POWERFUL PORTABLE & ENERGY EFFICIENT
EXPERIENCE THE COMFORT OF A COOL LAKE BREEZE IN YOUR HOME
Honeywell Evaporative Air Coolers are an environmentally-friendly and cost-friendly cooling option for your home or office. Much like a breeze flowing across a lake, air coolers produce a comfortable, cool breeze with the natural process of water evaporation.
HOW DOES AN EVAPORATIVE AIR COOLER WORK?
When warm air is drawn into an air cooler, it passes through a wet Honeycomb Cooling Media. As it passes through the honeycomb, water flowing over the honeycomb absorbs heat from the air causing the water to evaporate. This results in cooler, moisturized air.
A powerful fan then propels the cool air into the room (or outdoor area). The result is a constant flow of fresh, moisturized, cool air while stale air is circulated out of the room through an open window or door.
Evaporative Air Coolers require cross ventilation to be effective. Doors and windows should be opened to allow free airflow and to reduce humidity collecting in the room. The maximum cooling effect is felt when a person is near the flow of air coming out of the Air Cooler.
Honeycomb Cooling Media
WHY BUY HONEYWELL AIR COOLERS?
Reliable Honeycomb Cooling Media
Evaporative Air Coolers use a Honeycomb Cooling Media. The cooling efficiency is much higher than other cooling media due to greater surface area for the transfer of humidity to the passing air.
Low Electricity Consumption
Evaporative Air Coolers consume very little electricity. Running air coolers requires significantly less electricity than running air conditioning units, making alternatives attractive cooling media in cities where electricity costs are high.
Feature-Rich, Easy Maintenance
Designed for comfort, a range of models are available with convenient features to make maintenance easy, including simple digital controls, lowwater alarms, detachable tanks, continuous water supply options, and ice compartments for faster cooling (see Product Features Chart).
Versatile for Year-Round Use
Evaporative Coolers combine 3 appliances into one compact system, providing powerful cooling during the summer, humidification during dry winters, and a calming fan breeze.
Powerful and Stylish
Evaporative Coolers are carefully designed to maximize airflow without sacrificing aesthetics.
Low Purchase Cost
Air coolers are a budgetfriendly cooling option because they are affordable to purchase and affordable to operate.
WHAT’S THE DIFFERENCE?
There is often confusion about the difference between an Evaporative Air Cooler versus a fan or air conditioner (window).
An Air Cooler is Not “Just a Fan”
Air coolers use the natural process of water evaporation to cool incoming warm air and use a powerful fan to expel newly cooled air. The temperature
of dry air can drop significantly when liquid water transforms to water vapor through evaporation.
An Air Cooler is Not an Air
Conditioner
Air conditioners require a chemical cooling refrigerant and an energy-consuming compressor. The more complex design of air conditioners also makes them more expensive to purchase, and they consume significantly higher electricity during use.
An Air Cooler is Not a Mist Fan
Mist fans simultaneously blow out air while spraying a fine mist of water droplets. It also has to be very hot and very dry for the water from the mist to evaporate completely without making a puddle on the ground around the mist fan base.
Mist fans are mainly for outdoor use. The air exiting the unit contains water vapor and not water droplets. This makes air coolers suitable for indoor rooms as well as the outdoors.
Cooling Mechanism
Temperature Reduction
Air
Ventilation
While Cooling
Creates a breeze by circulating the room air
LowAir circulates with minimal temperature reduction
Poor- Recirculates stale air as a breeze. A window can be opened for fresh air, but warmer outside air will be drawn into the room
Uses water evaporation to cool incoming hot air and fan to blow out the cooled air
ModerateTemperature of dry air can drop significantly when liquid water transforms to water vapor (evaporation)
ExcellentCross-ventilation, together with evaporative cooling, creates a cooling breeze and helps renew stale air
Uses refrigerant and compressor to cool
High -
Uses a chemical refrigerant and an energy-consuming compressor
Poor - Requires windows and doors to be closed for effective cooling. Stale air is recirculated
Energy Consumption1 Low Low Med-high
Dust Filter None Available Available
Portability Portable Portable Fixed
Moisture Level of Room Does not humidify or dehumidify
Outdoor Use Outdoor models available
HumidifiesAdds moisture to air. Ideal for dry environments with low humidity levels
Honeywell Air Cooler outdoor models available
DehumidifiesRemoves moisture from air. Ideal for environments with high humidity levels
Indoor only
Energy consumption is based on the power consumption of each product of approximately equivalent cooling capacity, such as: standard household floor fan, 7.9 gal (30 L) air cooler, 8,000 BTU window air conditioner, and standard 112-watt household floor fan, 30 L/8,000 BTU/288-watt Honeywell Air Cooler, 740-watt window air conditioner
ES800
Indoor Portable Evaporative Air Cooler
PORTABLE AND DURABLE
Innovative technology minimizes energy consumption and noise while maximizing airflow. Consuming only 36 W and emitting only 25 dBA of sound in Quiet Mode, this is one of the most energy efficient cooling solutions available.
Recommended area up to 12 m²* For Spot Cooling
TOP LOADING ICE CHAMBER
Easy access for faster cooling
QUIET & TURBO MODES
Special fan settings allow for quiet comfort at night or extra powerful airflow when needed
MORE FEATURES & SPECIFICATIONS
Low Power Consumption: only 36 Watts*
Fast Air Distribution 4 Fan Speeds: Low/Medium/ High/Auto
Convenient Digital Control LED Control Panel and Remote Control
Detachable Water Tank for Easy Refills
Powerful Airflow: 359 m3/h*
Honeycomb Cooling Media and Carbon-Dust Filter
Set It & Forget It Timer for Unattended Operation
Ice Compartment for Faster Cooling
SET IT &
FORGET IT
Set the timer for unattended operation
Water Capacity: 7 L**
Ionizer (Optional) An Ionizer helps to reduce particles in the air.N
Low Water Alarm Alerts when to Refill
Slim Compact Design for Easy Positioning Almost Anywhere
Dimensions 250 x 316 x 733 mm
Dimensions 280 x 340 x 750 mm
Ideal for: • Small Living Room
Study Room
Bedroom
Small Play Room
CS10XE
Indoor Portable Evaporative Air Cooler
POWERFUL & LONG-LASTING COOL AIR
The eye-catching CS10XE portable evaporative air cooler keeps the atmosphere pleasant in almost any small indoor space such as a bedroom, office or playroom. An angled LED control panel keeps operating functions in view from a distance while a full function remote control puts you in command wherever you are. The water tank is detachable for easy maintenance and cleaning.
Recommended area up to 16 m²* For Spot Cooling
SET IT & FORGET IT
DETACHABLE WATER TANK
Set the timer for unattended operation SLEEK, COMTEMPORARY
Easy to refill, easy to clean
Clean curves and modern silhouette enhance its setting
MORE FEATURES & SPECIFICATIONS
Low Power Consumption: Only 100 Watts*
Fast Air Distribution
4 Fan Speeds: Low/Medium/ High/Sleep
Convenient Digital Control LED Control Panel and Remote Control
Detachable Water Tank for Easy Refills
Powerful Airflow: 510 m3/h*
Honeycomb Cooling Media and Carbon-Dust Filter
Set It & Forget It Timer for Unattended Operation
Reduce Temperature by Water Evaporation
Ideal for:
Water Capacity: 10 L**
Quiet Sleep Mode
Special fan settings allow for quiet comfort at night
Low Water Alarm Alerts when to Refill
Compact Design for Easy Positioning Almost Anywhere
CL30XC
Indoor Portable Evaporative Air Cooler
LONG-LASTING EVAPORATIVE COOLER
The CL30XC includes an automatic off timer for even more energy savings. The LCD control panel is easy to use and the remote control lets you operate your cooler from across the room. Plus, this lightweight unit has side handles and four durable caster wheels allowing easy mobility from room to room.
Recommended area up to 30 m²* For Room Cooling
CARBON DUST AIR FILTER
Easy-to-clean filter
Easy access for faster cooling
MORE FEATURES & SPECIFICATIONS
Power Consumption: 252 Watts*
Fast Air Distribution
3 Fan Speeds: Low/Medium/High
Set It & Forget It Timer for Unattended Operation
Ice Compartment for Faster Cooling
Powerful Airflow: 900 m3/h*
Honeycomb Cooling Media and Carbon-Dust Filter
Low Water Alarm Alerts when to Refill
Adjustable
Humidification Dial Choose your Preferred Humidification Level
Set the timer for unattended operation
Ideal for:
Water Capacity: 30 L**
Convenient Digital Control LCD Control Panel and Remote Control
Detachable Water Tank for Easy Refills
Reduce Temperature by Water Evaporation
CL40PM
Indoor
Portable Evaporative Air Cooler
KEEPS INDOOR AND SEMI-OUTDOOR ENVIRONMENTS COOL & BREEZY
Its powerful motor and wide fan blades help to deliver strong airflow while the 3-sided honeycomb cooling media keep performance optimal. A continuous water supply connection, large water tank, and built-in water overflow protection system allow long periods of cooling, making it ideal for more demanding applications.
Recommended area up to 57 m²*
For Indoor & Semi-Outdoor Cooling
AUTO-REFILL HOSE INLET
Hassle-free cooling all day long
WIDE ALUMINUM FAN BLADES Powerful air velocity for large spaces
MORE FEATURES & SPECIFICATIONS
LOADING ICE CHAMBER Easy access for faster cooling
Power Consumption: 140 Watts* Water Capacity: 40 L**
Fast Air Distribution
3 Fan Speeds: Low/Medium/High
Ice Compartment for Faster Cooling
Indoor/Semi-Outdoor Use C Covered Patio, Garage, Living Room
Powerful Airflow: 1800 m3/h*
3 Sided Honeycomb Cooling Media for Long-Lasting Evaporative Cooling
Auto-Refill Hose Inlet Hassle-Free Cooling All Day Long
Durable Casters for Easy Mobility
Ideal for:
Garage
Workshop
Wash Area
Mechanical Control Panel Easy and Simple to Use
Easy Set Up, Easy Storage Cord Wrap & Drain Plug
Reduce Temperature by Water Evaporation
Covered Patio
Covered Garage
Covered Balcony
CL60PM
Indoor Portable Evaporative Air Cooler
BUILT FOR MORE HEAVY-DUTY APPLICATIONS
The premium copper motor with double ball bearing, thick honeycomb cooling pads, carbon dust filter and 16” aluminum fan blades help deliver high velocity airflow, with an air throw distance up to 30 feet. The auto-refill hose inlet, huge 60 L water tank and built-in overflow protection system allows for longer periods of unattended operation, making it an ideal choice for large spaces.
Recommended area up to 80 m²*
For Indoor & Semi-Outdoor Cooling
AUTO-REFILL HOSE INLET
Hassle-free cooling all day long
WIDE ALUMINUM FAN BLADES
Powerful air velocity for large spaces
MORE FEATURES & SPECIFICATIONS
Power Consumption: 220 Watts*
Fast Air Distribution
3 Fan Speeds: Low/Medium/High
Ice Compartment for Faster Cooling
Indoor/Semi-Outdoor Use C Covered Patio, Garage, Living Room
Powerful Airflow: 2610 m3/h*
3 Sided Honeycomb Cooling Media for Long-Lasting Evaporative Cooling
Auto-Refill Hose Inlet Hassle-Free Cooling All Day Long
Durable Casters for Easy Mobility
LOADING ICE CHAMBER
Easy access for faster cooling Ideal for:
Garage
Wash Area
Water Capacity: 60 L**
Mechanical Control Panel Easy and Simple to Use
Easy Set Up, Easy Storage Cord Wrap & Drain Plug
Reduce Temperature by Water Evaporation
Covered Patio
Covered Garage
Covered Balcony
SAVE THE TIME SAVE THE HEAVY LIFTING
Honeywell Local Air Conditioners are 3 appliances in 1. An air conditioner and a multi-speed fan to keep you cool in the summer, a dehumidifier helps your space stay dry during wetter, potentially mold-inducing months. These local air conditioner’s come in a full range of cooling capacities to keep you comfortable in rooms up to a spacious area.
STYLISH, POWERFUL AND DEPENDABLE
The auto-evaporation system allows for hours of continuous operation with no water to drain (depending on the humidity level at your location).
With a small footprint and easy 10-minute tool-free setup, Honeywell Local Air Conditioners are ideal for both personal and professional spaces. Whether you want a cooler bedroom, den or home office, it can quickly and efficiently cool the room
down to your preprogrammed, optimal temperature. Plus, it’s constructed to run quietly, so you can sleep, work, and relax in peace and comfort.
EASY MOBILITY
Honeywell Local Air Conditioners are designed with
portability in mind, smoothgliding wheels and handles allow from room-to-room. It’s easier to keep your energy costs low when you’re not wasting effort cooling down empty rooms.
EASY INSTALLATION
The unit comes with a flexible exhaust hose that expands from 1.2 up to 1.5m to channel heat outdoors. The easy-install window venting kit includes an adjustable window bracket and versatile panels that configures to both horizontal and vertical window openings.
WHY BUY HONEYWELL LOCAL AIR CONDITIONERS?
Set It & Forget It
24 hour energy saving timer
Auto Evaporation System
Allows continuous use without draining water (except in high humidity environments)
R290 Refrigerant
Eco-friendly and non-ozone depleting refrigerant
Thermal Overload Protection
Added safety and endurance to compressor and motor
Dehumidification
Built-in dehumidifier to help control humidity
Quiet Operation
Thanks to its efficient compressor and components
HM Series
Local Air Conditioners
HM12CESWK/ HM14CESWK
STAY COOL. STAY DRY.
Stylish, powerful & dependable, enjoy immediate comfort with the HM Series Honeywell Local Air Conditioners. Built with extra safety features like thermal overload protection and a heat-safe internal casing, you can operate with peace of mind all day or all night long.
Enjoy year round comfort with this versatile appliance offering 3-in-1 functions. The AC provides powerful cooling in the summer, needed dehumidification during humid seasons and the Fan circulates air for everyday comfort.
Recommended area up to:
HM12CESWK: 3.52 kW (12,000 BTU)* / 18-23 m²
HM14CESWK: 4.10 kW (14,000 BTU)* / 21-27 m²
Helps filter unwanted dust, protects & extends the life of the AC
CONVENIENT DIGITAL CONTROL
With Full Function LCD Remote Control
MORE FEATURES & SPECIFICATIONS
Power Consumption:
HM12: 1,346 Watts*
HM14: 1,500 Watts*
Dehumidification Capacity:
HM12: 28.8L/24 hrB
HM14: 36L/24 hrB
Auto Swing Evenly for Fast and Consistent Cooling
Adjustable Temperature 16°C to 31°C
Powerful Airflow:
HM12: 320m³/h*
HM14: 380m³/h*
Sound Level: 65 dBA (Max)
Set It & Forget It Timer for Unattended Operation
Continuous Drain System With drain tube included (Dehumidifier mode only)
ENERGY SAVING SLEEP MODE
Sleep Mode reduces the temperature gradually near the end of the cycle
Cooling Capacity:
HM12: 3.50 kW*
HM14: 3.80 kW*
Convenient Digital Control Soft-Touch Control Panel and LCD Remote Control
Quick And Easy Installation Full Set Window Kit Included
Eco-Friendly Refrigerant
HM12: R290
HM14: R32
Net weight
Gross weight
HM12: 30 kg
HM14: 31 kg
HM12: 33 kg
HM14: 34 kg
Product Dimensions 440 x 350 x 715 mm
Carton Dimensions 474 x 376 x 885 mm
Ideal for: • Living Room • Study Room • Wash Area • Covered Balcony • Bedroom • Dining Area
• Covered Garage
