Portfolio Sezim Syidalieva

ARCHITECTURE PORTFOLIO 2024

Sezim Syidalieva | MSc Building Architecture | Politecnico di Milano

EDUCATION

SEZIM SYIDALIEVA

syidalievas@gmail.com

+393317841383

linkedin/in/sezimsyidalieva/ Milan,Italy CV

Master of Science in Building Architecture 2021 — 2023

Politecnico di Milano (GPA: 110/110 with Honours)

Bachelor of Science in Architecture 2015 — 2020

Kyrgyz Slavic University (GPA: 4.92/5 with Honours)

CERTIFICATES

• Successfully completed “BIM Technologies for Architects and Engineers” in collaboration with the University of East London

• Union of Architects of the Kyrgyz Republic for participating in the competition Multi Comfort Student Contest Milan 2019

INTERESTS

Handcraft, parametric design, culinary, historical patterns in architecture

LANGUAGES

Kyrgyz

Russian

Native

Native

English Fluent C1

Italian Beginner A2

German Beginner A1

SKILLS

Digital modeling ArchiCad, Revit Autodesk, Rhino Grasshopper, 3DS Max, AutoCad

Visualization

Chaos Corona, V-Ray, Lumion, D5 Render, Enscape, Cinema 4D

Graphical Connection Photoshop, Illustrator, Indesign Simulations

MIDAS Gen, Tekla Structures, Synchro 4D, Velux Daylight, Dalux,MatLab

Digital Photogrammetry

Agisoft Metashape Professional

EXPERIENCE

Tsarik Architecture |Junior Architect

Bishkek. Kyrgyzstan 08/2020 — 07/2021

• Led strategic zoning rationalization for a 3500 m2 construction equipment center “Monolit” in Bishkek, implementing movable eco partitions for optimal space utilization. Developed detailed specifications for each premises block, integrating diverse stained glass designs, and managed efficient lighting and air exhaust distri bution for enhanced functionality.

• Designed and executed a 300 m2 private residential building, closely adhering to the initial conceptualization.

• Contributed to the development of the “Altai Ordo” park and beach area project, covering 5 hectares, for a competition. Successfully secured the development tender for the project.

• Designed and implemented an interior design project for a kindergarden,serving as a prototype for subsequent constructions of similar kindergartens in Bishkek.

PROJECTS

Thesis Library project “Gateway to Knowledge”

2022-2023

Revitalized the Scalo Farrini railway yard in Milan with a dynamic library design, strategically catalyzing urban renewal by addressing historical and spatial challenges within the city’s evolution.

Advanced Design Studio Workshop 2023

Collaborated on Madrid skyscraper project, ensuring alignment with historical context and urban fabric, emphasizing functionality and rationality in design under the guidance of architect Vincens Ignacio.

Skyscraper “Royal Skyline” in Stockholm

2021-2022

Strategically developed a culturally resonant tower in Stockholm, showcasing architectural balance, integrating design, functionality, and sustainability.

Architecture Preservation Studio Project 2020-2021

Led a historical building preservation project, applying advanced methods (geometrical survey, structural analysis, material recognition). Developed a conscious, respectful preservation plan highlighting unique characteristics and addressing decay issues meticulously.

01

Highrise multifunctional building

Stockholm, Sweden (page 6-17)

02

An individual single-family

Bishkek, Kyrgyzstan (page 18-23)

03

Thesis project of innovative European Library

Milan,Italy (page 24-35)

SKYSCRAPER “ROYAL SKYLINE”

Group work on a project, created a strategically positioned tower in Stockholm that resonates with cultural significance, exemplifying a harmonious fusion of architectural elements, functional design, and sustainable practices.

Phase 1: History and Culture

We delve into Sweden’s history and tower symbolism, laying the groundwork for our tower’s cultural resonance.

Phase 2: Strategic Location Selection

With meticulous urban analysis, we pinpoint the ideal location, considering density, transportation, history, green spaces, and sustainability.

Our project aims to create a tower that harmoniously blends with Stockholm’s heritage while serving its modern needs—a testament to architectural excellence in a historic city.

Functionality of the Tower

• view of the tower to the city

• location of the residential area

• view of the tower to the city

• location of the university nearby

• direction of the city center

• direction to the port

• sound insulation from the road

• location of the harbor

• best orientation due to the sun

• best orientaion due to the wind

Restaurant

32F-33F

3 Zone: Hotel

23F-31F

Buffer Zone:

Mechanical

22F

2 Zone: Coworking

13-21F

Buffer Zone: Garden

11-12F

1 Zone: Coworking

4-11F

Buffer Zone: Library

Pedestrian bridge

Strategic Connection

Rail or Road development

Skyscraper

Functionality of the Podium

Green rooftop

Operational Room

Cinema

Reception

Commercial

Urban access

Supermarket

Climbing wall

Bar

Cinema Lobby

Structural elements

Our facade features windows of various sizes, a design choice influenced by several factors.

Through the analysis conducted with Ladybug and Honeybee, we gained insights into the varying levels of solar

resulting in differing amounts of sunlight and natural light.

Furthermore, given the diverse functions within the tower, we determined that varying levels

Core Coulumns Beams Facade

8 Double layer glass

9 Steel beam HEA 360

“SALKYN

As a key member of the dynamic “Tsarik&Co” team, I actively contributed to the design of an individual singlefamily house. Our overarching goal was to materialize the client’s architectural vision, striking a harmonious balance between visual lightness and simplicity.

This project not only allowed us to explore innovative design solutions but also provided a unique opportunity to tailor our creative expertise to the distinctive preferences of our client, resulting in a residence that seamlessly blends aesthetics with functionality.

The project involved the creation of spacious interiors, featuring a home cinema and an open staircase that provided a view of the living room below. The core concept revolved around a simple cube design, cleverly transformed on the upper levels to maximize the available space.

Notably, every area was functional, eliminating any wasted space As a result, the residence boasts an efficient, comfortable, and inviting living environment.

LIBRARY “GATEWAY TO KNOWLEDGE”

The Library entails a thorough examination of the territory, considering its geographical location, regional context, functional requirements, and historical significance.

Beginning with a detailed exploration of the library theme itself, our aim has been to emphasize the importance of the surrounding territory.

The Farini yard, historically significant and centrally located, is undergoing substantial changes, impacting the northwest urban

axis from Porta Nuova to the Expo. Our masterplan development:

-Implementation of the grid for the new master plan

-Buildings of historical signifi cance

-New masterplan with various functions according PGT Milano

-Importance of the library in the specific place

-Relation with other educational institutions and heritage

-Sustainability. Natural ventilation.

Villa Simonetta New Brera Campus Dogana Cimeterio Monumentale

Functionality of the Library

Departments

Open Auditorium

Public space

Departments

BEIC forum

Digital department

Imaginarium

Auditorium

Entrance hall

Central storage

Internal services

Ground floor plan

ENTRANCE AREA

1. circulation space

2. “book return” stations

3. reception

4. infopoint area

5. self-loan station

6. exposition of volumes

7. unsystematic consultation

9. bookshop

10. pop-up stores

11. cafe

Facade structure

1. Microcement Floor finish 3 mm

2. Concrete Screed finish 63 mm

3.

4. Vapour Barrier 0.5 mm

5.

7. Sound insulation 50 mm

8. Air Gap with Ventilation system 150-600 mm

9. KNAUF Insulation 100mm

10. Plaster Board finish 12.5 mm

Screed + Water Pipes 140 mm

Metal sheeting with reinforced concrete top

6. Primary beam HEA550, S275 steel class

Interior organization (AI technology help)

Architectural design

3ds Max Experiment idea

Midjourney prompt with a reference image

First image do you like the result?

Vary by region

Second image do you like the result?

Implementation of a new idea in design
