SPARES BROCHURE|2023

WELCOME TO OUR SPARES BROCHURE

We are constantly listening to our customers on how to improve our support, from this it was discovered you wished to have a better way to view our most sought after spare parts. This brochure will help you to navigate our spares through providing the code, price and image, so making it even easier to order the spares you need through our customer services team.

HOW TO USE THE PDF TO FIND YOUR SPARE

1. Press CTRL+F (Windows) or CMD+F (Mac)

2. In the text box, enter your search term

3. The first match will be highlighted

4. Press Enter or click the right arrow to navigate between the results

CONTENTS

4 Furniture & Fitted Furniture

7 Sanitaryware & Toilet seats

19 Taps & Showers

23 Mirrors & Cabinets

25 Accessories

FURNITURE & FITTED FURNITURE FURNITURE & FITTED FURNITURE

CN6012, CN6016, CN5412, CNL119, CNR119, CN5012, CN5010

Contour 500mm Floor Mounted Handle

CN5480

Chrome Overflow For Isocast Basins Scheme, System & Frame Isocast Basins SCH600IS, SCH800IS, SCH1000IS, SCH1200IS, SYS500IS, SYS600IS, SYS800IS, SYS1200IS, FRM600IS, FRM800IS, FRM1200IS SP12018

Fitted Hinge Mounting Plate

SP12812

FURNITURE & FITTED FURNITURE

SP11237

Fitted Furniture Drawer Fascia Fitting Block White Finish

SP11037

SANITARYWARE & TOILET SEATS

Chrome Ring Cloakroom Basin Overflow Cover

Mia Cloakroom Basin MIA450C, Esta Cloakroom Basin ESB45

SP17569

Furniture Basin Chrome Ring Overflow Cover

CN5480, CN6080, CN7080, CN5080, WS7080 DC12010, DC12011, DC12012, DC12013, DC12014, HALD5480, HALS5480 HALD6080, HALS6080, HALS4680, HALD4680, TY5080, TY6080

SP14610

Geo Semi Recess Basins - G2SCBAS & G3SCBAS

TSP1144

Chrome Ring Overflow Cover

Hampton 575mm, Mini, Harrow, Archetype, Radar & Nashville Basins

TSP0348

Air Gap Inlet Valve High 1/2” Plastic Shank Minerva MCCTNK, Radar RA453CCC, Langford DC14014, Serenity SN63CCC, Debut DCCTNK, Archetype DC14035, Mini MIN53CCC

SP19528

Cable Operated Flush Valve Inc Ceramic Lever

Harrow HCCTNK

SP19531

Flush Valve with Telescopic Overflow

Minerva MCCTNK, Radar RA453CCC, Langford DC14014, Serenity SN63CCC, Debut DCCTNK, Archetype DC14035, Mini MIN53CCC

TR9033

Modern Chrome Flush Button Ø38 Hole - 106mm Legs (Customer Cut to Size)

Minerva MCCTNK, Radar RA453CCC, Debut DCCTNK

SP19532

Classic Chrome Flush Button Ø38 Hole - 106mm Legs (Customer Cut to Size)

Langford DC14014

SP19533

Modern Chrome Flush Button Ø48 Hole - 80mm Legs (Customer Cut to Size)

Serenity SN63CCC, Archetype DC14035, Mini MIN53CCC

SP19534

SANITARYWARE & TOILET SEATS

Ø85 CC Cistern Rubber Gasket/Donut Washer H32

Harrow HCCTNK

SP19535

Ø90 CC Cistern Foam Gasket/Donut Washer H20

Minerva MCCTNK

SP19537

SANITARYWARE & TOILET SEATS

Ø90 CC Cistern Foam Gasket/Donut Washer H15 Ø88 CC Cistern Foam Gasket/Donut Washer H29

Radar RA453CCC, Langford DC14014

SP19538

Serenity SN63CCC, Debut DCCTNK

SP19539

Ø93 CC Cistern Rubber Gasket/Donut Washer H25

Archetype DC14035, Mini MIN53CCC

SP19540

M6 63.5mm Stainless Steel Tank Fixing Bolt Set

Debut DCCTNK

SP19541

M6*65 Brass Tank Fixing Bolt Set

Radar RA453CCC

SP19825

M6*80 Brass Tank Fixing Bolt Set

Debut DCCTNK, Serenity SN63CCC, Langford DC14014, Archetype DC14035, Mini MIN53CCC, Minerva MCCTNK

SP19542

Rubber Diaphragm used in SP19528

Minerva MCCTNK, Radar RA453CCC, Langford DC14014, Serenity SN63CCC, Debut DCCTNK, Archetype DC14035, Mini MIN53CCC

SP19616

Ø38mm Flush Valve Flow Reducer

Serenity SN63CCC

SP19618

Radar RA453CCC

SP19707

SIAMP Compact 99AG Air Gap Inlet Valve 1/2” BSP Plastic Shank

Cover CCCTNK-R, Geo GCCTNK

SP19715

SANITARYWARE & TOILET SEATS

Wall Hung Pan Mounting Connector Kit

0.82m WH Frame TR9005, 1m WH Frame TR9015, 1.17m WH FRAME TR9006, 1/2 Height WH Frame TR9018

SP14720

Diaphragm For Compact 99 Inlet Valve

Cover CCCTNK-R, Geo GCCTNK

SP19716

SANITARYWARE & TOILET SEATS

Optima 49 Flush Valve Inc Strainer

Cover CCCTNK-R, Geo GCCTNK

SP19717

Optima Chrome Flush Button

Cover CCCTNK-R, Geo GCCTNK

SP19718

Optima 49 Foam Doughnut Washer/Gasket Pan To Cistern Coupling SS Bolts Set

Cover CCCTNK-R, Geo GCCTNK

SP19719

Cover CCCTNK-R, Geo GCCTNK

SP19720

Optima 49 Outlet Flap Seal

Cover CCCTNK-R, Geo GCCTNK

SP19721

0.82m WH Frame TR9005, 1m WH Frame TR9015, 1.17m WH Frame TR9006, In-Wall Cistern TR9009

SP14733

Concealed Cistern Air Gap Bottom Inlet Valve

Torrent TR9001, Comfort TR9008

SP19745

Concealed Cistern Air Gap Side Inlet Valve

Cascade Side Inlet Cistern TR9002, 0.82m WH Frame TR9005, 1m WH Frame TR9015, 1.17m WH Frame TR9006, In-Wall Cistern TR9009

SP19744

Torrent TR9001, Comfort TR9008

SP19757

Split Washer

Torrent TR9001, Comfort TR9008, Cascade TR9002

SP19685

SANITARYWARE & TOILET SEATS

Concealed Cistern Nut & Washers for Flush

Bend Pipe

Torrent TR9001, Cascade TR9002

SP12168

Chrome Round Flush Button for Concealed Cistern

Torrent TR9001, Comfort TR9008, Cascade TR9002

SP12169

SANITARYWARE & TOILET SEATS

Concealed Cistern Cover

Torrent TR9001, Comfort TR9008, Cascade TR9002

SP12164

Extra Long Pneumatic Hose Pair 1.5m

Torrent TR9001, Comfort TR9008, Cascade TR9002

SP17421

Concealed Cistern Pneumatic Flush Valve and hoses (Integrated overflow type)

& TR9015 For In-Wall WH Frame cisterns, also order SP20584 for the strainer (cradle) if required.

SP12166

Concealed Cistern Flush Valve Flapper Seal Washer

Torrent TR9001, Cascade TR9002, 0.82m WH Frame TR9005, 1m WH Frame TR9015, 1.17m WH Frame TR9006, In-Wall Cistern TR9009

SP12551

Concealed Cistern Flush Bend Pipe

Torrent TR9001, Cascade TR9002, Comfort TR9008

SP12167

Concealed Cistern Flush Seal/Cone for Pan

Cascade Side Inlet Cistern TR9002, Apex Side Inlet Cistern APX790, 0.82m WH Frame TR9005, 1m WH Frame TR9015, 1.17m WH Frame TR9006, In-Wall Cistern TR9009

SP12170

Concealed Cistern Bottom Inlet Fill Valve (Pre Air Gap)

Torrent TR9001, Comfort TR9008

SP12165

Concealed Cistern Inlet Valve Stem Washer (Non Air Gap)

Torrent TR9001, Comfort TR9008

SP16503

Torrent TR9001, Comfort TR9008

SP18310

In-Wall/WH Frame Side Inlet Valve (Pre Air Gap)

0.82m WH Frame TR9005, 1m WH Frame TR9015, 1.17m WH Frame TR9006, In-Wall Cistern TR9009

SP14735

SANITARYWARE & TOILET SEATS

In-Wall Cistern Down Pipe Rubber Seal Washer

In-Wall Cistern TR9009

SP16849

Wall Hung Frame Threaded Pan Mounting Rods x2

0.82m WH Frame TR9005, 1m WH Frame TR9015, 1.17m WH Frame TR9006, 1/2 Height Frame TR9018

SP12169

SANITARYWARE & TOILET SEATS

WH Frame Flush Valve For TR9006

1.17m WH Frame TR9006

SP14774

In-Wall Cistern Down Pipe With Seal

In-Wall Cistern TR9009

SP16848

Concealed Cistern Flush Valve Base Gasket Air Gap Inlet Valve Aerator Lid Pack (For SP19745 & SP19744 Inlet Valves)

Torrent TR9001, Cascade TR9002

SP19766

Torrent TR9001, Comfort TR9008, Cascade TR9002

SP19827

Concealed Cistern Air Gap Inlet Valve Filter

Torrent TR9001, Comfort TR9008, Apex SI TR9002

SP19828

Flush Valve Flapper Seal Washer for TR9033

Minerva MCCTNK, Radar RA453CCC, Langford DC14014, Serenity SN63CCC, Debut DCCTNK, Archetype DC14035, Mini MIN53CCC

SP19617

Contactless Sensor Decal

Contactless Dual Sensor Flush TR9014

SP16853

Geo Cover Cistern Kit Bag (Pre Air Gap)

Geo GCCTNK, Cover CCCTNK-R

SP16687

Torrent TR9001, Cascade TR9002, Comfort TR9008

SP12163

Traditional Soft Close Quick Release Chrome Hinge Pack

Traditional Seats 8081 Series

SP14430

SANITARYWARE & TOILET SEATS

Curve/Eclipse Soft Close Hinge Pair

Curve & Eclipse Soft Close Seats 8402WSC & 81152

SP11080

Soft Close Bar Hinge Assembly For Oak Seats

Harrow Seats TS850NOSC, HSCTSNO, Greenwich Seats 8099NOSC, 8099HOSC, 8099LISC

SP14199

SANITARYWARE & TOILET SEATS

Mini Soft Close Seat Hinge Fixing Pack (Push Button Version)

MINSCTS

Traditional Wooden Soft Close Seat Hinge Fixing Pack

Traditional Seats - 8081SERIES

SP14431 (Not compatible with lift off version of Mini Seat)

SP13939

Single Button Thermoset Seat Hinge Fixing Pack Mini Seat Fixing Pack & SS Covers

Juno Soft Close Seat 8703WSC, Zenith Soft Close Seat

8702WSC, Elite Soft Close Seat 8601WSC

SP12920

Mini Soft Close Seat (Push Button Only) MINSCTS

(Not compatible with lift off version of Mini Seat)

SP13938

Debut Soft Close Seat (Hinge Fixing Pack)

Debut DSCTS2 (Not compatible with 1st Generation Debut seats with pinch type quick release button)

SP17862

Toilet Seat Ring Buffer

Axis Toilet Seat 8605WH

SP10529

Greenwich & Harrow Soft Close Seat Fixing Pack

For Harrow, Greenwich and DC coded Colour Painted Toilet Seats

SP14200

Lift off style soft close seat hinge fixing pack

Archetype Soft Close Seat DC14030, Radar Soft Close Seat RASCTS, Note Slim Soft Close Seat NSLSCTS

SP16318

Serenity Wrap Over Soft Close Seat SNSCTS (Not compatible with slim seat model)

SP17851

Debut Soft Close Seat (1st Gen) - Pinch Button Version

Debut Seat DSSCTS

SP13427

SANITARYWARE & TOILET SEATS

Soft Close Damper Set

Debut Seat DSCTS2, Radar Seat RASCTS

SP18108

Seat Fixing Screw & Butterfly Clip Set

Universal (Use if pan holes are too big for top fix inserts)

SP17064

TAPS & SHOWERS

2-Way Diverter Valve

All Concealed Valves - Event, Node, Craft, Escape, Clear, Aim, Veer, Elate, Verse, Sign, Sync, Code, Hydra, Stream, Wessex, Henley

SP12597

Brass Pop-Up Waste Mechanism

Waste7 Slotted Waste

SP12256

Pop-Up Waste Plug Top with Seal

Waste7 Slotted Waste

SP12252

Thermostatic Shower Bar Valve Cartridge

All Concealed Valves Event, Node, Craft, Scape, Clear, Aim, Veer, Elate, Verse, Sign, Sync, Code, Hydra, Stream, Wessex, Henley

SP12225

3/4” Quarter Turn Shower Flow Valve (Hot) Concealed Valves Storm and Factor

SP11319

Basin Mixer Cartridge

Storm T221002, Hydra T151102, T151103, T151104

SP11437

TAPS & SHOWERS

TAPS & SHOWERS

Handset Holder Slider - Round 24mm Event SVSET30

SP13866

Basin Mixer Cartridge Storm T226002, Hydra T156102

SP11436

Thermostatic Shower Cartridge

Bar Valves - Push Button DC3003, DC3004, Event SVSET30, SVSET31, Marine TR3003, Harbour TR3004, Arctic TR3005

SP13854

Bar Valve Flow Valve

Factor SV1307, SV1308, SVSET36, SVSET37. Storm SV2207, SV2208

SP12567

Basin Mixer Cartridge Stream taps

SP12357

3/4” Quarter Turn Tap Valve (Cold) Aero, Bora, Factor, Storm & Wessex taps

SP11321

Handset Holder Slider Event SVARM10, SVSET31

SP13868

Shower 3/4” Turn Valve

All Concealed Valves - Henley, Keswick, Cranbourne, Event, Node, Craft, Scape, Clear, Aim, Veer, Elate, Verse, Sign, Sync, Hydra, Stream, Wessex

SP12232

Thermostatic Shower Cartridge

Concealed Valves - Bora, Factor, Storm

SP11312

Hot and Cold Set - Bath Filler Valve Ergo TR1019,TR1020. Fuse TR1023, TR1024. Info TR1031, TR1032. Scape T353202, T354202

SP14976

Fresh, Wessex, Bora, Aero, Reef

SP3005

Bath Filler Valve (Hot)

Fresh, Wessex, Bora, Aero, Reef

SP3001

TAPS & SHOWERS

Basin Mixer Cartridge Fairview TR1045, Ashton TR1070

SP15805

Basin Mixer Valve Regatta TR1056, TR1057, TR1058, TR1059

SP17255

MIRRORS & CABINETS

Basin Mixer Cartridge

Clear T361102, T366102. Crew TR1025. Scape T351102, T356102. Sync T201102, T205002

SP16977

Tap Cartridge

Storm T221902

SP3004

Ascension Glass Shelf Support/Lug

SP10917

Infrared Sensor Switch & Control HZK 218C-1

TSP0672

Envy/FF/Vista/Fever Glass Shelf Bracket

SP10135

Infrared Sensor Colour Changing Switch & Control SHE-Z-60C-K1

SP17366

Adjustable Wall Fixing Bracket Mirror Kit

SP14924

Infrared Sensor Front Face Switch & Controller HZK 218C-4

SP14315

MIRRORS & CABINETS ACCESSORIES

T9 40W Bulb, Solo, Echo, DRM, ASP, Encode SP12810

Ascension

T9 40W Bulb, Solo, Echo, DRM, ASP, Encode SP13404

Metal Shelf Lug/Pin SP12832

Ascension Sliding Shelf Support SP13112

Shelf Support Plugs SP10922

Illusion, Transition Acrylic Cover SP13120

Ignite Soap Pump Mechanism SP12844
