TABLE OF CONTENTS DESIGN STUDIOS

06

Extended Play

12

Blurred Boundaries

24

Unified

30

Sensory Chamber

OTHER WORK

36

Case Studies for Construction Technology

40

Drawing Matters

DESIGN STUDIOS

EXTENDED PLAY ARC 201| FALL 2020 PARTNERS: SABRI HAFIZ UDDIN, JP COLLANTES INSTRUCTOR: JIN YOUNG SONG

Extended Play was designed by representing the diversity of movements through boundless spaces while promoting the various layers of play to dismantle the level of the hierarchical nature to further emphasize ambiguity.

We

were

interested

in

representing

an

architecture that can be more open and more communicative to the broader audience. The program of this project is a little gym, a kid’s play space, that offers various activities.

The use of LED lights throughout the space emphasizes where the play happens in the building but also as a way for kids to use their imagination.

6

1.

2.

L1 - LEVEL ONE

L2 - LEVEL TWO

3.

4.

8

9

L3 - LEVEL THREE

10

L4 - LEVEL FOUR

11

BLURRED BOUNDARIES ARC 403| FALL 2022 PARTNERS: CASSIDY FRISCH INSTRUCTOR: ANNETTE LECUYER

Blurred Boundaries aim was to bring people of all ages together to live on the site to create a multi-generational housing complex. This is accomplished through various unit sizes in both the existing building (Sedita) and the new buildings which include studios, one bedroom, two bedroom, and three bedroom units.

This project blends the boundaries that the different generations may have and allows them to come together, interact, and help one another.

The blurry boundaries can not only be seen in the public program of the library, but also with the connection points of the shared balcony spaces and courtyard spaces on both the ground and basement levels.

The building creates characters of the existing building and site by activating the street frontages and the building facades with lively occupiable space.

12

TYPICAL FLOOR PLAN A 1/8” = 1’-0”

TYPICAL FLOOR PLAN A 1/8” = 1’-0”

UNIT PLAN 1A 1/8” = 1’-0”

UNIT PLAN 1A

TYPICAL FLOOR PLAN B 1/8” = 1’-0”

UNIT PLAN 2A

UNIT PLAN 2A 1/8” = 1’-0”

UNIT PLAN 2C UNIT PLAN 2C 14

1/8” = 1’-0”

SECTION A 15

1/8” = 1’-0”

UNIT PLAN 2A

UNIT 1/8”PLAN = 1’-0” 1B 1/8” = 1’-0”

UNIT PLAN 1B

UNIT PLAN 2C 1/8” = 1’-0”

UNIT PLANUNIT 2B PLAN 2B 1/8” = 1’-0”

UNIT PLAN C

UNIT PLAN C 16

1/8” = 1’-0”

17

EXPLODED SECTION AXONOMETRIC 18

19

GROUND LEVEL

THIRD FLOOR

SECTION C 20

21

22

23

UNIFIED ARC 302| SPRING 2022 INSTRUCTOR: ELAINE CHOW

Black Rock is a community located in nothwestern Buffalo. The community is mainly residential and with that there are not enough services that support the community. To allow as much services needed for the community a community center was designed on a site to fulfil the needs of the residents.

Unified is designed to create a a small community within a big community with the main idea being to allow the circulation and the spaces to complement each other.

The programs to which surrounds the most important space in the centre, acts as the core of the building, from that creates circulation.

24

SECOND LEVEL

THIRD LEVEL

FOURTH LEVEL

KEY Lobby Food Pantry Cafe Mechanical Room Youth Center Meeting room Locker room Storage Child Daycare Multi-Purpose Room Admin Office Exercise Room Workshop Storage Janitor

GROUND LEVEL

Game Room Employment Office

26

27

28

SECTION A

SECTION C

SECTION B

ELEVATION

29

SENSORY CHAMBER ARC 301| FALL 2021 INSTRUCTOR: SETH AMMAN

Sensory

chamber

is

a

boathouse/boat

museum designed for 17 Sweeney Street, North Tonawanda, Buffalo. The building was designed based on the concept of

using

two senses, seeing and hearing of the water which encourages people to interact with the water-front.

The curvature of the building forms a circulation which allows people to flow through the spaces. The exposure of the structure which is similar to wood framing boat.

The buiding creates a community on the inside and also on the outside by providing spaces where

residents of North Tonawanda can

experience different views and enjoy one another’s company.

30

27

Sweeney Street

GROUND LEVEL WALL SECTION

SECTION A

SECTION B

32

SECOND LEVEL

SECTION C 33

OTHER WORK

OUTLINE SPECIFICATION NOTES C. Wall -to- Roof Axon 6

CASE STUDIES

C

2 Ground Floor 4 inch compacted sand over compacted earth fill vapor barrier 4 inch thick site cast concrete slab on grade with wire mesh reinforcement

ARC 442| SPRING 2022 INSTRUCTOR: ANNETTE LECUYER

The drawings were done for Construction

B. Floor -to- Wall Axon

Technology as a way to identify and be knowledgeable about construction materials and

systems.

The

drawings

1 Foundation for perimeter wall 36 inch wide x 12 inch thick site cast concrete strip footing with 3-#5 reinforcement bars 24 inch o.c.

include

the

3 Window at ground level site cast concrete sill 1 course CMU bond beam lintel at outer wythe with 2 course CMU bond beam lintel at inner wythe, grouted solid with (4) #5 reinforcement bars steel frame doubled glazed window.

elevation, section and plan of the portion of 4 Wall at ground level 8 x 16 x 8 CMU inner wythe with (3) #5 reinforment bars at corner, (1) #5 reinforcement bar at openings, and (1) #5 reinforcement bar at 48 inches o.c., cells fully grouted. horizontal joint reinforcement at 16 inches on center vapor barrier 2 iches rigid insulation 2 inche cavity 8 x 8 x 4 CMU outer wythe

the buildings which were the Croffead House

by Clark and Manefee and the Pierce County Environmental Service Building by Miller Hull.

5

B

An extraction of the area that shows important elements within the section were drawn as axons for a closer look of what materials were used to construct the building.

4

A. Foundation -to- Wall Axon

A

2 1

5 Second floor Floor 2 x 10 joist at 16 inches o.c.

3/4 inch plywood subflooring 3/4 inch finish wood flooring at 1 x 6 tongue and groove Ceiling 2 x 4 joists at 16 inches o.c.

3/4 inch gypsum board

3

CROFFEAD HOUSE Architect :Bent Clark and Manefee Rohanna

Scale: 3/4” = 1’-0”

5’-0” 36

6 Roof 2 x 8 rafters at 16 inches o.c.

3/4 inch plywood sheathing built-up roof membrane Ceiling 2 x 4 joists at 16 inches o.c. with 4 inches batt insulation between vapor barrier 3/4 inch gypsum board

OUTLINE SPECIFICATION NOTES C. Wall -to- Roof Axon C 4

7

1 Foundation 18 inch wide x 10 inch deep site cast concrete strip footing with 2-#5 rebar reinforcement continuous 2 Ground Level 4 inch crushed gravel Vapor Barrier 2 inch sand R-10 rigid insulation at perimeter 4 inch concrete slab on grade Raised floor system

6

5

B

3

B. Floor -to- Wall Axon

4 Roof 36 inch wide cast-in-place concrete beam Sloping 8 inch precast hollow core concrete planks 2.5 inches cast concrete slab R-30 rigid insulation Single ply vented roof membrane

A

2

1

A. Foundation -to- Wall Axon

PIERCE COUNTY Architect : Miller Hull

Rohanna Bent

MILLER HULL ARCHITECTS

3 Upper Floor 36 inch wide cast-in-place concrete beam 8 inch precast Hollow Core Concrete Planks 2 1/2 inch Topping Slab Raised Floor System Suspended Ceiling System

5 Exterior Wall (ALL LEVELS) 6 inch metal studs at 16 inches on center with R-19 batt insulation 5/8 inch gypsum sheathing Building wrap ½ inch cement panel Interior: Vapor Barrier 5/8 inch gypsum wall board 6 Windows at Upper and Lower Levels Aluminum Storefront System with Casement Window 7 Pre-Engineered Aluminum Sunscreen Sysytem Aluminum cantilevered brackets, top edge cut to slope with 6 inch flange, bolted to cast-in-place concrete fascia 24 inch wide by 2 inch deep aluminum grills

38

39

DRAWING MATTERS ARC 404| SPRING 2023 INSTRUCTOR: BRIAN CARTER

This class was focused on the art of drawing.

The bicycle was is a design of the famous Penny Farthing. The name Penny Farthing came from England because the small wheel was similar in size to an English penny.

The size of the large wheel is 56 inches in diameter and the smaller wheel is 18 inches in diameter in full scale.

40

DETAILED DRAWING

42

43
