Instruction Manual Form 5207 April 2007
Key 48*
49
51 52* 53
54 55
4195KA, KB, KC, and KS Controllers
Description Bellows ass’y (2 req’d) Brass SST Bellows beam, A96061 (aluminum) 0.2 to 1.0 bar (3 to 15 psig) 0.4 to 2.0 bar (6 to 30 psig)
Part Number
Key
16A6953X012 16A6953X022
56
Part Number
Process and set pt indicator ass’y w/sensing element The part numbers in the Key 56 tables are for the complete process and set pt indicator ass’y with a process sensing element. Individual indicator ass’y parts are listed in two subsections of this parts list: the Process and Set Point Indicator Assembly (key 56) subsection and the Indicator Assembly (key 101) subsection. Key numbers for individual indicator parts also appear in figures 7-2 and 7-3.
16A6957X012 16A6958X012
Relief valve cover plate, A03600 (aluminum) O-ring, nitrile Used w/key 51 (2 req’d) Machine screw, fill hd, 18−8 SST Used w/key 51 (2 req’d) 4195KA, KB, and KS Series 4195KC Series (7 req’d) Reset restriction valve (4195KB Series only) Differential relief valve For all 4195KB and KC Series w/suffix letter F, anti-reset windup
Description
2V597308012 1C853806992
Process and set pt indicator ass’y w/Bourdon tube sensing element Process and set pt indicator ass’y w/capsular element ass’y
1U8842X0012 19A4361X032
See Key 56 tables See Key 56 tables
21A6447X0A2
Key 56 Process and Set Point Indicator Assembly with Bourdon Tube BAR RANGE
PSIG RANGE
ASSEMBLY PART NUMBER W/O Remote Set Point
W/Remote Set Point
With S31600 (316 SST) Bourdon Tube 0 to 1.6 or 0 to 2 0 to 4 or 0 to 2.5 0 to 6 0 to 10
0 to 30 0 to 60 0 to 100 0 to 200
32B1532X012 32B1532X022 32B1532X032 32B1532X042
32B1532X142 32B1532X152 32B1532X162 32B1532X172
0 to 16 0 to 40 or 0 to 25 0 to 60 0 to 100
0 to 300 0 to 600 0 to 1000 0 to 1500
32B1532X052 32B1532X062 32B1532X072 32B1532X082
32B1532X182 32B1532X192 32B1532X202 32B1532X212
0 to 160 0 to 250 or 0 to 300
0 to 3000 0 to 5000
32B1532X092 32B1532X102
32B1532X222 32B1532X232
Key 56 Process and Set Point Indicator Assembly with Capsular Element Assembly ASSEMBLY PART NUMBER RANGE
W/O Remote Set Point
W/Remote Set Point
N09902
N09902
Positive and Compound Element 0 to 60 inch wc 0 to 5 psig 0 to 10 Psig 0 to 12 Psig 0 to 15 Psig 0 to 20 Psig 0 to 24 Psig 0 to 30 Psig
U.S. Units
36A6986X082 36A6986X092 36A6986X102 36A6986X112 36A6986X302 36A6986X122 36A6986X132 36A6986X142
36A6986X222 36A6986X232 36A6986X242 36A6986X252 36A6986X322 36A6986X262 36A6986X272 36A6986X282
Vacuum Element U.S. Units
−5 to 0 Inch Hg −10 to 0 Inch Hg −20 to 0 Inch Hg −30 to 0 Inch Hg
*Recommended spare parts
36A6987X052 36A6987X062 36A6987X072 36A6987X082
36A6987X132 36A6987X142 36A6987X152 36A6987X162
7-3
