NEW THIS YEAR
Our new “Data Sheet” style round-up format Links to the full data sheets for each of these products are posted on the online version of this section.
3U OpenVPX Blends QorIQ T4080 CPU and Crosspoint Switch
4-core 1.91 GHz Atom Processor Rides Conduction-Cooled SBC
Freescale T2080 Board Features Two Independent SBCs on a Single Card
The RIOV-2478 from CES is a 3U OpenVPX single board computer for airborne applications requiring conduction-cooled equipment. It is specifically designed for the most demanding applications, combining very high computing and flight-worthiness capabilities along with harsh environment criteria.. It combines a multi-core processor with modern interconnect high-speed links and an onboard Crosspoint switch. It features an eight-core QorIQ P3/P4 processor designed for combined data and control plane processing.
The TR D2x/msd-RCx from Concurrent Technologies is a rugged conductioncooled 3U VPX board based on the Intel Atom processor E3800 product family. The board is offered with two processor options: single-core for lowest power consumption and quad-core for enhanced performance.
Curtiss Wright Defense Solutions offers a dual-node Power Architecture OpenVPX card that provides two independent SBC nodes on a single 6U VPX board. The rugged VPX6-195 features dual Freescale 1.5 GHz quad-core T2080 processing nodes, each of which is provided with its own power, I/O, FPGA and XMC expansion site. This innovative processing engine is designed so that both of its SBC nodes are isolated and incapable of impacting the other.
• 3U OpenVPX form-factor (VITA 65). • Freescale QorIQ P4080 processor. • Dual 1/2/4 Gbyte DDR3 memory. • Crosspoint switch (PCIe x4, GbE, 10GbE). • 3x PCIe x4, 8x GbE, 2x 10GbE, 4x UART, 1x Aurora Debug.
• 3U VPX-REDI (VITA 48.0) processor board. • Conduction-cooled to VITA 48.2, conformally coated. • -40°C to +85°C operating temperature (at card edge). • I/O interfaces compatible with several OpenVPX profiles, • Intel Atom processor E3800 family up to 4-core 1.91 GHz. • 4 Gbytes DDR3L DRAM with ECC.
• One XMC site.
• 2 x SATA300 mass storage interface,; Up to 2 x serial ports; Up to 3 x USB 2.0 ports.
• Advanced Board Management Controller (aBMC).
• XMC module interface (x4 PCI Express Gen 2) with rear I/O.
CES (Creative Electronic Systems) Geneva, Switzerland +41 (0)22 884 51 00 www.ces-swap.com
Concurrent Technologies Woburn, MA (781) 933-5900 www.gocct.com
• 6U OpenVPX format, support for 2 OpenVPX slot profiles. • Dual processing node general purpose SBC. • Two Freescale T2080 Quad-core 64-bit Power Architecture with AltiVec at 1.5GHz. • Up to 8 Gbytes of DDR3 SDRAM per processing node. • Full complement of I/O per processing node - Ethernet, serial (RS-232 and RS422), USB 2.0, 10G Ethernet TTL and differential discretes. • 10Base-KX4 Ethernet data plane ports. Curtiss-Wright Defense Solutions Ashburn, VA (703) 779-7800 www.cwcdefense.com
FIND the products featured in this section and more at
www.intelligentsystemssource.com
COTS Journal | July 2015
29
