Caterpillar Cat 160H Motor Grader (Prefix ASD) Service Repair Manual (ASD00001 and up)

Service Repair Manual

Models

160H Motor Grader

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

1/9

Shutdown SIS Previous Screen Product: MOTOR GRADER Model: 160H MOTOR GRADER ASD Configuration: 160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine

Disassembly and Assembly 12H, 140H and 160H Motor Graders Machine Systems Media Number -RENR4124-06

Publication Date -01/09/2007

Date Updated -24/09/2007

i05508896

Circle Drive - Disassemble SMCS - 5207-015

Disassembly Procedure Table 1 Required Tools Tool

Part Number

A

Part Description

Qty

Forcing Bolt 3/8-16 by 4 inch

2

B

138-7575

Link Bracket

1

C

8H-0663

Bearing Puller Gp

1

8B-7554

Bearing Cup Puller Gp

1

8B-7548

Push-Puller Tool Gp

1

D

Start By: a. Remove the circle drive. Refer to Disassembly and Assembly, "Circle Drive - Remove".

Note: Cleanliness is an important factor. Before you begin the disassembly procedure, the exterior of the components should be thoroughly cleaned. This will help to prevent dirt from entering the internal mechanism. Precision components can be damaged by contaminants or by dirt. Perform disassembly procedures on a clean work surface. Keep components covered and protected at all times.

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 1

g00937730

1. Remove coupling (1) from housing (3). Remove pin (2) from coupling (1).

Illustration 2

g00937733

2. Remove nuts (4). Remove bracket (5).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

2/9

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

3. Remove O-ring seal (7) and shims (8).

4. Remove bearing cup (6) from bracket (5).

Illustration 3

g00937735

5. Remove bolts (9) and cover (10).

6. Remove bolts (11).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

3/9

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 4

g00937707

7. Install Tooling (A) and remove cover (12).

Illustration 5

g00937728

8. Remove plug (13) and O-ring seal (14) from cover (12).

9. Remove bearing (15) from cover (12).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

4/9

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 6

g00937708

10. Install Tooling (B) on shaft assembly (16). Attach a suitable lifting device to Tooling (B).

The weight of shaft assembly (16) is approximately 32 kg (70 lb).

11. Remove shaft assembly (16). Remove Tooling (B).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

5/9

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 7

g00937732

12. Remove remaining bolts (17) and retainer (18). Remove spacer (19) and shims (20).

13. Remove spring (21) and spacer (22).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

6/9

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 8

7/9

g00937709

14. Remove gear (23) from shaft assembly (16). Remove friction discs (24) and discs (25) from gear (23). Remove spacer (26).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 9

8/9

g00937727

15. Remove thrust washer (27) and remove bearing (28).

16. Remove worm assembly (29) from housing (3).

Illustration 10

g00937739

17. Use Tooling (C) and a suitable press in order to remove bearings (31) from worm assembly (29).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 11

9/9

g00937737

18. Use Tooling (D) in order to remove bearing cup (32) from housing (3).

Copyright 1993 - 2019 Caterpillar Inc.

Thu Nov 28 11:22:20 UTC+0800 2019

All Rights Reserved.

Private Network For SIS Licensees.

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

1/12

Shutdown SIS Previous Screen Product: MOTOR GRADER Model: 160H MOTOR GRADER ASD Configuration: 160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine

Disassembly and Assembly 12H, 140H and 160H Motor Graders Machine Systems Media Number -RENR4124-06

Publication Date -01/09/2007

Date Updated -24/09/2007

i07424503

Circle Drive - Assemble SMCS - 5207-016

Assembly Procedure Table 1 Required Tools Tool

Part Number

Part Description

Qty

B

439-3940

Bracket As

1

E

8T-5096

Dial Indicator Gp

1

F

-

Loctite 243

-

Note: Check the O-ring seals, the gaskets, and the seals for wear or for damage. Replace the components, if necessary.

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 1

2/12

g02815057

1. Lower the temperature of bearing cup (32). Install bearing cup (32) in housing (3). Lower the temperature of bearing (28). Install bearing (28) to a depth of 2.00 Âą 0.50 mm (0.079 Âą 0.020 inch) below the face.

Illustration 2

g00938141

2. Raise the temperature of bearing cones (31). Install bearing cones (31) on worm assembly (29).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 3

g03890578

Illustration 4

g03890590

3/12

3. Install worm assembly (29) in housing (3).

4. Lower the temperature on bearing cup (6). Install bearing cup (6) in bracket (5).

5. Torque nut (4A) to 20 N·m (15 lb ft) and nut (4B) 40 N·m (30 lb ft). Then Torque nut (4A) to 80 N·m (60 lb ft) and nut (4B) 80 N·m (60 lb ft). Rotate the worm 3 revolutions then back off the nuts.

6. Torque nut (4A) to 20 N·m (15 lb ft) and nut (4B) 40 N·m (30 lb ft) then torque nut (4A) to 40 N·m (30 lb ft) rotate the worm 3 revolutions.

7. Torque nut (4A) to 40 N·m (30 lb ft) and nut (4B) 40 N·m (30 lb ft). Measure the average gap between the housing and adapter at the locations being torqued. Subtract 0.145 ± 0.065 mm (0.006 ± 0.003 inch) to obtain the desire shim pack thickness.

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 5

g00938174

8. Remove nuts (4) and bracket (5).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

4/12

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 6

g00938187

9. Install gear (23) on shaft assembly (16). Install spacer (26). Install friction discs (24) and discs (25) in gear (23).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

5/12

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 7

g00938190

10. Install spacer (22), spring (21), and spacer (19).

11. Install Tooling (B) (not shown) and bolts (17). Attach a suitable lifting device to Tooling (B). The weight of shaft assembly (16) is approximately 32 kg (70 lb).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

6/12

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 8

7/12

g00938199

12. Install thrust washer (27).

Illustration 9

g02816216

Note: If bolts (17) are M16 bolts, follow Step 13 through Step 19 for the correct shimming procedure.

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

Thank you very much for your reading. Please Click Here. Then Get COMPLETE MANUAL. NO WAITING

NOTE: If there is no response to click on the link above, please download the PDF document first and then click on it.

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

8/12

13. Install shaft assembly (16). Remove Tooling (B). Tighten bolts (17) to 150 ± 20N·m (111 ± 15 lb ft).

14. Wait 45 minutes, then remove bolts (17) and retainer (18) to add shims (20) 15. Determine the required number of shims (20) to obtain 2.30 ± 0.25 mm (0.10 ± 0.01 inch) of deflection in spring (21). Use a depth micrometer to obtain the distance from the end of shaft assembly (16) to the flat surface on spacer (19).

16. Subtract 2.30 ± 0.25 mm (0.10 ± 0.01 inch) from the dimension that was measured in Step 15. The calculated dimension is the thickness of shims (20).

17. Install shims (20), retainer (18), and bolts (17).

18. Tighten bolts (17) to a torque of 240 ± 40 N·m (177 ± 30 lb ft).

19. Tighten bolts (17) again to a torque of 240 ± 40 N·m (177 ± 30 lb ft).

Note: If bolts (17) are 1/2-13 thd bolts, follow Step 20 through Step 26 for the correct shimming procedure.

20. Install shaft assembly (16). Remove Tooling (B). Tighten bolts (17) to 130 ± 7 N·m (96 ± 5 lb ft).

21. Wait 45 minutes, then remove bolts (17) and retainer (18) to add shims (20) 22. Determine the required number of shims (20) to obtain 2.30 ± 0.25 mm (0.10 ± 0.01 inch) of deflection in spring (21). Use a depth micrometer to obtain the distance from the end of shaft assembly (16) to the flat surface on spacer (19).

23. Subtract 2.30 ± 0.25 mm (0.10 ± 0.01 inch) from the dimension that was measured in Step 15. The calculated dimension is the thickness of shims (20).

24. Install shims (20), retainer (18), and bolts (17).

25. Tighten bolts (17) to a torque of 130 ± 7 N·m (96 ± 5 lb ft).

26. Tighten bolts (17) again to a torque of 130 ± 7 N·m (96 ± 5 lb ft).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(SEB...

Illustration 10

g00938238

27. Lower the temperature of bearing (15). Install bearing (15) even with the bottom face of cover (12).

28. Install O-ring seal (14) on cover (12). Lubricate the O-ring seal with the lubricant that is being sealed. Install plug (13).

29. Install cover (12).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28

9/12

160H Motor Grader ASD00001-UP (MACHINE) POWERED BY 3176C Engine(S...

Illustration 11

g03802219

30. Install five bolts (11). Apply Tooling (F) to new bolts (11A). Install new bolts (11A), as shown.

31. Install cover (10) and bolts (9).

https://127.0.0.1/sisweb/sisweb/techdoc/techdoc_print_page.jsp?returnurl=/sis... 2019/11/28
