustainable events venue.

Technologies throughout the building ensure the highest energy efficiency, which makes it

an ideal backdrop to this summit.

The summit will specifically focus on the controls aspects of lighting with the following subject areas: • LED lighting control – covering the latest control systems, wired/non-wired and being part of a larger automation offering including integrations with HVAC systems and appliances.

• Energy efficiency – this session will look at the controls that eliminate over-lighting and creating huge energy savings in the face of needs to reduce energy usage.

• Electrical compliance and protocol – with the rapid growth in lighting controls available protocols are in place to standardise and meet compliance requirements.

• Emergency lighting – emergency lighting systems are intrinsic to every commercial/ industrial building and smart lighting controls are helping create more efficient testing procedures and allow for more integration with the rest of the buildings systems. This session covers the latest techniques and developments.

To discuss sponsorship opportunities please contact Phillip.Woolley@electricalreview. co.uk or call on +44(0)20 7933 8989

ECA urges government to address payment problems to boost investment As a government consultation on skills in the construction industry closed recently, the Electrical Contractors’ Association (ECA) has said the review “unfortunately fails to tackle the main reason for low investment and productivity – which is fair and prompt payment.”

The government recently urged the construction industry, through the Construction Leadership Council, to ‘develop an ambitious action plan to address the skills pressures and other constraints that are limiting house building and infrastructure development’.

However, ECA director of business Paul Reeve said: “It’s widely known that engineering is inherently innovative, but while there are innovation hotspots in the wider construction industry, it is hardly endemic.

This is mainly due to the prevailing industry approach to payment, which works against

investment. This problem affects building services engineering, and many of the other sectors it works with.

“Skilled staff is definitely one way to achieve better productivity and innovation, but in a business environment where the priority for contractors is to be paid what they are owed, the investment tap is almost entirely turned off.

“Unfortunately, the review does not focus on the main reason for low industry investment and productivity – which is fair and prompt payment. Ending the practice of ‘cash retentions’ would be an important next step. This would help to boost the balance sheets of smaller businesses in particular, allowing them to invest in the skilled workforce that this consultation is looking for.”

8 | GOSSAGE

GOSSAGE Less Means More

Physician, heal thyself

Britain’s electricity industry thinks official Government policy is completely overestimating likely demand growth between now and 2030.

Following a large membership survey, the electricity trade group Energy UK has established that almost everybody in its industry reckons that demand for electricity will continue to decline overall, or at most remain constant. Sales have fallen regularly over the past decade. Nobody seems to be expecting any serious increases in consumption levels.

In contrast, official Department of Energy forecasts are still assuming a 17% growth in consumption levels to 2030.

Energy UK has concluded that official policy “overestimates the amount of new large-scale plant to 2030.”

Its members are apparently “sceptical” whether all this is “affordable, achievable or even necessary.” Instead, the next decade “should be all about energy efficiency”, supported by “new policy frameworks to unlock the benefits.” Demand side management has the “key role.”

Even as the price of Hinkley C, the first of the so-called new generation of nuclear power stations continues to rise, and even as its official completion date vanishes further and further into the future, this survey - one of the most extensive ever undertaken of existing electricity industry opinion – ought to serve as a wake-up call to Energy Secretary “Forever” Amber Rudd.

Ought to. But given past experience of her dogged determination to defy the facts before her, still in all probability won’t.

Dr Joanna Haigh is a very distinguished professor of atmospheric physics. She is the head of the Grantham Institute for Climate Change and the Environment at Imperial College, London. This makes her one of the great gurus in the science behind runaway climate change. And very vocal she is too, regarding what needs to be done.

So important is her voice that the Financial Times devoted two-thirds of a page to an interview with her. Global warming, she is quoted as saying, is like a runaway train. Unless we all put the brakes on, it will keep on rolling. “If you ever want the global temperature to plateau, you’ve got to get to zero carbon emissions.”

The interview took place in Haigh’s large south-west London house. Which she agreed had a traditional fossil fuel-based heating system, draughty Victorian sash windows, and “we don’t have much insulation”.

Nonetheless she ended the interview with a flourish: “To think that we rich people in the west are so profligate that we cause all this harm and do nothing about it… it makes me feel a bit sick.”

Yet another case of “do what I say, now what I do?” In the immortal words of the great Sunday Express editor, Sir John Junor: pass the sick bag, Alice.

Let loose the Dogs of War In January the electricity network in southern and western Ukraine suddenly went haywire. This was not due to incompetence at the grid. But to something far more ominous: an outright cyber attack.

Ukraine’s energy ministry has now announced that they have established that cyber hackers operating from Russian soil, who apparently targeted three different utilities over the course of several days, caused the blackouts.

The Ministry statement said: “According to one of the power companies, the connection by the attackers to its IT network occurred from a subnetwork, belonging to an internet service provider in the Russian Federation.” US security forces have broadly corroborated this claim.

For several years, there has been much speculation in the western security world that cyber hackers would eventually try to attack our utilities. I have in the past had reason to alert my devoted readers to such concerns myself. Last year, there were several rumours of rummaging around other European electricity systems, with malicious intent.

Now for the first time a cyber group has actually turned the lights out. We have reached a new and alarming position, whereby our electricity infrastructure is coming under threat from criminals, terrorists or even nation states.

Effectively, a new face of war.

Do you therefore wonder at the horror that the UK military establishment feel, at the cavalier way in which Chancellor George Osborne is actively encouraging the Chinese government to build and run our future nuclear power stations? No need for any mysterious cyber hacking there. Metaphors about lunatics and nuclear asylums seem all too appropriate.

“What advancement may I hope from thee?”

I have just received an invitation to attend a Central London conference on UK energy security. Amongst the speakers is one Simon Virley.

Mr. Virley is billed as being the UK chair of energy and natural resources at KPMG. Which is indeed the role that Mr. Virley is currently undertaking.

KPMG is not however Mr. Virley’s full-time employer. He has taken “leave of absence” for three years from the Department of Energy and Climate Change, where he was the director in charge of energy supply. During this period his salary is being paid by KPMG – believed to be some three times higher than that paid by the Government.

Whilst undertaking his civil service role, Mr. Virley had to place a significant number of lucrative contracts. Sadly, the Department of Energy and Climate Change have been unable to tell me just how many of these contracts were let to KPMG before he left. But I am confident each one will have been awarded judiciously, and without any concern as to prospective personal significance.
