Blueprint reading for welders 9th edition bennett test bank

Blueprint Reading for Welders 9th Edition Bennett Test Bank Visit to download the full and correct content document: https://testbankdeal.com/dow nload/blueprint-reading-for-welders-9th-edition-bennett-test-bank/

Name:

Class:

Date:

Unit 10—Welding Symbols and Abbreviations 1. A standard welding symbol and weld symbols have been developed by the American Welding Society (AWS). a. True b. False ANSWER: True 2. When weld symbols are placed on both sides of the reference line, the welds can be made on either side of the joint. a. True b. False ANSWER: False 3. Certain operations require a specific welding process, a particular type of electrode, or other information necessary to complete the weld. a. True b. False ANSWER: True 4. To save drafting time and to reduce drafting costs, it is common practice to designate similar welds by additional (multiple) arrows, or by an indication placed in the tail of the symbol. a. True b. False ANSWER: True 5. All letters shown on prints represent letter designations or abbreviations. a. True b. False ANSWER: False 6. The standard welding symbol consists of ____. a. a reference line b. an arrow and a reference line c. a reference line, an arrow, and a tail d. an arrow ANSWER: c 7. In the standard welding system, the _____ line is used to apply weld symbols and other data. a. reference b. refer c. standard d. common ANSWER: a 8. In the standard welding system, the ____ connects the reference line to the joint or area to be welded. a. tail b. arrow c. header d. trailer ANSWER: b 9. In the standard welding system, the ____ is added only when needed for the purpose of including a specification process or other reference. a. header b. arrow Copyright Cengage Learning. Powered by Cognero.

Page 1

Name:

Class:

Date:

Unit 10—Welding Symbols and Abbreviations c. trailer ANSWER: d

d. tail

10. The phrase ____ symbol refers to the symbol for a specific type of weld. a. join b. joint c. weld d. combine ANSWER: c 11. When a weld symbol is placed on the reference line on the lower side of the line, the weld must be made on the ____ side of the joint. a. top b. right c. left d. arrow ANSWER: d 12. The vertical leg of the fillet weld symbol is always shown drawn to the ____ of the slanted side of the symbol. a. right b. left c. top d. bottom ANSWER: b 13. Applying the letter “____” to a contour symbol signifies any method of finish may be used. a. G b. H c. R d. U ANSWER: d 14. The term “____” indicates removal of weld metal and base metal from the other side of a partially welded joint. a. gouge b. top bulge c. back gouge d. forward gouge ANSWER: c 15. When the letters “____” are found in the tail of the arrow, a complete joint penetration weld is required regardless of the type of weld or joint preparation that is used. a. CJP b. CPJ c. CPR d. JPC ANSWER: a 16. The phrase ____________________ symbol refers to the total symbol including all information added to it to specify the weld(s) required.

ANSWER: welding 17. Welds not made in the shop are identified as ____ welds.

ANSWER: field 18. A(n) ____________________ describes an edge preparation with a sharp or “feather” edge or with a root face or “land.”

ANSWER: bevel Copyright Cengage Learning. Powered by Cognero.

Page 2

Name:

Class:

Date:

Unit 10—Welding Symbols and Abbreviations 19. The abbreviation for each welding process ends with the letter ____________________.

ANSWER: W 20. When a(n) ____________________ symbol is used, an abbreviation for the method of finish may be included.

ANSWER: contour
