THE BIRD RE-CLAD STUDY
USING GRASSHOPPER AND CLIMATE PLUG-INS TO RECLAD THE HILTON UN BUILDING.
THE BIRD
The image of a bird emerging from water inspired the form of the recycling and waste-to-energy center, reflecting nature’s efficiency and sustainability principles in its design.
This design approach reflects the center’s commitment to ecological principles and resource optimization.
M.ARCH | YEAR 2 | SEMESTER 4 | STUDIO
Professer SARA LOPERGOLO
Coordinator ALEX BARKER
Partner PEYTON FLOYD
PATHWAYS ON ANABLE BASIN
THE WOOD DECK PATHWAYS FOLLOW THE CONTOURS OF THE BUILDING, BRINGING VISITORS UP TO THE TERRACES OF THE ARTISTS’ STUDIOS AND DOWN TO THE SHORE OF THE BASIN.
THE BIRD
RHINO 7 | VRAY | ENSCAPE GRASSHOPPER
CONCEPTUAL DESIGN
THE FORM OF THE BUILDING IS DERIVED FROM THE NATURE OF A BIRD’S WING FLAPPING IN MOTION. THE WINGS TOUCH THE WATER AS IF IT IS EMERGING FROM THE BASIN.
THE BIRD
ELEVATED BIRD’S WING
THE SEGMENTED BIRD’S WING ELEVATE GRADUALLY WITH THE SPACE OF THE BASIN. ALGAE PANELS DESIGNED BY THE RESIDENT ARTISTS CLAD THE ENTRANCE OF THE FERRY AND BARGE DOCKS.
THE BIRD
7 | VRAY | ENSCAPE GRASSHOPPER
RHINO
FLOOR PLATES VERSUS WINGS
THE CHALLENGES WE FACED PRIMARILY INVOLVED PROGRAMMING WITHIN THE CANTED WINGS, SO WE EXPLORED THE OPPORTUNITIES FOR VISITORS TO WALK BETWEEN THE BOX TRUSSES, MAKING LOOKOUT POINTS INTO THE RECYCLING CENTER, AND MAKING ADA COMPLIANT RAMP SYSTEMS.
HAND SKETCHES THE BIRD
WASTE-TO-ENERGY PANELIZATION
WE EXPLORED ITERATIONS OF PATTERNS AND MATERIALS TO CLAD THE FACILITY SPACES DIFFRERNT TO THE SHARED PUBLIC SPACES. WHERE THE WALKWAYS OF THE SPINE MERGE INTO THE WTE FACILITY IS WHERE VISITORS CAN LOOK INTO SPACES AS WELL AS EXPERIENCE THE ALGAE FARM UNDERWATER.
HAND SKETCHES ON TRACE THE BIRD
LONGITUDINAL ELEVATION AND SECTION
EACH SEGMENTED WING IS HELD UP BY A BOX TRUSS SYSTEM WITHIN A FRAYING COLUMN GRID. THE LEFT WING HOUSES THE ARTIST RESIDENCE, GALLERY SPACE AND RECYCLING CENTER WHILE THE WING OF THE LEFT HOUSES THE WASTE TO ENERGY FACILITY. EACH FORM IS CLADDED DIFFERENTLY TO AN INDUSTRIAL STANDARD.
THE
RHINO 7 FORMATTED TO 24X36 SPREAD BIRD
GROUND FLOOR PLAN
THE WINGS OF THE BIRD ARE ERECTED SEPARATELY WITH THE DROP-OFF AND WEIGHING AREAS BETWEEN THE LOWEST POINTS OF THE MASSINGS.
5
1 BARGE AND FERRY DOCKS
2 PARK BY THE BASIN
3 ART GALLERY
4 RECYCLING FACILITY
WASTE-TO-ENERGY FACILITY
1 2 3 4 THE BIRD
6 ALGAE FARM FOR ARTISTS
EXPLODED AXONOMETRIC
WE PHASED THE ASSEMBLY OF THE BUILDING WITH THE ATTITUDES OF A BIRD’S ANATOMY.
5 6 RHINO 7 | PHOTOSHOP THE BIRD
FEATHERS
SPINE
ALGAE
BONES
ORGANS
WASTE-TO-ENERGY LOOKOUT
THE MERGING PATHWAYS THAT ACT AS THE SPINE OF THE BIRD CONNECT THE FACILITIES TOGETHER WHILE CREATING A PUBLIC GROUNDS FOR THE COMMUNITY TO EXPERIENCE AND LEARN ABOUT HOW WASTE IS MANAGED AND DISPOSED.
THE
RHINO 7 | VRAY BIRD
UNDERSIDE OF BIRD’S WING
SIMILAR TO THE SHINY REFLECTIVE FEATHERS OFTEN FOUND ON THE UNDERSIDE OF A BIRDS WING, THE UNDERSIDE OF THE SEGMENTS ARE CLADDED IN A REFLECTIVE MIRROR-LIKE MATERIAL REFLECTING THE WATER ELEMENTS UNDERNEATH BACK ONTO THE VISITORS.
THE BIRD
RHINO 7 | VRAY | ENSCAPE GRASSHOPPER
UNDERSIDE OF BIRD’S WING
THE SEGMENTS OF THE WING WERE INTENDED TO GIVE THE ILLUSION OF “HEAVINESS” HOVERING ABOVE THE VISITORS IN THE PARK. TO EXPRESS THIS, WE SOURCED BLUE-STONE, A NEW YORK LOCAL STONE, TO CLAD THE FACES OF THE WING.
THE BIRD
RHINO 7 | VRAY | ENSCAPE GRASSHOPPER
THE MINI CITY
The Mini City in Sawtelle addresses LA’s housing crisis by offering a multi-generational communal compound, accommodating diverse family structures within a cohousing framework. Through strategic unit arrangements and shared courtyards, the design promotes independence and support, while re-contouring the lot integrates rainwater harvesting and enhances social connectivity.
M.ARCH | YEAR 3 | SEMESTER 5 | STUDIO
Professer PETER MARTINEZ ZELLNER
Coordinator ALEX BARKER
Partner MARINA MARGELOU
Winners of 2024 SARA CALIFORNIA DESIGN AWARDS
STREET VIEW OF COMMUNAL COMPOUND
THE PUBLIC PROGRAMS OF THE COMPOUND ARE SITUATED AT THE STREET ELEVATION OF THE LOT, LIKE THE LAUNDROMAT AND GYM.
THE MINI CITY RHINO 7 | VRAY | ENSCAPE
L.A. WALKING TOURS
ON OUR TRIP TO LOS ANGELES, WE VISITED MANY PUBLIC HOUSING PROJECTS TO ANALYZE THE BASIS OF THEIR INCEPTION AND THE AESTHETIC CHOICES MADE.
THE MINI
RHINO 7 | VRAY | ENSCAPE MINI CITY
L.A. WALKING TOURS
ON OUR TRIP TO LOS ANGELES, WE VISITED MANY PUBLIC HOUSING PROJECTS TO ANALYZE THE BASIS OF THEIR INCEPTION AND THE AESTHETIC CHOICES MADE.
BLACKBIRDS
| BARBARA BESTOR
RESIDENTIAL BACKYARD | SHARIF LYNCH ARCHITECTS ISLA INTERSECTIONS SUPPORTIVE HOUSING AND PASEO | LOHA THE MINI CITY
CO-HOUSING PROJECT
ARCHITECTS
ENTRANCES TO THE COMMUNAL COMPOUND
ONE OF THE TAKE AWAYS FROM OUR VISIT TO LOS ANGELES WAS HOW RESIDENTS TAKE PRIDE IN PERSONALIZING THEIR OUTDOOR SPACES AS MUCH AS THE INTERIOR OF THEIR HOMES. ONE OF THE WAY THEY DO THIS IS BY INCORPORATING VIBRANT COLOURS.
7 | VRAY | ENSCAPE THE MINI CITY
RHINO
COMMUNAL KITCHEN SECTION
LIKE THE ARRANGEMENT OF A CITY, WE GROUNDED MOST OF THE SHARED SPACES LIKE THE LAUNDROMAT, COMMUNAL KITCHEN AND AUDITORIUM/MEETING AREA WHILE ELEVATING THE RESIDENTIAL SPACES AND TERRANCES ON THE UPPER LEVELS.
RHINO 7 | PHOTOSHOP THE MINI CITY
Program
Client Profile: 20 People:
RESIDENT PROFILES: MAX. 25 PEOPLE
- MULTIGENERATIONAL FAMILIES + UNRELATED INDIVIDUALS
- AGE RANGE: 1-100
- 7 KIDS UNDER THE AGE OF 16
- 11 UNITS - 15 BEDROOMS
- 2 LIVE/WORK STRUCTURES
- 1 ADA COMPLIANT UNIT
UNIT VARIATIONS:
UNIT A: 1900 SQFT - 4 BED - 2 BATH - 1 W/C - 2 FLEXIBLE SPACES X1
UNIT B: 950 SQFT - 2 BED - 1 BATH - 1 W/C - 1 FLEXIBLE SPACE X4
UNIT C: 650 SQFT - 1 BED - 1 BATH X2
UNIT D: 500 SQFT - STUDIO X3
UNIT E (ADA): 500 SQFT - STUDIO X1
Multigenerational families - Unrelated Individuals (Seniors, Single Parents, Young Professionals,Couple with young kids, Reintegrated 18+)
Age range: 0-100 years
2/ Program
10 units- 15 bedrooms 2 Live/Work structures 1 fully ADA compliant unit
Size:
Client Profile: 20 People:
A: 1900 sqft- 4 Bed - 2 Bath- 1 WC - 2 Flexible spaces x1
Unrelated Individuals Professionals,Couple 18+) - 2 Flexible spaces x1
Unrelated Individuals Professionals,Couple 18+)
- Multigenerational families - Unrelated Individuals (Seniors, Single Parents, Young Professionals,Couple with young kids, Reintegrated 18+)
Space
- Age range: 0-100 years
B: 950 sqft- 2 Bed- 1 Bath- 1 WC- 1 Flexible Space x4
C: 650 sqft- 1 Bed- 1 Bath x2
D: 500 sqft - Studio Ap. x2
E (ADA): 550 sqft - Studio Ap. x3
TOTAL : 9650 sqft
- 10 units- 15 bedrooms - 2 Live/Work structures - 1 fully ADA compliant unit
- 2 Flexible spaces x1
PROGRAM AND RESIDENTS
THE COMPOUND IS COMPOSED OF VARYING UNIT SIZES AND AMENITIES THAT CATER TO THE SPECIFIC NEEDS OF LARGE FAMILIES, SINGLE PARENTS, AND YOUNG PROFESSIONAL COUPLES.
Flexible
x4 x2 x2 x3 Large Nuclear Family Senior Citizens Single Parents Young Professional Couples 18+ Orphans
Bed-
WC-
Units Size: Unit A 1900 sqft- 4 Bed - 2 Bath- 1 WC - 2 Flexible spaces x1 Unit B: 950 sqft- 2
1 Bath- 1
1 Flexible Space x4 Unit C 650 sqft- 1 Bed- 1 Bath x2
Unit D: 500 sqft - Studio Ap x2
Unit E (ADA): 550 sqft - Studio Ap. x3
TOTAL 9650 sqft Large Nuclear Family Senior Citizens Single Parents Young Professional Couples 18+ Orphans
Flexible Space x4 x2 x2 x3 Large Nuclear Family Senior Citizens Single Parents Young Professional Couples 18+ Orphans PROGRAM
Large Nuclear Family Senior Citizens Single Parents Young Professional Couples
18+ Orphans LARGE NUCLEAR FAMILY 18+ ORPHANS SINGLE PARENTS SENIOR CITIZENS YOUNG PROFESSIONAL COUPLES
GROUND
THE MINI CITY
UPPER BRIDGE VIEW
THE VERTICAL CIRCULATION IS REPRESENTED IN A VIBRANT COLOUR THAT VISUALLY MARKS CHECKPOINTS ALONG THE SQUARESHAPED PATHWAYS AND BRIDGES ON THE SECOND LEVEL OF THE COMPOUND.
THE MINI CITY
|
RHINO 7
| VRAY
ENSCAPE
MAIN COURTYARD AND COMMUNAL
THE INTERIOR COURTYARD IS A SHARED SPACE FOR RESIDENTS TO INHABIT. IT IS CENTRAL TO THE LOT WHILE THEIR RESPECTIVE PRIVATE HOMES ARE SITUATED ALONG THE PERIMETER OF THE LOT.
KITCHEN
THE MINI CITY
|
| ENSCAPE
RHINO 7
VRAY
PHOTOSHOP
RED HOOK MIDDLE SCHOOL
Analysis of emergent sports like MMA informed the design of the stratas of the school, integrating principles of movement and functionality to optimize training spaces.
Attitudes cultivated from studying MMA were utilized to program interior spaces, fostering an environmentv conducive to discipline, collaboration, and physical development.
M.ARCH | YEAR 1 | SEMESTER 2 | STUDIO
Professor BILL MAC DONALD Coordinator HART MARLOW
CONTOURS OF SAND DUNES
CLOSE UP SHOT OF THE CRUSH SPACE AND MAIN ENTRANCE OF THE MIDDLE SCHOOL.
RED HOOK MIDDLE SCHOOL
LASERCUT BRISTOL CNC MILLED HIGH DENSITY FOAM
SPACE-TIME CONTINUUM STUDIES
AFTER ANALYZING AN EMERGENT SPORT, LIKE MIXED MARTIAL ARTS, WE EXTRACTED THE ATTITUDES OF THE FIGHTERS AND OVERLAYED THEM ONTO THE STRATAS OF THE SITE.
RECENTERING DECEPTIVE OSCILLATING ADAPTIVE ENFOLDING POSITIVE NEGATIVE ELASTIC
RED HOOK MIDDLE SCHOOL RHINO 7 UFC GAME PLAY
ELASTIC
STRATA THREE
ADAPTIVE
STRATA TWO
DECEPTIVE
STRATA ONE
POSITIVE AND NEGATIVE STRATAS ON SITE EACH STRATA REPRESENTS AN ATTITUDE STUDY OF OUR SPORT AND DICTATES HOW WE PURPOSE THE SPACES PROGRAMMATICALLY.
RHINO 7 RED HOOK MIDDLE SCHOOL
STACKING DEVELOPMENT DIAGRAMS
BY OVERLAYING ALL THREE STRATAS, I COULD BEGIN TO SEE WHERE THE PROGRAMS ON SEPARATE FLOORS COULD WORK RELATE AS WELL AS WHERE TO HOUSE VERTICAL CIRCULATION.
RHINO 7| PROREATE RED HOOK MIDDLE SCHOOL
GROUND FLOOR PLAN | DECEPTIVE
THE SWEEPS OF THE FIGHTERS RESULTED IN A SAND DUNE LIKE QUALITY TO THE GROUND FLOOR. THESE SPACES ARE PROGRAMMED FOR MORE ACTIVE USES LIKE ELEVATED SEATING, CLIMBING, AND SLIDING.
1
2
3
4
7
9
A A 1 2 9 9 3 6 5 8 7 4 5
7
RHINO
EXCHANGE CRUSH ZONE
MAIN ENTRANCE
CHURCH VIEW CAFE
INFO COLLECTION SPACE
AUDITORIUM SEATING
PARK ENTRANCE
5
6
STORAGE AND LOADING
MEDIA ROOM
8
READING NOOKS RED HOOK MIDDLE SCHOOL
DECEPTIVE READING NOOKS
ON THE DECEPTIVE FLOOR, I CHOSE TO PURPOSE THE UPPER CARVINGS OF THE MASSING AS SPACES TO CLIMB INTO AND HIDE FROM THE TEACHERS. THIS IS ONE WAY DECEPTION IS USED IN A MEANINGFUL MANNER.
RHINO 7 PHOTOSHOP | PROCREATE RED HOOK MIDDLE SCHOOL
PHYSICAL MODEL ON SITE
THIS PHYSICAL MODELS WAS INTENDED TO REPRESENT THE SLOW AND GRADUAL STEPPING OF THE GROUND FLOOR AND HOW IT SITS ON THE SITE IN RELATIONSHIP TO THE PUBLIC PARK INFRONT OF THE LOT.
RED HOOK MIDDLE SCHOOL
LASERCUT BRISTOL CNC MILLED HIGH DENSITY FOAM
DECEPTIVE ROCK CLIMBING AREAS
UNLIKE TYPICAL SCHOOLS, THE HALLWAYS ARE USED AS LEARNING SPACES AND PHYSICAL ACTIVITIES IN ADDITION TO THE CLOSED INTERIOR CLASSROOMS.
RHINO 7 PHOTOSHOP | PROCREATE RED HOOK MIDDLE SCHOOL
PHYSICAL MODEL ON SITE
THIS PHYSICAL MODELS WAS INTENDED TO REPRESENT THE SLOW AND GRADUAL STEPPING OF THE GROUND FLOOR AND HOW IT SITS ON THE SITE IN RELATIONSHIP TO THE PUBLIC PARK INFRONT OF THE LOT.
RED HOOK MIDDLE SCHOOL
LASERCUT BRISTOL CNC MILLED HIGH DENSITY FOAM
RE-CLAD STUDY
This project was aimed to establish the fundamentals of Grasshopper scripting and implement them in a new design proposal for an existing building in NYC.
My building was the Hilton UN Building, housing both office and hotel. My proposal was to make a breathable skin, a second layer to the building that acted as circulation, shading and planting devices.
M.ARCH | YEAR 2 | SEMESTER 4 | COMMUNCATIONS
Professor ANTHONY SAMAHA Coordinator ROBERT CERVELLIONE
STREET VIEW OF ETFE PANELS
THIS VIEW SHOWS THE VARYING EXPANSION LEVELS OF THE ETFE PANELS FROM STREET PERSPECTIVE. GRASSHOPPER
RHINO 7 RE-CLAD STUDY
OFFICE SPACE
13 FLOORS
HOTEL
20 FLOORS
ADDITIONAL PROGRAM
PROGRAM AND FORM
ANALYSIS OF THE BUILDING IN RELATIONSHIP TO SITE AND FOCUSED ON DISTINGUISHING SPECIFIC AREAS OF FOCUS TO ALTER.
RHINO 7 GRASSHOPPER
RE-CLAD STUDY
PROPOSED DESIGN ON SITE
THE NORTH FACE OF THE BUILDING EXPERIENCES THE LEAST AMOUNT OF SUN EXPOSURE, ALLOWING FOR THE ETFE PANELS TO BE EXCLUDED FROM THE AREAS OF THE FORM THAT ARE CARVED AND INSET.
RHINO 7 GRASSHOPPER RE-CLAD STUDY
DESIGN PROPOSAL
THIS IS THE PROPOSED DESIGN OF THE FACADE OVERLAYING THE EXISTING STRUCTURE.
RHINO 7 GRASSHOPPER CLIMATE STUDIO RE-CLAD STUDY
PARAMETRIC CONTROLS
A | SIZE VARIATIONS OF PANELS
BY OVERLAYING THE EXISTING SLANTED EDGES AND STRUCTURAL GRID ONTO THE NEW SKIN, THIS PARAMETRIC GUIDELINE DICTATED THE NUMBER OF COLUMNS AND CANTED MULLIONS OF THE PANELLING SYSTEM. THE EXISTING STUCTURE ALSO PROVIDED FOR AN EDGE CONDITION OF THE ETFE PANELS.
B | EXPANSION LEVELS OF ETFE
BY USING CLIMATE STUDIO AND LADYBUG PLUG-INS, THE LEVEL OF EXPANSION THE ETFE PANELS FOLLOW ARE GUIDED BY THE VARYING LEVELS OF SUN EXPOSURE ON THE FACES OF THE BUILDING. LESS EXPANSION RESPONDS TO HIGH SUN EXPOSURE, WHILE MORE EXPANSION ENCOURAGES SUN EXPOSURE INTO THE INTERIOR SPACES.
C | SECONDARY CIRCULATION
DEPENDING ON HEIGHT RESTRICTIONS AND ANNUAL WIND PATTERNS, A SECONDARY CORRIDOR (BLUE) IS PROPOSED BETWEEN THE OLD AND NEW SKIN OF THE BUILDING.
D | VEGETATED AREAS
IN-PUTTING BOTH SUN EXPOSURE AND ANNUAL WIND EXPOSURE INTO THE PANELLING SYSTEM, IT DETERMINES WHICH PANELS WERE MORE SUITABLE TO HOST VERTICAL FARMING SYSTEMS. THIS ONLY HAPPENS WHERE THE SECONDARY CIRCULATION IS TRUE AND AN ETFE PANEL EXISTS.
PHASING OF PANEL ASSEMBLY
THIS INVESTIGATION FOCUSES ON THE ASSEMBLY OF ALL STRUCTURAL AND STRUCTURAL AND SKIN COMPONENTS BASED ON CLIMATE STUDIO INPUTS TO REGULATE THE INTERIOR ENVIRONMENTAL CONDITION.
RHINO | GRASSHOPPER LADYBUG | CLIMATE STUDIO WEAVERBIRD - TOPOGRAPHICAL MESH EDITOR B A C D RE-CLAD STUDY
CHUNK MODEL
THIS PHYSICAL MODEL AIMED TO REPRESENT THE RELATIONSHIP OF THE OLD BUILDING VERSUS THE NEW PERFORMING SKIN.
VACUUM
|
| CLEAR
| CHIPBOARD RE-CLAD STUDY
FORM POLYCARBONATE MUSEUM BOARD
METAL MESH
ACRYLIC ACRYLIC PAINTED SPONGE
RYERSON UNIVERSITY
2019
COMPLETED
CHURCH OF TRANSFIGURATION
A COLLAGE OF NEW AND OLD TO FORM A LEGITIMATE PRE-VATICAN II SANCTUARY.
CHURCH OF TRANSFIGURATION
TRANSFIGURATION is a complete change of form or appearance into a more beautiful or spiritual state. By extracting the geometries of the painting, we overlayed the linework as guides to programming the Church of Transfiguration.
This geometry also dictated the forms of the acoustic panels and wings of the sanctuary.
B.ARCH.SCI | YEAR 4 | SEMESTER 7 | STUDIO
Professor ED WOJS
Partner ASAL KHALILI
SECTION OF PROCESSION
FOLLOWING THE NARRATIVE OF BEGINNING, MIDDLE AND END - THE BELLTOWER STANDS AS THE TALLEST FORM, FOLLOWED BY THE HEAVY TIMBER COLONNADE OF THE PROCESSION TO THE ALTAR WHICH SITS AS THE LOWEST FORM OF THE BUILDING.
REVIT | PHOTOSHOP CHURCH OF TRANSFIGURATION
EVOLVING GEOMETRY
WE EXTRACTED THE FORMS AND GEOMETRIES FROM OUR ARTWORKS AND MULTIPLIED THEM AS A GUIDE FOR THE FORM OF THE CHURCH.
CHURCH OF TRANSFIGURATION AUTOCAD
THE GEOMETRY IS OVERLAYED ONTO THE MARBLE FLOOR PATTERN OF THE MAIN CHURCH FLOOR.
1
2
5
6
4
7
8
9
1 2 3 4 5 5 4 6 6 8 7 9
GROUND FLOOR PLAN
REVIT PHOTOSHOP CHURCH OF TRANSFIGURATION
CRUSH ZONE
ENTRANCE AND BELL TOWER
NARTHEX AND PROCESSION
3
CONFESSIONALS
STATIONS OF THE CROSS
SIDE CHAPEL AND ALTAR
BAPTISTERY
PULPIT
ALTAR AND SACRISTRY
ALTAR AND PRIORY
SEPARATE CONCRETE SYSTEM
GLULAM BUTTRESSES
ALTERNATING DIMENSIONS SUPPORT INNER STRUCTURAL SYSTEM
CONCRETE FOUNDATION
HOUSING ALL SERVICING SYSTEMS
GLULAM TRUCE SYSTEM
ALTERNATING DIMENSIONS PROVIDE SUPPORT AND DEFINE SIDE AISLES
STRUCTURAL SYSTEMS
THE CHURCH FOLLOWS AN AXIS OF SYMMETRY DOWN THE PROCESSION, WHICH IS FOLLOWED BY THE HEAVY TIMBER CONSTRUCTION
BELL TOWER
SEPARATE BRICK CLADDING OVER STEEL FRAMING
REVIT CHURCH OF TRANSFIGURATION
ACOUSTICAL STUDY
ENSURING THAT THE SPACE WITHIN IS ACOUSITCALLY SOUND, WE DESIGNED ACOUSTIC PANELS THAT WOULD ALLOW THE SPEAKER AT MULTIPLE POINTS ACROSS THE CHURCH TO BE HEARD TO THE PERISH IN THE PEWS.
REVIT | PHOTOSHOP CHURCH OF TRANSFIGURATION
PROFESSIONAL
IZEN ARCHITECTURE INC.
GROUND FLOOR RENOVATION OF STUCCO 1970’S SINGLE DETACHED HOUSE.
HOUSE 32 HOUSE 3
A NEW-BUILD CONSTRUCTION DRAWING SET FOR A MULTI-GENERATIONAL FAMILY HOME.
HOUSE 32
A residential building in North York, Toronto constructed in the 1970s undergoing its second extensive renovation. Total floor area is 2050 sq. ft.
Scope of work:
– Ground floor interior gut
– Window treatment on rear elevation
– Rear exterior cladding
– Custom stairs
Architect BRENDA IZEN
Interior Designer INNA SHAULSKY
Project Lead RHEA MAZGAONKAR
2019
PROFESSIONAL W ORK FROM IZEN ARCHITECTURE INC.
BACKYARD VIEW OF EXTERIOR RENOVATION
THE SEAMS OF THE ALUMINUM CLADDING ALIGN WITH THE PLACEMENT OF THE OPENINGS OF THE
HOUSE 32
GROUND FLOOR WINDOWS.
ALUMINUM CLADDING FLOOR-TO-CEILING WINDOWS
DEMOLITION PLAN
THE PRIMARY INCEPTION OF THIS RENOVATION WAS TO RELCATE THE CENTRAL KITCHEN SPACE TO ACCOMODATE FOR MORE NATURAL LIGHT IN THE FAMILY’S MOST COMMONLY USED SPACES.
HOUSE 32 AUTOCAD DN 7R DN 6R UP 14R DN 5R D1 D1 D1 D1 D1 D3 D3 D3 D3 D3 D3 D3 D4 D4 D4 D4 D4 D4 D4 D4 D4 D4 D4 D2 D1 ALL APPLIANCES. D2 FIREPLACE, CAPPED GAS LINE D3 FLOORING AND TILES. D4 WINDOWS AND DOORS.
PROPOSED PLAN
THE PRIMARY INCEPTION OF THIS RENOVATION WAS TO RELCATE THE CENTRAL KITCHEN SPACE TO ACCOMODATE FOR MORE NATURAL LIGHT IN THE FAMILY’S MOST COMMONLY USED SPACES.
HOUSE 32 AUTOCAD DN 7R DN 6R UP 14R W101 W102 W103 W104 W105 W106 E101 E102 D101 F1 F1 F1 F1 F1 F2 F1 P1 P1 P1 P1 EXIST DJ EXISTING WALL ASSEMBLY W1 W1 DN 5R D103 P1 4-2x6 W1 W1 DW DW P1 F1 F2 F1 NEW WALL ASSEMBLY 1 2 3 4 5 6 7 8 1 FOYER 2 DINING ROOM 3 KITCHEN 4 WALK-IN PANTRY 5 SITTING AREA 6 FAMILY ROOM 7 POWDER ROOM 8 MUDROOM
CONCRETE FINISH ON STUD WALL GUARD (SPEC.1)
GLASS GUARD
HANDRAIL WITH INTEGRATED LIGHTING (SPEC. 3)
3 3 4" GAP IN BETWEEN CONCRETE GUARDS
WHITE OAK STAINED TO MATCH; WATERFALL TREADS
UNDERSIDE OF THE STAIRS TO FINISH IN DRYWALL (SPEC.2) WITH 1" C-CHANNEL REVEAL BETWEEN DRYWALL AND GUARD
FEATURE STAIRS
MILLWORK DESIGN PROPOSAL (LEFT) OF FEATURE STAIR FROM GROUND TO SECOND FLOORS. CONCRETE CLADDED GUARD (RIGHT) WITH CUSTOM UNDERLIT BLACK HANDRAILS AND WATERFALL STAIR TREADS TO MATCH WHITE OAK FLOORING.
ON SITE WALL PROJECTION FINISHED WITH MITERED CONCRETE
WHITE OAK LANDING STAINED TO MATCH
FIN. SECOND FLOOR 5370.00 (+1.16m)
FIN. SECOND LANDING 4210.00 (+1.56m)
FIN. GROUND FLOOR 2650.00 (+1.02m) BASEMENT LANDING 1630.00 (+1.63m)
FIN. BASEMENT FLOOR 0.00 (+0.00m)
5'-4" [1.63m] 3'-4" [1.02m] 5'-1 1"2 [1.56m] 3'-9 1 2 " [1.16m]
SECTION
3 A8.2.2 2 A8.2.2
1
HOUSE 32 AUTOCAD WHITE OAK FLOORING | CUSTOM HANDRAILS | CONCRETE CLADDED GUARDS
DEMOLITION AND PROPOSED PLANS
THE PRIMARY INCEPTION OF THIS RENOVATION WAS TO RELCATE THE CENTRAL KITCHEN SPACE TO ACCOMODATE FOR MORE NATURAL LIGHT IN THE FAMILY’S MOST COMMONLY USED SPACES.
HOUSE 32 AUTOCAD
FINAL PHOTOGRAPHY
TV WALL UNIT WITH INSET SLIDING DOOR JAMB (LEFT). CUSTOM PULLS FOR FLUSH KITCHEN CABINETS AND FRIDGE (CENTER). OVERAL VIEW OF KITCHEN WITH ISLAND-TABLE UNIT AND RETURNED QUARTZ BACKSPLASH (RIGHT).
HOUSE 32
|
WOOD LAMINATE MILLWORK
WHITE OAK FLOORING
QUARTZ COUNTERTOP | BLACK LAMINATE ISLAND COUNTERTOP
CUSTOM BLACK PULLS AND ACCESSORIES
FINAL PHOTOGRAPHY
INTERIOR SHOTS OF KITCHEN SPACE LOOKING TO THE SITTING AREA AND WALK-IN PANTRY (LEFT). DESK AND LANDLINE UNIT WITH RETRACTABLE DOORS (CENTER). FOYER BENCH CLADDED IN CONCRETE AND RETURNED TO THE WALL WITH FLOOR-TOCEILING COAT CLOSETS (RIGHT).
REEDED GLASS SLIDING DOORS WITH BLACK ALLUMINUM FRAMES TERRAZZO FLOOR TILES | CONCRETE PANELLING
HOUSE 32
HOUSE 3
A new build residential construction in Scarborough, Toronto situated on TRCA preservation territory. This proposal was for a client who was also the contractor on the project.
Scope of Work:
– Schematic Design Proposal
– Building Permit Submission
Architect BRENDA IZEN
Project Lead RHEA MAZGAONKAR
2020
PROFESSIONAL W ORK FROM IZEN ARCHITECTURE INC.
3 TARDREE PLACE
3 TARDREE PLACE
DRAWING LIST
TORONTO, ONTARIO BUILDING PERMIT APPLICATION - NOVEMBER 11, 2019 ARCHITECT IZEN ARCHITECTURE AND DESIGN SURVEY A1.0 SITE PLAN A2.2 BASEMENT FLOOR PLAN A2.3 GROUND FLOOR PLAN A2.4 SECOND FLOOR PLAN A2.5 ROOF PLAN A2.5 BASEMENT FLOOR RCP A2.6 GROUND FLOOR RCP A2.7 SECOND FLOOR RCP A3.1 SCHEDULES A4.1 ELEVATION A4.2 ELEVATION A5.1 SECTION AA A5.2 SECTION BB A8.1 DETAILS A8.2 DETAILS S1 GENERAL NOTES AND DETAILS S2 FOUNDATION PLAN S3 BASEMENT FL SHOWING GROUND FL FRAMING S4 GROUND FL SHOWING SECOND FL FRAMING S5 SECOND FL SHOWING ROOF FRAMING
NEW REVISED NO CHANGES OMITTED 2019.11.11 BUILDING PERMIT APPLICATION CONTRACTOR SPARVIEW DESIGN BUILD STRUCTURAL ENGINEER PALMA STRUCTURAL ENGINEERING INC.
TORONTO, ONTARIO BUILDING PERMIT APPLICATION - NOVEMBER 11, 2019 ARCHITECT IZEN ARCHITECTURE AND DESIGN 91 TYCOS DRIVE #203, TORONTO , ON M6B 1W3 416.792.5330 SURVEY A1.0 SITE PLAN A2.2 BASEMENT FLOOR PLAN A2.3 GROUND FLOOR PLAN A2.4 SECOND FLOOR PLAN A2.5 ROOF PLAN A2.5 BASEMENT FLOOR RCP A2.6 GROUND FLOOR RCP A2.7 SECOND FLOOR RCP A3.1 SCHEDULES A4.1 ELEVATION A4.2 ELEVATION A5.1 SECTION AA A5.2 SECTION BB A8.1 DETAILS A8.2 DETAILS S1 GENERAL NOTES AND DETAILS S2 FOUNDATION PLAN S3 BASEMENT FL SHOWING GROUND FL FRAMING S4 GROUND FL SHOWING SECOND FL FRAMING S5 SECOND FL SHOWING ROOF FRAMING DRAWING LIST NEW REVISED NO CHANGES OMITTED 2019.11.11 BUILDING PERMIT APPLICATION CONTRACTOR SPARVIEW DESIGN BUILD 3410 YONGE STREET, TORONTO , ON M4N 2M9 416.877.2887 STRUCTURAL ENGINEER PALMA STRUCTURAL ENGINEERING INC. 85 PARK PLACE DRIVE, TORONTO , ON L6E 1Z7 647.261.5602 ELEVATION PROPOSAL AND DRAWING LIST THE FRONT FACADE OF THE BUILDING FEATURES A SLATTED WOOD BOX PROPOSED TO FRAME THE UPPER LIVING SPACE. HOUSE 3 AUTOCAD
GROUND FLOOR PLAN
THE GROUND FLOOR WAS DEISNGED TO ACCOMODATE A NEW FAMILY WITH IMMEDIATE ACCESS TO THE FAMILY’S ELDERLY IN-LAWS ON THE SECOND FLOOR.
HOUSE 3 AUTOCAD
SECOND FLOOR PLAN
THIS SCHEME SHOWS SEPARATE SETS OF LIVING AND KITCHEN SPACES FOR EACH FAMILY.
HOUSE 3 AUTOCAD
WINDOW AND
STANDARD LAYOUT OF
EXTERIOR WINDOWS AND DOORS TO CODE AND ZONING COMPLIANCE.
9'-6" 8'-0" 7'-10 1 2 FIN. CEILING 156.64 (+6.54m) FIN. SECOND FLOOR 154.20 (+4.10m) FIN. GROUND FLOOR 151.30 (+1.20m) FIN. BASEMENT FLOOR (EXISTING) 148.54 (-1.57m) 8'-0" 6'-2" 3'-0" 8'-4" 3'-1" 8'-0" 10'-0" 8'-6" 6'-10" 5'-0" W201 W101 E101 W202 E102 E104 3'-1" E103 11'-10 1 2 8'-0" 5'-6" WINDOW LEGEND WEST ELEVATION SOUTH ELEVATION EAST ELEVATION W203 5'-6" 3'-0" FIN. FL. LEVEL EXTERIOR DOOR LEGEND 11'-8" 5'-6" 14'-6" W204 W206 W104 W103 11'-8" W001 3'-0" 11'-8" W102 W102 W205 11'-9 9'-5 1 2 5'-6" 9'-6" 6'-9 9'-6" 5'-6" 9'-6" 7'-9" 3'-0" NORTH ELEVATION 2'-0" 7'-1" 3'-10" 2'-0" 3'-10" 2'-0" W003 W004 W108 W105 W207 3'-3" 2'-0" 2'-0" W107 3'-10" 2'-0" W208 2'-0" 3'-0" W106 6'-2 1 2 2'-0" 6'-2 1 4'-10" 7'-5 1 2 7'-5 1 2 7'-5 1 2 2'-5 1 2 4'-10 1 2 4'-10 1 2 2'-6 1 2 2'-6 1 2 2'-6 1 2 6'-0" 6'-0" 4'-10" 2'-6 1 2 3'-0 1 2 2'-6" ELEVATION FRAME TYPE OPENING DIMS (W X H) WINDOW # W001 W002 OPERABLE QTY LOCATION GROUND FLOOR BASEMENT SILL HEIGHT (A.F.F.) W101 COLOUR SECOND FLOOR W201 NOTES W102 W103 W104 W105 W106 W202 W203 W204 W205 W206 W003 WINDOW SCHEDULE 1 1 4'-10 1/2" 7'-9" x 3'-0" EAST BLACK OUT / WHITE IN 11-8" 3'-0" EAST BLACK OUT / WHITE IN 1 3'-10" x 2'-0" OPERABLE NORTH BLACK OUT / WHITE IN 4'-10" 1 FIXED 2'-6" 8'-0" x 6'-2" WEST BLACK OUT / BLACK IN 1 6'-9 1/2" 9-6" EAST BLACK OUT / BLACK IN 1 0'-0" EAST BLACK OUT / BLACK IN 1 OPERABLE EAST BLACK OUT / BLACK IN 1 7'-5 1/2" 6'-2 1/2" 2'-0" FIXED NORTH BLACK OUT / BLACK IN 1 FIXED NORTH BLACK OUT / BLACK IN 1 WEST BLACK IN / BLACK OUT 1 6'-10" x 5'-0" WEST 1 2'-6" 3'-0" x 5'-6" SOUTH 1 EAST 1 9'-5 1/5" 5'-6" FIXED EAST 1 11'-8" x 5'-6" EAST 2'-6 1/2" W207 W208 1 6'-0" 3'-3" x 2'-0" NORTH 1 6'-0" 3'-10" x 2'-0" FIXED NORTH 11'-10 1/2" 5'-6" W004 1 3'-10" x 2'-0" NORTH BLACK OUT / WHITE IN 4'-10 1/2" 4'-10" 3-0 1/2" 14'-6" x 9'-6" 11'-8" x 9'-6" 0'-0" 1'-2" 11'-9 1/2" 5'-6" 2'-6 1/2" BLACK IN / BLACK OUT BLACK IN / BLACK OUT BLACK IN / BLACK OUT BLACK IN / BLACK OUT BLACK IN / BLACK OUT BLACK IN / BLACK OUT BLACK IN / BLACK OUT FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS FIBREGLASS W107 3'-0" x 2'-0" 1 NORTH BLACK OUT / BLACK IN FIBREGLASS W108 2'-0" x 7'-1" 1 NORTH BLACK OUT / BLACK IN FIBREGLASS FIXED FIXED FIXED 7'-5 1/2" 7'-5 1/2" 2'-5 1/2" 6'-2 1/2" 2'-0" OPERABLE FIXED FIXED FIXED 2'-6" 2'-6 1/2" 2'-6 1/2" FIXED FIXED FIXED FIXED OPERABLE OPERABLE HANDLE FRAME TYPE SWING DOOR TYPE DOOR SIZE (W X H X D) DOOR # HINGES QTY LOCATION NOTES E101 TYP. TYP E102 TYP. TYP TYP EXTERIOR DOOR SCHEDULE MAIN ENTRANCE 1 SEE SPEC. SIDE ENTRANCE 1 SEE SPEC. 3'-1" 8'-0" 2-3/4" WOOD-SOLID CORE;THERMAL 1 E103 TYP. STUDY ENTRANCE SEE SPEC. 3'-0" 8'-0" 2-3/4" E104 GARAGE 1 GARAGE TYP. TYP. SEE SPEC. 3'-0" 8'-0" 2-3/4" 10' x 8'-6" x 2-3/4" WOOD-SOLID CORE;THERMAL WOOD-SOLID CORE;THERMAL WOOD-SOLID CORE;THERMAL ELEVATION FRAME TYPE OPENING DIMS (W X H) WINDOW # S201 OPERABLE QTY LOCATION SILL HEIGHT (A.F.F.) COLOUR NOTES WINDOW SCHEDULE - SKYLIGHT ABOVE STAIRS 1 FIBREGLASS FIXED - 7-11" x 4'-8" - BLACK OUT WHITE IN REC ROOM REC ROOM BEDROOM 5 BEDROOM 4 STUDY LIVING ROOM DINING ROOM KITCHEN KITCHEN DINING ROOM STUDY STUDY MASTER ENSUITE BEDROOM 2 BEDROOM 3 WASHROOM POWDER ROOM BEDROOM 5 WASHROOM BEDROOM 4 COPYRIGHT 2019 IZEN ARCHITECTURE INC. 203-91 TORONTO, +1 416 www.izenarch.ca ISSUE RECORD © 3 TARDREE 18058 THIS DRAWING ARCHITECTURE FOR SAFETY PRECAUTIONS OMISSIONS OF OF THE WORK, WITH THE CONTRACT ACCURATELY DEPICT THIS DRAWING THE CONTRACTOR CONSTRUCTION DRAWINGS. THE TO THE ARCHITECT KNOWN TO THE
WINDOW 1/4"=1'-0" 1 BUILDING
A3.1
DOOR SCHEDULES
HOUSE 3 AUTOCAD
ALL
LONGITUDINAL SECTION
STANDARD SECTION DRAWING OF THE HOUSE AT ITS ENTRANCE AND STAIR CORE, WHILE ENSURING THE FOOTPRINT DOES NOT ENCROACH THE TRCA PRESERVATION LINE IN THE REAR OF THE PROPERTY.
1'-7" CRAWL SPACE 24'-7 1 2 9'-6" 8'-0" 7'-10 1 2 FIN. CEILING 156.64 (+6.54m) FIN. SECOND FLOOR 154.20 (+4.10m) FIN. GROUND FLOOR 151.30 (+1.20m) ESTABLISHED GRADE 150.10m FIN. BASEMENT FLOOR (EXISTING) 148.54 (-1.57m) 25'-7 1 4 [7.80m] 55'-9" [16.99m] 12'-1 1 2 TOP OF ROOF 157.30 (+7.20m) TOP OF PARAPET 157.58 (+7.48m) TOP OF PLENUM 156.99 (+6.89m) 1'-0" ALUMINUM FEATURE BOX BLACK ALUMINUM PARAPET 26'-101 4 [8.19m] 12'-83 4 [3.88m] 4'-0" [1.22m] 9'-6" [2.89m] REC ROOM DINING ROOM BEDROOM FAMILY ROOM DINING ROOM P1 P1 P1 P1 P1 P1 P1 R1 R1 F1 F1 F1 TOTAL BUILDING LENGTH F2 F2
HOUSE 3 AUTOCAD
