Project – Office 63, Sanjay Puri Architects Selecting an appropriate projects and study it in detail on the basis of architecture as architecture, interior design sensibilities, interior design specialisation.

Selecting a project on the basis of our study and extracting it into three major criterions namely; architecture

as

architecture,

interior

design

sensibilities and interior design specialisation.

Further

understanding

it,

the

orthographic

drawings of the assigned project were studied and an attempt was made to manually draft the plans and sections of the same.

Analysing it even further to understand the design sensibilities of the space an isometric drawing was drafted manually. The final stage being able to understand and develop an idea about interior design sensibility of the space, an exploded isometric view with an in-detail study was made with an in depth idea about it’s tectonics and materiality.

Section A-A’

Ground floor Plan 8

Isometric View

Early Attempts – Exploded Isometric view 10

Early Attempts – Exploded Isometric view 11

12

13

Final - Exploded Isometric view

Meeting room Details

Detail of the cubicle 14

Details- Back lit Panels in the common areas

Details – Manager’s Cabin 15

Starbucks Coffee, Kengo Kuma Understanding the importance of materiality and tectonics in the interior specialisation, a project was assigned. We studied the project in detail, analyzed it with the perspective of interior design specialisation.

Based on the study, an abstract model was created representing the project selected. The model being the exact representation of the materials coming together and the tectonics between each one of them.

16

Process – Understanding interior design specialisation

Process – Understanding interior design specialisation 17

Process – Understanding interior design specialisation

Process – Understanding interior design specialisation 18

Understanding interior design specialisation by exploring materials and their tectonics.

Understanding interior design specialisation by exploring materials and their tectonics.

19

20

Projects: Historical Era Historical Era Individual Identity Current Modern Practices

Carma Mehrauli Flagship Store, New Delhi 1Q1 Restaurant, Bangalore The Cardboard Office, Pune Office 63, Mumbai

Based on the 4 criterions being Historical Era, Collective Identity and Current modern Practices, 4 projects were identified and studied. The idea being not to merely identify a project but to critically examine the core understanding of materiality reflected in it. A curation of sketches in the form of matrix based on certain parameters was made to understand the project further.

While collating the projects in a matrix, outcome of the design process was reflected in the project The matrix decipher the meaning of materiality in the selected projects and identification of

key

elements that lead to the development of ahypothesis for the further design process was done.

21

Case Study Analysis Matrix 22

Case Study Analysis Matrix 23

Hypothesis Can Materiality Of Threshold Render An Identity To A Space?

24

Shefali Gabada PID 22321 shefali.pid22321@cept.ac.in

Translucent Mysteries Within The Boundaries

Shefali Gabada PID 22321

1. Site Attributes Analysis

6

2. Existing Site and Design Interventions

8

3. Final Design Interventions

9

Translucent Mysteries Within The Boundaries Site – Kochi Biennale Understanding the significance of a historical site and proposing a design for exhibiting Da Vinci’s 15 dream machines.

The site with great historical significance was assigned and a detailed analysis studying all its features was done.

Retaining hypothesis

the

site

further

attributes in

detail,

and a

studying

visual

and

permeable boundary was defined using varied materials and finishes. Metal rods were used as a significant material to provide an industrial look to the site relating to the machines. Metal rods acts like a physical and permeable boundary and provides definition to the exhibit space. Wooden pedestal for the exhibits were raised above the ground giving it a significant importance. Existing rafters were retained on the site and the windows were made bigger to compensate the lack of natural lighting in the exhibition space.

Site Attributes Analysis – Symmetry, Directionality, Framed Space, Windows for Natural Light, Space looks

bigger due to White paint and reflecting light

Site Attributes Analysis – Symmetry, Directionality, Framed Space, Lack of Natural Light, Dark Space, Bigger in Height

Site Attributes Analysis – Symmetry, Directionality, Lack of Natural Light, Entrance being the focal Point,

Linearity, Use of Vernacular Materials

Site Attributes Analysis –Lack of Natural Light, Linearity, Use of Vernacular Materials, Large Volume, Light getting filtered from the roofing tiles

Exsisting Site and the design interventions derived from the idea of Tectonics and materiality

Design intervention 1 – Using Photo montage as a technique to create an Exhibition Space for the 15 Dream Machines by Da Vinci. Single Coloured material defining a threshold within a space.

9

Design intervention 2.1 – Metal rods and a pedestal to define a space for the Exhibit giving them importance.

Design intervention 2.2 – Materials, Surface Finishes, Strip Lights, Levels defining a threshold within the space, demarcating a region for objects of importance.

Design intervention 3.1 – Site elements like rafters, sloping roof and windows retained to respect the site and compensate for the lack of natural light in the space.

12

Design intervention 3.2 – Objects placed in a way to compliment the natural light getting inside the space and the area for each object is demarcated to give equal importance to each one of them.

13

Shefali Gabada PID 22321 shefali.pid22321@cept.ac.in

Translucent Mysteries Into the Mystery World

Shefali Gabada PID 22321

1. Site Selection and Analysis

6

2. Conceptual Development

7

3. Previous Design Interventions

8

4. Final Design Drawings and Details

11

4. Tectonics And Materiality

17

Translucent Mysteries Into The Mystery World Site – Learning Courtyard, Aurangabad by Sanjay Puri Architects Understanding Interior Design Specialization through current modern

Practices selecting a site based on standardization and creating a design intervention for the same.

The interiora space and its represent art structure sculpture Selecting site based onenvironment standard column beamangrid and render a unique experience to interior a space.

HighThe impact and understanding its role to play in design. site environment with repeated organic formsit’s andfloor surprising had beautiful terraces carved inside plate materials and the

reflects the technologicalkeeping advances Da Vinci.

The task was toideologies design anofintervention in of mind the basic product display is made in such a way that it integrates the

structural grid and creating an exhibition space for Da Vinci’s

machines and defines a movement. The envelope is designed in a

Dream Machines.

way as to accommodate the objects. The design is a combination of

Da Vinci was quite ahead of it’s time. Keeping the program in

sinuous forms along with surprising materials. Entire interior is

mind and reflecting his ideas, holographic steel plates were

based on sinuous horizontal lines that protrudes and recedes to

used as a major material along with light boxes which

create a seamless three-dimensional effect. Relatively low lighting

enhances the reflectivity of the Holographic sheet.

makes for an atmosphere creating mystery for the user.

The planning was done in a way to always have an element of

Polished mirror ceiling adds reflection and create the illusion of

curiosity whenFloor the and userceiling passesboth by. have The user just finishes gets a bigger space. reflective glimpse the andhigh is gloss intrigued by accentuating the complexity encouraging creating look and the feeling of the him/her to move towards the main object. space.

Reflections render floor and ceiling insubstantial, directing Making the design more on flexible, the elements behaves a attention to the products display.

The design limits the like views that experience at aamodular time so piece increasing its mystery and lego people blocks making them of display enabling a element of surprise when the it user Lit from person to easily dismantle andmoves movearound. it according tobehind there the translucent theinterlocks elements each glow other Focusing preference.

Thewall, blocks and the the attention finishes firmly oninterlocks the product.

Around further with them.the floor plan the walls undulate in a sinuous rhythm of display shelves.

Project – Learning Courtyard, Aurangabad Architect – Sanjay Puri Architects Typology – Institutional (School)

Site Selection on the basis of Standardization – Column Grid Structure

Conceptual Design Development – Rearranging the Blocks to create a form

Conceptual Design Development – Rearranging the Blocks to create a form

Initial Design Intervention

Initial Design Interventions

Conceptual Design Development

9

Conceptual Design Development

Conceptual Design Development

10

Ground Floor Plan showing the movement pattern in the exhibition gallery and cafeteria

Detailed Section and Plan showing the display gallery and the Terrace

11

First Floor Plan showing the movement pattern in the exhibition space

Detailed Section and Plan showing the display gallery and the Terrace

12

View showcasing the object, how it’s displayed and the movement around it

Detailed Section showing the display gallery

13

Section showing the flow of natural light through the terrace into the double heighted display

Detailed Plan and Section showing the display of an object, and the connection of exhibition gallery with the terrace besides.

14

X-Ray view showcasing the object, how it’s displayed and the movement around it

Detailed Plan and Section showing the display of an object

15

3D Render showing the exhibit displayed in the space, and the movement around it.

3D Render showing the exhibit displayed in the space, and the movement around it.

16

Modular Fixing Detail showing fixing of surface finishes with the wooden blocks

Modular Fixing Detail showing joining of 2 wooden blocks together

17

Shefali Gabada PID 22321 shefali.pid22321@cept.ac.in

Translucent Mysteries The Seamless Transition

Shefali Gabada PID 22321

1. Conceptual Development

6

2. Previous Design Interventions

8

3. Final Design Interventions

10

4. Tectonics And Materiality

14

5. Foreword

15

Translucent Mysteries The Seamless Transition Creating experiences through interior design sensibilities using measures like Movement, Light, Scale, Inside Outside and Volume and further develop it into Interior Design Specialization through Perspective Drawings.

The interior space and its environment represent an art sculpture and render a unique experience to a space. High impact environment with repeated organic forms and surprising materials reflects the ideologies of technological advances of Da Vinci. The product display is made in such a way that it integrates the machines and defines a movement. The envelope is designed in a

way as to accommodate the objects. The design is a combination of sinuous forms along with surprising materials. Entire interior is based on sinuous horizontal lines that protrudes and recedes to create a seamless three-dimensional effect. Relatively low lighting makes for an atmosphere creating mystery for the user.

Polished mirror ceiling adds reflection and create the illusion of bigger space. Floor and ceiling both have reflective finishes creating the high gloss look and accentuating the feeling of the space. Reflections render floor and ceiling insubstantial, directing attention to the products on display. The design limits the views that people experience at a time so increasing its mystery and element of surprise when the user moves around. Lit from behind the translucent wall, the elements glow Focusing the attention firmly on the product. Around the floor plan the walls undulate in a sinuous rhythm of display shelves.

Charcoal Sketches representing Inside Outside

Charcoal Sketches representing Movement

Charcoal Sketches representing Light

Charcoal Sketches representing Scale

Conceptual development – Creating Charcoal Sketches representing Spatial Experiences through measures like Scale, Light, Movement, Inside Outside and Volume

Charcoal Sketches representing Movement

Charcoal Sketches representing Volume

Charcoal Sketches representing Light

Charcoal Sketches representing Light

Conceptual development – Creating Charcoal Sketches representing Spatial Experiences through measures like Scale, Light, Movement, Inside Outside and Volume

Previous Design Iterations – Taking Inspiration from the charcoal sketches and creating a perspective view of an exhibition space 8

Previous Design Iterations – Taking Inspiration from the charcoal sketches and creating a perspective view of an exhibition space 9

Further Development of the Charcoal Sketches through tectonics of materiality.

Fig - Perspective View defining a movement pattern in the space.

10

Fig – Sinuous Forms created using layered Wire mesh Display shelves and Frosted Glass Wall undulating in a way to accommodate the objects 11

Entire interior is based on sinuous horizontal lines that protrudes and recedes to create a seamless three – dimensional effect.

12

Design limiting the views that people experience at a time creating an element of surprise and a sense of mystery for the User 13

Details showing tectonics between wire mesh and steel sections

Part Key Plan Showing the Display Area

Physical Model Image using actual materials to create a part of the Display area

14

The most impactful architects design structures that serve as works of art, as cultural statements that impact and inspire their surrounding communities.

The interior space and its environment represent an art sculpture and render a unique experience to a space. High impact environment with repeated organic forms and surprising materials reflects the ideologies of technological advances of Da Vinci. The

product display is made in such a way that it integrates the machines and defines a movement. The envelope is designed in a way as to accommodate the objects. The design is a combination of sinuous forms along with surprising materials. Entire interior is based on sinuous horizontal lines that protrudes and recedes to create a seamless three-dimensional effect. Relatively low lighting makes for an atmosphere creating mystery for the user.

Polished mirror ceiling adds reflection and create the illusion of bigger space. Floor and ceiling both have reflective finishes creating the high gloss look and accentuating the feeling of the space. Reflections render floor and ceiling insubstantial, directing attention to the products on display. The design limits the views that people experience at a time so increasing its mystery and element of surprise when the user moves around. Lit from behind the translucent wall, the elements glow Focusing the attention firmly on the product. Around the floor plan the walls undulate in a sinuous rhythm of display shelves.

The space is united by its sense of movement, embedding motion directly into the design so that the space, flow, curve, bend, and crumple in novel and unexpected ways, subverting traditional building norms.

15
