WIRING DIAGRAM Both bulbs must be fitted and wired for the flasher unit to function correctly. As the flasher unit depends on the Earth from the 2nd bulb. If the flasher unit is not wired correctly it will not work. Also check that the bulbs are working because if they are blown they will not let the flasher work correctly. Fused Supply 10 amp

Live Supply

+

1710 - Flasher Unit Diagram
