Instruction Manual Form 5207 April 2007
4195KA, KB, KC, and KS Controllers Description
Section 7 Parts
4190 Series Relay Replacement Kit Contains Relay Assembly (includes keys 13 and 15) and key 10 0.2 to 1.0 bar (3 to 15 psig) RRELAYX83C2 0.4 to 2.0 bar (6 to 30 psig) RRELAYX83D2 Type 4195KBF Anti-Reset Windup Retrofit Kit, SST tubing, Contains keys 44 and 55 R4190X00S22
Parts Ordering Whenever corresponding with your Emerson Process Management sales office about this equipment, always mention the controller serial number. When ordering replacement parts, refer to the 11-character part number of each required part as found in the following parts list.
Parts List Abbreviations Used In Parts List adj: alt desgntn: ass’y: conn(s): diff:
WARNING Use only genuine Fisher replacement parts. Components that are not supplied by Emerson Process Management should not, under any circumstances, be used in any Fisher instrument. Use of components not supplied by Emerson will void your warranty, might adversely affect the performance of the instrument, and could give rise to personal injury and property damage.
fdback: fill hd: ext: hd: int: OD: p/o pl: pt: qty: SST: w/: w/o: Key
Note Neither Emerson, Emerson Process Management, nor any of their affiliated entities assumes responsibility for the selection, use, and maintenance of any product. Responsibility for the selection, use, and maintenance of any product remains with the purchaser and end-user.
4190 Series Auto/Manual Repair Kit Contains keys 277, 278, 279, 281, 292, 293, 294, 298, 306, 312 R4190X0AM12 4190 Series Auto/Manual Retrofit Kit, SST tubing, Contains keys 138, 273, 312, 313, 314, 315, 316 R4190X00S12 4190 Series Case Handle Kit Contains lever and mounting hardware R4190X00H12 4190 Series Controller Repair Kit Contains keys 4, 5, 7, 8, 24, 52 R4190X00C12 4190 Series Pointer and Bracket Repair Kit Contains pointer and bracket ass’y, three machine screws, three washers R4190X00P12
*Recommended spare parts
Description
Part Number
Note Figure 7-1 shows key numbers for the common construction of all controller types. Figure 7-1 continues over several pages. Be sure to check all pages of figure 7-1 to find the common key numbers. 1
Part Number
adjustment alternative designation assembly connection(s) differential (as in process differential pressure) feedback fillister head (as in fillister head cap screw) external head (as in machine screw head) internal outside diameter part of (as in part of another assembly) plated (as in plated steel) point (as in set point) quantity stainless steel with without
Controller Common Parts (figure 7-1)
Parts Kits Description
Part Number
2 3 4*
5*
6
Case and cover ass’y For use w/o remote set pt For use w/remote set pt Nameplate, A91100 (aluminum) Frame, A03600 (aluminum) Frame gasket, chloroprene For use between frame and frame manifold (key 135) Gasket, chloroprene 4195KA, KB, and KS (1 req’d) 4195KC (2 req’d) Machine screw, fill hd, 18−8 SST (9 req’d) 2 req’d to mount the prop band ind cover to the frame 4 req’d to mount bellows bracket (key 31) to bellows beam (key 49) 2 req’d to attach process scale brackets (keys 376, 377) to frame
46A5903X012 46A5902X012 --56A7001X012
18A0749X012
18A0742X012
1P4373X0012
7-1
